CORDLESS GRASS
TRIMMER KIT
18V Lithium Ion
INSTRUCTION MANUAL
SPECIFICATIONS
Voltage:
18V
Battery:
1.5Ah Li-ion
Charge Time:
2 Hours
No Load Speed:
8,500/min
Cutting Diameter:
240mm
Weight with Battery:
2.2kg
ozito.com.au
WHAT'S IN THE BOX
Grass Trimmer
Blades x 10
Battery Pack
Battery Charger
PXCLTK-018
Advertisement
Table of Contents
Related Manuals for Ozito PXCLTK-018
Summary of Contents for Ozito PXCLTK-018
- Page 1 CORDLESS GRASS TRIMMER KIT Grass Trimmer 18V Lithium Ion INSTRUCTION MANUAL Blades x 10 SPECIFICATIONS Voltage: Battery: 1.5Ah Li-ion Charge Time: 2 Hours No Load Speed: 8,500/min Battery Pack Cutting Diameter: 240mm Weight with Battery: 2.2kg ozito.com.au Battery Charger PXCLTK-018...
-
Page 2: Know Your Product
KNOW YOUR PRODUCT SETUP & PREPARATION CORDLESS GRASS TRIMMER 1. ASSEMBLY 1 Telescopic Shaft 8 Battery Seating 2 Shaft Adjustment Collar 9 Head Tilt Button WARNING! ENSURE THE TOOL IS SWITCHED OFF AND 3 Adjustable Handle Lever 10 Edging Guide BATTERY DISCONNECTED BEFORE PERFORMING ANY OF THE FOLLOWING TASKS. -
Page 3: Adjusting The Trimmer
2. ADJUSTING THE TRIMMER Adjusting the Height Adjusting the Handle 1 Loosen the shaft 1 Release the adjustable adjustment collar. handle lever. 2 Extend to the 2 Rotate the handle desired height and into the desired then retighten the position and then shaft adjustment lock in place with collar to secure in... -
Page 4: Battery And Charging
3. BATTERY & CHARGING CAUTION: THE CHARGER FOR THIS PRODUCT SHOULD Charger LED Indicator BE PROTECTED BY A RESIDUAL CURRENT DEVICE LED Indicator Situation (RATED AT 30MA OR LESS). GREEN (Flashing) Stand By (no battery pack is inserted) Charging your lithium ion battery RED (Illuminated) Battery is charging (low charge) The tools battery has been shipped in a low charge condition, and... -
Page 5: Controls And Operation
ON A LADDER, OR ON A SCAFFOLD, THIS IS EXTREMELY DANGEROUS. CAUTION! BYSTANDERS MUST KEEP A MINIMUM SAFE DISTANCE OF 10M AWAY FROM THE TRIMMER WHILE IT IS OPERATING. WARNING! STONES, PIECES OF METAL AND OTHER OBJECTS CAN BE THROWN OUT AT HIGH SPEED BY THE BLADE. PXCLTK-018... -
Page 6: Maintenance
• When not in use, the grass trimmer should be stored in a dry, frost free location not within the reach of children. Note: Ozito Industries will not be responsible for any damage or injuries caused by the repair of the grass trimmer by an unauthorised person or by mishandling of the grass trimmer. -
Page 7: Troubleshooting
Wear safety glasses at your local Bunnings Warehouse. Do not expose to rain. For further information, or any parts not listed here, visit www.ozito.com.au or contact Ozito Customer Service: Australia 1800 069 486 New Zealand 0508 069 486 E-mail: enquires@ozito.com.au Keep bystanders away. -
Page 8: Electrical Safety
Replace the extension lead if damaged or defective. Note: The supply of 230V and 240V on Ozito tools are interchangeable for Australia and New Zealand. When using an extension lead on a reel, always unwind the lead completely. Use of an extension lead not suitable for the power input of the tool or which is damaged or defective may result in a risk of fire and electric shock. -
Page 9: Warranty
HAVE RELATING TO THE WARRANTY POLICY the terms of this warranty. You have the option to register your OR PROCEDURE. product with Ozito on www.ozito.com.au/registrations for an extended warranty of 2 years within four weeks of purchase. The WARNING registration confirmation, which is sent out by e-mail, and the original receipt showing the date of purchase will serve as proof of The following actions will result in the warranty being void.
