For Wan3 (Usb) - Draytek Vigor2860 Series User Manual

2 . 3 . 3 F o r W A N 3 (
2 . 3 . 3 F o r W A N 3 (
WAN3 is dedicated to physical mode in USB. If WAN3 is selected, it is not necessary for you
to type any information for such connection.
1. Choose WAN3 as WAN Interface.
2. Then, click Next for getting the following page.
Available settings are explained as follows:
Item
Internet Access
3G/4G USB Modem
(PPP mode)
U S B )
U S B )
Description
Choose one of the selections as the protocol of accessing
the internet.
SIM Pin code –Type PIN code of the SIM card that will be
used to access Internet. The maximum length of the pin
code you can set is 15 characters.
Modem Initial String – Such value is used to initialize
31 Vigor2860 Series User's Guide
