USER GUIDE &
INSTALLATION INSTRUCTIONS
Professional+ FXP 90 Dual Fuel
Australia

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Professional+ FXP 90 Dual Fuel and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Falcon Professional+ FXP 90 Dual Fuel

  • Page 1 USER GUIDE & INSTALLATION INSTRUCTIONS Professional+ FXP 90 Dual Fuel Australia...
  • Page 3: Table Of Contents

    Cleaning Your Cooker Servicing Daily Care Panels Cleaning for Spills Hotplate Hotplate Burners Controls Griddle Ovens The Wok Cradle Door Control Panel and Oven Doors 10. Circuit Diagram Self-Clean Oven Cleaning Table 11. Technical Data Professional+ FXP 90 Dual Fuel U110102-05A...
  • Page 5: Before You Start

    1. Before You Start... If You Smell Gas Thank you for buying a Falcon cooker. It should give you many years of trouble-free cooking if installed and operated • DO NOT turn electric switches on or off correctly. It is important that you read this section before •...
  • Page 6: Cooker Care

    When the oven is on, DO NOT leave the oven door NEVER leave a chip pan unattended. Always heat fat open for longer than necessary – otherwise, the slowly, and watch as it heats. Deep fry pans should control knobs may become very hot. be only one third full of fat.
  • Page 7: Overview

    2. Overview Fig. 2.1 ArtNo.273-0001 - 90 Pro+ FXP annotated The dual fuel single cavity cooker (Fig. 2.1) has the following ArtNo.270-0001 Fig. 2.2 features: Proplus control to high 5 hotplate burners including a wok burner Control panel incorporating a timer Multifunction oven Storage drawer Hotplate Burners...
  • Page 8: Wok Burner

    If, when you let go of the control knob, the burner goes out, Fig. 2.3 then the FSD has not been bypassed. Turn the control knob ArtNo.270-0003 Proplus control to low to the OFF position and wait for one minute before you try again, this time making sure to hold in the control knob for slightly longer.
  • Page 9: The Griddle

    The Griddle Fig. 2.10 The griddle fits the left-hand well, front to back (Fig. 2.11). It is designed for cooking food on directly. DO NOT use pans of any kind on it. The griddle surface is non-stick and metal cooking utensils (e.g. spatulas) will damage the surface. Use heat resistant plastic or wooden utensils.
  • Page 10: The Multifunction Oven

    The Multifunction Oven Fig. 2.12 The oven is a multifunction oven (Fig. 2.12). In addition to convection elements around the fans, it is fitted with extra heating elements, in the top of the oven and under the oven base. Take care to avoid touching the top elements when placing or removing items from the oven.
  • Page 11 door should be kept closed while cooking is in progress, so Fig. 2.13 saving energy. You will also find that the food needs to be watched and turned less than for normal grilling. Preheat this function before cooking. Note: When grilling full width, to allow sufficient access for tending foods we recommend placing the grill pan tray support on the second from top level.
  • Page 12: Energy Saving Panel

    Self-Cleaning Fig. 2.14 The oven has a self-cleaning function. The oven will run at a high temperature cycle to burn any cooking residue to ash that is easily cleaned away with a damp cloth. For safety, the oven will lock during the cleaning cycle. See the ‘Cleaning’...
  • Page 13: The Clock

    The Clock Fig. 2.18 Fig. 2.19 You can use the 6-button timer (Fig. 2.20) to turn the oven on and off. The clock must be set to the time of day before the oven will work. To Set the Time of Day ArtNo.270-0030 Press and hold both the [C] and [D] buttons as shown in Pro+ FXP oven...
  • Page 14: Key Lock

    AUTO is Showing, But You Want to Reset to Fig. 2.28 Fig. 2.29 Manual Cooking When cancelling an automatic setting, any cooking time already set must be returned to ( 0.00 ) before you can return ArtNo.302-0005 - ArtNo.302-0005a - to manual, by pressing the [B] button.
  • Page 15: Accessories

    Two full capacity shelves (Fig. 2.35) Grill pan tray support (Fig. 2.36) ArtNo.326-0013 - Full capacity shelf ArtNo.326-0004 - Cradle shelf • (Falcon) Two grill pans with trivets (Fig. 2.37) • • Three energy saving shelves (Fig. 2.38) Four ladder shelf supports (Fig. 2.39) •...
  • Page 16: Storage

    Storage Fig. 2.44 The bottom drawer is for storing oven trays and other cooking utensils. It can get very warm, so do not store anything in it that may melt or catch fire. Never store flammable materials in the drawer. This includes paper, plastic and cloth items, such as cookbooks, plastic ware and towels, as well as flammable liquids.
  • Page 17: Cooking Tips

    3. Cooking Tips Cooking with a Multifunction Oven General Oven Tips Remember: not all modes are suitable for all food types. The The wire shelves should always be pushed firmly to the back oven cooking times given are intended for a guide only. of the oven.
  • Page 18: Cooking Table

    4. Cooking Table DocNo.031-0004 - Cooking table - electric & fan single cavity The oven control settings and cooking times given in the table below are intended to be used Top (T) AS A GUIDE ONLY. Individual tastes may require the temperature to be altered to provide a ArtNo.050-0007 preferred result.
  • Page 19: Cleaning Your Cooker

    5. Cleaning Your Cooker Isolate the electricity supply before carrying out any major Fig. 5.1 cleaning. Allow the cooker to cool. NEVER use paint solvents, washing soda, caustic cleaners, biological powders, bleach, chlorine based bleach cleaners, coarse abrasives or salt. DO NOT mix different cleaning products –...
  • Page 20: Griddle

    The Wok Burner Fig. 5.2 ArtNo.311-0014 Wok burner details When reassembling the wok burner (Fig. 5.2) turn over the large base ring and find the ‘D’ shaped area (Fig. 5.3). Turn the head until the ‘D’ matches the one on the burner base. Flip the burner over once again and place it on the burner base.
  • Page 21: Self-Clean Oven

    Self-Clean Oven Fig. 5.6 WARNING! Remove all cookware, shelves, and the shelf supports from the oven before using the self-clean ArtNo.272-0007 function. If the shelves and supports are left in the Prof+ pyro US - MF oven - oven they will discolour and become rough. Self clean setting WARNING! Using the self-cleaning function results in higher...
  • Page 22 When the door has unlocked turn the oven function control Fig. 5.10 back to OFF. When the door has unlocked and the oven has cooled, use a damp cloth the clean the debris and ash. ArtNo.302-0005 - 6BC Stopping the oven 1 To Cancel the Self-Cleaning Cycle To cancel the self-clean function, hold down the [D] button and then press the [–] button to set the timer back to ( 0.00 ).
  • Page 23: Cleaning Table

    Cleaning Table Cleaners listed are available from supermarkets or electrical retailers as stated (Table 5.2). For enamelled surfaces use a cleaner that is approved for use on vitreous enamel. Regular cleaning is recommended. For easier cleaning, wipe up any spillages immediately. Hotplate Part Finish...
  • Page 24: Troubleshooting

    6. Troubleshooting Hotplate ignition or cooktop burners faulty If there is an installation problem and I don’t get my original installer to come back to fix it who pays? Is the power on? You do. Service organizations will charge for their call Are the sparker (ignition electrode) or burner holes outs if they are correcting work carried out by your blocked by debris?
  • Page 25 Oven not coming on Fig.6-1 Is the power on? If not there may be something wrong with the power supply. Is the cooker supply on at the circuit breaker? ArtNo.324-0005 Oven light bulb Have you set a cooking function? Oven temperature getting hotter as the cooker gets older If turning the knob down has not worked or only worked for a short time then you may need a new Fig.6-2...
  • Page 26: Installation

    INSTALLATION Check the appliance is electrically safe and gas sound when you have finished. 7. Installation Service and Spares Firstly, please complete the appliance details below and keep them safe for future reference – this information will enable us to accurately identify the particular appliance and help us to help you. Filling this in now will save time and inconvenience if you later have a problem with the appliance.
  • Page 27: Provision Of Ventilation

    INSTALLATION Check the appliance is electrically safe and gas sound when you have finished. You must be aware of the following safety requirements & Provision of Ventilation regulations. This appliance is not connected to a combustion products Prior to installation, make sure that the local distribution evacuation device.
  • Page 28 Wall plugs (only required if fitting the cooker on a stone or concrete floor) ArtNo.311-0043 - Griddle 09 ArtNo.326-0013 - Full capacity shelf Steel tape measure (Falcon) Cross head screwdriver Flat head screwdriver 4 mm & 3 mm Allen keys Grill pan tray support 2 grill pans &...
  • Page 29: Positioning The Cooker

    INSTALLATION Check the appliance is electrically safe and gas sound when you have finished. Positioning the Cooker Fig.7-1 The diagram (Fig.7-1) shows the minimum recommended distance from the cooker to nearby surfaces as given in AS 5601. *Any splashback must be fitted in accordance with the manufacturers instructions.
  • Page 30: Moving The Cooker

    INSTALLATION Check the appliance is electrically safe and gas sound when you have finished. Moving the Cooker Fig.7-2 On no account try and move the cooker while it is plugged into the electricity supply. The cooker is very heavy, so take great care. We recommend that two people manoeuvre the cooker.
  • Page 31: Levelling

    INSTALLATION Check the appliance is electrically safe and gas sound when you have finished. Levelling Fig.7-6 You are recommended to use a spirit level on a shelf in one of the ovens to check for level. Place the cooker in its intended position, taking care not to twist it within the gap between the kitchen units as damage may occur to the cooker or the units.
  • Page 32: Gas Connection

    INSTALLATION Check the appliance is electrically safe and gas sound when you have finished. Gas Connection Fig.7-10 Must be in accordance with the relevant standards. The gas supply needs to terminate with a threaded fitting ½”. The inlet connector is located just below the hotplate level at the rear of the cooker.
  • Page 33: Electrical Connection

    INSTALLATION Check the appliance is electrically safe and gas sound when you have finished. Electrical Connection Fig.7-11 This appliance must be installed by a qualified electrician to comply with the relevant regulations (AS/NZS 60335.2.6) and also the local electricity supply company requirements.
  • Page 34: Final Checks

    INSTALLATION Check the appliance is electrically safe and gas sound when you have finished. Final Checks Fig.7-15 Hotplate Check Check each burner in turn. There is a Flame Supervision Device (FSD) that stops the flow of gas to the burner if the flame goes out.
  • Page 35: Conversion To Propane Gas

    WARNING – SERVICING TO BE CARRIED OUT ONLY BY AN AUTHORISED PERSON Disconnect from electricity and gas before servicing. Check appliance is safe when you have finished. 8. Conversion to Propane Gas Conversion from Natural Gas (1.0 kPa) Fig.8-1 to LPG X Propane (2.54 kPa) A suitably competent person must perform the conversion.
  • Page 36: Set The Governor

    WARNING – SERVICING TO BE CARRIED OUT ONLY BY AN AUTHORISED PERSON Disconnect from electricity and gas before servicing. Check appliance is safe when you have finished. Set the Governor Fig.8-5 Unscrew the governor’s brass top. In the base of the brass top is a plastic snap-in converter device (Fig.8-5).
  • Page 37: Servicing

    WARNING – SERVICING TO BE CARRIED OUT ONLY BY AN AUTHORISED PERSON Disconnect from electricity and gas before servicing. Check appliance is safe when you have finished. 9. Servicing BEFORE SERVICING ANY GAS CARRYING Fig.9-1 COMPONENTS TURN OFF THE GAS SUPPLY Check the appliance is gas sound after completion of service.
  • Page 38: Hotplate

    WARNING – SERVICING TO BE CARRIED OUT ONLY BY AN AUTHORISED PERSON Disconnect from electricity and gas before servicing. Check appliance is safe when you have finished. 2 Hotplate Wok Burner Disconnect the burner feed pipes at the burner. Fit the 2.1 To Remove the Hotplate new one and reassemble in reverse order.
  • Page 39: Ovens

    WARNING – SERVICING TO BE CARRIED OUT ONLY BY AN AUTHORISED PERSON Disconnect from electricity and gas before servicing. Check appliance is safe when you have finished. 4 Ovens Fig.9-5 4.1 To Change an Oven Thermostat Protection & primary phials DISCONNECT FROM THE ELECTRICITY SUPPLY.
  • Page 40 WARNING – SERVICING TO BE CARRIED OUT ONLY BY AN AUTHORISED PERSON Disconnect from electricity and gas before servicing. Check appliance is safe when you have finished. 4.3 To Replace the Oven Catalytic Converter Fig.9-7 DISCONNECT FROM THE ELECTRICITY SUPPLY. Filter cover Undo the 2 screws holding the catalytic filter cover in place (Fig.9-7) and remove.
  • Page 41 WARNING – SERVICING TO BE CARRIED OUT ONLY BY AN AUTHORISED PERSON Disconnect from electricity and gas before servicing. Check appliance is safe when you have finished. Top Element Fig.9-12 Remove the top element bracket fixings and withdraw the elements carefully, lifting to clear the clips on the support bar (Fig.9-12).
  • Page 42: Door

    WARNING – SERVICING TO BE CARRIED OUT ONLY BY AN AUTHORISED PERSON Disconnect from electricity and gas before servicing. Check appliance is safe when you have finished. 5 Door Fig.9-16 5.1. To Remove the Oven Door CAUTION! The door is very heavy. Take care when removing. To remove the door, open the door fully.
  • Page 43 WARNING – SERVICING TO BE CARRIED OUT ONLY BY AN AUTHORISED PERSON Disconnect from electricity and gas before servicing. Check appliance is safe when you have finished. 5.5. To Replace the Oven Door Hinge Fig.9-20 Centre glass Remove the oven door (see 5.1). panel assembly Lift out the inner panel and place it, outer side up, on a clean level surface.
  • Page 44: Circuit Diagram

    10. Circuit Diagram A2/B1 B2 Code Description Code Description Code Colour Multi-function oven master switch Oven protect thermostat Blue Multi-function oven drone switch Oven neon Brown Oven thermostat Oven light Black Oven front switch Oven light switch Orange Right-hand oven base element Door lock neon Right-hand oven top outer element Ignition spark generator...
  • Page 45: Technical Data

    11. Technical Data This cooker is designed for use on Natural gas, although a conversion for LP (LPG X Propane (2.54 kPa)) gas is packed with the cooker. INSTALLER: Please leave these instructions with the user. DATA BADGE LOCATION: Inside base drawer of cavity and on rear of the appliance. COUNTRY OF DESTINATION: Australia.
