Item
Enable
Channel
Enable
Add Tag
Priority
WAN link for Channel 5, 6 and 7 are provided for router-borne application such as TR-069.
The settings must be applied and obtained from your ISP. For your special request, please
contact with your ISP and then click WAN link of Channel 5, 6 or 7 to configure your router.
Available settings are explained as follows:
Item
WAN for Router-borne
Application
Description
Check it to enable such function.
Display the number of each channel.
Check this box to enable that channel. The channels that
you enabled here will be shown in the Multi-VLAN
channel drop down list on the web page of Internet Access.
Though you can enable eight channels in this page, yet only
one channel can be chosen on the web page of Internet
Access.
To identify the usage of VLAN, check this box to invoke
this setting. And type the number for VLAN ID (number).
To add the packet priority number for such VLAN. The
range is from 0 to 7.
Description
Choose the router service for channel 5, 6 or 7.
Management - It can be specified for general management
(Web configuration/telnet/TR069). If you choose
Management, the configuration for this VLAN will be
effective for Web configuration/telnet/TR069.
VoIP - It can be specified for VoIP only. If you choose
VoIP, the configuration for this VLAN will be effective for
95 Vigor2860 Series User's Guide
