Parts & Maintenance
Manual
Greens King VI
62275 – 1862G, Briggs Vanguard Engine, 2WD
62276 – 1862G, Briggs Vanguard Engine, 3WD
62277 – 1962D, Kubota D662-EB Engine, 2WD
62278 – 1962D, Kubota D662-EB Engine, 3WD
GB
2811150-Rev D
6
5
9
1 1
1 6
1 3
1 5
7
8
1 8
1 7
1 - I N C L U D E S I T E M S 3 - 1 6
1 9
3
1 0
4

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Greens King VI and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Jacobsen Greens King VI

Summary of Contents for Jacobsen Greens King VI

  • Page 1 1 - I N C L U D E S I T E M S 3 - 1 6 Parts & Maintenance Manual Greens King VI 62275 – 1862G, Briggs Vanguard Engine, 2WD 62276 – 1862G, Briggs Vanguard Engine, 3WD 62277 –...

  • Page 2: Table Of Contents

    To Order Parts 1. Write your full name and complete address on the 5. Send or bring the order to an authorized Textron Turf order. Care And Specialty Products Dealer. 2. Explain where and how to make shipment. 6. Inspect all shipments on receipt. If any parts are damaged or missing, file a claim with the carrier 3.

  • Page 3: Service Parts

    Suggested Stocking Guide To Keep your Equipment fully operational and productive, Textron Turf Care And Specialty Products suggests you maintain a stock of the more commonly used maintenance items. We have included part numbers for additional support materials and training aids. To order any of the following material: 3.

  • Page 4: Safety

    SAFETY SAFETY OPERATING SAFETY ______________________________________________________ WARNING EQUIPMENT OPERATED IMPROPERLY OR BY UNTRAINED PERSONNEL CAN BE DANGEROUS. Familiarize yourself with the location and proper use of all controls. Inexperienced operator’s should receive instruction from someone familiar with the equipment before being allowed to operate the machine. 1.

  • Page 5: Important Safety Notes

    SAFETY IMPORTANT SAFETY NOTES ________________________________________________ This safety alert symbol is used to alert you to potential hazards. DANGER - Indicates an imminently hazardous situation which, if not avoided, WILL result in death or serious injury. WARNING - Indicates a potentially hazardous situation which, if not avoided, COULD result in death or serious injury.

  • Page 6: Specifications

    SPECIFICATIONS SPECIFICATIONS PRODUCT IDENTIFICATION _________________________________________________ 62275 ......Greens King VI 1862G 2-WD Always provide the serial number of the unit when ordering Tractor, 18 hp gasoline engine. replacement parts or requesting service information. Without battery, or mowers. 62276 ......Greens King VI 1862G 3-WD Tractor, 18 hp gasoline engine.

  • Page 7: Cutting Units

    SPECIFICATIONS CUTTING UNITS: __________________________________________________________ Reel......... 3 Reels, 22 in. (559 mm) wide. Cutting Frequency: Reel Diameter ....5 in. (127 mm) 7 Blade...... 0.074 in./mph (1.17 mm/kph) Blade Options ....7 or 11 blades 11 Blade....0.047 in./mph (0.74 mm/kph) Cutting Width ....

  • Page 8: Adjustments

    ADJUSTMENTS ADJUSTMENTS GENERAL________________________________________________________________ 1. Adjustments and maintenance should always be WARNING performed by a qualified technician. If proper adjustment cannot be made, contact an authorized To prevent injury, lower implements to the ground, Textron Turf Care And Specialty Products Dealer. disengage all drives, engage parking brake, stop 2.

  • Page 9: Bedknife-To-Reel

    ADJUSTMENTS BEDKNIFE-TO-REEL _______________________________________________________ (Pre-adjustment Check) Check the reel bearings for end play or radial play. The reel must be parallel to the bedknife. An There should be no end play or radial play. See Section improperly adjusted reel will lose its sharp edges 3.7.

  • Page 10: Cutting Height

    ADJUSTMENTS CUTTING HEIGHT _________________________________________________________ Note: Always make the reel to bedknife adjustment 6. Repeat Steps 4 and 5 on opposite end. Complete before adjusting height of cut. (Sections 3.4 and 3.5). adjustment to one end before adjusting opposite end. 7. Tighten nuts (K) and recheck each end. 1.

  • Page 11: Mow / Transport Switch

    ADJUSTMENTS MOW / TRANSPORT SWITCH ________________________________________________ 1. Remove the engine cowling to gain access to the switch. 2. Use a volt/ohm meter to determine when switch contacts open or close. 3. Place traction lever in transport position (2). 4. Adjust switch (R) so contacts are open in transport position, and close when lever is moved to mow position (1).

  • Page 12: Parking Brake Switch

    ADJUSTMENTS 3.12 PARKING BRAKE SWITCH __________________________________________________ 1. Use a volt/ohm meter to determine when switch contacts open or close. 2. Engage parking brake and adjust parking brake switch (A) as required to close contacts. Switch contacts should open when parking brake is disengaged.

  • Page 13: Reel Proximity Switch

    ADJUSTMENTS 3.15 REEL PROXIMITY SWITCH __________________________________________________ 1. The switch is factory set and should not require adjustment. The reels start turning when lowered and shut off when raised. 2. If reels do not shut off when raised, or turn on too slowly, loosen hardware (D) and adjust switch up or down as required.

  • Page 14: Torque Specification

    ADJUSTMENTS 3.17 TORQUE SPECIFICATION___________________________________________________ CAUTION All torque values included in these charts are approximate and are for reference only. Use of these torque values is at your sole risk. Textron Turf Care And Specialty Products is not responsible for any loss, claim, or damage arising from the use of these charts.

  • Page 15: Maintenance

    MAINTENANCE MAINTENANCE GENERAL ________________________________________________________________ b. Keep all moving parts properly adjusted and WARNING lubricated. Replace worn or damaged parts before operating Before you clean, adjust, or repair this equipment, the machine. disengage all drives, lower implements to the ground, engage parking brake, stop engine and remove key d.

  • Page 16: Engine Oil

    MAINTENANCE ENGINE OIL ______________________________________________________________ Check the engine oil at the start of each day, before starting the engine. If the oil level is low, remove oil filler cap and add oil as required. Diesel Engine Dipstick Diesel Engine: Safe Operating Range Perform initial oil change after first 50 hours of operation and every 75 hours thereafter.

  • Page 17: Diesel Air Filter

    MAINTENANCE DIESEL AIR FILTER ________________________________________________________ Check the service indicator daily. If red band appears in the Reassemble cap making sure it seals completely window (C) replace the element. around the filter housing. Dust evacuator must be facing down. Do not remove the element for inspection or cleaning. Check all hoses and air ducts.

  • Page 18: Battery

    MAINTENANCE BATTERY ________________________________________________________________ Make absolutely certain the ignition switch is “Off” and the When installing the battery, always assemble the RED, positive (+) battery cable first and the ground, BLACK, key has been removed before servicing the battery. negative (-) cable last. When removing the battery, always remove the ground, CAUTION BLACK, negative (-) cable first and the RED, positive...

  • Page 19: Hydraulic Hoses

    MAINTENANCE 4.11 HYDRAULIC HOSES _______________________________________________________ IMPORTANT: hydraulic system WARNING permanently damaged becomes contaminated. Before disconnecting any hydraulic To prevent serious injury from hot, high pressure oil, component, clean the area around the fittings and the never use your hands to check for oil leaks, use paper hose ends to keep impurities out of the system.

  • Page 20: Hydraulic Oil Filters

    MAINTENANCE 4.13 HYDRAULIC OIL FILTERS __________________________________________________ The hydraulic system is protected by one 10 micron filter. Operate engine at idle speed with hydraulic system in neutral for five minutes. To replace hydraulic oil filter: Check hydraulic oil level in reservoir and fill to full mark Remove the old filter.

  • Page 21: Wheel Mounting Procedure

    MAINTENANCE 4.17 WHEEL MOUNTING PROCEDURE ____________________________________________ Remove dirt, grease and oil from stud thread. Do not lubricate threads. WARNING Position wheel on hub and inspect to insure full contact Make sure the tractor is parked on a solid and level between mounting surface of wheel and hub or brake drum.

  • Page 22: Backlapping

    MAINTENANCE 4.20 BACKLAPPING ___________________________________________________________ 4. Adjust the backlapping valve located under the left WARNING rear of the machine, to the desired speed. 5. Apply lapping compound with a long handle brush To prevent injury, keep hands, feet and clothing away to high spots first then along entire length of the from rotating reels.

  • Page 23: Storage

    MAINTENANCE 4.21 STORAGE ________________________________________________________________ General Cutting Units Wash the tractor thoroughly and lubricate. Repair and Wash the cutting units thoroughly, then repair and paint paint damaged or exposed metal. any damaged or exposed metal. Inspect the tractor, tighten all hardware, replace worn Lubricate all fittings and friction points.

  • Page 24: Troubleshooting

    TROUBLESHOOTING TROUBLESHOOTING GENERAL________________________________________________________________ The troubleshooting chart below lists basic problems that may occur during start-up and operation. For more detailed information regarding the hydraulic and electrical systems contact your area Textron Turf Care And Specialty Products Dealer. Symptoms Possible Causes Action Engine will not start.

  • Page 25: Maintenance & Lubrication Charts

    MAINTENANCE & LUBRICATION CHARTS MAINTENANCE & LUBRICATION CHARTS GENERAL ________________________________________________________________ 3. Periodically apply a small amount of lithium based WARNING grease to the seat runners. 4. For smooth operation of all levers, pivot points and Before you clean, adjust, or repair this equipment, other friction points that are not shown on the disengage all drives, lower implements to the ground, lubrication chart apply several drops of SAE 30 oil...

  • Page 26: Maintenance Charts

    MAINTENANCE & LUBRICATION CHARTS MAINTENANCE CHARTS ___________________________________________________ Recommended Service and Lubrication Intervals Every Every Every Every Every Every Every Yearly Lubricant 8-10 1000 Section Type Hours Hours Hours Hours Hours Hours Hours Air Filter (Diesel) Air Filter (Gas) Battery Charge Belts I-A* 3.2,...

  • Page 27: Parts Catalog Table Of Contents

    PARTS CATALOG PARTS CATALOG TABLE OF CONTENTS______________________________________________________ 1.1 ..Decals ..............28 30.1..Pump Hydraulics..........80 2.1 ..Hood ..............30 31.1..Traction Hydraulics .......... 81 3.1 ..Hood, Cowling, and Console ......31 32.1..Steering Hydraulics .......... 82 4.1 ..Operator’s Platform .......... 32 33.1..

  • Page 28: Decals

    DO NOT USE FOR TOWING has dead battery. OPERATING INSTRUCTIONS READ MANUAL THOROUGHLY FOR OPERATING AND SAFETY INSTRUCTIONS. REPLACEMENT MANUAL AVAILABLE FROM: JACOBSEN/TEXTRON, RACINE, WI. TO START TO STOP TO TRANSPORT 1. Engage parking brake.
  • Page 29 Decal, Soft Drop Located on Front Carrier 3004320 Decal, Patent 339237 Decal, Heat Gas Units Only 3006486 Decal, Flash Attach 3007953 Decal, Greens King VI 3007830 Decal, 3WD 3WD Units Only 3007504 Decal, Jacobsen 3007513 Decal, Textron 3007531 Emblem, Diamond J...

  • Page 30: Hood

    GREENS KING VI Serial No. All 2.1 Hood Item Part No. Qty. Description Serial Numbers/Notes 2811078 Hood Assembly Includes Decals 2811130 • Handle, Hood 2810673 • Support, Hood 445796 • Nut, 3/8-16 Spiralock Flange 460010 • Cotter Pin, 3/32 x 1/2”...

  • Page 31: Hood, Cowling, And Console

    GREENS KING VI Serial No. All 3.1 Hood, Cowling, and Console Item Part No. Qty. Description Serial Numbers/Notes 2811401 Console 2811080 Cowling 2810578 Bracket, Cowling 404014 Screw, 1/4-20 x 1/2” Truss Head 2811414 Plug, Plastic 443106 Nut, 5/16-18 Hex 400108 Screw, 1/4-20 x 3/4”...

  • Page 32: Operator's Platform

    GREENS KING VI Serial No. All 4.1 Operator’s Platform 16/17 Detail "B" Detail "C" "A" "A" Detail "C" Repeat for this side...
  • Page 33 GREENS KING VI Item Part No. Qty. Description Serial Numbers/Notes 2810457 Operator Platform 366724 • Bushing, Flanged Pedal Pivot See 9.1 2810451 Panel, Right Side Floor 2811118 Pad, Left Side Floor Panel 3000842 Panel, Battery Cover 3002593 Pad, Floor Panel...

  • Page 34: Instrument Panel

    GREENS KING VI Serial No. All 5.1 Instrument Panel Relay Identification Component Identification SW16 SW15 (Optional Kit) Instrument Panel Instrument Panel (Viewed From Top) (Viewed From Bottom)
  • Page 35 GREENS KING VI Item Part No. Qty. Description Serial Numbers/Notes 2810292 Instrument Panel See 6.1 366932 Snap-in Blank 3001375 Switch, Light Reference SW15 2811173 Switch, Hydraulic Oil Level/ Test Reference SW16 3001780 Switch, PTO Reference SW6 338601 Circuit Breaker, 10 Amp...

  • Page 36: Gasoline Engine Control Console

    GREENS KING VI Serial No. All 6.1 Gasoline Engine Control Console Throttle Cable Choke Cable Mow / Transport Adjustment Cable...
  • Page 37 Item Part No. Qty. Description Serial Numbers/Notes 2811061 Lamp, Dome Reference L5 3004329 Panel, Mechanical Instrument 2811595 Screw, #8-32 x 1/2” One-Way Security 403908 Screw, #10-24 x 3/8” Truss Head 446116 Lockwasher, #10 444310 Nut, #10-24 Hex 445207 Speed Nut, #10-24 446142 Lockwasher, 3/8 Heavy 443112...

  • Page 38: Diesel Engine Control Console

    GREENS KING VI Serial No. All 7.1 Diesel Engine Control Console Throttle Cable Mow/Transport Adjustment Cable Throttle Cable...
  • Page 39 GREENS KING VI Item Part No. Qty. Description Serial Numbers/Notes 338289 Solenoid, Fuel Reference K18 367191 Rod, 1/4-28 x 6-1/4” Threaded 162478 Ball Joint, 1/4-28 443104 Nut, 1/4-28 Hex 443102 Nut, 1/4-20 Hex 400108 Screw, 1/4-20 x 3/4” Hex Head...

  • Page 40: Steering Tower And Gauges

    GREENS KING VI Serial No. All 8.1 Steering Tower and Gauges Gasoline Units Part of Item #7 Diesel Units Part of Item #7...
  • Page 41 GREENS KING VI Item Part No. Qty. Description Serial Numbers/Notes 162723 Hour Meter Reference U2 447006 • Lockwasher, #10 External Tooth 444310 • Nut, #10-32 Hex 162721 Volt Meter Reference U3 447002 • Lockwasher, #6 External Tooth 444304 • Nut, #6-32 Hex 447206 •...

  • Page 42: Traction Pedal Linkage

    GREENS KING VI Serial No. All 9.1 Traction Pedal Linkage Common to both Models (Set-up for 2 WD Models Only) Traction Pedal *(Set-up for 3 WD Models Only)
  • Page 43 GREENS KING VI Item Part No. Qty. Description Serial Numbers/Notes 1003381 Pedal Arm 2810486 Lever, Pivot 361108 • Bushing 357855 Washer 463003 Woodruff Key 471216 Grease Fitting 345625 Spacer 364235 Rod End 434044 Screw, #8-32 x 1/2” Socket Head 400116 Screw, 1/4-20 x 1-1/2”...

  • Page 44: Parking Brake

    GREENS KING VI Serial No. All 10.1 Parking Brake...
  • Page 45 GREENS KING VI Item Part No. Qty. Description Serial Numbers/Notes 2810048 Parking Brake Lever 345689 Grip, Brake 3001005 Link, Handbrake 364528 Spacer 453009 Flat Washer, 5/16 460010 Cotter Pin, 3/32 x 1/2” 400118 Screw, 1/4-20 x 1-3/4” Hex Head 446130...

  • Page 46: Front Wheel Motors And Brakes

    GREENS KING VI Serial No. All 11.1 Front Wheel Motors and Brakes Brake Calipers To Parking Brake Lever...
  • Page 47 GREENS KING VI Item Part No. Qty. Description Serial Numbers/Notes 1003508 Wheel Motor See 45.1 463027 • Key 590101 • Nut 2809909 Brake Shaft 2809910 Brake Arm 2809911 Rod, Brake Arm 2809998 Guide, Brake 3001512 Spring, Die 310711 Washer, Pulley Retaining...

  • Page 48: Lift Mow Controls

    GREENS KING VI Serial No. All 12.1 Lift Mow Controls Item Part No. Qty. Description Serial Numbers/Notes 2811065 Arm Assembly, Valve Mount 453009 Flat Washer, 5/16 446136 Lockwasher, 5/16 Heavy 443106 Nut, 5/16-18 Hex 365960 Cover, Floor Switch 400204 Screw, 5/16-18 x 3-1/2” Hex Head...

  • Page 49: Seat

    GREENS KING VI Serial No. All 13.1Seat Item Part No. Qty. Description Serial Numbers/Notes 66172 Seat, Standard 554390 • Seat Switch Reference SW5 163583 • Harness, Switch (Not Shown) 434011 • Screw, 1/4-20 x 5/8” Socket Head 446130 • Lockwasher, 1/4 Heavy...

  • Page 50: Baseframe And Lift Arms

    GREENS KING VI Serial No. All 14.1 Baseframe and Lift Arms Grounding Strap from Engine...
  • Page 51 GREENS KING VI Item Part No. Qty. Description Serial Numbers/Notes 4117463 Baseframe 357999 • Bushing, Front Cam (Not Shown) See 15.1 3007694 • Bushing, Lift Arm 360460 • Bushing, Steering Tube 328016 • Bushing, Parking Brake Pivot 2811403 Cable, Negative, Battery...

  • Page 52: Lift Linkage

    GREENS KING VI Serial No. All 15.1 Lift Linkage...
  • Page 53 GREENS KING VI Item Part No. Qty. Description Serial Numbers/Notes 458433 Retaining Ring 400106 Screw, 1/4-20 x 5/8” Hex Head 357998 Retaining Pin 446130 Lockwasher, 1/4 Heavy 443102 Nut, 1/4-20 Hex 1004439 Cam, Rear Mower Lift 3007694 • Bushing 412017 Screw, 5/16-18 x 3/4”...

  • Page 54: Steering Axle-2Wd Units

    GREENS KING VI1 Serial No. All 16.1 Steering Axle-2WD Units Item Part No. Qty. Description Serial Numbers/Notes 2812251 Steering Yoke 367249 Collar 345621 Seal, Steering Shaft 3003360 Thrust Washer 3003361 Cup, Thrust Bearing 458466 Retaining Ring 2500477 Washer, Shim 2810327 Spacer, Yoke 2810351 Axle, Rear Wheel...

  • Page 55: Steering Axle-3Wd Units

    GREENS KING VI Serial No. 17.1 Steering Axle-3WD Units Item Part No. Qty. Description Serial Numbers/Notes 2812252 Steering Yoke 367249 Collar 345621 Seal, Steering Shaft 3003360 Thrust Washer 3003361 Cup, Thrust Bearing 458466 Retaining Ring 2500477 Washer 1003508 Wheel Motor See 45.1...

  • Page 56: Steering Tower

    GREENS KING VI Serial No. All 18.1 Steering Tower Part of Item 18...
  • Page 57 GREENS KING VI Item Part No. Qty. Description Serial Numbers/Notes 2811360 Steering Valve See 46.1 • Nut 443108 Nut, 5/16-24 Hex 446136 Lockwasher, 5/16 Heavy 444306 Nut, #8-32 Hex 402458 Screw, #8-32 x 1/2” Flat Head 446110 Lockwasher, #8 366878...

  • Page 58: Gasoline Fuel Lines

    GREENS KING VI Serial No. All 19.1 Gasoline Fuel Lines Reverse View Battery...
  • Page 59 GREENS KING VI Item Part No. Qty. Description Serial Numbers/Notes 400184 Screw, 5/16-18 x3/4” Hex Head 1002659 Pump, Electric, Fuel Reference M2 2810702 Valve, Needle 3002238 Hold Down, Fuel Tank 3004142 Gauge, Fuel 554748 Hose, 5/16 x 74” 3005937 Regulator, Fuel...

  • Page 60: Diesel Fuel Lines

    GREENS KING VI Serial No. All 20.1 Diesel Fuel Lines Battery Well Battery...
  • Page 61 GREENS KING VI Item Part No. Qty. Description Serial Numbers/Notes 2810702 Valve, Needle 3002238 Hold Down, Fuel Tank 3004142 Gauge, Fuel 3008415 Tank, Fuel 338547 Cap, Hydraulic Tank Intake 341837 Filter, Fuel Line Pre 554748 Hose, 5/16 x 25” 361117...

  • Page 62: Air Duct And Oil Cooler

    GREENS KING VI Serial No. All 21.1 Air Duct and Oil Cooler Diesel Units Gasoline Units Part of Item 1 Part of Item 1...
  • Page 63 GREENS KING VI Item Part No. Qty. Description Serial Numbers/Notes 1001701 Air Duct Flange Gas Units 1001565 Air Duct Flange Diesel Units 1001566 Air Duct Door 366013 Hinge 363848 Grommet 3003446 Quick Panel Fastener 3003511 Screen 3008769 Oil Cooler 358971...

  • Page 64: Radiator

    GREENS KING VI Serial No. All 22.1 Radiator Diesel Units Only...
  • Page 65 GREENS KING VI PLUS Item Part No. Qty. Description Serial Numbers/Notes 3006135 Screw, M10-1.25 x 40mm Hex Head 446136 Lockwasher, 5/16 Heavy 443106 Nut, 5/16-18 Hex 3004223 Spacer, Threaded 3006066 Bracket, Door Mount 446130 Lockwasher, 1/4 Heavy 362535 Screw, M6-1 x 16mm Hex Head...

  • Page 66: Gasoline Engine Mounting

    GREENS KING VI Serial No. All 23.1 Gasoline Engine Mounting Engine shown Rotated 180º for Clarity Frame...
  • Page 67 GREENS KING VI Item Part No. Qty. Description Serial Numbers/Notes 1003851 Pump Brace 391201 Base, Gas Engine 354417 Spacer 446142 Lockwasher, 3/8 Heavy 453017 Flat Washer, 1/2 443118 Nut, 1/2-13 Hex 447216 Lockwasher, 3/8 Internal Tooth 400408 Screw, 1/2-13 x 1-1/2” Hex Head...

  • Page 68: Gasoline Engine

    GREENS KING VIZ Serial No. All 24.1 Gasoline Engine Included with Engine...
  • Page 69 GREENS KING VI Item Part No. Qty. Description Serial Numbers/Notes 336481 Belt, Pump Drive See 27.1 340654 Pulley, Gas Engine 362320 415527 Set Screw, 5/16-18 x 3/4” 446142 Lockwasher, 3/8 1001346 Duct, Engine 3003255 Gasket, Duct 3004280 Screw, M6-1 x 10mm Hex Head...

  • Page 70: Diesel Engine Mounting

    GREENS KING VI Serial No. All 25.1 Diesel Engine Mounting Engine Shown Rotated 180° for Clarity P/O 26...
  • Page 71 GREENS KING VI Item Part No. Qty. Description Serial Numbers/Notes 3002994 Brace, Pump 3006267 Mount, Right Rear Engine 453017 Flat Washer, 1/2 446150 Lockwasher, 1/2 443118 Nut, 1/2-13 Hex 346006 Cable, Ground 363586 Screw, M8-1.25 x 20mm Hex Head 400408 Screw, 1/2-13 x 1-1/2”...

  • Page 72: Diesel Engine

    GREENS KING VI Serial No. All 26.1 Diesel Engine Rotated 140° For Clarity...
  • Page 73 GREENS KING VI Item Part No. Qty. Description Serial Numbers/Notes 391127 Air Cleaner 5000913 • Element, Air Cleaner 5000912 • Cover, Air Cleaner 5000914 • Valve 3006254 Pad, Radiator 2810499 Pulley, Engine 3002388 Bracket, Air Cleaner 3006142 Plate, Radiator Stop 2810545 Screw, M8-1.25 x 30mm...

  • Page 74: Pump Assembly

    GREENS KING VI Serial No. All 27.1 Pump Assembly...
  • Page 75 GREENS KING VI Item Part No. Qty. Description Serial Numbers/Notes 123299 Hydrostatic Pump, Traction See 44.1 5002066 • Coupler, Hydro to Gear Pump 362743 • O-Ring 2811091 Gear Pump, Equipment 5001858 • Seal Kit 453011 Flat Washer, 3/8 446142 Lockwasher, 3/8 Heavy 400266 Screw, 3/8-16 x 1-1/2”...

  • Page 76: Rear Frame Hydraulic Components

    GREENS KING VI Serial No. All 28.1 Rear Frame Hydraulic Components Reverse View Reverse View 3WD Units 2WD Units Reverse View (From Above) 2WD Units Only...
  • Page 77 GREENS KING VI Item Part No. Qty. Description Serial Numbers/Notes Serial No 62275 1601 ~ 2056 Serial No 62276 1601 ~ 1731 3002633 Bracket Serial No 62277 1601 ~ 2243 Serial No 62278 1601 ~ 1847 2810561 Valve, Reel Control 2811184 •...

  • Page 78: Hydraulic Tanks

    GREENS KING VI Serial No. All 29.1 Hydraulic Tanks...
  • Page 79 GREENS KING VI Item Part No. Qty. Description Serial Numbers/Notes 3008592 Tank, Hydraulic 3001402 Plug, O-Ring 366673 Elbow, 90°, Beaded 3003773 Clamp, Choke Cable Gas Units Only 324887 Clamp, Throttle Cable Diesel Units Only 472205 Plug, 3/8 Square Head 2810703...

  • Page 80: Pump Hydraulics

    GREENS KING VI Serial No. All 30.1 Pump Hydraulics Item Part No. Qty. Description Serial Numbers/Notes 1000749 Hose, Tank to Charge Pump Inlet 1001984 Hose, Pump Case Drain to Tank Gas Units 1000750 Hose, Pump Case Drain to Tank Diesel Units...

  • Page 81: Traction Hydraulics

    GREENS KING VI Serial No. All 31.1 Traction Hydraulics 3WD Traction Hydraulic System Used Only for 3WD Units Used Only for 2WD Units 2WD Traction Hydraulic System Item Part No. Qty. Description Serial Numbers/Notes 2810261 Tube, Forward Traction 2810260 Tube, Reverse Traction Wheel Motor See 45.1...

  • Page 82: Steering Hydraulics

    GREENS KING VI Serial No. All 32.1 Steering Hydraulics Reference Reference Reference Reference Frame...
  • Page 83 GREENS KING VI Item Part No. Qty. Description Serial Numbers/Notes 2810206 Tube, Steering Cylinder To Bulkhead (Reference O, See 36.1) 2810207 Tube, Steering Cylinder To Bulkhead (Reference P, See 36.1) 2810313 Hose Assembly (Reference F, See 36.1) 2810314 Hose Assembly (Reference G, See 36.1)

  • Page 84: Lift Hydraulics

    GREENS KING VI Serial No. All 33.1 Lift Hydraulics...
  • Page 85 GREENS KING VI Item Part No. Qty. Description Serial Numbers/Notes 1001972 Tube, U 1002030 Tube, Soft Drop 2811074 Hose, Rear Cylinder (Base) to Tube 2810485 Hose, Rear Cylinder (Rod) to Tube 162561 Needle Valve 2810181 Tube, Bulkhead to Rear Cylinder (Reference L, See 36.1)

  • Page 86: Front Reel Hydraulics

    GREENS KING VI Serial No. 62275 1601 ~ 2056 34.1 Front Reel Hydraulics Serial No. 62276 1601 ~ 1731 Serial No. 62277 1601 ~ 2243 Serial No. 62248 1601 ~ 1846...
  • Page 87 GREENS KING VI Item Part No. Qty. Description Serial Numbers/Notes 1004790 Hose, Right Motor Drain 1001075 Hose, Right Motor to Left Motor 1001076 Hose, Right Motor to Bulkhead 1004791 Hose, Left Motor Drain 1001073 Hose, Left Motor to Right Motor...

  • Page 88: Front Reel Hydraulics

    GREENS KING VI Serial No. 62275 2057 and Up 34.2 Front Reel Hydraulics Serial No. 62276 1732 and Up Serial No. 62277 2244 and Up Serial No. 62278 1847 and Up...
  • Page 89 GREENS KING VI Item Part No. Qty. Description Serial Numbers/Notes 1004790 Hose, Right Motor Drain 4114954 Hose, Right Motor to Left Motor 4114953 Hose, Right Motor to Bulkhead 1004791 Hose, Left Motor Drain 4114957 Hose, Left Motor to Right Motor...

  • Page 90: Rear Reel And Return Hydraulics

    GREENS KING VI Serial No. 62275 1601 ~ 2056 35.1 Rear Reel and Return Hydraulics Serial No. 62276 1601 ~ 1731 Serial No. 62277 1601 ~ 2243 Serial No. 62278 1601 ~ 1846 See Item 9 Above...
  • Page 91 GREENS KING VI Item Part No. Qty. Description Serial Numbers/Notes 4113432 Tube, Forward Pressure Bulkhead (Reference K, See 36.1) 4113429 Tube, Bulkhead to Center Motor (Reference R, See 36.1) 4113541 Hose, Tube to Center Motor 4113597 Hose, Center Motor to Cooler...

  • Page 92: Rear Reel And Return Hydraulics

    GREENS KING VI Serial No. 62275 2057 and Up 35.2 Rear Reel and Return Hydraulics Serial No. 62276 1732 and Up Serial No. 62277 2244 and Up Serial No. 62278 1847 and Up See Item 9 Above...
  • Page 93 GREENS KING VI Item Part No. Qty. Description Serial Numbers/Notes 4113432 Tube, Forward Pressure Bulkhead (Reference K, See 36.1) 4113429 Tube, Bulkhead to Center Motor (Reference R, See 36.1) 4113541 Hose, Tube to Center Motor 4113597 Hose, Center Motor to Cooler...

  • Page 94: Hydraulic Hose Clamps

    GREENS KING VI Serial No. 62275 1601 ~ 2056 36.1 Hydraulic Hose Clamps Serial No. 62276 1601 ~ 1731 Serial No. 62277 1601 ~ 2243 Serial No. 62248 1601 ~ 1846 14 2 Reference See 34.1 See 34.1 See 34.1 See 32.1...
  • Page 95 GREENS KING VI Item Part No. Qty. Description Serial Numbers/Notes 2809827 Clamp, 5 Hose 453023 Flat Washer, 1/4 364221 Clamp, 3/8” Double Tube 364738 Clamp, 3/8” Tube 3003110 Clamp, 5/8” Double Tube 367186 Clamp, 1/2” Double Tube 400202 Screw, 5/16-18 x 3” Hex Head...

  • Page 96: Hydraulic Hose Clamps

    GREENS KING VI Serial No. 62275 2057 and Up 36.2 Hydraulic Hose Clamps Serial No. 62276 1732 and Up Serial No. 62277 2244 and Up Serial No. 62248 1847 and Up 14 2 Reference See 34.1 See 34.1 See 34.1 See 32.1...
  • Page 97 GREENS KING VI Item Part No. Qty. Description Serial Numbers/Notes 4116698 Clamp, 5 Hose 453023 Flat Washer, 1/4 364221 Clamp, 3/8” Double Tube 364738 Clamp, 3/8” Tube 3003110 Clamp, 5/8” Double Tube 367186 Clamp, 1/2” Double Tube 400202 Screw, 5/16-18 x 3” Hex Head...

  • Page 98: Circuit Breaker Mounting

    GREENS KING VI Serial No. All 37.1 Circuit Breaker Mounting Gasoline Units Detail View Detail View From Rear Harness is Secured to Hydraulic Lines Item Part No. Qty. Description Serial Numbers/Notes 361439 Circuit Breaker, 50 Amp Reference CB1 361439 Circuit Breaker, 50 Amp...

  • Page 99: Circuit Breaker Mounting

    GREENS KING VI Serial No. All 38.1 Circuit Breaker Mounting Diesel Units Detail View Harness is Secured to Hydraulic Lines Viewed From Right Side of Unit Item Part No. Qty. Description Serial Numbers/Notes 361439 Circuit Breaker, 50 Amp Reference CB1...

  • Page 100: Electrical Routing

    GREENS KING VI Serial No. All 39.1 Electrical Routing Items Common to Both Units Gas Unit Starter Solenoid Hook-up A Brake Lights V Reel Switch B Circuit Breakers W Fuel Pump-Used on C Center Light Gasoline Units Only D Rocker Switches...
  • Page 101 GREENS KING VI Item Part No. Qty. Description Serial Numbers/Notes 2811015 Harness, Console 2811375 • 4 Diode Circuit Board Reference D1 2811608 • Cover, Relay Board 2811358 • Relay Mounting Clip 2812286 Harness, Platform 2811375 • 4 Diode Circuit Board...

  • Page 102: Reel

    GREENS KING VI Serial No. All 40.1 Reel WARNING To prevent cuts use socket wrench or Turf Groomer knob to turn reel. DANGER To prevent injury, disengage all drives, engage parking brake and stop engine before working in machine or emptying grass catchers.
  • Page 103 GREENS KING VI Item Part No. Qty. Description Serial Numbers/Notes 5002577 Frame, Reel 361877 • Decal, Danger 1000997 • Decal, Warning 5003054 7 Blade Reel 68645 Only 5001102 11 Blade Reel 68646 Only 1004786 Bearing Housing 500534 • Bearing, Cup and Cone 336962 •...

  • Page 104: Reel (Continued)

    GREENS KING VI Serial No. All 41.1 Reel (Continued) 21/22...
  • Page 105 GREENS KING VI Item Part No. Qty. Description Serial Numbers/Notes 1000770 Rear Roller See 42.1, 68645 Only 1004990 Rear Roller See 43.1, 68646 Only 1002224 Zerk Bolt 446142 Lockwasher, 3/8 Heavy 400264 Screw, 3/8-16 x 1-1/4” Hex Head 453011 Flat Washer, 3/8...

  • Page 106: Rear Roller

    GREENS KING VI Serial No. All 42.1 Rear Roller Part Number 1000770 Item Part No. Qty. Description Serial Numbers/Notes 3001654 Shaft, Roller 3001655 Tube, Roller 3001656 Seal, Grease 5000625 Bearing, Cup and Cone 3000983 Seal, Grease 3001762 Sleeve, Wear 445801...

  • Page 107: Rear Roller

    GREENS KING VI Serial No. All 43.1 Rear Roller Part Number 1004990 Item Part No. Qty. Description Serial Numbers/Notes Roller Tube 3010422 Shaft 3010712 Bearing 3010286 Seal > Change from previous revision...

  • Page 108: Hydrostatic Pump

    GREENS KING VI Serial No. All 44.1 Hydrostatic Pump Part Number 123299...
  • Page 109 GREENS KING VI Item Part No. Qty. Description Serial Numbers/Notes 156287 Cylinder Block Kit • Slipper Retainer • Piston Assembly 2500597 Implement Relief Valve Kit Includes Items 2 ~ 6 • Implement Relief Spring • Relief Valve • Plug • Relief Shim Kit (Not Shown) •...

  • Page 110: Wheel Motor

    GREENS KING VI Serial No. All 45.1 Wheel Motor Part Number 1003508...
  • Page 111 GREENS KING VI Item Part No. Qty. Description Serial Numbers/Notes 5003734 Seal Kit (Not Shown) Includes Grease Pack • Seal • Back-Up Ring • Shaft Seal • Seal Ring • Manifold • Bonded Ring 554519 Bearing Thrust Washer Thrust Bearing...

  • Page 112: Steering Valve

    GREENS KING VI Serial No. All 46.1 Steering Valve Part Number 2811360...
  • Page 113 GREENS KING VI Item Part No. Qty. Description Serial Numbers/Notes 443108 Locknut, 5/16-18 Center 5002074 Port Cover Seal, O-Ring C and E Seal, O-Ring Seal, O-Ring Ring, Retaining Plate 5002056 Special Bolt Port Manifold B and E Spring, Port Side...

  • Page 114: 3Wd Valve

    GREENS KING VI Serial No. All 47.1 3WD Valve Part Number 4111942 Item Part No. Qty. Description Serial Numbers/Notes 2810173 Check Valve 5003578 • Seal Kit, Check Valve 5001353 Spool Valve Reference K8, See 51.1 5003579 • Seal Kit, Spool Valve...

  • Page 115: Lift Valve

    GREENS KING VI Serial No. All 48.1 Lift Valve Part Number 2810600 4 / 5 Item Part No. Qty. Description Serial Numbers/Notes 2811337 Check Valve 5003578 • Seal Kit 2811334 4 Way Valve 5003579 • Seal Kit 4103460 Relief Valve 5003578 •...

  • Page 116: Wheel And Tire

    GREENS KING VI Serial No. All 49.1 Wheel and Tire Item Part No. Qty. Description Serial Numbers/Notes 5000910 Tire 3008134 Wheel 360111 Valve > Change from previous revision...

  • Page 117: Lift Cylinder

    GREENS KING VI Serial No. All 50.1 Lift Cylinder Part Number 131450 Item Part No. Qty. Description Serial Numbers/Notes 590287 Gold Star Cylinders Only 551067 Piston Gold Star Cylinders Only Cylinder Tube Gold Star Cylinders Only 551068 Gold Star Cylinders Only...

  • Page 118: Electrical Schematic

    RD/BN RD/BN RD/OG J1-1 RD/BK RD/BK J3-2 RD/BN RD/OG RD/OG J1-12 RD/BK RD/BU Gas Units Off - None RD/OG On - B+I RD/OG BN/BU GP - B+I+G OG/RD OG/BU Start - B+I+G+S Diesel Units RD/OG BN/RD RD/OG OG/BU RD/OG See Seat Circuit BN/BK BN/BK Options...
  • Page 119 RD/BN RD/OG RD/OG RD/BN RD/YE J3-6 RD/BN RD/GN RD/GN BK/WH SW16 RD/GN BK/WH VT/YE VT/WH SW14 RD/GN J3-8 J2-3 OG/WH OG/WH RD/GN VT/BK J1-2 BK/WH RD/GN RD/GN BK/WH VT/OR VT/WH VT/BK J4-1 J2-4 OG/BU OG/BU OG/BU VT/BK BK/WH SW15 BK/YE BK/YE YE/GY YE/GY...
  • Page 120 Gas Engine Connections RD/OG RD/OG OG/BN RD/OG BU/BN OG/GN OG/GN SW19 BU/GN RD/OG BU/BN BU/RD OG/GN RD/OG GN/BN OG/RD RD/WH BU/BN RD/VT SW17 RD/OG RAISE RD/OG BU/BN LOWER GN/BN RD/OG GN/BN GN/BN GN/BN Diesel Engine Connections OG/GN RD/OG RD/OG GN/BN RD/OG RD/OG SW20...
  • Page 121 GREENS KING VI Reference Part Item Description Serial Numbers/Notes Illustration Number Not Shown Battery CB1 See 37.1, 38.1 361439 50 Amp Circuit Breaker (Main) See 5.1 338601 10 Amp Circuit Breaker (Lights) See 5.1 338551 10 Amp Circuit Breaker (Instruments) See 5.1...
  • Page 122 GREENS KING VI Reference Part Item Description Serial Numbers/Notes Illustration Number See 5.1 3001780 Reel Switch Not Shown 3003243 Forward/Reverse Switch (Optional) Included in Product 68657 Not Shown 3003243 Backlap Switch (Optional) Included in Product 68657 See 15.1 3007392 Reel Position Proximity Switch SW10 See 27.1...

  • Page 123: Hydraulic Schematic

    GREENS KING VI Serial No. All 52.1 Hydraulic Schematic Steering 3WD Valve Cylinder 3.30 10.0 Steering Motor Valve 0.086 Lift Lower Rear Lift Cylinder 785 psi .020 Return 70-150 10.0 120 psi 0.91 Front Lift Cylinder 0.33 Traction Lift 0.086...

  • Page 124: O-Ring Chart

    GREENS KING VI Serial No. All 53.1 O-Ring Chart O-Ring Face O-Ring Boss O-Ring Face O-Ring Face O-Ring Boss O-Ring Boss Seal Size Dash Size Seal Size Seal Size Dash Size Dash Size Straight Adapter 45° Adapter 90° Adapter W-X-Y...
  • Page 125 GREENS KING VI Adapter Part Dash (Z) O- Adapter Type (W) O-Ring (X) O-Ring (Y) O-Ring Number. Size Ring 339972 Straight Adapter 339908 339896 339974 Straight Adapter 339908 339897 339979 Straight Adapter 339909 339897 339980 Straight Adapter 339909 339898 339984...
  • Page 126 Fluids and Compounds Hydraulic Fluid* 5001405 Two 2-1/2 Gallon Container of ISO VG68 Oil 5001404 One 5 Gallon Pail of ISO VG68 Oil 2500548 Two 2-1/2 Gallon Container of 10W30 Oil 2500546 One 5 Gallon Pail of 10W30 Oil 503409 Two 2-1/2 Gallon Container of ATF Fluid 503407 One 5 Gallon Pail of ATF Fluid...
  • Page 127 INDEX 1000252...... 51 122786 ...... 105 2810318 ...... 83 2811078 ......30 1000253...... 51 122787 ...... 105 2810319 ...... 83 2811080 ......31 1000255...... 75 123299 ......75 2810327 ...... 54 2811091 ......75 1000327...... 53 131450 ......53 2810333 ...... 85 2811118 ......33 1000328......
  • Page 128 INDEX 3000926.......43 3002994.......71 3006991 ...... 49 336481 ......69 3000928.......33 3003110....95 3007392 ..43 336962 ...... 103 3000930.......77 3003255.......69 3007504 ...... 29 338289 ......39 3000983.....106 3003261....69 3007513 ...... 29 338383 ......47 3001005.......45 3003360....54 3007531 ...... 29 338547 ....
  • Page 129 INDEX 349577...... 109 365976 ......59 5000441 ...... 69 503477 ......103 349816.... 80 366013 ......63 5000527 ...... 41 503478 ......103 350542......53 366197 ......53 5000614 ....69 503479 ......103 352726......47 366403 ......41 5000625 ....106 530660 ......47 352737......
  • Page 130 Textron Golf, Turf & Specialty Products PO Box 7708, Charlotte, NC 28241-7708 www.ttcsp.com...

This manual is also suitable for:

Greens king vi series62275622766227762278Greens king vi 1862g ... Show all

Table of Contents

Save PDF
