Image Output
Target/Flood LEDs
EZ Trax Output
Database Identifier Output
EZ Button
EZ Button Modes
Trend Analysis Output 1
Trend Analysis Output 2
Trend Analysis Output 3
Diagnostic Output 1
Diagnostic Output 2
Diagnostic Output 3
ISO/IEC 16022 Symbol Quality Output 1 <K800,output on symbol contrast,symbol contrast threshold,output
ISO/IEC 16022 Symbol Quality Output 2 <K801,output on symbol contrast,symbol contrast threshold,output
ISO/IEC 16022 Symbol Quality Output 3 <K802,output on symbol contrast,symbol contrast threshold,output
Configurable Output 1
Configurable Output 2
Configurable Output 3
Symbol Quality
Symbol Quality Separator/ Data Matrix
Output Mode
ISO/IEC 16022 Symbol Quality Output
Microscan Symbol Quality Output
Static Validation Report
Matchcode
Matchcode Type
Number of Master Symbols
New Master Pin
Enter Master Symbol Data
Request Master Symbol Data
MINI Hawk Xi High Performance Imager User's Manual
<K739,image output mode,communication port,file format,JPEG
quality>
<K750,green flash LED status,target pattern LED status,green
flash duration>
<K757,comm port,image mode,image format,JPEG quality,
object info output,grade output>
<K759,status,separator>
<K770,global status,default on power-on,load Configuration
Database,save for power-on>
<K771,single beep,two beeps,three beeps,four beeps>
<K780,trend analysis mode,trigger evaluation period,number to
output on,decodes per trigger threshold>
<K781,trend analysis mode,trigger evaluation period,number to
output on,decodes per trigger threshold>
<K782,trend analysis mode,trigger evaluation period,number to
output on,decodes per trigger threshold>
<K790,unused 1,service unit>
<K791,unused 1,service unit>
<K792,unused 1,service unit>
on print growth,print growth threshold,output on axial non-uniformity,
axial non-uniformity threshold,output on UEC,UEC threshold>
on print growth,print growth threshold,output on axial non-uniformity,
axial non-uniformity threshold,output on UEC,UEC threshold>
on print growth,print growth threshold,output on axial non-uniformity,
axial non-uniformity threshold,output on UEC,UEC threshold>
<K810,output on,output state,pulse width,output mode>
<K811,output on,output state,pulse width,output mode>
<K812,output on,output state,pulse width,output mode>
<K708,symbol quality separator,data matrix output mode>
<K709,symbol contrast,print growth,axial non-uniformity,UEC>
<K710,percent cell damage,total read time,capture time,locate
time,decode time,pixels per element,ECC level,matrix size,quiet
zone>
<VAL>
<K223,matchcode type,sequential matching,match start position,match
length,wild card character,sequence on No Read,sequence on
mismatch>
<K224,number of master symbols>
<K225,status>
<K231,master symbol number,master symbol data>
<K231?,>[for all] or <K231?,master symbol number>
Appendices
A-19
