PETROL

HEDGE TRIMMER

24.5cc 2 Stroke
INSTRUCTION MANUAL

SPECIFICATIONS

Engine:
24.5cc, 2-Stroke
Power Output:
0.85 kW / 1.1 hp
Fuel Mix
40:1
Blade Length:
550 mm
Max. Cutting Capacity:
19 mm
Fuel Tank Capacity:
0.33 L
No Load Speed:
3,300 rpm
Spark Plug:
Champion RCJ7Y
Weight:
5.4 kg
ozito.com.au
1
WHAT'S IN THE BOX
Hedge Trimmer
Blade Cover
Fuel Mixing Bottle
Spark Plug Wrench
Screwdriver
Spanner
PHT-550

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PHT-550 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Ozito PHT-550

Summary of Contents for Ozito PHT-550

  • Page 1: Hedge Trimmer

    0.85 kW / 1.1 hp Fuel Mixing Bottle Fuel Mix 40:1 Blade Length: 550 mm Max. Cutting Capacity: 19 mm Fuel Tank Capacity: 0.33 L No Load Speed: 3,300 rpm Spark Plug: Champion RCJ7Y Weight: 5.4 kg Spark Plug Wrench ozito.com.au Screwdriver Spanner PHT-550...
  • Page 2 KNOW YOUR PRODUCT SETUP & PREPARATION PETROL HEDGE TRIMMER 1. ROTATABLE REAR HANDLE 1 Cutting blade 10 Air filter cover 2 Safety guard 11 Gearbox lubrication nipple To make it easier to control, 3 Front handle 12 Spark plug lead the hedge trimmer is fitted 4 Side cover 13 Throttle lever...

  • Page 3: Operation

    OPERATION 3. STARTING & STOPPING 2. FUEL & OIL Pre-startup checks WARNING!: BE SURE TO STOP THE ENGINE BEFORE REFUELLING. DO NOT SMOKE WHILE REFUELLING. 1. Ensure that the blade cover has been removed and the rotating handle MOVE AT LEAST 3M AWAY FROM THE FUELLING POINT is secured into the desired position.
  • Page 4 4. OPERATING THE HEDGE TRIMMER Warm starting Note: Before using the hedge trimmer: • Remove the blade cover. 1. Put the equipment down on a hard, level surface. • Make sure you have a secure and balanced footing. • Make sure the cutting blade is not touching the ground or 2.

  • Page 5: Maintenance

    Use clean cloths to remove dirt, dust, oil, grease, etc. motor may stall. NOTE: DO NOT CUT HEDGES WHEN WET. (THE BEST RESULTS ARE ACHIEVED WHEN DRY.) PHT-550...
  • Page 6 MAINTENANCE 6. BLADE MAINTENANCE 7. FILTER & SPARK PLUG MAINTENANCE Cleaning the air filter Sharpening the cutting blade The cutter blades are high quality, made of tempered steel and in Dirty air filters reduce the engine output by restricting air to the normal use there is no need to sharpen the blades.

  • Page 7: Description Of Symbols

    Spare parts can be ordered from the Special Orders Desk at your local Bunnings Warehouse. For further information, or any parts not listed here, visit TROUBLESHOOTING www.ozito.com.au or contact Ozito customer service Australia 1800 069 486 New Zealand 0508 069 486 E-mail: enquires@ozito.com.au...

  • Page 8: Additional Safety Instructions For Hedge Trimmers

    SAFETY INSTRUCTIONS WARNING! Read all safety warnings and all instructions. Failure to follow serious personal injury. the warnings and instructions may result in electric shock, fire and/or serious b) Use safety equipment. Always wear eye protection. Safety equipment such as a injury.

  • Page 9: Warranty

    • Failure to perform maintenance as set out within the instruction manual. • If the tool is disassembled or tampered with in any way. OZITO Australia/New Zealand (Head Office) 1-23 Letcon Drive, Bangholme, Victoria, Australia 3175. 0614...
