Port Forwarding - D-Link GO-DSL-AC750 User Manual

Section 3 - Configuration
Port forwarding is a method to direct incoming traffic to a
particular server on the LAN. Up to 16 port forwarding entries
are supported.
Click Add, Edit, or Delete to reveal the Port forward setup options.
WAN Connection:
Server Name:
Schedule:
Server IP Address:
D-Link Wireless AC Dual-Band ADSL Router User Manual

Port Forwarding

Specify the WAN connection to use.
Enter a name for the server or service.
Select a schedule for the port to be forward-
ed.
Enter the internal IP address for the traffic to
be forwarded to.
44
