Table of Contents

Advertisement

Quick Links

CÓPIA NÃO CONTROLADA
B079/B082

SERVICE MANUAL

001634MIU
RICOH GROUP COMPANIES
CÓPIA NÃO CONTROLADA

Advertisement

Table of Contents
loading

Related Manuals for Ricoh B079

Summary of Contents for Ricoh B079

  • Page 1: Service Manual

    CÓPIA NÃO CONTROLADA B079/B082 SERVICE MANUAL 001634MIU RICOH GROUP COMPANIES CÓPIA NÃO CONTROLADA...
  • Page 2 CÓPIA NÃO CONTROLADA CÓPIA NÃO CONTROLADA...
  • Page 3 CÓPIA NÃO CONTROLADA ® ® RICOH GROUP COMPANIES CÓPIA NÃO CONTROLADA...
  • Page 4 CÓPIA NÃO CONTROLADA CÓPIA NÃO CONTROLADA...
  • Page 5 CÓPIA NÃO CONTROLADA B079/B082 SERVICE MANUAL 001634MIU CÓPIA NÃO CONTROLADA...
  • Page 6 CÓPIA NÃO CONTROLADA CÓPIA NÃO CONTROLADA...
  • Page 7 It is the reader's responsibility when discussing the information contained within this document to maintain a level of confidentiality that is in the best interest of Ricoh Corporation and its member companies. NO PART OF THIS DOCUMENT MAY BE REPRODUCED IN ANY FASHION AND DISTRIBUTED WITHOUT THE PRIOR PERMISSION OF RICOH CORPORATION.
  • Page 8 CÓPIA NÃO CONTROLADA CÓPIA NÃO CONTROLADA...
  • Page 9 Ricoh Corporation. Users of this manual should be either service trained or certified by successfully completing a Ricoh Technical Training Program. Untrained uncertified users utilizing...
  • Page 10 CÓPIA NÃO CONTROLADA CÓPIA NÃO CONTROLADA...
  • Page 11 CÓPIA NÃO CONTROLADA LEGEND PRODUCT CODE COMPANY GESTETNER LANIER RICOH SAVIN B079 3532 LD035 Aficio 2035 4035 B082 4532 LD045 Aficio 2045 4045 DOCUMENTATION HISTORY REV. NO. DATE COMMENTS 05/2003 Original Printing CÓPIA NÃO CONTROLADA...
  • Page 12 CÓPIA NÃO CONTROLADA CÓPIA NÃO CONTROLADA...

  • Page 13: Table Of Contents

    CÓPIA NÃO CONTROLADA B079/B082 TABLE OF CONTENTS INSTALLATION 1. INSTALLATION PROCEDURE............ 1-1 1.1 INSTALLATION REQUIREMENTS ............1-1 1.1.1 ENVIRONMENT ................1-2 1.1.2 MACHINE LEVEL................1-2 1.1.3 MINIMUM SPACE REQUIREMENTS ..........1-3 1.1.4 POWER REQUIREMENTS ...............1-5 1.2 INSTALLATION FLOW CHART ..............1-6 1.3 MAIN MACHINE INSTALLATION...............1-7 1.3.1 ACCESSORY CHECK ..............1-7...
  • Page 14 3.8.1 LEFT UPPER COVER...............3-7 3.9 SCANNER UNIT..................3-8 3.9.1 ARDF....................3-8 3.9.2 EXPOSURE GLASS................3-9 3.9.3 SCANNER EXTERIOR PANELS/OPERATION PANEL ....3-10 3.9.4 LENS BLOCK/SBU ASSEMBLY .............3-11 3.9.5 ORIGINAL SIZE SENSORS ............3-12 3.9.6 EXPOSURE LAMP................3-13 3.9.7 SCANNER HP SENSOR/PLATEN COVER SENSOR ....3-14 B079/B082 CÓPIA NÃO CONTROLADA...
  • Page 15 3.15.1 FUSING UNIT REMOVAL .............3-52 3.15.2 FUSING UNIT EXIT GUIDE............3-53 3.15.3 HOT ROLLER STRIPPERS............3-53 3.15.4 FUSING LAMPS ................3-54 3.15.5 THERMISTORS AND THERMOSTATS ........3-56 3.15.6 FUSING ROLLER/PRESSURE ROLLER ........3-57 3.15.7 FUSING UNIT SIDE FAN ..............3-59 3.15.8 FUSING UNIT CORNER FAN ............3-61 B079/B082 CÓPIA NÃO CONTROLADA...
  • Page 16 Registration: Platen Mode..............3-85 Magnification..................3-85 3.21.3 ADF IMAGE ADJUSTMENT ............3-86 Registration..................3-86 3.21.4 TOUCH SCREEN CALIBRATION ..........3-87 TROUBLESHOOTING 4. TROUBLESHOOTING ..............4-1 4.1 SERVICE CALL CONDITIONS ..............4-1 4.1.1 SUMMARY ..................4-1 4.1.2 SC CODE DESCRIPTIONS ..............4-2 4.2 ELECTRICAL COMPONENT DEFECTS..........4-24 B079/B082 CÓPIA NÃO CONTROLADA...
  • Page 17 5.2 SOFTWARE DOWNLOAD ...............5-88 5.3 UPLOADING/DOWNLOADING NVRAM DATA........5-89 5.3.1 UPLOADING NVRAM DATA (SP5-824)..........5-89 5.3.2 DOWNLOADING NVRAM DATA (SP5-825) ........5-90 5.4 SELF-DIAGNOSTIC MODE ..............5-91 5.4.8 SELF-DIAGNOSTIC MODE AT POWER ON ........5-91 5.4.9 DETAILED SELF-DIAGNOSTIC MODE..........5-92 Executing Detailed Self-Diagnosis ............5-92 B079/B082 CÓPIA NÃO CONTROLADA...
  • Page 18 ID sensor ....................6-11 Cleaning....................6-11 Quenching ..................6-11 6.4 SCANNING....................6-12 6.4.1 OVERVIEW ..................6-12 6.4.2 SCANNER DRIVE ................6-13 Book Mode..................6-13 ADF mode...................6-13 6.4.3 ORIGINAL SIZE DETECTION IN PLATEN MODE......6-14 6.5 IMAGE PROCESSING ................6-16 6.5.1 OVERVIEW ..................6-16 6.5.2 SBU (SENSOR BOARD UNIT)............6-17 B079/B082 CÓPIA NÃO CONTROLADA...
  • Page 19 6.7.4 DRUM CHARGE ROLLER CLEANING ...........6-52 6.7.5 CORRECTION FOR PAPER WIDTH AND THICKNESS ....6-53 6.7.6 DEVELOPMENT BIAS ..............6-54 Mechanism ..................6-54 Correction for paper width and thickness (by-pass tray only)....6-54 6.8 DEVELOPMENT ..................6-55 6.8.1 OVERVIEW ..................6-55 6.8.2 DRIVE MECHANISM...............6-56 B079/B082 CÓPIA NÃO CONTROLADA...
  • Page 20 6.13.5 TRANSFER BELT CHARGE ............6-80 Mechanism ..................6-80 Correction for paper width and thickness..........6-81 Currents applied to leading edge and image areas, and for by-pass feed ......................6-82 6.13.6 TRANSFER BELT CLEANING MECHANISM .......6-83 6.14 IMAGE FUSING AND PAPER EXIT ............6-84 B079/B082 viii CÓPIA NÃO CONTROLADA...
  • Page 21 AUTO REVERSE DOCUMENT FEEDER B541 SEE SECTION B541 FOR DETAILED TABLE OF CONTENTS LARGE CAPACITY TRAY B543 SEE SECTION B543 FOR DETAILED TABLE OF CONTENTS PAPER TRAY UNIT B542 SEE SECTION B542 FOR DETAILED TABLE OF CONTENTS B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 22: Bridge Unit B

    SEE SECTION B545 FOR DETAILED TABLE OF CONTENTS BRIDGE UNIT B538 SEE SECTION B538 FOR DETAILED TABLE OF CONTENTS PRINTER OPTION B548 SEE SECTION B548 FOR DETAILED TABLE OF CONTENTS FAX OPTION B547 SEE SECTION B547 FOR DETAILED TABLE OF CONTENTS B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 23: Important Safety Notices

    CÓPIA NÃO CONTROLADA IMPORTANT SAFETY NOTICES PREVENTION OF PHYSICAL INJURY 1. Before disassembling or assembling parts of the copier and peripherals, make sure that the copier power cord is unplugged. 2. The wall outlet should be near the copier and easily accessible. 3.

  • Page 24: Laser Safety

    CÓPIA NÃO CONTROLADA 1. SAFETY AND ECOLOGICAL NOTES FOR DISPOSAL Do not incinerate toner bottles or used toner. Toner dust may ignite suddenly when exposed to an open flame. 2. Dispose of used toner, developer, and organic photoconductors in accordance with local regulations. (These are non-toxic supplies.) 3.
  • Page 25 CÓPIA NÃO CONTROLADA Conventions in this Manual This manual uses several symbols. Symbol What it means Refer to section number  See Core Tech Manual for details  Screw  Connector  E-ring  Clip ring Short Edge Feed (SEF) Long Edge Feed (LEF) CÓPIA NÃO CONTROLADA...
  • Page 26 CÓPIA NÃO CONTROLADA CÓPIA NÃO CONTROLADA...
  • Page 27 CÓPIA NÃO CONTROLADA INSTALLATION AUTO REVERSE DOCUMENT FEEDER B541 FAX OPTION B547 PREVENTIVE MAINTENANCE PAPER TRAY UNIT B542 PRINTER OPTION B548 REPLACEMENT AND ADJUSTMENT LARGE CAPACITY TRAY B543 TROUBLESHOOTING BOOKLET FINISHER B546 1000 SHEET FINISHER B408 2-TRAY FINISHER B545 SERVICE TABLES DETAILED DESCRIPTIONS SPECIFICATIONS 1-BIN TRAY B544...
  • Page 28 CÓPIA NÃO CONTROLADA CÓPIA NÃO CONTROLADA...

  • Page 29: Installation

    CÓPIA NÃO CONTROLADA INSTALLATION CÓPIA NÃO CONTROLADA...
  • Page 30 CÓPIA NÃO CONTROLADA CÓPIA NÃO CONTROLADA...

  • Page 31: Installation Procedure

    “Rating Voltage of Output Connector, Max. DC24 V” Scanner Unit “Rating Voltage of Output Connector, Max. DC24 V” Finisher “Rating Voltage of Output Connector, Max. DC24 V” B079I016.WMF “Rating Voltage of Output Connector, Max. DC24 V” B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 32: Environment

    5 mm (0.2"). 10. Do not place the machine where it may be subjected to strong vibrations. 1.1.2 MACHINE LEVEL Front to back: Within 5 mm (0.2") of level Right to left: Within 5 mm (0.2") of level B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 33: Minimum Space Requirements

    D: Right > 10 cm (4") NOTE: The 75 cm (29.5") recommended for the space at the front is for pulling out the paper tray only. If the operator stands at the front of the main machine, more space is required. B079/B082 CÓPIA NÃO CONTROLADA...
  • Page 34 CÓPIA NÃO CONTROLADA INSTALLATION REQUIREMENTS 670 mm (26.4”) 180 mm (7.1”) B079I012.WMF 620 mm (24.4") 726 mm (28.6") 670 mm (23.4") B079I014.WMF B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 35: Power Requirements

    North America 120 V, 60 Hz: More than 12.5 A Europe/Asia 220 V ~ 240V, 50 Hz/60 Hz: more than 6.8 A 2. Permissible voltage fluctuation: ±10 % 3. Never set anything on the power cord. B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 36: Installation Flow Chart

    Install the remaining options in any order B079I510.WMF Bridge Unit: Needed for the finishers and external output tray. Paper Tray Unit (or Cabinet): Needed for LCT and finishers. Other requirements: See Overall Machine Information – Installation Option Table. B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 37: Main Machine Installation

    (-22, -24, -26, -27, -62, -64, -66, -67 Machines)..... 1 16. Address Information Sheet – China (-21 Machine) ....1 17. Paper Caution Sheet – China (-21 Machine) ......1 18. Energy Start Sticker (-26, -66 Machines) ....... 1 (NECR: New Equipment Condition Report) B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 38: Installation Procedure

    NOTE: If the paper tray unit is to be installed, do this now. (!1.4) 5. If the paper tray unit is not to be installed, install the middle front cover [E] (provided in the second paper tray). B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 39: Development Unit And Pcu

    2. Loosen [B] ( x 1) and rotate the bracket [C]. 3. Open the right cover [D]. 4. Raise the lever [E] 5. Holding the PCU [F] as shown slide it out and place it on a clean flat surface. 6. Remove clamps and wire [G]. B079/B082 CÓPIA NÃO CONTROLADA...
  • Page 40 8. Slide the development unit [A] out and place it on the paper. 9. Remove the tape and tag [B] from the development unit 10. Remove the entrance seal plate [C] ( x 2). B079/B082 1-10 CÓPIA NÃO CONTROLADA...
  • Page 41 4) Continue to turn the drive gear until the developer is even with the top of the unit. 13. Reassemble the development unit. NOTE: Make sure that the earth plate [D] is positioned correctly. 14. Re-install the development unit and PCU. 1-11 B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 42: Toner Bottle

    4. Push the toner bottle holder into the main machine until it locks in place, and then lower the holder lever to secure the toner bottle. NOTE: The holder lever cannot be lowered unless the toner bottle is installed. B079/B082 1-12 CÓPIA NÃO CONTROLADA...

  • Page 43: Paper Trays

    • Confirm that there is no gap between the stack and the side fences. If you see a gap, adjust the position of the side fences. • After loading the stack, confirm that the right side of the stack is not on top of both cushions. 1-13 B079/B082 CÓPIA NÃO CONTROLADA...
  • Page 44 8. Paper size decals are also used for the optional paper tray unit. Keep any remaining decals for use with the paper tray unit. 9. Repeat this procedure to load paper in the 2nd paper tray. B079/B082 1-14 CÓPIA NÃO CONTROLADA...

  • Page 45: Initialize Td Sensor And Developer

    9. Press Exit twice to return to the copy window. Plug and Play Setting 1. Press “SP Direct” and enter 5907, press . 2. Select the appropriate maker/model name, press . 3. Press Exit twice to return to the copy window. 1-15 B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 46: Set Paper Size For Paper Trays

    8. Check the copy quality and machine operation. NOTE: The test pattern print procedure is slightly different for this machine. Use SP2-902 and select 2 for the IPU Test Print or 3 for the Print Test Patterns. (! 5.1.3 Test Pattern Printing) B079/B082 1-16 CÓPIA NÃO CONTROLADA...

  • Page 47: Electrical Total Counter

    1. Attach the exposure glass cleaner holder [B] to the left side of the machine. 2. Place the exposure glass cleaner [C] inside the holder. NOTE: The exposure glass cleaner is used to clean the ARDF exposure glass, the glass strip to the left of the large exposure glass. 1-17 B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 48: Paper Tray Unit Installation (B542)

    2. Knob Screw – M4 ..............1 3. Joint Bracket ................1 4. Front Stand ................1 5. Rear Stand................1 6. Stand Bracket ................ 1 7. NECR ..................1 8. Installation Procedure ............1 (NECR: New Equipment Condition Report) B079/B082 1-18 CÓPIA NÃO CONTROLADA...

  • Page 49: Paper Tray Unit Installation Procedure

    1.4.2 PAPER TRAY UNIT INSTALLATION PROCEDURE B542I557.WMF B542I112.WMF  CAUTION Unplug the main machine power cord before starting the following procedure. 1. Unpack the paper tray unit. 2. Remove all tape and shipping materials. 3. Remove the paper trays [A]. 1-19 B079/B082 CÓPIA NÃO CONTROLADA...
  • Page 50 10. Secure the joint bracket [H] (1 long knob screw). 11. Remove the connector cover [I] of the main machine ( x 1). 12. Connect the paper tray unit harness [J] to the main machine and reinstall the connector cover. B079/B082 1-20 CÓPIA NÃO CONTROLADA...
  • Page 51 CÓPIA NÃO CONTROLADA PAPER TRAY UNIT INSTALLATION (B542) B542I118.WMF B542I119.WMF 13. Install the front and rear stands [A] as shown above. 14. Install the stand bracket [B]. 1-21 B079/B082 CÓPIA NÃO CONTROLADA...
  • Page 52 16. Attach the appropriate tray decals [A] which are included in the accessory box for the main machine. 17. Turn on the ac switch. 18. Turn the paper size dial to the correct setting for the paper size. 19. Check the machine’s operation and copy quality. B079/B082 1-22 CÓPIA NÃO CONTROLADA...

  • Page 53: Cabinet Installation Procedure

    2. Remove all tape and shipping materials. 3. Install the 2 longer [A] locating pins and the shorter [B] locating pin. 4. Install the LCT mounting screws [C] (2 types x2). 5. Remove the paper trays [D]. 1-23 B079/B082 CÓPIA NÃO CONTROLADA...
  • Page 54 8. Slowly lower the machine onto the cabinet with the pegs [D] aligned with the peg holes on the bottom of the machine. NOTE: Do not hold the scanner unit. 9. Re-install the middle front cover [A]. 10. Attach the step screw [E]. Then, secure the cabinet. B079/B082 1-24 CÓPIA NÃO CONTROLADA...
  • Page 55 CÓPIA NÃO CONTROLADA CABINET INSTALLATION PROCEDURE B542I118.WMF B542I119.WMF 11. Install the front and rear stands [A] as shown above. 12. Install the stand bracket [B]. 1-25 B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 56: 1-Bin Tray Unit Installation (B544)

    9. Screw – M4 x 7 ..............1 10. Tapping Screw – M3 x 6 ............2 11. Tapping Screw – M3 x 14 ............1 12. Tapping Screw – M3 x 8 ............1 13. Installation Procedure ............1 B079/B082 1-26 CÓPIA NÃO CONTROLADA...

  • Page 57: 1-Bin Tray Installation Procedure

    NOTE: If the ARDF is installed, remove the ARDF before removing the scanner unit. 1) Remove the connector cover [A]. 2) Disconnect the scanner cable [B]. 3) Remove the scanner unit [C] ( x 3). 1-27 B079/B082 CÓPIA NÃO CONTROLADA...
  • Page 58 6. Trim the edges so they are smooth. 7. Install the base cover [E] ( x 3: stepped screw). 8. Set the 1-bin tray unit [F] on the base cover and slide onto the heads of the stepped screws. B079/B082 1-28 CÓPIA NÃO CONTROLADA...
  • Page 59 13. Install the connector cover [E] ( x 1 M3 x 8) 14. Re-install the front bracket [F] ( x 2 M4 x 7, M4 x 10) and the rear bracket [G] ( x 1 M4 x 10). 1-29 B079/B082 CÓPIA NÃO CONTROLADA...
  • Page 60 1) Open the cover of the bridge unit [C]. 2) First, remove the copy tray bracket [D] ( x 1). 3) Install the copy tray bracket ( x 1: tapping screw). 4) Re-install the copy tray [E] ( x 1). B079/B082 1-30 CÓPIA NÃO CONTROLADA...
  • Page 61 18. Raise the scanner stand until the next set of screw holes in the main frame can be seen through the screw holes in the scanner stand. " 19. Secure the stand ( x 2: ) and install the arm cover [D] ( x 1). 1-31 B079/B082 CÓPIA NÃO CONTROLADA...
  • Page 62 20. Attach two mylar strips [A] to the scanner stand [B]. 21. Reinstall the scanner stand cover. 22. Reinstall the scanner unit. 23. Turn on the main switch and check the 1-bin tray unit operation. B079/B082 1-32 CÓPIA NÃO CONTROLADA...

  • Page 63: Bridge Unit Installation (B538)

    Check the quantity and condition of the accessories in the box against the following list: Description Q’ty 1. Stepped Screw ..............2 2. Connector Cover..............1 3. Exit Mylar ................2 4. Installation Procedure ............1 1-33 B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 64: Bridge Unit Installation Procedure

    If the optional external output tray (A825) will be installed (instead of a finisher), do Step 4. 4. Remove the two small covers [C]. 5. Remove the cover [D] ( x 1). 6. Remove the cap [E]. B079/B082 1-34 CÓPIA NÃO CONTROLADA...
  • Page 65 10. Connect the bridge unit I/F harnesses [D] ( x 2). 11. Install the connector cover [E]. 12. Turn on the main switch and check the bridge unit operation (make sure that there are no paper jams). 1-35 B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 66: Two-Tray Finisher Installation (B545)

    2. Rear Joint Bracket ..............1 3. Shift Tray ................2 4. Screw – M4 x 8 ..............2 5. Screw – M4 x 12 ..............5 6. Ground Plate................1 7. Installation Procedure ............1 B079/B082 1-36 CÓPIA NÃO CONTROLADA...

  • Page 67: Two-Tray Finisher Installation Procedure

    2. Open the front door [B] and remove all tapes and shipping materials from inside the finisher unit. 3. Save the retainer [C] and other shipping material. NOTE: The retainer [C] must be re-installed in the finisher before moving or shipping the finisher to another location. 1-37 B079/B082 CÓPIA NÃO CONTROLADA...
  • Page 68 7. Push the finisher to the side of the machine with the holes in the finisher aligned with the joint brackets, and then dock the finisher against the machine. 8. Push in the locking lever and secure it ( x 1), then close the front door. B079/B082 1-38 CÓPIA NÃO CONTROLADA...
  • Page 69 9. Install two trays [A] ( x 1 each). 10. Connect the finisher cable [B] to the main machine below the right, rear handle. 11. Turn on the main switch and check the finisher operation. 1-39 B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 70: Punch Unit Installation (B377)

    1. Punch unit................1 2. Sensor arm ................1 3. Hopper ...................1 4. Step screw ................1 5. Spring ..................1 6. Spacer (2 mm) ...............1 7. Spacer (1 mm) ...............1 8. Tapping screw ...............1 9. Tapping screw ...............2 B079/B082 1-40 CÓPIA NÃO CONTROLADA...

  • Page 71: Punch Unit Installation Procedure

    1. Unpack the punch unit and remove all tapes and shipping retainers. 2. Open the front door and remove the rear cover [A] ( x4). 3. Remove the bracket [B] ( x2) and paper guide [C] ( x 1). 1-41 B079/B082 CÓPIA NÃO CONTROLADA...
  • Page 72 5. Install the sensor bracket [B] (stepped  x 1). 6. Install the spring [C]. 7. Install the 2 mm spacer [D]. 8. Install the punch unit [E] ( x 2, stepped  x 1) B079/B082 1-42 CÓPIA NÃO CONTROLADA...
  • Page 73 11. Fasten the two 1 mm spacers [C] to the rear frame for future adjustment. NOTE: The spacers are used to adjust the horizontal positioning of the holes. 12. Reassemble the finisher and check the punch operation. 1-43 B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 74: Ardf Installation (B541)

    Description Q’ty 1. Stepped Screw ..............2 2. Screw – M4 x 10 ..............2 3. Attention Decal - Scanner ............1 4. Attention Decal – Top Cover..........1 5. Installation Procedure ............1 B079/B082 1-44 CÓPIA NÃO CONTROLADA...

  • Page 75: Ardf Installation Procedure

    CÓPIA NÃO CONTROLADA ARDF INSTALLATION (B541) 1.10.2 ARDF INSTALLATION PROCEDURE B541I904.WMF  CAUTION Unplug the main machine power cord before starting the following procedure. 1. Unpack the ARDF and remove all tapes and shipping retainers. 1-45 B079/B082 CÓPIA NÃO CONTROLADA...
  • Page 76 ARDF toward the front of the machine. NOTE: To avoid damaging the ARDF, hold it as shown in the illustration. 4. Secure the ARDF [C] ( x 2). 5. Connect the I/F cable [D] ( x 1) to the main machine. B079/B082 1-46 CÓPIA NÃO CONTROLADA...
  • Page 77 [E] of the left scale as shown. As with step 9, choose the language most suitable for the machine installed. 11. Turn on the main switch. 12. Check the ARDF operation and copy quality. Be sure to check and adjust the registration for the ARDF with the SP modes 1-47 B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 78: Ardf Skew Adjustment

    1. Remove the tape [A] covering the elliptical hole. 2. Remove right screw [B] and install it into the elliptical hole [C]. 3. Move the right side of the ARDF forward or back to adjust the position then tighten the screw. B079/B082 1-48 CÓPIA NÃO CONTROLADA...

  • Page 79: Lct Installation (B543)

    Description Q’ty 1. Joint Pin ................. 2 2. Stepped Screw M3 x 18............4 3. Magnet Cover ................ 1 4. NECR (-17, -27 machines)............. 1 5. Installation Procedure ............1 (NECR: New Equipment Condition Report) 1-49 B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 80: Lct Installation Procedure

    3. Open the lower right cover [B] and cut the holding band [C]. NOTE: When cutting the holding band, the upper part of the band should be cut as shown. Otherwise, paper jams may occur. 4. Remove the lower right cover. B079/B082 1-50 CÓPIA NÃO CONTROLADA...
  • Page 81 8. Hang the LCT [C] on the joint pins, then secure the brackets [D] ( x 4). 9. Return the LCT to the previous position and connect the LCT cable [E]. 10. Open the LCT cover and load the paper. 11. Turn on the ac switch and check the LCT operation. 1-51 B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 82: Platen Cover Installation (G329)

    1. Install [A] ( x 2) on the top cover as shown. 2. Position the platen cover bracket [B] on the heads of the stud screws and slide the platen cover [C] to the left. B079/B082 1-52 CÓPIA NÃO CONTROLADA...

  • Page 83: Booklet Finisher Installation (B546)

    3. Tapping Screw -M4 x 6............2 4. Rail Ass’y................1 5. Joint Bracket ................1 6. Tapping Screw - M4 x 16.............8 7. Rail Bracket .................1 8. Tapping Screw - M4 x 6............1 9. Harness Cover..............1 10. Sensor Feeler ..............1 1-53 B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 84: Booklet Finisher Installation Procedure

    CÓPIA NÃO CONTROLADA BOOKLET FINISHER INSTALLATION (B546) 1.13.2 BOOKLET FINISHER INSTALLATION PROCEDURE B546I102.WMF B546I104.WMF  CAUTION Keep the power cord unplugged when starting the following procedure. 1. Unpack the finisher and remove the tapes and shipping retainers. B079/B082 1-54 CÓPIA NÃO CONTROLADA...
  • Page 85 5. Remove the right lower cover [C] ( x 4). 6. Remove the front pressure release bracket [D] ( x 1). 7. Remove the rear pressure release bracket [E] ( x 1). 8. Reattach the cover [C]. 1-55 B079/B082 CÓPIA NÃO CONTROLADA...
  • Page 86 9. Set the hooks [A] of the shift tray [B] in the notches in the shift tray bracket, and secure the tray with two M4 x 6 screws. 10. Connect the shift tray sensor harness [C]. 11. Install the harness cover [D] (2 hooks). B079/B082 1-56 CÓPIA NÃO CONTROLADA...
  • Page 87 14. Remove the stand bracket [C]. 15. Attach the rail [D] to the rail bracket [E] as shown. 16. Install the rail bracket [F] on the left lower cover of the copier ( x 4). 1-57 B079/B082 CÓPIA NÃO CONTROLADA...
  • Page 88 19. Align the finisher on the joint bracket and lock the 2 hooks [C] of the finisher on the joint bracket. 20. Connect the finisher cable [D] to the copier. 21. Turn on the main switch and check the finisher operation. B079/B082 1-58 CÓPIA NÃO CONTROLADA...
  • Page 89 7 Screw - M4 x 14..............4 8 Knob Screw - M4 x 10 ............1 9 Screw - M3 x 8..............1 10 Knob Screw - M3 x 8 ............1 : Rear joint bracket is not required for these models. 1-59 B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 90: 1000 Sheet Finisher (B408)

    - Bridge Unit (B538) - Paper Tray Unit (B542) 2. Unpack the finisher and remove the tapes. NOTE: Be sure to keep screw [A]. It will be needed to secure the grounding plate in Step 3. B079/B082 1-60 CÓPIA NÃO CONTROLADA...
  • Page 91 6. Secure the locking lever ( x 1 knob screw M3 x 8). 7. Close the front door. 8. Install the copy tray [F] ( x 1 knob screw M4 x 10). 9. Connect the finisher cable [G] to the main machine below the right rear handle. 1-61 B079/B082 CÓPIA NÃO CONTROLADA...
  • Page 92 CÓPIA NÃO CONTROLADA 1000 SHEET FINISHER (B408) B408I501.WMFF 10. Attach the staple position decal [A] to the ARDF as shown. 11. Turn on the main power switch and check the finisher operation. B079/B082 1-62 CÓPIA NÃO CONTROLADA...

  • Page 93: Check All Connections

    2. Enter the printer user mode and print the configuration page. User Tools> Printer Settings> List Test Print> Config. Page NOTE: The same data can also be printed by executing SP1-004 – Print Summary. All installed options are listed in the “System Reference” column. 1-63 B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 94: Key Counter Installation (A674)

    3. Attach the key counter cover [D] ( x2). 4. Remove the connector cover [E]. 5. Remove the knockout [F] from the connector cover. 6. Remove the rear upper cover [G] ( x4) and left corner cover [H] ( x2). B079/B082 1-64 CÓPIA NÃO CONTROLADA...
  • Page 95 NOTE: When attaching the key counter assembly, press the assembly hard against the scanner cover. Otherwise, the key counter assembly may come off easily. 11. Set “User Tools”, “System Settings”, “Key Operator Tools”, and “Key Counter Management” to restrict access to each available function mode. 1-65 B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 96: Anti-Condensation Heater

    5. Lift the harness guide [D] B004I205.WMF 6. Install the heater brackets [E] ( x2, M3x6). NOTE: Use the screws already attached at the same position. 7. Install the heater [F] ( x2, M4x6) and route the harness. B004I206.WMF B079/B082 1-66 CÓPIA NÃO CONTROLADA...
  • Page 97 NOTE: Do not remove the ground wire from the ac outlet. 13. Install the ac outlet. 14. Install the ground wire [N] ( x1, M4x6). 15. Re-install the rear cover, rear lower cover. B004I209.WMF 16. Connect the harness [O]. B004I210.WMF 1-67 B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 98: Tray Heater

    5. Install the heater assembly [D] ( x1). 6. Install the harness clamp [E]. 7. Fasten the harness [F] with the clamp. 8. Route the heater harness [G] and connect it to the ac harness [H]. B079/B082 1-68 CÓPIA NÃO CONTROLADA...

  • Page 99: Tray Heater (Optional Paper Tray Unit)

    4. Remove the upper and lower paper trays of the optional paper tray unit. 5. Install the heater assembly [D] ( x1). 6. Install four harness clamps [E]. 7. Route the harness [F] and connect it to the harness [G] and heater harness [H]. 1-69 B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 100: Optional User Account Enhancement Unit (B443)

    OPTIONAL USER ACCOUNT ENHANCEMENT UNIT (B443) 1.19 OPTIONAL USER ACCOUNT ENHANCEMENT UNIT (B443) 1. Remove the controller PCB. 2. Install the user account enhancement unit (NVRAM) into IC 10 socket on the controller PCB. 3. Re-install the controller PCB. B079/B082 1-70 CÓPIA NÃO CONTROLADA...

  • Page 101: Preventive Maintenance

    CÓPIA NÃO CONTROLADA PREVENTIVE MAINTENANCE CÓPIA NÃO CONTROLADA...
  • Page 102 CÓPIA NÃO CONTROLADA CÓPIA NÃO CONTROLADA...

  • Page 103: Preventive Maintenance Schedule

    CÓPIA NÃO CONTROLADA PM TABLE 2. PREVENTIVE MAINTENANCE SCHEDULE 2.1 PM TABLE NOTE: Amounts mentioned as the PM interval indicate the number of prints. Symbol key: C: Clean, R: Replace, L: Lubricate, I: Inspect B079/B082 150K 300K 450K NOTE SCANNER/OPTICS...
  • Page 104 CÓPIA NÃO CONTROLADA PM TABLE B079/B082 150K 300K 450K NOTE DEVELOPMENT UNIT Development Drive Gears Development Filter Developer Entrance Seal Side Seal Development Roller Dry cloth PAPER FEED Registration Roller Water or alcohol. Idle Roller Dust Blade Detach and tap gently on flat surface to empty.
  • Page 105 CÓPIA NÃO CONTROLADA PM TABLE B079/B082 150K 300K 450K NOTE FUSING UNIT AND PAPER EXIT Fusing Entrance and Water or alcohol. Exit Guide Plates Hot Roller Pressure Roller Fusing Thermistors Cleaning Roller Cleaning Roller Grease: Barrierta JFE 55/2 Bushings Hot Roller Strippers Water or alcohol.
  • Page 106 B544 150K 300K 450K NOTE 1-BIN TRAY UNIT Rollers Dry or damp cloth Copy Tray Dry or damp cloth Sensors Blower brush Lubricate the paper feed clutch gear [A] with Silicone Grease G501 every P.M. B079P900.WMF B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 107: Replacement And Adjustment

    CÓPIA NÃO CONTROLADA REPLACEMENT AND ADJUSTMENT CÓPIA NÃO CONTROLADA...
  • Page 108 CÓPIA NÃO CONTROLADA CÓPIA NÃO CONTROLADA...

  • Page 109: General Cautions

    5. After replacing the LD unit, do the laser beam pitch adjustment. Otherwise, an SC condition will be generated. 3.1.2 USED TONER 1. Dispose of used toner in accordance with local regulations. Never throw toner into an open flame, for toner dust may ignite. B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 110: Special Tools And Lubricants

    Test Chart – S5S (10 pcs/Set) G0219350 Parallel Loopback Connector 3.2.2 LUBRICANTS Part Number Description Q’ty A2579300 Grease Barrierta S552R 52039502 Silicone Grease G-501 3.2.3 SYMBOLS USED IN TEXT Screw:  Connector:  C-clamp (snap ring):  E-clamp:  B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 111: Front Door

    1. Connector cover [A] ( x1) 2. Duplex connectors [B] ( x2) 3. Duplex support arm [C] ( x1) 4. Duplex unit [D] NOTE: Grip the duplex unit with both hands, slowly rotate it towards you and then lift up. B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 112: Upper Right Cover

    1. Duplex Unit (! 3.4) 2. Transfer belt unit (! 3.13.1) 3. Metal support arm [A] ( x1) 4. Band support arm [B] (loop fastener) 5. Connector [C] ( x1) 6. Upper right cover ( x1, Bushing x1) B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 113: By-Pass Tray

    2. Left cover [A] ( x1) 3. Right cover [B] ( x1) 4. Connectors [C] ( x2) 5. By-pass unit [D] ( x4) NOTE: After removing the screws, lift to unhook the by-pass tray unit from the frame of the machine. B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 114: Rear Covers

    REAR COVERS 3.7 REAR COVERS 3.7.1 REAR UPPER COVER B004R953.WMF 1. Left corner cover [A] ( x2) 2. Rear upper cover [B] ( x2) 3.7.2 REAR LOWER COVER B004R954.WMF 1. Rear lower cover [A] ( x4) B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 115: Left Covers

    CÓPIA NÃO CONTROLADA LEFT COVERS 3.8 LEFT COVERS 3.8.1 LEFT UPPER COVER B004R955.WMF 1. Rear left corner cover [A] ( x2) 2. Left upper cover [B] ( x4) B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 116: Scanner Unit

    1. Interface connector 2. ARDF [A] ( x2) Push the ARDF towards the front of the machine to align the keyholes (not shown) of the ARDF base with the heads of the stud screws and lift. B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 117: Exposure Glass

    3. Left scale [B] ( x2) 4. Exposure glass [C] 5. DF exposure glass [D] NOTE: When reinstalling the DF exposure glass, make sure that the white dot is positioned, dot down, at the rear left corner. B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 118: Scanner Exterior Panels/Operation Panel

    4. Operation panel base [B] ( x4) 5. Rear cover [C] ( x4). Carefully lift in the direction of the arrow to disconnect the tab. 6. Right cover [D] ( x3 ) 7. Left cover [E] ( x2) B079/B082 3-10 CÓPIA NÃO CONTROLADA...

  • Page 119: Lens Block/Sbu Assembly

    NOTE: The elements of the lens block assembly have been factory adjusted and paint locked at 8 points. Do not attempt to replace these items. Replace the unit. 6. Perform scanner and printer copy adjustments (! 3.21) 3-11 B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 120: Original Size Sensors

    2. Exposure glass (! 3.9.2) 3. Lens block (! 3.9.4) 4. Original size sensor [A] ( x1,  x1) 5. Original size sensor [B] ( x1,  x1) 6. Original size sensor [C] ( x1,  x1) B079/B082 3-12 CÓPIA NÃO CONTROLADA...

  • Page 121: Exposure Lamp

    5. Exposure lamp [C] ( x1,  x1) NOTE: Never touch the glass surface of the exposure lamp with fingers. Slide the exposure lamp toward the rear to disengage the tab on its base from the hole below and then lift out. 3-13 B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 122: Scanner Hp Sensor/Platen Cover Sensor

    B004R107.WMF 1. ARDF (! 3.9.1) 2. Scanner rear cover (! 3.9.3) 3. Scanner HP sensor bracket [A] ( x1) 4. Scanner HP sensor [B] ( x1) 5. Platen cover sensor [C] ( x1,  x1) B079/B082 3-14 CÓPIA NÃO CONTROLADA...

  • Page 123: Scanner Motor

    4. Scanner motor bracket [B] ( x3,  x1, spring x1, timing belt x1) NOTE: Loosen motor bracket [B] ( x3) to release tension on belt (motor slides side to side). 5. Scanner motor [C] ( x2,  x1) 6. Perform scanner and printer copy adjustments (! 3.21) 3-15 B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 124: Lamp Stabilizer And Scanner Motor Drive Board

    1. ARDF (! 3.9.1) 2. Scanner rear cover (! 3.9.3) 3. Rear bracket [A] ( x5,  x2) 4. Lamp stabilizer [B] ( x2, standbys x3) 5. Scanner motor drive board [C] ( x2,  x2) B079/B082 3-16 CÓPIA NÃO CONTROLADA...

  • Page 125: Scanner Wire

    Front wire: 4. Left stay [A] ( x4) 5. Right stay [B] ( x4) 6. Front stay [C] ( x6) 7. Front scanner rail [D] ( x2) 8. To replace the scanner wire, see page 3-19. 3-17 B079/B082 CÓPIA NÃO CONTROLADA...
  • Page 126 Rear wire: B004R961.WMF 1. Scanner HP sensor bracket [A] ( x1) 2. Scanner motor (!3.9.8) 3. Rear bracket [B] ( x9) 4. Rear scanner rail [C] ( x2) 5. Scanner drive pulley [D] ( x1) B079/B082 3-18 CÓPIA NÃO CONTROLADA...
  • Page 127 8. Without allowing the wire to loosen, tape the wire to the pulley. 9. Pass the wire through " 10. Complete threading the wire: #Tension spring#Screw & 11. Scanner wire bracket ( x1) 3-19 B079/B082 CÓPIA NÃO CONTROLADA...
  • Page 128 1) Remove the positioning tools. After sliding the scanner to the right and left several times, set the positioning tools to check the scanner wire bracket and tension bracket again. 2) Reassemble the scanner and do the scanner and printer copy adjustments (! 3.21) B079/B082 3-20 CÓPIA NÃO CONTROLADA...

  • Page 129: Laser Unit

    Laser beams can seriously damage your eyes. 3.10.1 CAUTION DECAL LOCATIONS Two caution decals are located in the laser section as shown below. (See the next page for removal instructions.) A232R500.CDR LASER-1.WMF LASER-3.WMF LASER-2.WMF 3-21 B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 130: Laser Unit

    To remove, on the left side press in the top leaf and pull off. When re-attaching the shield glass cover, note that the top leaf lies on top of the plastic form. 5. Shield glass [E] B079/B082 3-22 CÓPIA NÃO CONTROLADA...
  • Page 131 7. Laser unit connectors [B] ( x 6,  x1 flat cable) NOTE: Hold the LD board securely when disconnecting connectors. 8. Laser unit [C] ( x 2) NOTE: When sliding out the laser unit, do not hold the LD board. Hold the laser unit casing. 3-23 B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 132: Polygon Mirror Motor

    B004R201.WMF 1. Laser unit (! 3.10.2) 2. Laser unit cover [A] ( x4, 2 hooks) 3. Polygon mirror motor [B] ( x4,  x1) 4. After replacing the motor, do the image adjustment. (! 3.21) B079/B082 3-24 CÓPIA NÃO CONTROLADA...

  • Page 133: Laser Synchronization Detector

    NOTE: To avoid damaging the LD board, hold it securely when disconnecting the connectors. Hold the laser unit casing. 3. After replacing the LD board, perform SP 2-109 to adjust the laser beam pitch (described on the next page). 3-25 B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 134: Laser Beam Pitch Adjustment

    600 dpi, using the same procedure as for 400 dpi (use the SP modes for 600 dpi). Laser beam pitch for 600 dpi should be 24~48 more than for 400 dpi. A284R512.BMP A284R513.WMF Adjustment not complete Adjustment complete B079/B082 3-26 CÓPIA NÃO CONTROLADA...

  • Page 135: Photoconductor Unit (Pcu)

    PCU and cover it with paper. Before you re-install the PCU, align the brackets on the PCU with the rails above and make sure they are engaged before you slowly push the PCU into the machine. 3-27 B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 136: Drum

    , then re-attach to • Moving this spring retracts the movable drum cleaning blade so it does not touch the surface of the drum when the drum is re- installed. B079R903.WMF B079/B082 3-28 CÓPIA NÃO CONTROLADA...
  • Page 137 Front Spring 10. Re-attach the rear spring on the left side of the PCU. 11. After replacing the drum, perform the ID sensor initial setting using SP3001 002. 12. Do the process initial setting procedure (SP2805). 3-29 B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 138: Pick-Off Pawls

    • Changing the spur position. • Changing the pick-off pawl assembly position CAUTION: After re-assembly make sure that the front spring of the movable #, $ cleaning blade is re-attached to the position. (! 3.11.2) B079/B082 3-30 CÓPIA NÃO CONTROLADA...

  • Page 139: Charge Roller And Cleaning Roller

    NOTE: If this is not done, the carrier will be attracted to the drum because the charge roller voltage will be too high. CAUTION: After re-assembly make sure that the front spring of the movable #, $ cleaning blade is re-attached to the position. (! 3.11.2) 3-31 B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 140: Drum Cleaning Blade 2

    • When you re-attach the snap-ring, make sure that the head of the snap ring [D] is below the blade. CAUTION: After re-assembly make sure that the front spring of the movable #, $ cleaning blade is re-attached to the position. (! 3.11.2) B079/B082 3-32 CÓPIA NÃO CONTROLADA...

  • Page 141: Drum Cleaning Blade 1

    3. Remove the movable cleaning blade. (! 3.11.5) 4. Remove the stationary drum cleaning blade [A] ( x 2) CAUTION: After re-assembly make sure that the front spring of the movable #, $ cleaning blade is re-attached to the position. (! 3.11.2) 3-33 B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 142: Development

    NOTE: Pull slowly to avoid scratching or nicking the development roller. 6. Set the development unit on the spread paper. 7. If you are temporarily installing a used development unit for test purposes, perform SP2-220 and 2-802-1 after installation (! Chapter 5, “Service Tables) B079/B082 3-34 CÓPIA NÃO CONTROLADA...

  • Page 143: Development Filter

    4. Make sure that the ground plate [C] is positioned correctly. 3.12.3 DEVELOPMENT ROLLER B004R106.WMF 1. Development unit (! 3.12.1) 2. Upper development cover (! 3.12.2) 3. Development roller [A] ( x2) NOTE: Work carefully to avoid scratching or nicking the development roller. 3-35 B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 144: Developer

    5. Pour approximately 1/3 of the developer [C] evenly along the length of the development unit. 6. Rotate the drive gear [D] to work the developer into the unit. Repeat steps 5 and 6 until all of the developer is in the unit and level with the edges. B079/B082 3-36 CÓPIA NÃO CONTROLADA...
  • Page 145 TD sensor initial setting and interfering with the Vref setting (toner density reference voltage). 11. After performing the TD sensor initial setting, remove the piece of paper [A] from the development unit. 3-37 B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 146: Td Sensor

    4. Pour new developer into the development unit and perform the TD sensor initial setting using SP2-801. NOTE: When performing the TD sensor initial setting, cover the toner entrance hole with a piece of paper (! 3.12.4). B079/B082 3-38 CÓPIA NÃO CONTROLADA...

  • Page 147: Transfer Unit

    1. Lower the by-pass tray, open the duplex unit, and open the right cover. 2. Transfer unit [A] (1 hook) 3. Transfer belt [B] (springs x2, 1 hook) NOTE: Avoid touching the transfer belt surface. 3-39 B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 148: Transfer Belt

    3) When reinstalling the transfer belt, make sure that the belt is under the pin [E]. 4) To avoid damaging the transfer belt during installation, manually turn the rollers and make sure that the new transfer belt is not running over the edges of any of the rollers. B079/B082 3-40 CÓPIA NÃO CONTROLADA...

  • Page 149: Transfer Belt Cleaning Blade And Toner Overflow Sensor

    3. Transfer belt cleaning blade [A] ( x3) 4. Turn over the transfer unit and empty the used toner in the transfer unit. 5. Toner overflow sensor [B] ( x1,  x3) NOTE: Re-install the color-coded wires in the correct order. 3-41 B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 150: Paper Feed

    3. Feed roller [B] ( x 1) 4. Separation roller [C] ( x 1) NOTE: Do not touch the roller surface with bare hands. After installing the new rollers, do SP 7-816 for the appropriate paper tray. B079/B082 3-42 CÓPIA NÃO CONTROLADA...

  • Page 151: Lower Right Cover

    4. Lower right cover [A] ( x5) 5. Vertical transport cover [B] NOTE: Push the cover completely to the left and then press in on the right tab to release the peg from the hole. 3-43 B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 152: Relay/Upper Paper Feed And Lower Paper Feed Clutches

    3. Second paper feed clutch bracket [B] ( x2, bushing x1) 4. Drive bracket [C] ( x1, spring x1, bearing x1) 5. Relay clutch [D] ( x1) 6. Upper paper feed clutch [E] ( x1) 7. Lower paper feed clutch [F] ( x1) B079/B082 3-44 CÓPIA NÃO CONTROLADA...

  • Page 153: Upper Paper Feed Unit For Tray 1

    2. Right lower cover. (! 3.14.2) 3. Upper right cover (! 3.5) 4. Upper paper feed clutch [A] (! 3.14.3) 5. 3 relay gears [B] 6. Upper paper feed unit [C] ( x2,  x1) 3-45 B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 154: Lower Paper Feed Unit For Tray 2

    2. Right lower cover (!3.14.2) 3. Remove the lower paper feed clutch [A] (! 3.14.3) 4. Relay gears [B] (x3) 5. Cover [C] ( x2) 6. Gear [D] (x1) 7. Lower paper feed unit [E] ( x2,  x1) B079/B082 3-46 CÓPIA NÃO CONTROLADA...

  • Page 155: Paper End/Paper Height/Relay Sensors

    1. Appropriate paper feed unit (! 3.14.4, 3.14.5) 2. Paper height sensor [A] ( x1) 3. Paper end sensor [B] ( x1). 4. Relay sensor bracket [C] ( x1,  x1) 5. Relay sensor [D] 3-47 B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 156: Registration Sensor

    11. Flywheel [F] ( x3) 12. Right rear cover [G] ( x3) B004R972.WMF 13. Right cover switch bracket [H] ( x1) 14. Rear registration holder [I] ( x1, spring x1) 15. Registration roller bushing [J] ( x1) B004R933.WMF B079/B082 3-48 CÓPIA NÃO CONTROLADA...
  • Page 157 16. Guide plate [A] and registration roller [B] (spring x1,  x 1) 17. Registration guide plate [C] ( x2,  x1) 18. Sensor bracket [D] ( x1) 19. Registration sensor [E] ( x1,  x1) 3-49 B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 158: Tray Lift Motor

    CÓPIA NÃO CONTROLADA PAPER FEED 3.14.8 TRAY LIFT MOTOR B004R964.WMF 1. Rear lower cover (! 3.7.2) 2. Bracket [A] ( x2) 3. Motor control board [B] ( x2,  x13) 4. Tray lift motor [C] ( x2) B079/B082 3-50 CÓPIA NÃO CONTROLADA...

  • Page 159: Feed/Development Motor

    2. Rear upper cover ( x4) (!3.7.1) 3. Tray lift motor (! 3.14.8) 4. Support [A] ( x2, harnesses x2) 5. Timing belt [B] (Raise arm to release tension on belt.) 6. Feed/development motor [C] ( x3,  x2) 3-51 B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 160: Fusing Unit

    4. Slide out the fusing unit [C] NOTE: A larger knob [D] is provided to make turning the hot roller easier to free jams. The drawing of the larger knob was not updated in the remaining illustrations. B079/B082 3-52 CÓPIA NÃO CONTROLADA...

  • Page 161: Fusing Unit Exit Guide

    3.15.3 HOT ROLLER STRIPPERS B004R602.WMF 1. Fusing unit (! 3.15.1) 2. Fusing unit cover [A] ( x4) NOTE: Note the positioning of the step screws x2 and the set screws x2. 3. Hot roller strippers x7, springs x7 3-53 B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 162: Fusing Lamps

    2. Fusing unit cover (!  3 .15.3) 3. Fusing entrance guide [A] ( x2) 4. Lower cover [B] ( x1) Left side 5. Two terminals [C] ( x2) 6. Center fusing lamp lead [D] (3 clamps) 7. Bracket [E] ( x1) B079/B082 3-54 CÓPIA NÃO CONTROLADA...
  • Page 163 The sizes of the holes in the holder match the sizes of the ends of the 650 W lamp (red) and 550 W lamp (brown). 5. Remove both fusing lamps. 3-55 B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 164: Thermistors And Thermostats

    4. End thermistor [B] ( x1,  x1, holder x1) CAUTION: The thermistors are thinly coated and extremely fragile. Handle with care to avoid damaging them. They should be replaced every 150K. 5. Center thermostat [C] ( x2) 6. End thermostat [D] ( x2) B079/B082 3-56 CÓPIA NÃO CONTROLADA...

  • Page 165: Fusing Roller/Pressure Roller

    1. Fusing unit (! 3.15.1) 2. Fusing upper and lower cover. (! 3.15.3, 3.15.4) 3. Fusing lamp. (! 3.15.4) 4. Springs x2 [A] (both sides) 5. Arms x2 [B] (both sides) 6. Pawl bracket [C] ( x4) 3-57 B079/B082 CÓPIA NÃO CONTROLADA...
  • Page 166 5) When reinstalling the hot roller assembly and pressure roller assembly, make sure that the flange position of the bushings is as shown. 6) When reinstalling the C-rings [B] of the hot roller, make sure that the position of the C-rings is as shown. B079/B082 3-58 CÓPIA NÃO CONTROLADA...

  • Page 167: Fusing Unit Side Fan

    FUSING UNIT 3.15.7 FUSING UNIT SIDE FAN B079R909.WMF B079R713.WMF 1. Open the duplex unit and right door. 2. Release the transfer unit [A] and remove it. 3. Remove the shaft cover [B] ( x 3). 3-59 B079/B082 CÓPIA NÃO CONTROLADA...
  • Page 168 NOTE: When re-connecting, be sure the thread the connector correctly between the gaps. 5. Close the right door. 6. Use a short screwdriver to remove the fan plate [B] ( x 2). 7. Pull the fan [C] out of the machine. B079/B082 3-60 CÓPIA NÃO CONTROLADA...

  • Page 169: Fusing Unit Corner Fan

    3. Remove the fusing unit. (! 3.4.1) 4. Remove the magnet lock [A] of the front door ( x 2). 5. Remove the fan bracket [B] ( x 2). 6. Remove the fan [C] from the bracket ( x 2). 3-61 B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 170: Idle Roller Dust Blade

    1. Open the duplex unit and right door. 2. Detach the dust blade [A]. 3. Spread some paper on a flat surface and tap the dust blade gently to remove paper dust collected in its dust box. B079/B082 3-62 CÓPIA NÃO CONTROLADA...

  • Page 171: Cover Replacement

    3.16.2 COVER REPLACEMENT B004R540.WMF 1. Rear cover [A] ( x1) 2. Front cover [B] ( x1) 3. Hinge cover [C] ( x1) 4. Upper cover [D] ( x2) 5. Close duplex unit and pull out upper cover. 3-63 B079/B082 CÓPIA NÃO CONTROLADA...
  • Page 172 2. Lift up paper end feeler [A] to lock feeler in position. NOTE: Before reinstalling the upper cover, return the paper end feeler to its original position. 3. Replace the paper feed roller [B] ( x1) 4. Replace pick-up roller [C]. B079/B082 3-64 CÓPIA NÃO CONTROLADA...

  • Page 173: By-Pass Separation Roller Replacement

    CÓPIA NÃO CONTROLADA 3.16.4 BY-PASS SEPARATION ROLLER REPLACEMENT A689R502.WMF 1. Close by-pass table. 2. Remove separation roller [A] from the bottom ( x1) 3-65 B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 174: Paper End Sensor And Pick-Up Solenoid

    2. Lift paper end feeler [A]. NOTE: Before reinstalling the upper cover, return the paper end feeler to its original position. 3. Replace paper end sensor [B] ( x1). 4. Pick-up solenoid [C] ( x1, ) x1, spring x1). B079/B082 3-66 CÓPIA NÃO CONTROLADA...

  • Page 175: Paper Size Sensor Board Replacement

    3.16.6 PAPER SIZE SENSOR BOARD REPLACEMENT B004R544.WMF 1. Hook [A] 2. Paper tray [B] ( x1). 3. Size sensor board [C]. NOTE: To avoid breaking the hook of the paper size sensor board, handle it carefully during removal. 3-67 B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 176: By-Pass Table Removal

    1. Harness [A] ( x1). 2. Screws [B] ( x2) 3. Retard spring bracket and remove the by-pass table [C]. CAUTION: To relieve pressure on the spring during removal, depress it as shown in the illustration. B079/B082 3-68 CÓPIA NÃO CONTROLADA...

  • Page 177: Paper Feed Clutch Replacement

    3.16.8 PAPER FEED CLUTCH REPLACEMENT A689R506.WMF A689R507.WMF 1. By-pass tray. 2. Paper feed unit [A] ( x2,  x2) 3. Rear bracket [B] ( x4, clip x1, bushing x1) 4. Paper feed clutch [C] ( x1) 3-69 B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 178: Registration Roller Dust Blade

    2. Remove the PCU. (! 3.11.1) 3. Remove the development unit [A]. 4. Press the top of the blade [B] to unlock it and open it to the left. 5. Remove the dust blade [C] from the machine. B079/B082 3-70 CÓPIA NÃO CONTROLADA...

  • Page 179: Duplex Cover Removal

    CÓPIA NÃO CONTROLADA DUPLEX UNIT 3.17 DUPLEX UNIT 3.17.1 DUPLEX COVER REMOVAL B363R101.WMF 1. Duplex unit cover [A] ( x4) 3-71 B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 180: Duplex Entrance Sensor Replacement

    CÓPIA NÃO CONTROLADA DUPLEX UNIT 3.17.2 DUPLEX ENTRANCE SENSOR REPLACEMENT B004R102.WMF 1. Duplex unit cover (! 3.17.1) 2. Sensor holder [A] ( x1) 3. Entrance sensor [B] ( x1) B079/B082 3-72 CÓPIA NÃO CONTROLADA...

  • Page 181: Duplex Exit Sensor Replacement

    CÓPIA NÃO CONTROLADA DUPLEX UNIT 3.17.3 DUPLEX EXIT SENSOR REPLACEMENT B004R103.WMF 1. Duplex unit (!3.4) 2. Sensor bracket [A] ( x1) 3. Exit sensor [B] ( x1) 3-73 B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 182: Drive Area

    They are labeled 1 # 2 # B # C 3. Flywheel [B] ( x3) 4. Registration clutch [C] ( x1,  x1) 5. Transfer belt contact clutch [D] ( x2,  x2) B004R502.WMF B079/B082 3-74 CÓPIA NÃO CONTROLADA...

  • Page 183: Main Motor

    DRIVE AREA 3.18.2 MAIN MOTOR B004R907.WMF 1. Rear upper cover, high voltage power supply, flywheel (! 3.18.1) 2. Timing belt [A] x1 3. Bracket [B] ( x3) 4. Main motor [C] ( x2,  x3) 3-75 B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 184: Toner Supply Motor

    5. Toner bottle holder and bottle [D] 6. Motor harness [E] (clamps x 2) 7. Toner supply motor [F] (hooks x2,  x1) NOTE: Press in on both sides of the motor to release it. B079/B082 3-76 CÓPIA NÃO CONTROLADA...

  • Page 185: Printed Circuit Boards

    CÓPIA NÃO CONTROLADA PRINTED CIRCUIT BOARDS 3.19 PRINTED CIRCUIT BOARDS 3.19.1 HIGH VOLTAGE POWER SUPPLY B004R965.WMF 1. Rear upper cover (! 3.7.1) 2. High voltage power supply [A] ( x3,  x6) 3-77 B079/B082 CÓPIA NÃO CONTROLADA...
  • Page 186 2. Remove the IOB [B] ( All,  x 4, Ribbon cable x 1). 3. The IOB is identical for the B079/B082. However, the DIP switches are set differently for each machine. Check the DIP switches then adjust settings as required.

  • Page 187: Iob Dip Switch Settings (Sw)

    1. The position of SW 1 determines the engine speed. This switch should be UP (ON) for the B079 (35 cpm) or DOWN (OFF) for the B082 (45 cpm) NOTE: Move a switch UP to ON or DOWN to OFF.

  • Page 188: Bicu Board

    CÓPIA NÃO CONTROLADA 3.19.3 BICU BOARD B004R969.WMF 1. I/O Board (! 3.19.2) 2. BICU board [A] ( x5, x all) 3.19.4 PSU B004R970.WMF 1. Left upper cover (! 3.8.1) 2. PSU [A] ( x4,  x all) B079/B082 3-80 CÓPIA NÃO CONTROLADA...

  • Page 189: Hard Disk, Controller Board

    NOTE: The controller boards are machine specific, i.e. the controller board for the B079 (35 cpm) must be installed in the B079 copier, and the controller board for the B082 (45 cpm) must be installed in the B082 copier. These controller boards are not interchangeable.

  • Page 190: Copy Adjustments: Printing/Scanning

    3rd paper feed SP1-002-3 (Optional PFU tray 1) 4th paper feed 2 ± 1.5 mm SP1-002-4 (Optional PTU tray 2) From the duplex tray SP1-002-5 By-pass feed SP1-002-6 A284R506.WMF SP1-002-7 A: Leading Edge Registration B: Side-to-side Registration B079/B082 3-82 CÓPIA NÃO CONTROLADA...

  • Page 191: Blank Margin

    Main Scan Magnification 1. Use SP2-902-3, 5 (Printing Test Pattern, Single-Dot Line) to print a single dot pattern. 2. Check magnification, and then SP2-909-1 (Main Scan Magnification: Copy) to adjust magnification if required. Specification: ±2%. 3-83 B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 192: Parallelogram Image Adjustment

    1) Adjust the laser unit position by turning the adjustment cam. (See illustration above.) 2) Tighten the adjustment bracket. 3) Print the trimming area pattern to check the image. If the results are not satisfactory, repeat steps 1 to 3. B079/B082 3-84 CÓPIA NÃO CONTROLADA...

  • Page 193: Registration: Platen Mode

    1. Place the test chart on the exposure glass and make a copy from one of the feed stations. 2. Check the magnification ratio. Use SP4-008 (Scanner Sub Scan Magnification) to adjust if necessary. Specification: ±0.9%. B004R510.WMF A: Main scan magnification 3-85 B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 194: Adf Image Adjustment

    SP Code What It Does Adjustment Range SP6-006-1 Side-to-Side Registration ±3.0 mm SP6-006-2 Leading Edge Registration (Simplex) ±3.0 mm SP6-006-3 Leading Edge Registration (Duplex: Front) ±4.2 mm SP6-006-4 Leading Edge Registration (Duplex: Back) ±4.2 mm B079/B082 3-86 CÓPIA NÃO CONTROLADA...

  • Page 195: Touch Screen Calibration

    Step 2. 6. When you are finished, press [#] OK on the screen (or press ). 7. Touch [#] Exit on the screen to close the Self-Diagnostic menu and save the calibration settings. 3-87 B079/B082 CÓPIA NÃO CONTROLADA...
  • Page 196 CÓPIA NÃO CONTROLADA CÓPIA NÃO CONTROLADA...

  • Page 197: Troubleshooting

    CÓPIA NÃO CONTROLADA TROUBLESHOOTING CÓPIA NÃO CONTROLADA...
  • Page 198 CÓPIA NÃO CONTROLADA CÓPIA NÃO CONTROLADA...

  • Page 199: Service Call Conditions

    NOTE: 1) If the problem concerns the electrical circuit boards, first disconnect then reconnect the connectors before replacing the PCBs. 2) If the problem concerns a motor lock, first check the mechanical load before replacing motors or sensors. B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 200: Sc Code Descriptions

    A charge roller current leak signal was PCU harness defective or disconnected detected. Charge roller current correction error ID sensor defective The charge roller bias correction is performed twice even if the maximum charge roller bias (-2000V) is applied to the roller. B079/B082 CÓPIA NÃO CONTROLADA...
  • Page 201 The XSCRDY signal is not issued mirror motor driver defective. (LOW: Active) within 25 s after the Polygonal mirror motor drive pulse is polygonal mirror motor switches on. not output incorrectly. GABIC cannot monitor XSCRDY signal. B079/B082 CÓPIA NÃO CONTROLADA...
  • Page 202 Poor ID sensor connector connection detected to be not 2.5V twice I/O board (IOB) defective consecutively during an 800 ms High voltage supply board defective interval. Dirty ID sensor Defect at the ID sensor pattern writing area of the drum B079/B082 CÓPIA NÃO CONTROLADA...
  • Page 203 Transfer belt position sensor error Main motor/drive malfunction Transfer belt contact clutch defective The transfer belt position sensor does Harness disconnected not activate even if the transfer belt contact clutch has been switched on twice and rotated once. B079/B082 CÓPIA NÃO CONTROLADA...
  • Page 204 If it does not deactivate within 5 s four times consecutively, a message will prompt the user to reset Tray 2. After two attempts to re-set the paper tray, if this does not solve the problem then this SC is displayed. B079/B082 CÓPIA NÃO CONTROLADA...
  • Page 205 LCT main motor lock (optional LCT) LCT main motor defective Paper tray unit main motor connection A main motor lock signal is detected for loose more than 50 ms during rotation. Too much load on the drive mechanism B079/B082 CÓPIA NÃO CONTROLADA...
  • Page 206 Thermistor warped or broken the fusing standby temperature of 45 Thermostat has tripped (113 F) within 9 seconds for the B079 BICU defective (35 cpm) 14 seconds for the B082 (45 Power supply board defective cpm) after switching on the main power...
  • Page 207 ARDF main board defective the ARDF main board. BICU board defective Communication command error Abnormal operation performed by between BICU and ARDF software The BICU sends a command to the ARDF main board that it cannot execute. B079/B082 CÓPIA NÃO CONTROLADA...
  • Page 208 BICU control data transfer sumcheck Controller board defective error External noise BICU board defective A sampling of control data sent from the BICU to the controller reveals a sumcheck error. Only the logging count is performed. B079/B082 4-10 CÓPIA NÃO CONTROLADA...
  • Page 209 Finisher staple hammer motor error Staple jam Stapler overload caused by trying to Stapling does not finish within 600 ms staple too many sheets after the staple hammer motor turned Staple hammer motor defective 4-11 B079/B082 CÓPIA NÃO CONTROLADA...
  • Page 210 Refer to page 4-20 Startup without video output end error Control board defective Video transfer to the engine is started, but a video transmission end command was not issued by the engine within the specified time. B079/B082 4-12 CÓPIA NÃO CONTROLADA...
  • Page 211 Self-diagnostic Error: Optional RAM RAM DIMM defective Controller board defective The optional RAM returned an error during the self-diagnostic test. Self-Diagnostic Error: Parallel Interface Loopback connector not detected IEEE1284 connector defective Loopback test error. Controller board defective 4-13 B079/B082 CÓPIA NÃO CONTROLADA...
  • Page 212 Startup without HD connection at main Cable between HDC and HD loose or power on defective HD power connector loose or defective The hard disk connection is not HD defective detected. HDC defective B079/B082 4-14 CÓPIA NÃO CONTROLADA...
  • Page 213 An internal application error was Software defective detected and operation cannot Insufficient memory continue. Network File Error F-gate error at write request Software defective BICU defective After the IPU receives an F-gate signal, it receives another F-gate signal. 4-15 B079/B082 CÓPIA NÃO CONTROLADA...
  • Page 214 Software continuity error Software bug Internal parameter incorrect The software attempted to perform and Insufficient working memory unexpected operation. However, unlike SC990, the object of the error is continuity of the software. B079/B082 4-16 CÓPIA NÃO CONTROLADA...
  • Page 215 SC code. Machine Type Information Error The B079 (35 cpm) and B082 (45 cpm) use the same controller board, but the After the machine is powered on, a DIP SW settings must be set correctly mismatch is detected between the CPM for the machine speed.
  • Page 216 3) The upper exit guide 2 switch does not turn on when the shift tray safety switch is off. - Possible causes - • Guide plate motor defective • Upper exit guide 2 switch defective B079/B082 4-18 CÓPIA NÃO CONTROLADA...
  • Page 217 1) The tray lift motor does not stop within 15s after being turned on. 2) The shift tray HP sensor does not activate within 15s after the tray lift motor turns on. 3) The shift tray upper limit switch turns on while the shift tray is being raised. 4-19 B079/B082 CÓPIA NÃO CONTROLADA...
  • Page 218 Communication error between finisher board and booklet unit board. - Possible causes - • Finisher board defective • Booklet unit board defective • Poor connection of the interface harness SC741: 1,000-sheet finisher error in saddle stitching area - Definition – [D] B079/B082 4-20 CÓPIA NÃO CONTROLADA...
  • Page 219 HP sensor does not deactivate within 0.5s. 2) After the booklet jogger motor turns on to return the booklet jogger plate to its home position, the booklet jogger HP sensor does not activate within 1s. 4-21 B079/B082 CÓPIA NÃO CONTROLADA...
  • Page 220 5) The pulse count from the folder plate motor sensor is lower than the target minimum. - Possible causes - • Folder plate motor defective • Folder plate HP sensor defective • Folder plate return sensor defective • Folder plate motor sensor defective B079/B082 4-22 CÓPIA NÃO CONTROLADA...
  • Page 221 1s after a copy job or warm-up idling begins. - Possible causes - • Booklet entrance guide safety switch defective • Lower door safety switch defective • Booklet exit cover safety switch defective 4-23 B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 222: Electrical Component Defects

    The Paper End indicator lights even if paper is Open placed in the upper paper tray. Upper Paper End 220-8 The Paper End indicator does not light even if (S17) (IOB) there is no paper in the upper paper tray. Shorted B079/B082 4-24 CÓPIA NÃO CONTROLADA...

  • Page 223: Blown Fuse Conditions

    SC302, or SC403, or SC405 displayed 3.15A/125V 3.15A/250V 4A/125V 4A/250V FU101 15A / 125V No response 10A / 125V 5A / 250V No response FU102 FU103 2A / 125V 1A / 250V Normal operation (optional heaters do not work) 4-25 B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 224: Test Points

    NOTE: LED 1 monitors Data Bus Bit 14, LED 2 monitors Data Bus Bit 15. 4.5 TEST POINTS Controller Board Number Monitored Signal DB0 RXD DB0 TXD TP10 TP11 +5VE TP12 TP13 TP14 +5VE TP15 TP16 R_FGATE TP17 W_FGATE B079/B082 4-26 CÓPIA NÃO CONTROLADA...

  • Page 225: Service Tables

    CÓPIA NÃO CONTROLADA SERVICE TABLES CÓPIA NÃO CONTROLADA...
  • Page 226 CÓPIA NÃO CONTROLADA CÓPIA NÃO CONTROLADA...

  • Page 227: Service Program Mode

    To enter the Special service Mode: Hold down  and then press Copy SP.  Copy SP 5. Press Exit twice to return to the copy window. Exit NOTE: Use SP2-902 to perform test pattern printing. (! 5.1.4) B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 228: Sp Mode Button Summary

    Press to scroll to the previous or next display in segments the size of the screen display (page). Press to scroll the display to the previous or next line, line by line. Press to move the highlight on the left to the previous or next selection in the list. B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 229: Selecting The Program Number

    Press Start  twice, and then press SP Mode (highlighted) in the copy window to return to the SP mode display. 7. When you are finished, press Exit twice to return to the copy window. B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 230: Service Table Key

    Program” mode setting that appears only after entering the SP mode by pressing and holding the  on the 10-key pad and then the “Copy SP” on the touch-screen. B079 Denotes the 35 cpm model. B082 Denotes the 45 cpm model.

  • Page 231: Sp1-Xxx: Feed

    Increase the value if the leading edges are jamming. Decrease the value if trailing edges are bending at the entrance. Exit Entrance Junction B079: Solenoid [200 ~ 450 ms / 370 ms / 10 ms] B082: Exit Last Junction Solenoid [200 ~ 450 ms / 300 ms (ent.) 370 ms (exit) /10 ms]...
  • Page 232 Feed temp. = Spec. temp. for thick paper – SP value Re-load Temp. Minus: Feed begins when the hot roller reaches the Roller Ends (Thick Paper) specified temperature. B079: [0 ~ 60 / 0 C/ 5] B082: [0~ 60 / 0 C /1] 1106...
  • Page 233 Adjusts the speeds of the main motor, feed/development motor, and fusing exit motor. Main Motor [-4 ~ +4 / 0 / 0.15%] Each step decreases or increases motor speed in Feed/Development Motor 0.15% increments Fusing/Exit Motor B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 234: Sp2-Xxx: Drum

    [0.0 ~ 9.0 / 0.3 / 0.1 mm step] ± Recommend: 2 1.5 mm Back Side - Left Adjusts the left side erase margin in the reverse side of duplex copies. [0.0 ~ 9.0 / 0.3 / 0.1 mm step] Recommended: 2 +2.5/-1.5 mm B079/B082 CÓPIA NÃO CONTROLADA...
  • Page 235 Current LD Unit Position Displays the current LD unit position (number of pulses from home position). If this is different from the value of 2-109-1 or 2-109-2, LD unit positioning has failed. B079/B082 CÓPIA NÃO CONTROLADA...
  • Page 236 Increasing this value reduces the toner supply clutch on time. Use a lower value if the user tends to make lots of copies that have a high proportion of black. [10 ~ 800 mg/s / 60 mg/s / 5 mg/s step] B079/B082 5-10 CÓPIA NÃO CONTROLADA...
  • Page 237 Rate of Change Displays the rate of change in the TD sensor output. GAIN Displays the GAIN value used to calculate the on time for the toner supply motor. Image Pixel Count Displays the image pixel count. 5-11 B079/B082 CÓPIA NÃO CONTROLADA...
  • Page 238 If the user uses thicker paper, the current may have to be increased to ensure sufficient transfer of toner. B079: [20 ~ 100µA / 35 / 1µA step] B082: [20 ~ 100µA / 45] / 1µA step] 2* 2nd Side of Paper Printing the second side of the paper (image area).
  • Page 239 [0 ~ 38 / 0 / 1 step] This SP mode is useful for finding whether the LDDR or the BICU is defective. If the printout is not satisfactory, the LDDR is defective. [0 ~ 38 / 0 ] (! 5.1.4) 5-13 B079/B082 CÓPIA NÃO CONTROLADA...
  • Page 240 SP2-309-1. Use this SP when an image problem (see 2-914-1) occurs when paper with a small width is fed from the by-pass feed tray. [0 ~ 300 / 200 / 10V step] B079/B082 5-14 CÓPIA NÃO CONTROLADA...
  • Page 241 [0 ~ 100 / 60 / 1 step] Lower Limit Defines the lower limit for grayscale. A smaller value allows a wider range of halftones at the dark end of the scale. [0 ~ 100 / 40 / 1 step] 5-15 B079/B082 CÓPIA NÃO CONTROLADA...
  • Page 242 Switches the number revolutions per minute of the Switching polygon mirror motor. DFU [0 ~ 2 / 0 / 1] 0: Rpm determined by engine 1: Rpm for B079 (35 cpm) 2: Rpm for B082 (45 cpm) B079/B082 5-16 CÓPIA NÃO CONTROLADA...

  • Page 243: Sp3-Xxx: Process

    [0 ~ 1000 / 0 / 1] Normally the motor is jogged once (switched off and on rapidly) after every print job that exceeds 15 pages. 5-17 B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 244: Sp4-Xxx: Scanner

    Displays the time required to detect the size of the paper on the scanner exposure glass. Asterisks (*) are displayed if the size cannot be detected. Dimensions are displayed in inches for North America and in mm for other areas. B079/B082 5-18 CÓPIA NÃO CONTROLADA...
  • Page 245 EO Adjustment Range Adjustment Gain Adjustment – Ech Gain Adjustment – Och Apli. Dummy Range Adjustment Apli. Range Adjustment Apli. Gain Adjustment – Ech Apli. Gain Adjustment – Dummy Gain Adjustment – Dummy Gain Adjustment – 5-19 B079/B082 CÓPIA NÃO CONTROLADA...
  • Page 246 (! Chap.6, “Image Processing”. [0~9 / 0 / 1 step] Increasing this value strengthens smoothing but can also increase the occurrence of moiré and reduce sharpness. B079/B082 5-20 CÓPIA NÃO CONTROLADA...
  • Page 247 [0~7 / 2 / 1 step] 6.2 Image Processing) Main Filter Level: Text Selects the MTF filter coefficient for the main 155%-256% scan direction in the text mode. [0~15 / 14 / 1 step] 6.2 Image Processing) 5-21 B079/B082 CÓPIA NÃO CONTROLADA...
  • Page 248 Smoothing Filter in Photo Selects the filter coefficient for smoothing in the Mode photo mode. The higher the number you select, the greater the applied smoothing effect. [0~7 / 2 / 1] 6.2 Image Processing) B079/B082 5-22 CÓPIA NÃO CONTROLADA...
  • Page 249 Select a higher number to improve the clarity of text and lines. However, greatly increasing the value could increase the incidence of moiré. [0~7 / 1 / 1 step] 0: Off 1: Softest 7: Sharpest 6.2 Image Processing) 5-23 B079/B082 CÓPIA NÃO CONTROLADA...
  • Page 250 (newspapers, magazines, etc.) [0~7 / 1 / 1 step] 0: Off 1: Softest 7: Sharpest 6.2 Image Processing) B079/B082 5-24 CÓPIA NÃO CONTROLADA...
  • Page 251 Generation Copy mode. While selecting a higher number strengthens the effect of the filter to improve contrast, a very high setting can increase the incidence of moiré. [0~6 / 3 /1 step] 6.2 Image Processing) 5-25 B079/B082 CÓPIA NÃO CONTROLADA...
  • Page 252 [0~15 / 8 / 1 step] 0: Off 1: Weakest (fewest dots erased) 15: Strongest (most dots erased) B079/B082 5-26 CÓPIA NÃO CONTROLADA...
  • Page 253 Selects the threshold for line width detection in Scan): Generation Mode the main scan direction in originals copied in the Generation Copy mode. [0~5 / 1 / 1 step] Low: More difficult to thicken thin lines. High: Easier to thicken thin lines. 5-27 B079/B082 CÓPIA NÃO CONTROLADA...
  • Page 254 6.2 Image Processing) [0~15 / 3 / 1] 0: Most edges detected. Settings near zero increase the range of the SP4903 039 setting. 15:Fewest edges detected. Settings near 15 decrease the range of the SP3903 039 setting. B079/B082 5-28 CÓPIA NÃO CONTROLADA...
  • Page 255 [0~15 / 3 / 1] 0: Most edges detected. Settings near zero increase the range of the SP4903 043 setting. 15: Fewest edges detected. Settings near 15 decrease the range of the SP3903 043 setting. (!6.2 Image Processing) 5-29 B079/B082 CÓPIA NÃO CONTROLADA...
  • Page 256 [0~15 / 3 / 1] 0: Fewest edges detected. Settings near zero increase the range of the SP4903 047 setting. 15: Most edges detected. Settings near 15 decrease the range of the SP3903 047 setting. 6.2 Image Processing) B079/B082 5-30 CÓPIA NÃO CONTROLADA...
  • Page 257 [0~15 / 3 / 1] 0: Fewest edges detected. Settings near zero increase the range of the SP4903 039 setting. 15: Most edges detected. Settings near 15 decrease the range of the SP3903 039 setting. 6.2 Image Processing) 5-31 B079/B082 CÓPIA NÃO CONTROLADA...
  • Page 258 [0~15 / 0 / 1] 0: Fewest edges detected. Settings near zero increase the range of the SP4903 036 setting. 15: Most edges detected. Settings near 15 decrease the range of the SP3903 036 setting. 6.2 Image Processing) B079/B082 5-32 CÓPIA NÃO CONTROLADA...
  • Page 259 Density Setting for Copied Setting same as above. Original Mode [0~1 / 0 /1 step] 5-33 B079/B082 CÓPIA NÃO CONTROLADA...
  • Page 260 15: Increasing the setting (approaching “15”) sharpens text and thin lines, but can also cause grayscale areas to degrade. (!6.2 Image Processing) B079/B082 5-34 CÓPIA NÃO CONTROLADA...
  • Page 261 15: Increasing the setting (approaching “15”) sharpens text and thin lines, but can also cause grayscale areas to degrade. (!6.2 Image Processing) 5-35 B079/B082 CÓPIA NÃO CONTROLADA...
  • Page 262 [0~13 / 0 / 1] 0: Off 1: Pictures highest priority 13: Text/thin lines highest priority (!6.2 Image Processing) B079/B082 5-36 CÓPIA NÃO CONTROLADA...
  • Page 263 [0~10 / 0 / 1] 0: Off 1: Pictures highest priority 10: Text highest priority 6.2 Image Processing) 5-37 B079/B082 CÓPIA NÃO CONTROLADA...
  • Page 264 [0~10 / 0 / 1] 0: Off 1: Pictures highest priority 10: Text highest priority 6.2 Image Processing) B079/B082 5-38 CÓPIA NÃO CONTROLADA...
  • Page 265 Allows switching between filter and magnification processing of the image for testing. DFU [0~3 / 0 / 1] 0: Uses settings of each application and mode 1: Through filter 2: Through magnification 3: Through filter, magnification 5-39 B079/B082 CÓPIA NÃO CONTROLADA...
  • Page 266 (4 pixles/8 bits) 3: Sets output from the Ri10 to the CDICA for grayscale output (1 pixel/8 bits), also sets output from the Ri10 to the write unit for grayscale output (4 pixels/8 bit) B079/B082 5-40 CÓPIA NÃO CONTROLADA...

  • Page 267: Sp5-Xxx: Mode

    2: Not normal reset. 5121* Counter Up Timing Determines whether the optional key counter counts up at paper feed or at paper exit. 0: Feed, 1: Exit The total counter is not affected by this SP mode. 5-41 B079/B082 CÓPIA NÃO CONTROLADA...
  • Page 268 60 min.) 5404 User Code Count Clear Execute 5501* PM Alarm Interval Sets the PM alarm interval. [0~9999 / 0 / 1 step] 0: Alarm off 1~9999: Alarm goes off when ≥ Value (1~9999) PM counter B079/B082 5-42 CÓPIA NÃO CONTROLADA...
  • Page 269 133* [00250 ~ 10000 / 1000 / 1 Step] 134* 141* 142* 160* 164* 166* 172* 5508 CC Call Jam Remains Enables/disables initiating a call for an unattended paper jam. [0~1/1/1] 0: Disable 1: Enable 5-43 B079/B082 CÓPIA NÃO CONTROLADA...
  • Page 270 [0~1 / 1 / 1] 0: OFF 1: ON. Displays a warning. Pressing the call button will contact the service center. This setting is available for setting only if SP5508 004 is set for 1. B079/B082 5-44 CÓPIA NÃO CONTROLADA...
  • Page 271 Enter the number and press #. This number is printed on the Counter Report (UP: System No. 19)  Press the key to input a pause. Press the “Clear modes” key to delete the telephone number. 5-45 B079/B082 CÓPIA NÃO CONTROLADA...
  • Page 272 Protocols are enabled/disabled with bit switch settings (0 = Off, 0 = On). Bit0: Bit1: Bit2: Bit3: Bit4~Bit7: Reserved Delete Password Execute to delete network password. Print Settings List Prints a list of all network related parameters. B079/B082 5-46 CÓPIA NÃO CONTROLADA...
  • Page 273 [0~1/0/1] 0: Disable 1: Enable Panel Setting Determines whether each capture related setting can be selected or updated from the initial system screen. [0~1/0/1] 0: Disable 1: Enable The setting for SP5836 001 has priority. 5-47 B079/B082 CÓPIA NÃO CONTROLADA...
  • Page 274 B&W black and white documents sent to the document management server via the MLB. [0~2 / 0 / 1] 0: 1-to-1 1: 1/2 2: 1/4 Enabled only when optional MLB (Media Link Board) is installed. B079/B082 5-48 CÓPIA NÃO CONTROLADA...
  • Page 275 Sets the default format for stored printer color documents sent to the document management server via the MLB. [0~3 / 0 / 1] 0: JFIF/JPEG 1: TIFF/MMR 2: TIFF/MH 3: TIFF/MR Enabled only when optional MLB (Media Link Board) is installed 5-49 B079/B082 CÓPIA NÃO CONTROLADA...
  • Page 276 Conducts a 1394a check of IRM when the independent node is in any mode other than IRM. [0~1/1/1] 0: Checks whether IRM conforms to 1394a 1: After IRM is checked, if IRM does not conform then independent node switches to IRM. B079/B082 5-50 CÓPIA NÃO CONTROLADA...
  • Page 277 4 bits to set the maximum number of channels. [1~14/ 14 / 1] [1~14 / 14 / 1 [1~13 / 13 / 1] China, Taiwan (Same as NA) Displayed only when the option 802.11b for wireless LAN is installed. 5-51 B079/B082 CÓPIA NÃO CONTROLADA...
  • Page 278 PC and the DeskTopBinder software 5844 Transfer Rate Sets the speed for USB data transmission. [0x01~0x04 / 0x04 / 0] 0x01: Full Speed (12 Mbps fixed) 0x04: High Speed/Full Speed (480 Mbps/12 Mbps auto adjust) B079/B082 5-52 CÓPIA NÃO CONTROLADA...
  • Page 279 SERVICE PROGRAM MODE TABLES Mode Number Function and [Setting] 5844 Vendor ID Sets the vendor ID: Initial Setting: 0x05A Ricoh Company. DFU [0x0000~0xFFFF/ 0x05CA /1] Product ID Sets the product ID. DFU [0x0000~0xFFFF/0x0403/1] Device Release Number Sets the device release number of the BCD (binary coded decimal) display.
  • Page 280 Changes the default settings of image data transferred externally by the Net File page reference function. Copy: Color [0~2 / 2 / 1] Copy : B&W Text [0~2 / 0 / 1] Copy: Other Than B&W [0~2 / 0 / 1] B079/B082 5-54 CÓPIA NÃO CONTROLADA...
  • Page 281 HDD. This SP can be executed as many times as required. This SP must be executed after replacing or formatting the hard disks. This SP can be executed only with the hard disks installed. 5856 Remote ROM Update Initial: 0 5-55 B079/B082 CÓPIA NÃO CONTROLADA...
  • Page 282 These SPs allow you to set up to 10 keys for log files for functions that use common memory on the Key 2 controller board. (!5.3.1) Key 3 [-9999999~9999999 / 0 / 1] Key 4 Key 5 Key 6 Key 7 Key 8 B079/B082 5-56 CÓPIA NÃO CONTROLADA...
  • Page 283 DFU 1st, 2nd Feed Clutches [35 ~ 57.5 / 42.5 / 2.5mm] 3rd, 4th, LCT Feed Clutches Leading Edge Jam [19~34 / 26.5 /2.5 mm] Detection Start Timing 5-57 B079/B082 CÓPIA NÃO CONTROLADA...
  • Page 284 (! 5.1.6) Input the number for the item All (Data List) that you want to print, and then press : SP (Mode Data List) “Execute” on the touch panel. User Program Logging Data Diagnostic Report B079/B082 5-58 CÓPIA NÃO CONTROLADA...

  • Page 285: Sp6-Xxx: Peripherals

    SP5131. [0~1 / 0 / 1] Japan DLT SEF 11”x15” North America DLT SEF 11” x 15” LT LEF US Exec LEF LT SEF 8”x10” SEF LG SEF F4 SEF 5-59 B079/B082 CÓPIA NÃO CONTROLADA...
  • Page 286 Allows fine adjustment of the fold position on paper when the Booklet Finisher is connected and used. A3/DLT [-30~+30 / 0 / 0.5 mm] [-20~+20 / 0 / 0.5 mm] A4/LT [-15~+15 / 0 / 0.5 mm] B079/B082 5-60 CÓPIA NÃO CONTROLADA...

  • Page 287: Sp7-Xxx: Data Log

    A5 LEF B5 LEF LT LEF HLT LEF 132* A3 SEF 133* A4 SEF 134* A5 SEF 141* B4 SEF 142* B5 SEF 160* DLT SEF 164* LG SEF 166* LT SEF 172* HLT SEF 5-61 B079/B082 CÓPIA NÃO CONTROLADA...
  • Page 288 (inch) Auto Reduce/Enlarge 7304* Copy Counter: Copy Mode Displays the total number of prints by copy operation mode. Original Mode: Text Original Mode: Text/Photo Original Mode: Photo Original Mode: Generation Original Mode: Pale Punch Repeat B079/B082 5-62 CÓPIA NÃO CONTROLADA...
  • Page 289 Document Server: Scan Storage Displays the original count stored on the document server. Scanning Count 7321* Document Server: Each Size of Displays the number of originals by paper size Originals scanned at the copy server. 5-63 B079/B082 CÓPIA NÃO CONTROLADA...
  • Page 290 Document Server: Job Counter – Displays the number of print jobs classed by the Set Number set sizes. 1 to 1 1 to 2~5 1 to 6~10 1 to 11~20 1 to 21~50 1 to 51~100 B079/B082 5-64 CÓPIA NÃO CONTROLADA...
  • Page 291 Paper Late Paper Lag Error Error Location Error No. At Power On Tray 1: On Tray 2: On Tray 3/LCT: On Tray 4: On External Tray: On Registration: On External Tray: On Internal Tray: On 5-65 B079/B082 CÓPIA NÃO CONTROLADA...
  • Page 292 “Paper Linger” paper jam occurs when the paper remains at the sensor for longer than the prescribed time. At Power On Paper Late Paper Lag Error Location Error No. Error No. Registration Sensor Check In Failure Nip-In Sensor Check In Failure B079/B082 5-66 CÓPIA NÃO CONTROLADA...
  • Page 293 DATE is the date the previous jamLEF occurred. Paper Size Code (hex) A4 LEF A5 LEF B5 LEF LT LEF HLT LEF A3 SEF A4 SEF A5 SEF B4 SEF B5 SEF DLT SEF LG SEF LT SEF HLT SEF Others 5-67 B079/B082 CÓPIA NÃO CONTROLADA...
  • Page 294 Execute to open the “Self-Diagnose Result Display” to view details about errors. Use the keys on in the display on the touch-panel to scroll through all the information. If no errors have occurred, you will see the “No Error” notation. B079/B082 5-68 CÓPIA NÃO CONTROLADA...
  • Page 295 Copy Counter/Doc. Svr Clear Press Execute to clear the following SP codes: SP7301, SP7304, SP7305, SP7306, SP7320, SP7321, SP7323, SP7324, SP7325, SP7326, SP7327, SP7328. 7901 Assert Info. Used for debugging. DFU File Name # oF Lines Location 5-69 B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 296: Test Pattern Printing: Sp

    Grayscale (Vertical) (8) Horizontal Line (1-dot) Cross Pattern (8) Vertical Line (2-dot) Cross Shape Horizontal Line (2-dot) Argyle Pattern Alternate Dot Pattern Cross Pattern (256) Grid Pattern (1-dot) Cross Pattern (64) Vertical Stripes Not used B079/B082 5-70 CÓPIA NÃO CONTROLADA...

  • Page 297: Test Pattern Table: Sp2-902-3 Printing Test Patterns

    Argyle Pattern (2-dot_) Grayscale (Horizontal Extension Margin) Hound’s Tooth Check (2-dot Grayscale (Vertical Extension Margin) Horizontal) Checker Flag Pattern White Pattern Point Black Pattern Grid (1-dot pair) (OR Outside Data 1) Black Band (Vertical) Independent Pattern (4-dot) 5-71 B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 298: Input Check

    Not locked Locked 3: Registration and Others Main Motor Lock Signal Not locked Locked Toner Overflow Sensor Tank not full Tank full Cover Open Cover closed Cover opened Registration Sensor Paper detected Paper not detected B079/B082 5-72 CÓPIA NÃO CONTROLADA...
  • Page 299 Lower Relay Sensor Paper detected Paper not detected Upper Relay Sensor Paper detected Paper not detected Lower Paper End Sensor Paper not detected Paper detected Upper Paper End Sensor Paper not detected Paper detected 5-73 B079/B082 CÓPIA NÃO CONTROLADA...
  • Page 300 Remainder of Not Used Bit 2 Bit 1 Bit 0 Capacity Feed Tray 2 LCT: Bit 2 Full LCT: Bit 1 80% or more LCT: Bit 0 50% or more 30% or more 10% or more B079/B082 5-74 CÓPIA NÃO CONTROLADA...
  • Page 301 Bit 4 Bit 3 Bit 2 Bit 1 Paper Width 4: By-pass Post Card B6 SEF B5 SEF A5 SEF / 5.5" B4 SEF A4 SEF / 8.5" / 8" A3 SEF 11" x 17" 5-75 B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 302: Ardf Input Check: Sp

    Pick-up roller up Pick-up roller down Inverter sensor Paper not detected Paper detected Exit sensor Paper not detected Paper detected Registration sensor Paper not detected Paper detected Interval Sensor Paper not detected Paper detected Original A4 sensor B079/B082 5-76 CÓPIA NÃO CONTROLADA...

  • Page 303: Output Check

    3. Press On then press Off to test the selected item. B079S902.WMF NOTE: You cannot exit and close this display until you press off to switch off the output check currently executing. Do not keep an electrical component switched on for a long time. 5-77 B079/B082 CÓPIA NÃO CONTROLADA...
  • Page 304 Registration Clutch Jogger Motor (Finisher) Development Clutch Stapler Unit Motor (Finisher) Exit Junction Gate Solenoid Stack Feed Out Motor (Finisher) (Upper Unit) Duplex Junction Gate Solenoid Shift Motor (Finisher) (Lower Unit) Stapler Rotation Motor (Two-Tray Finisher) B079/B082 5-78 CÓPIA NÃO CONTROLADA...

  • Page 305: Ardf Output Check: Sp

    3. Select “Single Face” or “Both Face”. 4. After printing the list, press “Close” to return to the SP mode display. 5. Press Exit twice to close the SP Mode screen and return to copy mode. 5-79 B079/B082 CÓPIA NÃO CONTROLADA...
  • Page 306 SC10n, SC12n occurences counted. No Counts Other IPU SCs Count Timing SC19n occurences counted. No Counts Other Printer SCs Count Timing SC30n, SC32n, SC35, SC39n, SC40n, SC42n, SC44n, SC49n, SC52n, SC54n, SC72n occurences counted. No Counts Other B079/B082 5-80 CÓPIA NÃO CONTROLADA...
  • Page 307 Also counts white sheets according to the mode. Copies by Quality Mode Text/Photo Mode Photo Mode Photo Original Mode Pencil Original Mode Count Timing Feed-in starts for each category. Counts according to the selection information of the basic screen. 5-81 B079/B082 CÓPIA NÃO CONTROLADA...
  • Page 308 White sheets (blank) for the selected mode. Auto Start Count Timing Copy feed-ins for Auto Start mode. Other White sheets (blank) for the high speed mode are also counted.. Electronic Collate Count Timing Feed-ins with the collate function selected. B079/B082 5-82 CÓPIA NÃO CONTROLADA...

  • Page 309: Nip Band Width Adjustment: Sp

    NOTE: Check the nip bandwidth around the center of the OHP. Pressure spring position Nip width Upper (default position) 6.0 ± 0.5 mm Lower 6.5 ± 0.6 mm If the width is out of the above specification, the pressure spring should be replaced. 5-83 B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 310: Memory Clear: Sp

    Initializes the Job login ID, SmartNetMonitor for Admin, Job History, and local storage file numbers. Initialization Initialization : Resetting 1~3 resets the operation panel screen coordinates, so after executing 1, 2, or 3, you must re-calibrate the screen. B079/B082 5-84 CÓPIA NÃO CONTROLADA...

  • Page 311: Software Reset

    Press and hold down   together for over 10 seconds. When the machine beeps once release both buttons. After “Now loading. Please wait” is displayed for a few seconds the copy window will open. The machine is ready for normal operation. 5-85 B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 312: System Settings And Copy Setting Reset

    NOTE: You must press  first. B004S503.WMF 3. When the message prompts you to confirm that you want to reset the system settings, press Yes. 4. When the message tells you that the settings have been reset, press Exit. B079/B082 5-86 CÓPIA NÃO CONTROLADA...
  • Page 313 B004S504.WMF 3. When the message prompts you to confirm that you want to reset the Copier Document Server settings, press Yes. 4. When the message tells you that the settings have been reset, press Exit. 5-87 B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 314: Software Download

    IC card. 8. If more software needs to be downloaded, repeat steps 1 to 7. 9. Turn the main power on and confirm that the new software loads and that the machine starts normally. B079/B082 5-88 CÓPIA NÃO CONTROLADA...

  • Page 315: Uploading/Downloading Nvram Data

    2. Remove the IC card cover [A]. 3. Plug the flash memory card [B] into the card slot. 4. Turn on the main switch. 5. Execute SP5-824. 6. Press  to start uploading the NVRAM data. B004I015.WMF 5-89 B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 316: Downloading Nvram Data (Sp)

    • If the correct card for the NVRAM data is not inserted in the card slot, after you press  a message will tell you that downloading cannot proceed because the card is abnormal and the execution will halt. B079/B082 5-90 CÓPIA NÃO CONTROLADA...
  • Page 317 Memory Check RTC Check IC Card Program ROM, DIMM CRC Check I/FCheck SSCG Check Network Check OPC Check Engine I/F Check Illegal Interrupt NVRAM Check Check System OS, HDD Check Application Check IEEE1284 I/F Check B004S516.WMF 5-91 B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 318: Detailed Self-Diagnostic Mode

    2. Hold down , press and hold down , and then while pressing both keys at the same time, switch on the machine. You will see “Now Loading” on the touch-panel, and then you will see the results of the test. B079/B082 5-92 CÓPIA NÃO CONTROLADA...
  • Page 319 BANK : A6825150 [Error List @@@] SCCODE (ERROR CODE ) SC CODE (ERROR CODE) SC CODE (ERROR CODE) SC CODE (ERROR CODE) SC835 (110C) SC820 (0001) SC820 (0002) SC820 (0003) SC820 (0004) SC820 (0005) B004S515.WMF 5-93 B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 320: User Program Mode

    Click a tab to display the settings. If the Next button is lit in the lower right corner, press to display more options. Perform the settings, press Exit to return to the User Tools/Counter display, and then press exit to return to the copy window. B004S506.WMFF B079/B082 5-94 CÓPIA NÃO CONTROLADA...

  • Page 321: Copier/Document Server Features

    In the User/Tools Counter display, press Printer Settings, Facsimile, or Scanner Settings to open the appropriate screen and then click the tab to display more settings. The screen below shows the Printer Features screen. B004S509.WMF 5-95 B079/B082 CÓPIA NÃO CONTROLADA...
  • Page 322 USER PROGRAM MODE Counter In the User/Tools Counter display, press Counter. B003SL07.WMF View the settings, press Print Counter Exit to return to the User Tools/Counter display, and then press Exit to return to the copy window. B079/B082 5-96 CÓPIA NÃO CONTROLADA...

  • Page 323: Dip Switches

    Print Output for OFF (Do not change) Debugging Factory Duplex OFF (Do not change) Function Check China Taiwan Asia Korea Destination NOTE: Disabling jam detection is effective only for the main machine (not for the options). 5-97 B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 324: Using The Debug Log

    • Press and hold down  for more than 3 seconds. • Enter  then press . 2. Under “5857 Save Debug Log”, press . COPY : SP-5-857-001 Save Debug Log On/Off (1:ON 0:OFF) Initial 0 3. Press  then press . B079/B082 5-98 CÓPIA NÃO CONTROLADA...

  • Page 325: Setting The Timing For Debug Log Acquisition

    2. To save data for items 1, 2, or 4, press the appropriate key. The example below shows the “Engine SC Error” selected after pressing . COPY : SP-5-858-001 Debug Save When Engine SC Error Press “ON” then press . 5-99 B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 326: Selecting A Module For Retrieval

    “1” is pressed to define “Key 1”. COPY : SP-5-859-001 Debug Save Key No. Key 1 3. Enter a number for the key. COPY : SP-5-859-001 Debug Save Key No. Key 1 2222 4. Press  to save the key definition. B079/B082 5-100 CÓPIA NÃO CONTROLADA...
  • Page 327 PRINTER debug log you must select all 9 available selections (001~009 in the PRINTER column of the Table above), and for a FAX debug log you must select all 10 selections (001~010 in the FAX column of the Table above.) 5-101 B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 328: Retrieving The Debug Log

    3. Select Image> Read then click OK to start reading the data. 4. After confirming that the data has been read, select File> Save, then enter an appropriate file name and save the file. This completes converting the debugging log to binary data. B079/B082 5-102 CÓPIA NÃO CONTROLADA...
  • Page 329 2) The target file name for the text file is generated automatically. 3) If the debug log was copied to an IC card of the wrong format, then an error is issued and the program halts. 5-103 B079/B082 CÓPIA NÃO CONTROLADA...
  • Page 330 CÓPIA NÃO CONTROLADA CÓPIA NÃO CONTROLADA...

  • Page 331: Detailed Section Descriptions

    CÓPIA NÃO CONTROLADA DETAILED SECTION DESCRIPTIONS CÓPIA NÃO CONTROLADA...
  • Page 332 CÓPIA NÃO CONTROLADA CÓPIA NÃO CONTROLADA...
  • Page 333 CÓPIA NÃO CONTROLADA OVERVIEW 6. DETAILED SECTION DESCRIPTIONS 6.1 OVERVIEW 6.1.1 COMPONENT LAYOUT B004V500.WMF B079/B082 CÓPIA NÃO CONTROLADA...
  • Page 334 17 Transfer Belt 39 Exit Junction Gate 18 OPC Drum 40 Exit Roller 19 Registration Roller 41 Paper Exit Sensor 20 Lower Transport Roller 42 3rd Mirror 21 Exit Sensor 43 Scanner HP Sensor 22 By-pass Tray B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 335: Paper Path

    CÓPIA NÃO CONTROLADA OVERVIEW 6.1.2 PAPER PATH B004V903.WMF 1 ARDF 2 Interchange unit 3 Duplex unit 4 By-pass tray 5 Large Capacity Tray (LCT) 6 Paper tray unit 7 Two-Tray Finisher 8 Bridge unit 9 1-Bin Tray B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 336: Drive Layout

    2 Registration Clutch 6 Main Motor 3 Upper Paper Feed Clutch 7 Paper Feed/Development Motor 4 Lower Paper Feed Clutch In this machine, the development unit is provided with its own motor, separate from the main motor. B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 337: Board Structure

    Takes charge of controlling memory and all peripheral devices. BICU (Base Engine and Image Control Unit) This is the engine control board. It controls the following functions. • Engine sequence • Timing control for peripherals • Image processing, video control B079/B082 CÓPIA NÃO CONTROLADA...
  • Page 338 Board). The functions of the PFB (paper feed control) have been taken over by the IOB. The same IOB is used for both the B079 and B082 but the DIP switches must be set correctly for each. See Section “3 Replacement and Adjustment”...
  • Page 339 IEEE 1394 USB 2.0 (Option) IEEE 802.11b Bluetooth (Only One) Resident DC Conv. IC CARD (3V→5V) Flash ROM (12MB) (System/NIB Firmware) NVRAM + RTC 32kB ROM_DIMM (Option) (Printer + Scanner) NVRAM 32kB (Option) ROM_DIMM (PS3) (Option) B079D901.WMF B079/B082 CÓPIA NÃO CONTROLADA...
  • Page 340 NCU installation. NOTE: The controller boards are machine specific and are not interchangeable. The controller board for the B079 (35 cpm) must be installed in the B079 and controller board for the B082 (45 cpm) must be installed in the B082.
  • Page 341 Image TMP area. These areas are used for applications to store copy, print, fax, and scanned pages. The actual number of pages that can be stored differs depending on the content of the document and the scanning resolution. B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 342: Copy Process Overview

    The magnetic developer brush on the development roller [D] contacts the latent image on the drum. Toner particles are electrostatically attracted to the areas of the drum surface where the laser reduced the negative charge on the drum. B079/B082 6-10 CÓPIA NÃO CONTROLADA...

  • Page 343: Image Transfer

    The drum cleaning blades [H] and [J] removes any toner remaining on the drum surface after the image is transferred to the paper. Quenching Finally, the light from the quenching lamp [I] electrically neutralizes the charge on the drum surface. 6-11 B079/B082 CÓPIA NÃO CONTROLADA...
  • Page 344 The light reflected by the reflector is of almost equal intensity in all directions, to reduce shadows on pasted originals. The optional optics anti-condensation heater is installed on the left side of the scanner. It turns on whenever the power cord is plugged in. B079/B082 6-12 CÓPIA NÃO CONTROLADA...

  • Page 345: Scanner Drive

    BICU board, like for book mode. NOTE: Magnification in the sub-scan direction can be adjusted by changing the ADF motor speed using SP6-017. In the main scan direction, it can be adjusted with SP2-909, like for book mode. 6-13 B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 346: Original Size Detection In Platen Mode

    The main CPU detects the original size by the on/off signals received from the APS sensors. NOTE: If the copy is made with the platen fully open, the main CPU determines the original size from the sensor outputs after the Start  key is pressed. B079/B082 6-14 CÓPIA NÃO CONTROLADA...
  • Page 347 (L). For example, if A4 sideways paper is placed on the by- pass tray, the machine assumes it is A3 paper and scans a full A3 area, disregarding the original size sensors. 6-15 B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 348: Image Processing

    γ correction, and gradation. The memory controller performs image compression, decompression, and memory address control (for binary picture processing mode only) LD Unit: Performs dual channel multi-beam exposure, multiple exposure, and synchronous detection. Controller: Controls image archiving, controls printing, and secondary image compression/decompression. B079/B082 6-16 CÓPIA NÃO CONTROLADA...

  • Page 349: Sbu (Sensor Board Unit)

    After the above processing, the analog signals are converted to 8-bit signals by the A/D converter. This gives a value for each pixel on a scale of 256 shades of gray. Then, this data goes to the BICU via the SIB. 6-17 B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 350: Auto Image Density (Ads)

    As with previous digital copiers, the user can select manual image density when selecting auto image density mode and the machine will use both settings when processing the original. B079/B082 6-18 CÓPIA NÃO CONTROLADA...

  • Page 351: Ipu (Image Processing Unit)

    2. Filtering (MTF and smoothing) 3. Magnification 4. γ correction 5. Grayscale processing 6. Binary picture processing 7. Error diffusion 8. Dithering 9. Video path control 10. Test pattern generation The image data then goes to the HDD. 6-19 B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 352: Image Processing Modes

    Reproduction similar to Text mode, but of lower contrast. Ideal for Pale copying thin originals. (! pg.6-26) Attempts to achieve the best reproduction of copied originals, which Generation Copy have faded due to making copies of copies. (! pg.6-27) B079/B082 6-20 CÓPIA NÃO CONTROLADA...
  • Page 353 Pre-Filter Smoothing Main Scan Magnification (Text/Photo, Photo) Primary Compression, Controller Decompression Independent Dot Erase Filtering Secondary Compression, (Text, Pale, Generation) Decompression γ Coefficient Sent to HDD Video Control Scanner/Printer Application Grayscale Processing FAX Application LD Unit 6-21 B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 354: Summary Of Image Processing Functions

    The best γ coefficient suited for the selected mode can be stored and adjusted as needed. Grayscale processing: Performs reproduction of grayscales, using mainly error diffusion. (In the Photo mode, conducts processing with dithering.) B079/B082 6-22 CÓPIA NÃO CONTROLADA...

  • Page 355: Image Processing Steps And Related Sp Modes

    Note: An SP code number and name set in bold italic denotes an SSP (Special Service Program) mode. To access an SSP, enter the SP mode: press and hold down  on the 10-key pad then “Copy SP” on the touch-screen. 6-23 B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 356: Text/Photo Mode

    Note: An SP code number and name set in bold italic denotes an SSP (Special Service Program) mode. To access an SSP, enter the SP mode: press and hold down  on the 10-key pad then “Copy SP” on the touch-screen. B079/B082 6-24 CÓPIA NÃO CONTROLADA...

  • Page 357: Photo Mode

    Note: An SP code number and name set in bold italic denotes an SSP (Special Service Program) mode. To access an SSP, enter the SP mode: press and hold down  on the 10-key pad then “Copy SP” on the touch-screen. 6-25 B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 358: Pale (Low-Density Mode)

    Note: An SP code number and name set in bold italic denotes an SSP (Special Service Program) mode. To access an SSP, enter the SP mode: press and hold down  on the 10-key pad then “Copy SP” on the touch-screen. B079/B082 6-26 CÓPIA NÃO CONTROLADA...

  • Page 359: Generation Copy Mode

    Note: An SP code number and name set in bold italic denotes an SSP (Special Service Program) mode. To access an SSP, enter the SP mode: press and hold down  on the 10-key pad then “Copy SP” on the touch-screen. 6-27 B079/B082 CÓPIA NÃO CONTROLADA...
  • Page 360 • Low contrast text characters • Fine lines While filter processing is provided to reduce the incidence of moiré generated from digital signals, you must always pay attention to how these adjustments affect text characters and fine lines. B079/B082 6-28 CÓPIA NÃO CONTROLADA...

  • Page 361: Background Erase

    Mode Background Erase Filter Default Range Text SP4903 65 Photo SP4903 66 Text/Photo SP4903 67 0 ~ 255 Pale SP4903 68 Generation Copy SP4903 69 NOTE: The “0” setting switches off the background erase filter. 6-29 B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 362: Independent Dot Erase

    SP can also remove small or fine text characters or even portions of large text characters. Mode Independent Dot Erase Filter Default Range Text SP4903 60 Text/Photo SP4903 62 0 ~ 15 Pale SP4903 63 Generation Copy SP4903 64 NOTE: The “0” setting switches off the filter. B079/B082 6-30 CÓPIA NÃO CONTROLADA...

  • Page 363: Line Width Correction

    However, remember that too large a setting can cause unexpected results in copied images. SP Mode Default Range SP4903 76 LWC Threshold (Main Scan): Generation Mode 0 ~ 5 SP4903 77 LWC Threshold (Sub Scan): Generation Mode 6-31 B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 364: Interactive Sp Codes

    Text (General) Quality 257%-400% SP4903 032 Main Scan Filter Level: Text 257%-400% SP4903 033 Sub Scan Filter Level: Text 257%-400% SP4903 034 Main Scan Filter Strength: Text 257%-400% SP4903 035 Sub Scan Filter Strength: Text 257%-400% B079/B082 6-32 CÓPIA NÃO CONTROLADA...
  • Page 365 NOTE: An SP code number and name set in bold italic denotes an SSP (Special Service Program) mode. To access an SSP, enter the SP mode: press and hold down  on the 10-key pad then “Copy SP” on the touch-screen. 6-33 B079/B082 CÓPIA NÃO CONTROLADA...
  • Page 366 Select a lower setting for better reproduction of photographs and a higher setting for sharper text. For details, refer to the SP table. B079/B082 6-34 CÓPIA NÃO CONTROLADA...
  • Page 367 (for range see Section “5. Service Tables”. To fine adjust the master setting set it to “0” then perform the adjustments listed below. SP4904 030 = 0 Generation (General) Quality SP4903 057 Filter Level: Generation Copy SP4903 058 Filter Strength: Generation Copy 6-35 B079/B082 CÓPIA NÃO CONTROLADA...
  • Page 368 Coefficient and strength adjustments for main scan affect lines parallel to the direction of Scan Direction scanning [A]. B079D909.WMF Coefficient and strength adjustments for sub scan affect lines at right angles to the direction of scanning [B]. B079/B082 6-36 CÓPIA NÃO CONTROLADA...
  • Page 369 “Filter Setting Edge” SP. Lowering this setting broadens the range for edge filter processing and increases clarity. Also, using this SP together with “Filter Adj. Mag.” below can sharpen edges to an extent that an abnormal looking image is created. 6-37 B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 370: Pale, Generation Mode Filter

    Basically, you should first just the MTF filter strength in 1 step increments without adjusting the coefficient to achieve the effect you want, and then use the coefficient settings for fine adjustment. B079/B082 6-38 CÓPIA NÃO CONTROLADA...

  • Page 371: Photo Mode Smoothing For Dithering

    To improve the clarity of fine lines and text, you can also increase the strength of the MTF filter. However, increasing the strength of the filter can also increase the incidence of moiré in areas of newspaper, magazine, or other photographs created with dot screening. 6-39 B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 372: Photo Mode Image Quality

    • When using the smallest matrix with setting “3” (4 x 4), you should switch off the smoothing filter for the Photo mode by setting SP4903 37 to “0”. • Use the largest dither matrix (setting “0”) for originals that contain dot screening such as newspaper and magazine photographs. B079/B082 6-40 CÓPIA NÃO CONTROLADA...

  • Page 373: Vertical Black Line Correction

    NOTE: Generally, this SP code corrects most low density vertical black lines but may not be able to correct extremely dark or wide black lines. 6-41 B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 374: Density Settings

    Filter Strength: Generation Copy 2 (or change as required) SP4903 64 Independent Dot Erase: Generation Copy 0 (OFF) SP4903 69 Background Erase Level: Generation Copy 0 OFF SP4903 75 Line Width Correction: Generation Mode 0 (LWC OFF) B079/B082 6-42 CÓPIA NÃO CONTROLADA...
  • Page 375 As with previous digital copiers, the user can select manual image density when selecting auto image density mode and the machine will use both settings when processing the original. 6-43 B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 376: Practical Application Of Sp Modes

    Strengthen the MTF filters for Text mode: • SP4903 24: Set to “9”. • SP4903 25: Set to “13”. • SP4903 26: Set to “3”. • SP4903 27: Set to “3”. B079/B082 6-44 CÓPIA NÃO CONTROLADA...

  • Page 377: Recommended Settings For Mtf Filters

    Text Mode (257% ~ 400%) – MTF Strength Strong ← Default → Weak Default Settings: Sharp Normal Soft SP4903 32 Main Filter Level SP4903 33 Sub Filter Level SP4903 34 Main Filter Strength SP4903 35 Sub Filter Strength 6-45 B079/B082 CÓPIA NÃO CONTROLADA...
  • Page 378 SP4903 55 Filter Level: Light Original SP4903 56 Filter Strength: Light Original Generation Copy Mode MTF Strength Strong ← Default → Weak Default Settings: Sharp Normal Soft SP4903 55 Filter Level: Light Original SP4903 56 Filter Strength: Light Original B079/B082 6-46 CÓPIA NÃO CONTROLADA...

  • Page 379: Laser Exposure

    The laser synchronizing detector determines the main scan starting position. NOTE: The front door and right door (transfer door) are equipped with safety switches that automatically shut down the laser unit when either door is opened. 6-47 B079/B082 CÓPIA NÃO CONTROLADA...
  • Page 380 The reference levels are adjusted on the production line. Do not touch the variable resistors on the LDDR in the field. B079/B082 6-48 CÓPIA NÃO CONTROLADA...

  • Page 381: Dual Beam Writing

    0.06 mm apart (at 400 dpi) in the sub scan direction (see the next page). The two-mm difference in the main scan direction allows the machine to detect the laser synchronization signal for each beam. 6-49 B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 382: Laser Beam Pitch Change Mechanism

    Usually, the LD unit moves directly to the proper position. However, when the number of times that the resolution has changed reaches the value of SP2-109-5 (LD Beam Pitch Adjustment), the LD unit moves to the home position, and this re- calibrates the LD unit positioning mechanism. B079/B082 6-50 CÓPIA NÃO CONTROLADA...

  • Page 383: Ld Safety Switches

    Four safety switches are installed in series on the LD5 V line from the power supply unit (PSU) via the BICU board. 6-51 B079/B082 CÓPIA NÃO CONTROLADA...
  • Page 384 8. Charge Roller Cleaning Roller 3. Image Density Sensor 9. Drum Cleaning Blade 2 4. Pick off Pawl 10. Quenching Lamp 11. Drum Cleaning Blade 1 5. OPC Drum (φ60 mm) 6. Transfer Entrance Guide B079/B082 6-52 CÓPIA NÃO CONTROLADA...

  • Page 385: Drum Pawls

    The gears [C] are removable, and the positions of the holders can be adjusted. B004R305.WMF 6.7.4 DRUM TONER SEALS Seals have been added to the structure of the PCU (photoconductor unit) to further prevent toner leakage. B004D902.WMF 6-53 B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 386: Drum Cleaning

    OPC drum. After cleaning or replacement, the spring must be returned to its original position to keep the blade in contact with the OPC drum for normal operation. For details, see Section “3 Replacement and Adjustment”. B079/B082 6-54 CÓPIA NÃO CONTROLADA...

  • Page 387: Drum Charge

    The high voltage supply board [C] supplies a negative dc voltage to the drum charge roller through the charge roller terminal [D], bias plate [E], and the rear roller bushing [F] to give the drum surface a negative charge of –950V. 6-55 B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 388: Charge Roller Voltage Correction

    The ID sensor measures the density of pattern [B], and Vsdp, the output voltage, is compared with Vsg which was read from the bare drum at the same time. B079/B082 6-56 CÓPIA NÃO CONTROLADA...

  • Page 389: Correction For Paper Width And Thickness

    Default: -1450+50 V Default: -1450 V B079D507.WMF For example, with the default settings, if the paper width fed from the by-pass tray is 200 mm, the charge roller voltage will be –1450 + 50 V. 6-57 B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 390: Id Sensor Pattern Production Timing

    [B] also remains in contact with the charge roller to clean it. The pin [C] in contact with the cam gear [D] enables the gear to move the cleaning pad from side to side and improve cleaning. B079/B082 6-58 CÓPIA NÃO CONTROLADA...
  • Page 391 CÓPIA NÃO CONTROLADA DEVELOPMENT 6.9 DEVELOPMENT 6.9.1 OVERVIEW B004D401.WMF 1 Drum 5 Mixing Auger 2 Development Roller 6 Development Filter 3 Paddle Roller 7 Doctor Blade 4 TD Sensor 6-59 B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 392: Developer Mixing

    & . New toner from the toner bottle and recycled toner from the toner collection coil both enter the development unit at [D]. B079/B082 6-60 CÓPIA NÃO CONTROLADA...

  • Page 393: Development Bias

    Default: -600+50 V Default: -600 V B004D508.WMF For example, with the default settings, if the paper width fed from the by-pass tray is 200 mm, the development bias voltage will be –600 + 50 V. 6-61 B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 394: Toner Supply

    The toner bottle has a spiral groove [H], which rotates the bottle to move toner to the development unit. When the bottle holder unit is pulled out, the chuck [G] releases the toner bottle cap and the toner shutter [D] closes and blocks the opening. B079/B082 6-62 CÓPIA NÃO CONTROLADA...

  • Page 395: Toner Supply Mechanism

    Toner falls into the toner bottle holder, and the toner supply mylar blades transfer the toner to slit [D]. Installing the PCU opens the shutter [E]. The toner falls into the development unit through the slit. B004D509.WMF 6-63 B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 396: Toner Density Control

    If the reflected light is too strong, this indicates that toner is low and toner is added to the development unit. (The frequency of these checks can be adjusted with SP2-210 (ID Sensor Pattern Interval). B079/B082 6-64 CÓPIA NÃO CONTROLADA...

  • Page 397: Toner Near End/End Detection

    90 copies have been made after toner near end was determined, the machine enters the toner end condition. NOTE: The number of copies between toner near-end and toner end can be changed with SP2-213. The default is 90 copies. 6-65 B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 398: Toner End Recovery

    Vref is not changed, the copy job is allowed to finish, and then the SC code is generated. If spare parts are not available, the technician can use SP2-208-1 to temporarily put the machine in image pixel count mode. (! Chapter 5 Service Tables) B079/B082 6-66 CÓPIA NÃO CONTROLADA...

  • Page 399: Drum Cleaning And Toner Recycling

    The paddle roller [C] mixes the collected toner with the new toner. NOTE: A screen filter [D) has been added to strain out paper dust and other foreign matter. B004D509.WMF 6-67 B079/B082 CÓPIA NÃO CONTROLADA...
  • Page 400 Each paper tray, which employs the FRR system, can hold 500 sheets. Two relay sensors, positioned above each set of relay rollers, detect paper jams. A selection dial allows you to select the setting for the size of the paper loaded in the tray. B079/B082 6-68 CÓPIA NÃO CONTROLADA...

  • Page 401: Paper Feed Drive

    When the paper tray is set into the B004D704.WMF machine, it pushes the release lever [E]. This causes the pick-up roller [D] to go down and the separation roller [B] to move up and contact the paper feed roller. B004D763.WMF 6-69 B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 402: Paper Lift

    When the paper tray is removed from the machine, the tray lift motor coupling gear disengages the pin on the lift arm shaft, and the tray bottom plate then drops under its own weight. B079/B082 6-70 CÓPIA NÃO CONTROLADA...

  • Page 403: Paper End Detection

    [B] is deactivates. When the paper tray runs out of paper, the paper end feeler drops into the cutout [C] in the tray bottom plate and the paper end sensor is activated. B004D706.WMF 6-71 B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 404: Paper Registration

    The registration roller dust blade [H] cleans the registration roller. For details about how to remove and clean these new parts, see Section “3 Replacement and Adjustment”. B079/B082 6-72 CÓPIA NÃO CONTROLADA...

  • Page 405: Paper Size Detection

    11" x 17" Portrait A5 Portrait " x 14" Portrait 8" x 13" Portrait " x 11" Portrait " x 11" Portrait " x 11" Landscape " x 11" Landscape ✻ ✻ ON: Pushed OFF: Not Pushed 6-73 B079/B082 CÓPIA NÃO CONTROLADA...
  • Page 406 CÓPIA NÃO CONTROLADA BY-PASS TRAY 6.12 BY-PASS TRAY 6.12.1 OVERVIEW B004V510.WMF Paper feed roller Paper end sensor Pick-up Roller By-pass Tray Separation roller B079/B082 6-74 CÓPIA NÃO CONTROLADA...

  • Page 407: By-Pass Tray Operation

    [C] moves onto the paper. When the by-pass tray runs out of paper, the paper end feeler [D] drops into the cutout in the by-pass tray and the paper end sensor [E] is activated. 6-75 B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 408: By-Pass Paper Size Detection

    Therefore, the copier determines which paper has been placed in the by-pass tray by the signal output from the board. However, the copier does not determine the paper length from the by-pass tray hardware. B079/B082 6-76 CÓPIA NÃO CONTROLADA...
  • Page 409 CÓPIA NÃO CONTROLADA DUPLEX UNIT 6.13 DUPLEX UNIT 6.13.1 OVERVIEW B004D101.WMF Entrance sensor Upper transport roller Inverter gate Lower transport roller Inverter roller Exit sensor 6-77 B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 410: Duplex Drive Layout

    CÓPIA NÃO CONTROLADA DUPLEX UNIT 6.13.2 DUPLEX DRIVE LAYOUT B004D103.WMF Inverter roller Transport motor Inverter motor Lower transport roller Upper transport roller B079/B082 6-78 CÓPIA NÃO CONTROLADA...

  • Page 411: Duplex Basic Operation

    Example: 8 pages. The number [A] in the illustration shows the order of pages. The number [B] in the illustration shows the order of sheets of copy paper (if shaded, this indicates the second side). ⇒ ⇒ ⇒ ⇒ ⇒ ⇒ ⇒ B004D531.WMF 6-79 B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 412: Duplex Unit Feed In And Exit Mechanism

    [D]. As a result, the inverter gate [E] is opened and the inverter roller rotates counterclockwise. The paper is sent to the copier through the upper and lower transport rollers [F, G]. B079/B082 6-80 CÓPIA NÃO CONTROLADA...

  • Page 413: Image Transfer And Paper Separation

    6.14.1 OVERVIEW B004D561.WMF 1 Transfer belt 6 OPC 2 Drive roller 7 Pick-off pawls 3 Transfer belt cleaning blade 8 ID sensor 4 Transfer roller 9 Contact lever 5 Idle roller 10 Transfer belt contact clutch 6-81 B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 414: Transfer Belt Unit Contact Mechanism

    The belt must be released from the drum between copy jobs in order to prevent the ID sensor pattern from being rubbed off B004D563.WMF and to prevent contamination of the drum from the surface of the belt. B079/B082 6-82 CÓPIA NÃO CONTROLADA...
  • Page 415 The paper moves to the end of the transfer belt unit, where it separates from the belt as the belt curves away and moves on to the fusing unit. B004D521.WMF 6-83 B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 416: Transfer Belt Charge

    If this current is not kept constant, efficiency of toner transfer and paper separation will vary with paper thickness, type, environmental condition, or changes in transfer belt surface resistance. B079/B082 6-84 CÓPIA NÃO CONTROLADA...
  • Page 417 297 mm Default: 150 mm Default: 216 mm Paper Tray SP2-309-3 SP2-309-4 Current x 1.0 Current x 1.2 Current x 1.2 By-pass Tray SP2-309-5 SP2-309-6 Current x 1.0 Current x 1.5 Current x 1.5 B004D571.WMF 6-85 B079/B082 CÓPIA NÃO CONTROLADA...
  • Page 418 1st Side of Paper SP2-301-2 2nd Side of Paper SP2-301-4 By-pass Feed Leading edge SP2-301-3 Leading Edge areas SP2-301-5 Leading Edge By-pass Feed SP2-911 Transfer Current Timing Timing SP2-911-1 On Timing SP2-911-2 Switch Timing SP2-911-3 Off Timing B079/B082 6-86 CÓPIA NÃO CONTROLADA...

  • Page 419: Transfer Belt Cleaning Mechanism

    This toner is not recycled. When the toner overflow sensor [C] detects toner overflow, the toner overflow indicator lights. Up to 999 copies can be made before the toner overflow condition shuts down the machine. 6-87 B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 420: Toner Scatter Prevention

    To reduce the incidence of toner scanner, the sponge strip has been replaced with a velvet strip [A] that extends across the length of the transfer belt unit. At each end of the strip [B] and [C] new seals have been added. B079/B082 6-88 CÓPIA NÃO CONTROLADA...

  • Page 421: Image Fusing And Paper Exit

    13 Fusing lamp (ends) 5 Fusing unit exit sensor 14 Thermistors (central/end) 6 Spring 15 Thermostat (central/end) 7 Fusing exit guide plate 16 Hot roller 8 Pressure roller 17 Hot roller strippers 9 Pressure arm 18 Exit roller 6-89 B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 422: Fusing Drive

    [A] when the right door [B] is opened. When the right cover is opened, the actuator plate [C] pulls release wire [D]. The wire pulls the fusing drive gear bracket [E] and the fusing unit drive is disengaged. B004D605.WMF B079/B082 6-90 CÓPIA NÃO CONTROLADA...

  • Page 423: Fusing Entrance Guide Shift Mechanism

    Two de-curler rollers [B] and [C] have been added under the exit roller [D] to correct the curl that paper acquires during transport through the fusing unit. B004D601.WMF 6-91 B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 424: Pressure Roller

    The left position [D] is the normal setting, and the right position [E] increases the pressure to prevent insufficient fusing by the fusing unit. B004D663.WMF B079/B082 6-92 CÓPIA NÃO CONTROLADA...

  • Page 425: Cleaning Mechanism

    The cleaning roller [A] is composed of an aluminum shell with an internal “heat pipe” suspended in the middle of the roller to dissipate heat more rapidly. 6-93 B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 426: Hot Roller Stripper Cleaning

    The timing chart below shows the fusing/exit motor switched off and on twice at the end of a print job. Print Job End On/Off 2 Off/On 1 1 min. 15 sec. 15 sec. Fusing/ exit motor Fusing Temperature Re-load Temperature B079D912.WMF B079/B082 6-94 CÓPIA NÃO CONTROLADA...
  • Page 427 • The cleaning cycle is not interrupted during free rotation of the hot roller when the machine is getting ready to print. • Opening the front door, however, will stop the cleaning cycle. 6-95 B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 428: Fusing Temperature Control

    In order to control the temperature of the roller, two high response thermistors are attached to the unit, one near the center [C] and one at the end [D] of the hot roller. B079/B082 6-96 CÓPIA NÃO CONTROLADA...

  • Page 429: Temperature Control

    CÓPIA NÃO CONTROLADA IMAGE FUSING AND PAPER EXIT Temperature Control B082 (45 cpm) B079 (35 cpm) °C °C Fusing Temp. 175°C Fusing Temp. 170°C 160°C 150°C Center Center Main SW ON Re-load Main SW ON Re-load B079D914.WMF There are two types of temperature control: •...

  • Page 430: Fusing Idling Temperature

    The fusing idling time is as follows. Temperature at Fusing Idling Mode power-on 0: Disabled 1: Enabled SP1103 1 30 s 30 s 15 °C or less SP1103 2 Not done 30 s Higher than 15°C B079/B082 6-98 CÓPIA NÃO CONTROLADA...

  • Page 431: Cpm Down For Thick Paper

    • The ID sensor pattern is created and the line speed remains the same until the end of the job. • The intensity of the LD unit is lowered evenly, 30 steps from its specified value. 6-99 B079/B082 CÓPIA NÃO CONTROLADA...

  • Page 432: Cooling And Overheat Protection

    If the temperature of the thermostat reaches 210 °C, the thermostat opens, removing power from the fusing lamp. At the same time, the copier stops operating. At this time, SC542 (Fusing Temperature Warm-up Error) will be displayed. B079/B082 6-100 CÓPIA NÃO CONTROLADA...

  • Page 433: Energy Saver Modes

    Energy Saver Mode (Low Power Mode) Operation Sw. On Platen Cover Open/Close Original Set ADF Auto Off Mode Return Time Less Than: 10 s: Model B079 15 s: Model B082 Off Mode FAX: RX, etc. Printer Data in After Printing Off Stand-by Mode B004D604.WMF...

  • Page 434: Energy Saver Mode

    • A sheet of paper is placed in the by-pass feed table The recovery time from energy saver mode is about 3 s. Operation Energy Mode Fusing Temp. +24V System +5V Switch Saver LED Energy B079: 130 Saver B082: 150 B079/B082 6-102 CÓPIA NÃO CONTROLADA...

  • Page 435: Auto Off Mode

    +5V and +24V supplies are activated. Returning to stand-by mode The machine returns to stand-by mode when the operation switch is pressed. The recovery time is about 10 s for the B079 and 15 s for the B082. Energy Operation...
  • Page 436 CÓPIA NÃO CONTROLADA CÓPIA NÃO CONTROLADA...

  • Page 437: Specifications

    CÓPIA NÃO CONTROLADA SPECIFICATIONS CÓPIA NÃO CONTROLADA...
  • Page 438 CÓPIA NÃO CONTROLADA CÓPIA NÃO CONTROLADA...

  • Page 439: General Specifications

    Inch version (%): 400, 200, 155, 129, 121, 93, 85, 78, 73, 65, 50, 25 Zoom: 25 ~ 400% in 1% steps Copying Speed B079 35 cpm A4, 8 " x 11" LEF, 1-to-1 (ARDF) 45 cpm, A4, 8 " x 11" LEF, 1-to-1 (ARDF)

  • Page 440: Power Consumption

    CÓPIA NÃO CONTROLADA SPECIFICATIONS Power Consumption Mainframe only B079 B082 Copying Less than 1.2 kW Less than 1.2 kW Warm-up Less than 1.25 kW Less than 1.25 kW Stand-by Less than 139 W/h Less than 170 W/h Auto Off Mode Ave.
  • Page 441 10. Booklet Finisher 4. Duplex unit 11. 1000 Sheet Finisher (1 shift tray) 5. By-pass tray 12. Bridge Unit 6. LCT (Large Capacity Tray) 13. Cabinet 7. Copier NOTE: The Bridge Unit is required for the optional finishers. B079/B082 CÓPIA NÃO CONTROLADA...
  • Page 442 CÓPIA NÃO CONTROLADA SPECIFICATIONS Key: Symbol: U: Unique option, C: Option also used with other products Item Machine Code B079 B079 B082 B082 ARDF (See Note 1.) B541 Platen Cover (See Note 1.) G329 Paper Tray Unit B542 Cabinet LCT (Large Capacity Tray)

  • Page 443: Optional Equipment

    220 ~ 240 Vac: 224/240 V version (from the copier) Power Consumption: 50 W Weight: Less than 25 kg (55.1 lb.) Size (W x D x H): 540 mm x 600 mm x 270 mm (21.3" x 23.6" x 10.6") B079/B082 CÓPIA NÃO CONTROLADA...
  • Page 444 2 Staples: 2 positions (Upper, Left Staple Cartridge (5,000 staples/cartridge) Replenishment Power Source DC 24 V, 5V (from copier) Power Consumption 50 W Weight 25 kg (55.2 lb.) Dimensions 527 x 520 x 790 mm 20.8" x 20.5" x 31.1" B079/B082 CÓPIA NÃO CONTROLADA...
  • Page 445 Less than 53 kg (116.8 lb.) (without punch unit) Less than 55 kg (121.3 lb.) (with punch unit) Size (W x D x H) 680 mm x 620 mm x 1030 mm (26.8" x 24.4" x 40.6") B079/B082 CÓPIA NÃO CONTROLADA...
  • Page 446 Staple 30 sets * 1-5 sheets 25 sets Booklet tray 6-10 sheets 15 sets 11-15 sheets 10 sets 80 g/m , 20 lb Setting DIP SW 3 No. 5 to ON releases the 30 set limit. B079/B082 CÓPIA NÃO CONTROLADA...
  • Page 447 24 Vdc, 5 Vdc (from copier) Power Consumption 40 W Weight Less than 17 kg (37.5 lb.) Size (W x D x H) 390 mm x 500 mm x 390 mm (15.4" x 19.7" x 15.4") B079/B082 CÓPIA NÃO CONTROLADA...
  • Page 448 CÓPIA NÃO CONTROLADA CÓPIA NÃO CONTROLADA...

  • Page 449: Booklet Finisher

    CÓPIA NÃO CONTROLADA BOOKLET FINISHER B546 CÓPIA NÃO CONTROLADA...
  • Page 450 CÓPIA NÃO CONTROLADA CÓPIA NÃO CONTROLADA...
  • Page 451 CÓPIA NÃO CONTROLADA BOOKLET FINISHER B546 TABLE OF CONTENTS 1. OVERALL MACHINE INFORMATION..........1 1.1 MECHANICAL COMPONENT LAYOUT............1 2. DETAILED DESCRIPTIONS ............2 2.1 JUNCTION GATE MECHANISM ..............2 2.1.1 SHIFT TRAY MODE ................2 A4/LT sideways or shorter ............... 2 Longer than A4 sideways.................
  • Page 452 CÓPIA NÃO CONTROLADA 3.1.14 FOLDER ROLLERS ................ 29 3.1.15 FOLDER PLATE................32 Removal....................32 Reinstalling .................... 33 3.1.16 BOOKLET STAPLER UNIT ............. 34 Removal....................34 Adjustment ..................... 35 3.1.17 BOOKLET BOARD ................37 3.1.18 POSITIONING PLATE UNIT............37 3.1.19 1ST AND 2ND BOOKLET UNIT GATES ......... 38 3.2 ADJUSTMENT ...................

  • Page 453: Overall Machine Information

    CÓPIA NÃO CONTROLADA MECHANICAL COMPONENT LAYOUT 1. OVERALL MACHINE INFORMATION 1.1 MECHANICAL COMPONENT LAYOUT B546V501.WMF B546V500.WMF 1. Shutter 15. Booklet Unit Entrance Roller 2. Shift Tray 16. 1st Booklet Unit Gate 3. Lower Exit Roller 17. 2nd Booklet Unit Gate 4.

  • Page 454: Detailed Descriptions

    CÓPIA NÃO CONTROLADA JUNCTION GATE MECHANISM 2. DETAILED DESCRIPTIONS 2.1 JUNCTION GATE MECHANISM 2.1.1 SHIFT TRAY MODE A4/LT sideways or shorter B546D564.PCX The booklet gate [A] and buffer roller entrance gate [B] are closed and the copy paper goes directly to the shift tray [C]. Longer than A4 sideways B546D565.PCX The booklet gate, proof tray gate [D], and buffer roller exit gate [E] are closed, and...

  • Page 455: Proof Tray Mode

    CÓPIA NÃO CONTROLADA JUNCTION GATE MECHANISM 2.1.2 PROOF TRAY MODE The booklet gate [A] is closed. The buffer roller entrance gate [B] and proof tray gate [C] are opened. The copy paper goes to the proof tray [D]. B546D101.WMF 2.1.3 BOOKLET STITCH MODE The booklet gate is opened and the copy paper goes to the booklet unit.

  • Page 456: Pre-Stack Mechanism

    CÓPIA NÃO CONTROLADA PRE-STACK MECHANISM 2.2 PRE-STACK MECHANISM This mechanism improves productivity in staple mode and shift mode. During stapling, the copier has to wait. This mechanism reduces the wait by holding the first two sheets of a job while the previous job is still being stapled. It only works during the second and subsequent sets of a multi-set copy job.

  • Page 457: Paper Shift Mechanism

    CÓPIA NÃO CONTROLADA PAPER SHIFT MECHANISM 2.3 PAPER SHIFT MECHANISM B546D569.PCX B546D104.WMF B546D570.PCX In sort and stack mode, only the 1st sheet of copy paper from the 2nd set is shifted to the front to separate each set of copies. When the copy paper comes into the staple tray [A], the upper exit guide [B] (which contains the upper exit roller) opens.

  • Page 458: Paper Positioning Mechanism

    CÓPIA NÃO CONTROLADA PAPER POSITIONING MECHANISM 2.4 PAPER POSITIONING MECHANISM B546D105.WMF B546D106.WMF B546D108.WMF B546D111.WMF When the trailing edge of the 1st copy paper passes the 2nd transport roller [A], the lower exit roller [B] stops and turns reverse. At the same time, the upper guide plate motor turns on and opens the upper exit guide [C].

  • Page 459: Stapler Unit Movement Mechanism

    CÓPIA NÃO CONTROLADA STAPLER UNIT MOVEMENT MECHANISM 2.5 STAPLER UNIT MOVEMENT MECHANISM 2.5.1 DRIVE The stapler motor [A] drives the stapler unit drive gear [B] via a timing belt. The stapler unit guide has a rack gear [C]. The stapler unit moves along the rack gear via the stapler unit [D] drive gear.

  • Page 460: Stapler

    CÓPIA NÃO CONTROLADA STAPLER 2.6 STAPLER B546D571.PCX B546D109.WMF B546D110.WMF The staple hammer motor [A] drives the cam [B] via 2 gears [C, D] and the guide roller on the staple hammer moves on the cam [D] . When the guide roller moves to the highest position on the cam, the copy paper is stapled.

  • Page 461: Shift Tray Mechanism

    CÓPIA NÃO CONTROLADA SHIFT TRAY MECHANISM 2.7 SHIFT TRAY MECHANISM B546D576.PCX B546D572.PCX The guide gear [A] on which the shift tray is mounted is driven by the lift motor [B] via gear [C]. The finisher board detects the direction of the motor rotation and motor position using the lift motor sensors 1 [D] and 2 [E].

  • Page 462: Booklet Unit Gate Mechanism

    CÓPIA NÃO CONTROLADA BOOKLET UNIT GATE MECHANISM 2.8 BOOKLET UNIT GATE MECHANISM B546D551.PCX B546D552.PCX B546D550.PCX B546D563.PCX There are two junction gates [A] and three paper sensors [B] at the entrance area of the booklet unit. Depending on paper size, the appropriate gate solenoid(s) [C] are energized to close the gate(s) in order to transport paper to the positioning plate [D] through a suitable paper path.
  • Page 463 CÓPIA NÃO CONTROLADA BOOKLET UNIT GATE MECHANISM The following tables show the relation between paper sizes and solenoids/sensors: A3, 11" x 17" B4, 11" x 14" A4, 8 " x 11" 1st Solenoid (Gate) OFF (Opened) ON (Closed) ON (Closed) 2nd Solenoid (Gate) OFF (Opened) OFF (Opened)

  • Page 464: Relay Roller And Positioning Plate Mechanism

    CÓPIA NÃO CONTROLADA RELAY ROLLER AND POSITIONING PLATE MECHANISM 2.9 RELAY ROLLER AND POSITIONING PLATE MECHANISM When the first sheet of paper comes to the booklet unit, the booklet transport motor turns on to drive the relay roller [A]. The two relay rollers are out of contact with each other before the paper comes.

  • Page 465: Positioning Roller Mechanism

    CÓPIA NÃO CONTROLADA POSITIONING ROLLER MECHANISM 2.10 POSITIONING ROLLER MECHANISM B546D554.PCX B546D555.PCX The booklet transport motor also drives the positioning roller [A] to vertically align paper against the positioning plate [B]. The positioning roller is not round but elliptical in shape so that it moves away from the paper while the paper is being horizontally aligned.

  • Page 466: Booklet Unit Jogger Movement Mechanism

    CÓPIA NÃO CONTROLADA BOOKLET UNIT JOGGER MOVEMENT MECHANISM 2.11 BOOKLET UNIT JOGGER MOVEMENT MECHANISM B546D557.PCX When the start key is pressed, the booklet jogger motor turns on to move the jogger fences [A] to the waiting positions that are 10 mm from each of the paper side edges.

  • Page 467: Booklet Stapler Unit

    CÓPIA NÃO CONTROLADA BOOKLET STAPLER UNIT 2.12 BOOKLET STAPLER UNIT B546D575.PCX There are two staplers whose positions are fixed. When the jogger fences finish aligning the last sheet, the jogger fences stay at the aligning positions and stapling starts. The two staplers do not operate at the same time, the rear stapler operates first, then the front one.

  • Page 468: Paper Folder Mechanism

    CÓPIA NÃO CONTROLADA PAPER FOLDER MECHANISM 2.13 PAPER FOLDER MECHANISM B546D560.PCX B546D559.PCX 20 mm B546D561.PCX B546D562.PCX The positioning plate moves down from the stapling position to a position such that the middle of the paper just comes to the folding position. It depends on the paper size.
  • Page 469 CÓPIA NÃO CONTROLADA PAPER FOLDER MECHANISM In the case of 10 sheets or more of A4 or 8 " x 11" paper, folding is done twice for 20 mm of the leading edge to fold the paper more firmly. When the leading edge of the folded paper passes 20 mm from the folder rollers, the folder roller motor reverses to feed the paper back 20 mm.

  • Page 470: Replacement And Adjustment

    CÓPIA NÃO CONTROLADA REMOVAL REPLACEMENT AND ADJUSTMENT 3.1 REMOVAL 3.1.1 UPPER DOOR B546R579.WMF 1. Open the upper door [A]. 2. Remove the lower hinge [B] ( x1). 3. Push up the upper door and remove it. B546 CÓPIA NÃO CONTROLADA...

  • Page 471: Upper Rear Cover

    CÓPIA NÃO CONTROLADA REMOVAL 3.1.2 UPPER REAR COVER B546R580.PCX B546R104.WMF 1. Hold up the proof tray and open the top cover [A]. 2. Unhook the upper rear cover [B] and remove it ( x3). 3.1.3 LOWER REAR COVER 1. Remove the lower rear cover [C] ( x4). B546 CÓPIA NÃO CONTROLADA...

  • Page 472: Top Cover

    CÓPIA NÃO CONTROLADA REMOVAL 3.1.4 TOP COVER B546R580.PCX B546R581.PCX 1. Hold up the upper tray [A] and open the top cover [B]. 2. Push the hooks [C] of the top cover and remove it. 3.1.5 UPPER INNER COVER B546R582.PCX 1. Open the upper door. 2.

  • Page 473: Shift Tray Unit

    CÓPIA NÃO CONTROLADA REMOVAL 3.1.6 SHIFT TRAY UNIT B546R107.WMF B546R106.WMF B546R108.WMF 1. Remove the upper and lower rear covers. 2. Disconnect the connector [A] and remove the grounding wire [B] ( x 1). 3. Unhook the two stoppers [C] and remove them. 4.

  • Page 474: Upper Shift Guide

    CÓPIA NÃO CONTROLADA REMOVAL 3.1.7 UPPER SHIFT GUIDE B546R112.WMF 1. Remove the slide guide and shift the shift tray unit down by releasing the clutch gear of the tray lift motor (see Shift Tray Unit Removal). shift guide [A] ( ...

  • Page 475: Exit Unit

    CÓPIA NÃO CONTROLADA REMOVAL 3.1.9 EXIT UNIT B546R113.WMF B546R114.WMF 1. Remove the shift tray unit, and the upper and lower shift guides. 2. Disconnect the connector [A] and remove the screw [B] that secures the transport belt unit [C]. 3. Disconnect [D] ( x4). 4.

  • Page 476: Buffer Roller Unit

    CÓPIA NÃO CONTROLADA REMOVAL 3.1.10 BUFFER ROLLER UNIT B546R112.WMF B546R583.PCX B546R585.PCX B546R584.PCX 1. Remove the upper rear cover and the top cover. 2. Disconnect the connector [A]. 3. Remove the upper shift guide [B] (  x 6) and the guide holder [C] ( ...

  • Page 477: Stapler

    CÓPIA NÃO CONTROLADA REMOVAL 3.1.11 STAPLER B546R586.PCX B546R587.PCX B546R588.PCX 1. Open the upper front door. 2. Slide the stapler [A] towards the front. 3. Remove the stapler ( x 1,  x 1 [B]). 4. Remove the cover [C] from the stapler ( x 2). B546 CÓPIA NÃO CONTROLADA...

  • Page 478: Finisher Board

    CÓPIA NÃO CONTROLADA REMOVAL 3.1.12 FINISHER BOARD B546R589.PCX 1. Remove the upper rear cover. 2. Remove the finisher board [A] ( x 4,  x 19). 3. Do the following adjustments after replacing the board: • Shift tray height • Jogger fence position •...

  • Page 479: Booklet Unit

    CÓPIA NÃO CONTROLADA REMOVAL 3.1.13 BOOKLET UNIT B546R561.WMF 1. Remove the following items. • Upper and lower rear covers. • Shift tray unit. • Lower shift guide. 2. Remove the lower right cover [A] ( x 4). 3. Remove the folder roller knob [B] ( x 1 stepped). 4.
  • Page 480 CÓPIA NÃO CONTROLADA REMOVAL B546R101.WMF B546R110.WMF B546R111.WMF 5. Remove the grounding wire [A] ( x 1) and upper booklet exit guide [B] ( x 2). 6. Open the lower booklet exit guide [C] and remove it (1 L-pin [D],  x 2 [E]). 7.

  • Page 481: Folder Rollers

    CÓPIA NÃO CONTROLADA REMOVAL 3.1.14 FOLDER ROLLERS B546R590.PCX B546R591.PCX B546R592.PCX B546R593.PCX 1. Remove the booklet unit 2. Remove the drive unit [A] ( x 4) [B], ( x 3), [C]). 3. Remove the front and rear tension springs [D]. B546 CÓPIA NÃO CONTROLADA...
  • Page 482 CÓPIA NÃO CONTROLADA REMOVAL B546R595.PCX B546R593.PCX B546R596.PCX B546R598.PCX B546R597.PCX the gears [A] and ball bearings [B] (4 C-rings). Remove 5. Remove the front and rear tighteners [C] (  x 1 stepped ea.). B546 CÓPIA NÃO CONTROLADA...
  • Page 483 CÓPIA NÃO CONTROLADA REMOVAL B546R599.PCX B546R549.PCX 6. Remove the jogger plates [A] ( x 1 ea.). 7. Slide the folder rollers [B] to the front and remove them. B546 CÓPIA NÃO CONTROLADA...

  • Page 484: Folder Plate

    CÓPIA NÃO CONTROLADA REMOVAL 3.1.15 FOLDER PLATE B546R117.WMF B546R116.WMF Removal 1. Remove the following items • Lower right cover • Folder roller knob • Lower door and lower inner cover • Booklet board 2. Release the harness [A] from the clamps. 3.

  • Page 485: Reinstalling

    CÓPIA NÃO CONTROLADA REMOVAL Reinstalling B546R578.PCX B546R575.PCX [A, B] B546R576.PCX B546R577.PCX 1. Line up the two small holes [A] in the folder plate with the two small protrusions on the bottom of the securing plate [B]. Then, push the two protrusions through the holes.

  • Page 486: Booklet Stapler Unit

    CÓPIA NÃO CONTROLADA REMOVAL 3.1.16 BOOKLET STAPLER UNIT Removal B546R562.PCX B546R563.PCX 1. Remove the lower door and inner cover. 2. Remove the guide roller [A] and shaft [B] (1 E-ring). 3. Pull out the booklet stapler unit [C]. B546 CÓPIA NÃO CONTROLADA...

  • Page 487: Adjustment

    CÓPIA NÃO CONTROLADA REMOVAL B546R564.PCX B546R565.PCX B546R567.PCX Adjustment 1. Remove the booklet stapler cover [A] ( x 3). 2. Remove the three paper guides [B] ( x 1 ea.). 3. Loosen the two screws on each of the anvils [C]. B546 CÓPIA NÃO CONTROLADA...
  • Page 488 CÓPIA NÃO CONTROLADA REMOVAL B546R568.PCX B546R569.PCX B546R570.PCX 4. Insert the anvil positioning plate [A] into the staple slot of the stapler [B]. NOTE: The anvil positioning plate is stored in the booklet stapler cover [C]. 5. Rotate the gear to move down the stapler. Then align the anvil positioning plate and the anvil [D].

  • Page 489: Booklet Board

    CÓPIA NÃO CONTROLADA REMOVAL 3.1.17 BOOKLET BOARD B546R115.WMF 1. Remove the lower right cover [A] ( x 4). 2. Remove the booklet board [B] ( x 4,  x 14). NOTE: After replacing the board, adjust the booklet stapling position. 3.1.18 POSITIONING PLATE UNIT B546R571.PCX 1.

  • Page 490: 1St And 2Nd Booklet Unit Gates

    CÓPIA NÃO CONTROLADA REMOVAL 3.1.19 1ST AND 2ND BOOKLET UNIT GATES B546R572.PCX B546R573.PCX B546R574.PCX 1. Remove the upper and lower rear covers. 2. Release the two tension springs [A] of the booklet entrance guide [B]. 3. Remove the booklet unit gate solenoids [C] ( x 1, 1 spring each). 4.

  • Page 491: Adjustment

    CÓPIA NÃO CONTROLADA ADJUSTMENT 3.2 ADJUSTMENT 3.2.1 SHIFT TRAY HEIGHT LED 1 LED 2 Dip Switch 3 B546R550.WMF Dip Switch 3 5 6 7 8 B546R551.WMF After replacing the finisher board or shift tray height sensor, always do this adjustment. 1.

  • Page 492: Jogger Fence Position

    CÓPIA NÃO CONTROLADA ADJUSTMENT 3.2.2 JOGGER FENCE POSITION Rear Jogger Fence LED 1 LED 2 Front Dip Switch 3 Shutter B546R550.WMF Dip Switch 3 Jogger Fence 5 6 7 8 B546R553.WMF B546R552.WMF After replacing the finisher board or if a paper alignment fault occurs, do this adjustment.

  • Page 493: Stapling Position

    CÓPIA NÃO CONTROLADA ADJUSTMENT 3.2.3 STAPLING POSITION 290 ± 2 mm (A4Y), 273 ± 2 mm (LTR) Dip Switch 3 Staple B546R554.WMF Rear Front B546R555.WMF After replacing the finisher board, do this adjustment. Doing this adjustment once will affect all paper sizes and all stapling positions. 1.

  • Page 494: Booklet Stapling Position

    CÓPIA NÃO CONTROLADA ADJUSTMENT 3.2.4 BOOKLET STAPLING POSITION Dip Switch 1 LED 1 Dip Switch 1 5 6 7 8 B546R556.WMF B546R557.WMF Mark (Trailing edge) Slot in direction (reading edge) B546R558.WMF After replacing the booklet board, dip switches 1 -6, -7, -8 on the new board must be set up the same way as on the old board.
  • Page 495 CÓPIA NÃO CONTROLADA ADJUSTMENT B546R548.PCX 6. Open the booklet entrance guide [A], then slide in the two sheets of paper [B] until their leading edges touch the positioning plate. 7. Press switch 2 on the booklet board. • The booklet finisher makes a booklet automatically. B546 CÓPIA NÃO CONTROLADA...
  • Page 496 CÓPIA NÃO CONTROLADA ADJUSTMENT Adjust towards the leading edge Adjust away from the leading edge Mark Mark Stapling Position Folding Position Folding Position Stapling Position Example 1: L= 1 mm Example 2: L= 0.75 mm B546R559.WMF Dip switch 1 -6, -7, -8 setting Adjustment (0.25 mm/ step) Do not use...

  • Page 497: Auto Reverse Document Feeder

    CÓPIA NÃO CONTROLADA AUTO REVERSE DOCUMENT FEEDER B541 CÓPIA NÃO CONTROLADA...
  • Page 498 CÓPIA NÃO CONTROLADA CÓPIA NÃO CONTROLADA...
  • Page 499 CÓPIA NÃO CONTROLADA AUTO REVERSE DOCUMENT FEEDER B541 TABLE OF CONTENTS REPLACEMENT AND ADJUSTMENT ..........1 1.1 COVERS ...................... 1 1.2 ORIGINAL FEED UNIT ................2 1.3 ORIGINAL PICK-UP ROLLER..............2 1.4 ORIGINAL FEED BELT ................3 1.5 SKEW CORRECTION/INTERVAL/ REGISTRATION/ORIGINAL WIDTH SENSORS ......................
  • Page 500 CÓPIA NÃO CONTROLADA 4.5.1 SINGLE-SIDED ORIGINALS............. 21 4.5.2 DOUBLE-SIDED ORIGINALS ............22 4.6 STAMP ....................... 23 4.7 DF70 SOFTWARE MODIFICATION HISTORY……………………………24 B541 CÓPIA NÃO CONTROLADA...

  • Page 501: B541

    CÓPIA NÃO CONTROLADA COVERS 1. REPLACEMENT AND ADJUSTMENT 1.1 COVERS B351R110.WMF B351R111.WMF 1. Front cover [A] ( x2) 2. Rear cover [B] ( x2) 3. Top cover [C] ( x1,  x2) 4. Original tray [D] ( x1,  x1) 5.

  • Page 502: Original Feed Unit

    CÓPIA NÃO CONTROLADA ORIGINAL FEED UNIT 1.2 ORIGINAL FEED UNIT 1. Open the top cover. 2. Original feed unit [A] Press it toward you on its shaft to release and lift out. B351R101.WMF 1.3 ORIGINAL PICK-UP ROLLER 1. Original feed unit (! 1.2) 2.

  • Page 503: Original Feed Belt

    CÓPIA NÃO CONTROLADA ORIGINAL FEED BELT 1.4 ORIGINAL FEED BELT B351R103.WMF B351R104.WMF 1. Original feed unit and original pick-up roller (! 1.2, 1.3) 2. Shaft [A] ( x1, spring x1) NOTE: Before removing the shaft, note carefully the positioning of the spring [B].

  • Page 504: Skew Correction/Interval/ Registration/Original Width Sensors

    CÓPIA NÃO CONTROLADA SKEW CORRECTION/INTERVAL/ REGISTRATION/ORIGINAL WIDTH SENSORS 1.5 SKEW CORRECTION/INTERVAL/ REGISTRATION/ORIGINAL WIDTH SENSORS B351R105.WMF B351R106.WMF 1. Open the top cover. 2. Upper original guide [A] ( x3). 3. Skew correction sensor [B] ( x1) 4. Interval sensor [C] ( x1) 5.

  • Page 505: Original Length Sensors

    CÓPIA NÃO CONTROLADA ORIGINAL LENGTH SENSORS 1.6 ORIGINAL LENGTH SENSORS 1. Raise the original table. 2. Lower cover of original tray [A] ( x4) 3. Original length sensor-1 [B] ( x1) 4. Original length sensor-2 [C] ( x1) B351R107.WMF 1.7 SEPARATION ROLLER 1.

  • Page 506: Inverter /Original Set Sensors

    CÓPIA NÃO CONTROLADA INVERTER /ORIGINAL SET SENSORS 1.8 INVERTER /ORIGINAL SET SENSORS 1. Rear cover. (! 1.1) 2. Lower the original stopper [A] by rotating the pick-up motor. 3. Original feed unit.(! 1.2) 4. Feed guide plate [B] ( x5) NOTE: Raise the original tray before you re-install the paper feed guide.

  • Page 507: Scanner Motor And Inverter Motor

    CÓPIA NÃO CONTROLADA SCANNER MOTOR AND INVERTER MOTOR 1.10 SCANNER MOTOR AND INVERTER MOTOR B351R113.WMF B351R112.WMF 1. Rear cover (! 1.1) 2. Pick-up roller assembly [A] ( x1,  x3,  x3) 3. Motor bracket [B] ( x3,  x2, Timing belt x2) 4.

  • Page 508: Feed Motor, Skew Correction Roller Clutch

    CÓPIA NÃO CONTROLADA FEED MOTOR, SKEW CORRECTION ROLLER CLUTCH 1.11 FEED MOTOR, SKEW CORRECTION ROLLER CLUTCH B351R115.WMF 1. Rear cover (! 1.1) 2. Motor bracket [A] ( x5,  x1) 3. Feed motor [B] (spring [C] x1) NOTE: To re-install the feed motor, secure the motor after the motor bracket has been installed.

  • Page 509: Exit Sensor

    CÓPIA NÃO CONTROLADA EXIT SENSOR 1.12 EXIT SENSOR 1. Open the ARDF. 2. Pull platen cover [A] off halfway. 3. Open exit guide plate [B]. 4. Exit guide plate cover [C] ( x2) 5. Exit sensor [D] ( x1,  x1) B351R116.WMF 1.13 STAMP SOLENOID 1.

  • Page 510: Troubleshooting

    CÓPIA NÃO CONTROLADA TIMING CHARTS 2. TROUBLESHOOTING 2.1 TIMING CHARTS 2.1.1 A4(S)/LT(S) SINGLE-SIDE ORIGINAL MODE 1000 1000 (ms) Original Set Sensor 1600 pps Pick-up Motor 1600 pps Original Stopper H.P Sn. Original Pick-up H.P Sn. 600 pps Feed Motor 4400 pps Feed Clutch Skew Correction Sn.

  • Page 511: A4(S)/Lt(S) Double-Sided Original Mode

    CÓPIA NÃO CONTROLADA TIMING CHARTS 2.1.2 A4(S)/LT(S) DOUBLE-SIDED ORIGINAL MODE 2000 (ms) 1000 1500 2500 1000 1500 1000 1500 2000 Original Set Sensor 1600 pps Pick-up Motor 1600 pps Original Stopper H.P Sn. Original Pick-up H.P Sn. 6000 pps Feed Motor 4400 pps Feed Clutch Skew Correction Sn.

  • Page 512: Jam Detection

    CÓPIA NÃO CONTROLADA JAM DETECTION 2.2 JAM DETECTION Jam Site Cause Original stopper HP Original stopper home position could not be detected within 500 ms sensor (Jam 1) after the pick-up motor switched on and started rotating counter- clockwise. Pick-up HP sensor Pick-up roller home position could not be detected within 500 ms (Jam 2) after the pick-up motor switched on and started rotating clockwise.

  • Page 513: Service Tables

    CÓPIA NÃO CONTROLADA DIP SWITCHES 3. SERVICE TABLES 3.1 DIP SWITCHES DPS101 Description Normal operating mode, with/without stamp. Not used Not used Not used Feed motor rotation (feed mode) 4400 pps (1-2 phase) Feed motor rotation (pull-out mode) 6100 pps (1-2 phase) Scanner motor rotation 4320 pps (2 phase) Inverter motor rotation 6000 pps (1-2 phase) Free run: one-sided original 100%...

  • Page 514: Detailed Description

    CÓPIA NÃO CONTROLADA MAIN COMPONENTS 4. DETAILED DESCRIPTION 4.1 MAIN COMPONENTS B351D103.WMF 1 Pick-up roller 10 Exit sensor 2 Original tray 11 Idle roller 3 3 Original length sensor 1 12 Idle roller 2 4 Original length sensor 2 13 Transport roller 5 Reverse table 14 Registration sensor 6 Inverter roller...

  • Page 515: Drive Layout

    CÓPIA NÃO CONTROLADA DRIVE LAYOUT 4.2 DRIVE LAYOUT B351D102.WMF 1 Feed motor 7 Inverter roller 2 Feed belt 8 Exit roller 3 Pick-up roller 9 Separation roller 4 Pick-up motor 10 Transport roller 5 Transport motor 11 Skew correction roller 6 Inverter motor B541 CÓPIA NÃO CONTROLADA...

  • Page 516: Original Size Detection

    CÓPIA NÃO CONTROLADA ORIGINAL SIZE DETECTION 4.3 ORIGINAL SIZE DETECTION 4.3.1 BASIC MECHANISM & " [B] B5 [C] LG B351D110.WMF The original size is detected by the four original width sensors [A] and two original length sensors, [B] and [C]. The machine determines the original width when the leading edge of the original activates the registration sensor.
  • Page 517 CÓPIA NÃO CONTROLADA ORIGINAL SIZE DETECTION Width Sensor Length Sensor Size (Width x Length) & " A3 L* (297 x 420 mm) B4 L (257 x 364 mm) A4 L (210 x 297 mm) A4 S* (297 x 210 mm) B5 L (182 x 257 mm) B5 S (257 x 182 mm) A5 L (148 x 210 mm)

  • Page 518: Mixed Original Size Mode

    CÓPIA NÃO CONTROLADA ORIGINAL SIZE DETECTION 4.3.2 MIXED ORIGINAL SIZE MODE This section explains what happens when the user selects mixed original size mode. Because this ADF is a sheet-through document feeder, the method for original document width detection is the same as when the originals are the same size, but the document length detection method is different.

  • Page 519: Original Feed-In Mechanism

    CÓPIA NÃO CONTROLADA ORIGINAL FEED-IN MECHANISM 4.4 ORIGINAL FEED-IN MECHANISM 4.4.1 PICK AND SEPARATION B351D109.WMF A858D505.WMF When the original is set on the original table, it contacts the original stopper [A] and pushes the actuator [B] out of the original set sensor [C]. When Start ...

  • Page 520: Original Skew Correction

    CÓPIA NÃO CONTROLADA ORIGINAL FEED-IN MECHANISM 4.4.2 ORIGINAL SKEW CORRECTION B351D202.WMF This mechanism is the same as the skew correction used by the registration roller in the main machine. The feed motor and the skew correction clutch control the skew correction roller. Immediately after separation, the skew correction sensor [A] detects the leading edge of the original.

  • Page 521: Original Transport And Exit

    CÓPIA NÃO CONTROLADA ORIGINAL TRANSPORT AND EXIT 4.5 ORIGINAL TRANSPORT AND EXIT 4.5.1 SINGLE-SIDED ORIGINALS B351D104.WMF The transport motor drives the transport roller [A] and the exit roller [B]. When the leading edge of the original activates the interval sensor [C], the transport motor rotates the transport roller.

  • Page 522: Double-Sided Originals

    CÓPIA NÃO CONTROLADA ORIGINAL TRANSPORT AND EXIT 4.5.2 DOUBLE-SIDED ORIGINALS Shortly after the transport motor has been turned on, the inverter solenoid is activated and junction gate [A] opens. The original is then scanned and transported towards the reverse table [B]. B351D105.WMF Shortly after the original exit sensor [C] detects the trailing edge of the original, the...

  • Page 523: Stamp

    CÓPIA NÃO CONTROLADA STAMP 4.6 STAMP B351D201.WMF NOTE: This function is only for fax mode. The stamp [A] is located between the transport roller [B] and the exit roller [C]. When the original reaches the stamp, the transport motor stops and the stamp solenoid turns on if the page is sent successfully (immediate transmission) or stored successfully (memory transmission).

  • Page 524: Df70 Software Modification History

    CÓPIA NÃO CONTROLADA DF70, SOFTWARE MODIFICATION HISTORY Rev.02/2002 ⇒ 4.7 DF70, SOFTWARE MODIFICATION HISTORY DF70 (ARDF) SOFTWARE MODIFICATION SOFTWARE PRODUCTION VERSION HISTORY LEVEL DATE B3515620 F First mass 1.74 First mass production production B3515620 G June 2001 1.75 Corrects the following: Production When scanning originals with the DF in Mixed Original or Double-Sided Original modes, a...

  • Page 525: Large Capacity Tray

    CÓPIA NÃO CONTROLADA LARGE CAPACITY TRAY B543 CÓPIA NÃO CONTROLADA...
  • Page 526 CÓPIA NÃO CONTROLADA CÓPIA NÃO CONTROLADA...
  • Page 527 CÓPIA NÃO CONTROLADA LARGE CAPACITY TRAY B543 TABLE OF CONTENTS 1. OVERALL MACHINE INFORMATION..........1 1.1 SPECIFICATIONS..................1 1.2 MECHANICAL COMPONENT LAYOUT ............2 1.3 ELECTRICAL COMPONENT LAYOUT............3 1.4 ELECTRICAL COMPONENT DESCRIPTION..........4 1.5 DRIVE LAYOUT ................... 5 2. DETAILED DESCRIPTIONS ............6 2.1 PAPER FEED MECHANISM ................
  • Page 528 CÓPIA NÃO CONTROLADA CÓPIA NÃO CONTROLADA...

  • Page 529: Overall Machine Information

    CÓPIA NÃO CONTROLADA SPECIFICATIONS 1. OVERALL MACHINE INFORMATION 1.1 SPECIFICATIONS A4 sideways/LT sideways Paper Size: Paper Weight: 60 g/m ~ 105 g/m , 16 lb ~ 28 lb Tray Capacity: 1500 sheets (80 g/m , 20lb) Remaining Paper Detection: 5 steps (100%, 75%, 50%, 25%, Near end) Power Source: 24 Vdc, 5 Vdc (from copier) Power Consumption:...

  • Page 530: Mechanical Component Layout

    CÓPIA NÃO CONTROLADA MECHANICAL COMPONENT LAYOUT 1.2 MECHANICAL COMPONENT LAYOUT A683V500.WMF 1. Relay Roller 5. Paper End Sensor 2. Relay Sensor 6. Paper Tray 3. Paper Feed Roller 7. Separation Roller 4. Pick-up Roller B543 CÓPIA NÃO CONTROLADA...

  • Page 531: Electrical Component Layout

    CÓPIA NÃO CONTROLADA ELECTRICAL COMPONENT LAYOUT 1.3 ELECTRICAL COMPONENT LAYOUT A683V501.WMF 1. Relay Clutch 10. LCT Set Sensor 2. Paper Feed Clutch 11. Tray Cover Switch 3. LCT Motor 12. Lift Motor 4. Paper Height 1 Sensor 13. Down Switch 5.

  • Page 532: Electrical Component Description

    CÓPIA NÃO CONTROLADA ELECTRICAL COMPONENT DESCRIPTION 1.4 ELECTRICAL COMPONENT DESCRIPTION Symbol Name Function Index No. Motors Drives all rollers. Lift Drives the paper tray up or down. Sensors Paper End Informs the copier when the paper has run out. Relay Detects the copy paper coming to the relay roller and checks for misfeeds.

  • Page 533: Drive Layout

    CÓPIA NÃO CONTROLADA DRIVE LAYOUT 1.5 DRIVE LAYOUT A683V502.WMF 1. Relay Clutch 6. Tray Drive Belts 2. Paper Feed Clutch 7. Lift Motor 3. LCT Motor 8. Separation Roller 4. Tray Bottom Plate 9. Paper Feed Roller 5. Pick-up Roller 10.

  • Page 534: Detailed Descriptions

    CÓPIA NÃO CONTROLADA PAPER FEED MECHANISM 2. DETAILED DESCRIPTIONS 2.1 PAPER FEED MECHANISM A683D500.WMF This machine uses the FRR (Feed and Reverse Roller) paper feed system (paper feed roller [A], separation roller [B], pick-up roller [C]). When the start key is pressed, the pick-up solenoid [D] energizes and the pick-up roller touches the paper.

  • Page 535: Tray Lift And Paper Height Detection Mechanism

    CÓPIA NÃO CONTROLADA TRAY LIFT AND PAPER HEIGHT DETECTION MECHANISM 2.2 TRAY LIFT AND PAPER HEIGHT DETECTION MECHANISM A683D501.WMF The lift motor [A] controls the vertical position of the tray bottom plate [B] through gears and timing belts [C]. Tray lifting conditions When the tray lift sensor [D] turns off in the following conditions, the tray lift motor raises the tray bottom plate until the tray lift sensor [D] turns on again.

  • Page 536: Tray Unit Slide Mechanism

    CÓPIA NÃO CONTROLADA TRAY UNIT SLIDE MECHANISM 2.3 TRAY UNIT SLIDE MECHANISM A683D502.WMF When there is a paper jam between the copier and the LCT, the user releases the lock lever [A] and can slide the LCT away from the copier to remove the jammed paper.

  • Page 537: Service Tables

    CÓPIA NÃO CONTROLADA DIP SWITCHES SERVICE TABLES 3.1 DIP SWITCHES DPS101 Description Default Free run NOTE: 1) Do not use any other settings. 2) To do the free run, proceed as follows: 1. Remove the paper from the LCT (this is because the machine has no jam detection).

  • Page 538: Replacement And Adjustment

    CÓPIA NÃO CONTROLADA COVER REPLACEMENT 4. REPLACEMENT AND ADJUSTMENT 4.1 COVER REPLACEMENT A683R500.WMF Tray Cover 1. Remove the tray cover [A] (1 snap ring). Front Cover 1. Remove the front cover [B] (2 screws). Rear Cover 1. Remove the tray cover. 2.

  • Page 539: Roller Replacement

    CÓPIA NÃO CONTROLADA ROLLER REPLACEMENT 4.2 ROLLER REPLACEMENT 4.2.1 PAPER FEED, SEPARATION, AND PICK-UP ROLLERS A683R501.WMF 1. Push the down switch to lower the tray bottom plate until it reaches its lowest position. 2. Open the tray cover. Pick-up Roller 3.

  • Page 540: Tray Lift And Paper End Sensor Replacement

    CÓPIA NÃO CONTROLADA TRAY LIFT AND PAPER END SENSOR REPLACEMENT 4.3 TRAY LIFT AND PAPER END SENSOR REPLACEMENT A683R502.WMF 1. Remove the front and rear cover. 2. Remove the upper cover. 3. Remove the sensor bracket [A] (1 screw). Tray Lift Sensor 3.

  • Page 541: Relay Sensor Replacement

    CÓPIA NÃO CONTROLADA RELAY SENSOR REPLACEMENT 4.4 RELAY SENSOR REPLACEMENT A683R503.WMF 1. Pull out the LCT. 2. Remove the joint guide [A] (4 screws). 3. Remove the sensor bracket [B] (1 screw). 4. Replace the relay sensor [C] (1 connector). B543 CÓPIA NÃO CONTROLADA...

  • Page 542: Side Fence Position Change

    CÓPIA NÃO CONTROLADA SIDE FENCE POSITION CHANGE 4.5 SIDE FENCE POSITION CHANGE A4 → LT A683R504.WMF 1. Push the down switch to lower the tray bottom plate until it reaches its lowest position. 2. Remove the tray cover. 3. Remove the front and rear side fences [A, B] (1 screw each). 4.
  • Page 543 CÓPIA NÃO CONTROLADA PAPER TRAY UNIT B542 CÓPIA NÃO CONTROLADA...
  • Page 544 CÓPIA NÃO CONTROLADA CÓPIA NÃO CONTROLADA...
  • Page 545 CÓPIA NÃO CONTROLADA PAPER TRAY UNIT B542 TABLE OF CONTENTS 1. REPLACEMENT AND ADJUSTMENT ..........1 1.1 COVER REPLACEMENT ................1 Right Cover....................1 Rear Cover ....................1 1.2 ROLLER REPLACEMENT ................2 1.2.1 PAPER FEED, SEPARATION, AND PICK-UP ROLLERS ....2 Pick-up Roller ..................
  • Page 546 CÓPIA NÃO CONTROLADA CÓPIA NÃO CONTROLADA...
  • Page 547 CÓPIA NÃO CONTROLADA SPECIFICATIONS 1. OVERALL MACHINE INFORMATION 1.1 SPECIFICATIONS A5 lengthwise to A3 Paper Size: HLT lengthwise to DLT Paper Weight: 60 g/m ~ 105 g/m , 16 lb ~ 28 lb Tray Capacity: 500 sheets (80 g/m , 20 lb ) x 2 Paper Feed System: FRR (Feed and Reverse Roller) Paper Height Detection:...

  • Page 548: Mechanical Component Layout

    CÓPIA NÃO CONTROLADA MECHANICAL COMPONENT LAYOUT 1.2 MECHANICAL COMPONENT LAYOUT A682V500.WMF 1. Upper Pick-up Roller 6. Lower Paper Feed Roller 2. Upper Paper Feed Roller 7. Lower Separation Roller 3. Upper Relay Roller 8. Lower Pick-up Roller 4. Upper Separation Roller 9.
  • Page 549 CÓPIA NÃO CONTROLADA ELECTRICAL COMPONENT LAYOUT 1.3 ELECTRICAL COMPONENT LAYOUT A682V501.WMF 1. Main Board 11. Lower Lift Sensor 2. Upper Tray Switch 12. Lower Paper End Sensor 3. Lower Tray Switch 13. Lower Relay Sensor 4. Tray Motor 14. Upper Relay Sensor 5.
  • Page 550 CÓPIA NÃO CONTROLADA ELECTRICAL COMPONENT DESCRIPTION 1.4 ELECTRICAL COMPONENT DESCRIPTION Symbol Name Function Index No. Motors Tray Drives all rollers. Tray Lift Lifts the upper and lower tray bottom plates (there are two motors in this unit, one for each tray.
  • Page 551 CÓPIA NÃO CONTROLADA DRIVE LAYOUT 1.5 DRIVE LAYOUT A682V502.WMF 1. Tray Motor 7. Lower Paper Feed Roller 2. Relay Clutch 8. Lower Pick-up Roller 3. Upper Paper Feed Clutch 9. Upper Separation Roller 4. Lower Paper Feed Clutch 10. Upper Relay Roller 5.
  • Page 552 CÓPIA NÃO CONTROLADA PICK-UP AND SEPARATION ROLLER RELEASE MECHANISM 2. DETAILED DESCRIPTIONS 2.1 PICK-UP AND SEPARATION ROLLER RELEASE MECHANISM A682500.WMF A682D501.WMF When the paper tray [A] is not inside the paper tray unit, the separation roller [B] is away from the paper feed roller [C], and the pick-up roller [D] stays in the upper position.
  • Page 553 CÓPIA NÃO CONTROLADA PAPER LIFT MECHANISM 2.2 PAPER LIFT MECHANISM A682D502.WMF The paper tray switch [A] detects when the paper tray [B] is placed in the machine. When the machine detects that the paper tray is in the machine, the tray lift motor [C] rotates and the coupling gear [D] on the tray lift motor engages the pin [E] on the lift arm shaft [F].
  • Page 554 CÓPIA NÃO CONTROLADA PAPER LIFT MECHANISM A682D504.WMF When the paper tray is placed in the machine, the pick-up roller [A] lowers. When the top sheet of paper reaches the proper height for paper feed, the paper pushes up the pick-up roller, and the actuator [B] on the pick-up roller supporter activates the lift sensor [C] to stop the tray lift motor.
  • Page 555 CÓPIA NÃO CONTROLADA PAPER END DETECTION 2.3 PAPER END DETECTION A682D503.WMF If there is some paper in the paper tray, the paper end feeler [A] is raised by the paper stack and the paper end sensor [B] is deactivated. When the paper tray runs out of paper, the paper end feeler drops into the cutout [C] in the tray bottom plate and the paper end sensor is activated.

  • Page 556: Paper Height Detection

    CÓPIA NÃO CONTROLADA PAPER HEIGHT DETECTION 2.4 PAPER HEIGHT DETECTION The amount of paper in the tray is Full detected by the combination of two paper height sensors, [A] and [B]. When the amount of 2 paper decreases, the bottom plate pressure lever [C] moves up and the actuator [D] which is mounted on the same drive shaft as the pressure lever rotates.
  • Page 557 CÓPIA NÃO CONTROLADA DIP SWITCHES 3. SERVICE TABLES 3.1 DIP SWITCHES DPS101 Description Default Free run, feed from upper tray Free run, feed from lower tray Free run, feed from upper and lower trays alternately NOTE: 1) Do not use any other settings. 2) To do the free run, proceed as follows: 1.

  • Page 558: Replacement And Adjustment

    CÓPIA NÃO CONTROLADA COVER REPLACEMENT 4. REPLACEMENT AND ADJUSTMENT 4.1 COVER REPLACEMENT A682R500.WMF Right Cover 1. Remove the right cover [A] (2 screws). Rear Cover 1. Remove the rear cover [B] (2 screws). B542 CÓPIA NÃO CONTROLADA...

  • Page 559: Roller Replacement

    CÓPIA NÃO CONTROLADA ROLLER REPLACEMENT 4.2 ROLLER REPLACEMENT 4.2.1 PAPER FEED, SEPARATION, AND PICK-UP ROLLERS A682R501.WMF 1. Remove the paper tray. Pick-up Roller 2. Replace the pick-up roller [A]. Paper Feed Roller 2. Replace the paper feed roller [B] (1 snap ring). Separation Roller 2.

  • Page 560: Tray Motor Replacement

    CÓPIA NÃO CONTROLADA TRAY MOTOR REPLACEMENT 4.3 TRAY MOTOR REPLACEMENT A682R502.WMF 1. Remove the rear cover. 2. Remove the tray motor [A] (1 connector, 3 screws). B542 CÓPIA NÃO CONTROLADA...

  • Page 561: Paper Feed And Relay Clutch Replacement

    CÓPIA NÃO CONTROLADA PAPER FEED AND RELAY CLUTCH REPLACEMENT 4.4 PAPER FEED AND RELAY CLUTCH REPLACEMENT A682R503.WMF 1. Remove the rear cover. 2. Remove the upper paper feed clutch holder [A] (2 screws). 3. Remove the lower paper feed clutch holder [B] (2 screws). 4.

  • Page 562: Paper Feed Unit Replacement

    CÓPIA NÃO CONTROLADA PAPER FEED UNIT REPLACEMENT 4.5 PAPER FEED UNIT REPLACEMENT A682R504.WMF A682R505.WMF 1. Remove the rear cover. 2. Remove the upper and lower paper feed clutch holder. 3. Remove the gear holder. 4. Remove the upper feed clutch [A] or lower feed clutch [B]. 5.

  • Page 563: Upper Paper Feed Unit

    CÓPIA NÃO CONTROLADA PAPER FEED UNIT REPLACEMENT A682R506.WMF A682R507.WMF Upper Paper Feed Unit 6. Remove the docking bracket [A] (1 screw). 7. Remove the vertical transport cover [B] of the copier (1 snap ring). 8. Remove the upper paper feed unit [C] (2 screws, 1 connector). Lower Paper Feed Unit 6.

  • Page 564: Paper End, Tray Lift, And Relay Sensor Replacement

    CÓPIA NÃO CONTROLADA PAPER END, TRAY LIFT, AND RELAY SENSOR REPLACEMENT 4.6 PAPER END, TRAY LIFT, AND RELAY SENSOR REPLACEMENT A682R508.WMF 1. Remove the paper feed unit. Paper End Sensor 2. Replace the paper end sensor [A] (1 connector). Tray Lift Sensor 2.
  • Page 565 CÓPIA NÃO CONTROLADA 1-BIN TRAY B544 CÓPIA NÃO CONTROLADA...
  • Page 566 CÓPIA NÃO CONTROLADA CÓPIA NÃO CONTROLADA...
  • Page 567 CÓPIA NÃO CONTROLADA 1-BIN TRAY B544 TABLE OF CONTENTS 1. OVERALL MACHINE INFORMATION..........1 1.1 SPECIFICATIONS..................1 1.2 MECHANICAL COMPONENT AND DRIVE LAYOUT ........2 1.3 ELECTRICAL COMPONENT LAYOUT ............3 1.4 ELECTRICAL COMPONENT DESCRIPTION..........3 2. DETAILED DESCRIPTIONS ............4 2.1 BASICS OPERATION ..................
  • Page 568 CÓPIA NÃO CONTROLADA CÓPIA NÃO CONTROLADA...

  • Page 569: Specifications

    CÓPIA NÃO CONTROLADA SPECIFICATIONS 1. OVERALL MACHINE INFORMATION 1.1 SPECIFICATIONS A5 lengthwise to A3 Paper Size: HLT to DLT Paper Weight: 60 g/m ~ 105 g/m , 16 lb ~ 28 lb Tray Capacity: 125 sheets (80 g/m , 20 lb) Power Source: 5 Vdc, 24 Vdc (from copier) Power Consumption:...

  • Page 570: Mechanical Component And Drive Layout

    CÓPIA NÃO CONTROLADA MECHANICAL COMPONENT AND DRIVE LAYOUT 1.2 MECHANICAL COMPONENT AND DRIVE LAYOUT B376V500.WMF B376V501.WMF 1. Paper Limit Sensor 5. Paper Sensor 2. Exit Roller 6. Paper Tray 3. Entrance Sensor 7. Tray Motor 4. Entrance Roller B544 CÓPIA NÃO CONTROLADA...

  • Page 571: Electrical Component Layout

    CÓPIA NÃO CONTROLADA ELECTRICAL COMPONENT LAYOUT ELECTRICAL COMPONENT LAYOUT B376V502.WMF 1. Motor Lock Sensor 5. Paper Limit Sensor 2. Main Board 6. Paper Sensor 3. Tray Motor 7. Entrance Sensor 4. Right Cover Switch 8. Paper Indicator 1.4 ELECTRICAL COMPONENT DESCRIPTION Symbol Name Function...

  • Page 572: Detailed Descriptions

    CÓPIA NÃO CONTROLADA BASIC OPERATION 2. DETAILED DESCRIPTIONS 2.1 BASIC OPERATION [E] [B] B376V501.WMF B376V500.WMF When the leading edge of the first sheet of copy paper reaches the copier’s hot roller, the tray motor [A] starts and turns off approximately 0.5 s after the trailing edge of the paper passes through the exit rollers [B].

  • Page 573: Replacement And Adjustment

    CÓPIA NÃO CONTROLADA COVER REMOVAL 3. REPLACEMENT AND ADJUSTMENT 3.1 COVER REMOVAL B376R500.WMF Front Cover 1. Remove the scanner unit if it is at the front. 2. Remove the front cover [A] (1 screw). Upper Cover 1. Remove the scanner unit. 2.

  • Page 574: Paper Sensor Replacement

    CÓPIA NÃO CONTROLADA PAPER SENSOR REPLACEMENT 3.2 PAPER SENSOR REPLACEMENT B376R501.WMF 1. Remove the front cover. 2. Remove the exit guide plate [A] (1 screw). 3. Replace the paper sensor [B] (1 connector). B544 CÓPIA NÃO CONTROLADA...

  • Page 575: Entrance And Paper Limit Sensor Replacement

    CÓPIA NÃO CONTROLADA ENTRANCE AND PAPER LIMIT SENSOR REPLACEMENT 3.3 ENTRANCE AND PAPER LIMIT SENSOR REPLACEMENT B376R502.WMF 1. Remove the front and upper covers. Paper Limit Sensor 2. Replace the paper limit sensor [A] (1 connector). Entrance Sensor 2. Remove the sensor bracket [B] (1 screw, 1 spring). 3.
  • Page 576 CÓPIA NÃO CONTROLADA CÓPIA NÃO CONTROLADA...

  • Page 577: Sheet Finisher

    CÓPIA NÃO CONTROLADA 1000-SHEET FINISHER B408 CÓPIA NÃO CONTROLADA...
  • Page 578 CÓPIA NÃO CONTROLADA CÓPIA NÃO CONTROLADA...
  • Page 579 CÓPIA NÃO CONTROLADA 1000-SHEET FINISHER B408 TABLE OF CONTENTS 1. REPLACEMENT AND ADJUSTMENT ..........1 1.1 MAIN PCB ....................1 1.2 STAPLER UNIT.................... 2 1.3 MOTORS...................... 3 1.3.1 SHIFT MOTOR..................3 1.3.2 STAPLER MOTOR ................3 1.3.3 UPPER TRANSPORT MOTOR AND EXIT MOTOR ......4 1.3.4 LOWER TRANSPORT MOTOR ............
  • Page 580 CÓPIA NÃO CONTROLADA CÓPIA NÃO CONTROLADA...

  • Page 581: Replacement And Adjustment

    CÓPIA NÃO CONTROLADA MAIN PCB 1. REPLACEMENT AND ADJUSTMENT  CAUTION Turn off the main power switch and unplug the machine before beginning any of the procedures in this section. NOTE: This manual uses the following symbols.  : Screws ...

  • Page 582: Stapler Unit

    CÓPIA NÃO CONTROLADA STAPLER UNIT 1.2 STAPLER UNIT 1. Side cover [A] ( x 2) 2. Open exit guide plate [B] 3. Upper side cover [C] ( x 2) B408R102.WMF 4. Front cover support plate [D] ( x 1) 5. Front cover [E] 6.

  • Page 583: Motors

    CÓPIA NÃO CONTROLADA MOTORS 1.3 MOTORS 1.3.1 SHIFT MOTOR 1. Rear cover (!1.1) 2. Shift motor [A] ( x 2,  x 1) B408R123.WMF 1.3.2 STAPLER MOTOR 1. Rear cover (!1.1) 2. Stapler motor [A] ( x 2,  x 1) B408R124.WMF B408 CÓPIA NÃO CONTROLADA...

  • Page 584: Upper Transport Motor And Exit Motor

    CÓPIA NÃO CONTROLADA MOTORS 1.3.3 UPPER TRANSPORT MOTOR AND EXIT MOTOR 1. Rear cover (!1.1) 2. Motor assembly [A] ( x 4,  x 2) 3. Upper transport motor [B] ( x 4) 4. Exit motor [C] ( x 4) B408R112.WMF 1.3.4 LOWER TRANSPORT MOTOR 1.

  • Page 585: Motors And Sensors

    CÓPIA NÃO CONTROLADA MOTORS AND SENSORS 1.4 MOTORS AND SENSORS 1.4.1 PREPARATION 1. Front cover and inner cover (!1.2) 2. Upper side cover [A] ( x 2) 3. Upper tray [B] ( x 1) B408R116.WMF 4. Lower side cover [C] ( x 2) 5.

  • Page 586: Stack Height Sensor

    CÓPIA NÃO CONTROLADA MOTORS AND SENSORS 1.4.2 STACK HEIGHT SENSOR 1. Stack height sensor assembly [A] ( x 2. Stack height sensor [B] ( x 1) B408R121.WMF 1.4.3 STAPLER TRAY PAPER SENSOR 1. Stapler tray paper sensor [A] ( x 1) B408R120.WMF B408 CÓPIA NÃO CONTROLADA...

  • Page 587: Lower Tray Lift Motor

    CÓPIA NÃO CONTROLADA MOTORS AND SENSORS 1.4.4 LOWER TRAY LIFT MOTOR 1. Lower tray lift motor [A] ( x 2,  x 1) B408R119.WMF 1.4.5 STACK FEED-OUT MOTOR 1. Stack feed-out motor [A] ( x 2,  x 1) B408R122.WMF B408 CÓPIA NÃO CONTROLADA...

  • Page 588: Troubleshooting

    CÓPIA NÃO CONTROLADA JAM DETECTION 2. TROUBLESHOOTING 2.1 JAM DETECTION Mode Content Shift Staple Entrance sensor: The entrance sensor does not turn on On check within the normal time after the main " " machine exit sensor turns on Entrance sensor: The entrance sensor does not turn off "...

  • Page 589: Service Tables

    CÓPIA NÃO CONTROLADA DIP SWITCH SETTINGS 3. SERVICE TABLES 3.1 DIP SWITCH SETTINGS The DIP switches should not be set to any combination other than those listed in the table below. SW100 Description Normal operation mode (Default) Packing mode. • Before packing the machine, do the following: Set switch 1 to 1 then back to zero.

  • Page 590: Detailed Descriptions

    CÓPIA NÃO CONTROLADA GENERAL LAYOUT 4. DETAILED DESCRIPTIONS 4.1 GENERAL LAYOUT B408D101.WMF 1. Upper Tray 8. Stapler 2. Upper Tray Exit Roller 9. Stack Feed-out Belt 3. Entrance Roller 10. Positioning Roller 4. Tray Junction Gate 11. Shift Roller 5. Upper Transport Roller 12.

  • Page 591: Electrical Component Layout

    CÓPIA NÃO CONTROLADA ELECTRICAL COMPONENT LAYOUT 4.2 ELECTRICAL COMPONENT LAYOUT B408D102.WMF B408D103.WMF 1. Upper Cover Switch 12. Jogger Fence HP Sensor 2. Paper Limit Sensor 13. Positioning Roller Solenoid 3. Entrance Sensor 14. Stapler HP Sensor 4. Exit Guide Plate Motor 15.
  • Page 592 CÓPIA NÃO CONTROLADA ELECTRICAL COMPONENT LAYOUT B408D104.WMF 22. Tray Junction Gate Solenoid 23. Lower Tray Lift Motor 24. Lower Tray Lower Limit Sensor 25. Stapler Motor 26. Jogger Fence Motor 27. Stack Feed-out Motor 28. Main Board 29. Lower Transport Motor 30.

  • Page 593: Electrical Component Description

    CÓPIA NÃO CONTROLADA ELECTRICAL COMPONENT DESCRIPTION 4.3 ELECTRICAL COMPONENT DESCRIPTION Symbol Name Function Index No. Motors Upper Drives the entrance roller and upper transport Transport rollers. Lower Drives the lower transport rollers and the Transport positioning roller. Jogger Fence Drives the jogger fences. Staple Hammer Drives the staple hammer.
  • Page 594 CÓPIA NÃO CONTROLADA ELECTRICAL COMPONENT DESCRIPTION Symbol Name Function Index No. Positioning Moves the positioning roller. SOL3 Roller Switches Lower Tray Detects when the lower tray is at its upper limit Upper Limit position. Front Door Cuts the dc power when the front door is Safety opened.

  • Page 595: Drive Layout

    CÓPIA NÃO CONTROLADA DRIVE LAYOUT 4.4 DRIVE LAYOUT B408D106.WMF B408D105.WMF B408D107.WMF 1. Exit Motor 6. Lower Tray Lift Motor 2. Upper Transport Motor 7. Stack Feed-out Motor 3. Lower Transport Motor 8. Jogger Motor 4. Shift Motor 9. Stapler Motor 5.

  • Page 596: Junction Gates

    CÓPIA NÃO CONTROLADA JUNCTION GATES 4.5 JUNCTION GATES B408D108.WMF Depending on the finishing mode, the copies are directed up, straight through, or down by the combination of the tray junction gate [A] and stapler junction gate [B]. These gates are controlled by the tray junction gate solenoid [C] and stapler junction gate solenoid [D].

  • Page 597: Upper Tray

    CÓPIA NÃO CONTROLADA UPPER TRAY 4.6 UPPER TRAY B408D109.WMF When the paper limit sensor [A] switches on during feed-out for each of three consecutive sheets of paper, paper overflow is detected. B408 CÓPIA NÃO CONTROLADA...

  • Page 598: Lower Tray Up/Down Mechanisms

    CÓPIA NÃO CONTROLADA LOWER TRAY UP/DOWN MECHANISMS 4.7 LOWER TRAY UP/DOWN MECHANISMS B408D112.WMF The vertical position of the lower tray [A] depends on the height of the copied paper stack on the lower tray. The stack height sensor feeler [B] contacts the top of the stack, and the lower tray lift motor [C] controls the tray height.

  • Page 599: Paper Shift Mechanism

    CÓPIA NÃO CONTROLADA PAPER SHIFT MECHANISM 4.8 PAPER SHIFT MECHANISM B408D110.WMF In the sort/stack mode, the shift roller [A] moves from side to side to separate the sets of copies. The horizontal position of the shift roller is controlled by the shift motor [B] and the shift gear disk [C].

  • Page 600: Jogger Unit Paper Positioning Mechanism

    CÓPIA NÃO CONTROLADA JOGGER UNIT PAPER POSITIONING MECHANISM 4.9 JOGGER UNIT PAPER POSITIONING MECHANISM B408D113.WMF B408D114.WMF In staple mode, each sheet of copy paper is vertically and horizontally aligned when it arrives in the jogger unit. For the vertical paper alignment, the positioning roller solenoid [A] turns on shortly after the stapler tray entrance sensor [B] turns off, and the positioning roller [C] pushes the copy against the bottom of the stack stopper [D].

  • Page 601: Exit Guide Plate

    CÓPIA NÃO CONTROLADA EXIT GUIDE PLATE 4.10 EXIT GUIDE PLATE [B] [C] B408D111.WMF When stacking a large size of paper (such as A3, DLT) in the jogger unit, the leading edge of the paper reaches the exit rollers. To prevent the paper from running into the exit rollers and not being aligned correctly, the exit guide plate [A] is moved up to make a gap between the exit rollers.

  • Page 602: Stapler Mechanism

    CÓPIA NÃO CONTROLADA STAPLER MECHANISM 4.11 STAPLER MECHANISM B408D116.WMF The staple hammer motor [A] drives the staple hammer. The staple sheet sensor [B] detects the leading edge of the staple sheet at the stapling position to prevent the hammer from operating if there are no staples at the stapling position.

  • Page 603: Stapler Unit Movement Mechanism

    CÓPIA NÃO CONTROLADA STAPLER UNIT MOVEMENT MECHANISM 4.12 STAPLER UNIT MOVEMENT MECHANISM B408D117.WMF The stapler motor moves the stapler [A] from side to side. After the start key is pressed, the stapler moves from its home position to the stapling position. If two-staple-position mode is selected, the stapler moves to the front stapling position first, then moves to the rear stapling position.

  • Page 604: Paper Feed-Out Mechanism

    CÓPIA NÃO CONTROLADA PAPER FEED-OUT MECHANISM 4.13 PAPER FEED-OUT MECHANISM B408D118.WMF After the copies have been stapled, the stack feed-out motor [A] starts. The pawl [B] on the stack feed-out belt [C] transports the set of stapled copies up and feeds it to the shift roller.
  • Page 605 CÓPIA NÃO CONTROLADA TWO-TRAY FINISHER B545 CÓPIA NÃO CONTROLADA...
  • Page 606 CÓPIA NÃO CONTROLADA CÓPIA NÃO CONTROLADA...
  • Page 607 CÓPIA NÃO CONTROLADA TWO-TRAY FINISHER B545 TABLE OF CONTENTS 1. REPLACEMENT AND ADJUSTMENT ........... 1 1.1 COVERS ...................... 1 1.1.1 EXTERNAL COVERS................1 1.1.2 INNER COVER..................1 1.2 POSITIONING ROLLER................2 1.3 TRAY 1 EXIT SENSOR ................2 1.4 ENTRANCE SENSOR/STAPLER TRAY ENTRANCE SENSOR ....3 1.5 STAPLER TRAY...................
  • Page 608 CÓPIA NÃO CONTROLADA Tray 1 (Upper Tray) ................21 TRAY 2 (LOWER TRAY) ................... 23 4.5.1 TRAY 1 ....................23 Introduction .................... 23 Normal and sort/stack modes ..............23 Staple mode................... 24 Tray 1 release mechanism..............25 4.5.2 TRAY 2 ....................27 4.5.3 PRE-STACK MECHANISM ...............

  • Page 609: Replacement And Adjustment

    CÓPIA NÃO CONTROLADA COVERS 1. REPLACEMENT AND ADJUSTMENT 1.1 COVERS 1.1.1 EXTERNAL COVERS 1. Top cover [A] ( x4) If the shift tray below is blocking the screw hole, remove the shift tray. 2. Bracket [B] ( x1) 3. Front door [C] 4.

  • Page 610: Positioning Roller

    CÓPIA NÃO CONTROLADA POSITIONING ROLLER 1.2 POSITIONING ROLLER 1. Open the front door. 2. Positioning roller [A] ( x1) 3. Belt [B] B352R103.WMF 1.3 TRAY 1 EXIT SENSOR 1. Top cover (! 1.1.1) 2. Open transport door [A] 3. Bracket [B] ( x1, ( x1) 4.

  • Page 611: Entrance Sensor/Stapler Tray Entrance Sensor

    CÓPIA NÃO CONTROLADA ENTRANCE SENSOR/STAPLER TRAY ENTRANCE SENSOR 1.4 ENTRANCE SENSOR/STAPLER TRAY ENTRANCE SENSOR 1. Entrance sensor bracket [A] ( x1,  x1) 2. Entrance sensor [B] ( x1) 3. Stapler tray entrance sensor bracket [C] ( x1,  x1) 4.

  • Page 612: Upper Stack Height Sensors/Tray 1 Upper Limit Switch

    CÓPIA NÃO CONTROLADA UPPER STACK HEIGHT SENSORS/TRAY 1 UPPER LIMIT SWITCH 1.6 UPPER STACK HEIGHT SENSORS/TRAY 1 UPPER LIMIT SWITCH B352R201.WMF B352R109.WMF B352R110.WMF 1. External covers (! 1.1.1) 2. Place one hand under tray 2 (the lower tray), press in on the gear [A] to release the tray, and then support it with your hand as it descends.

  • Page 613: Exit Guide Plate Motor

    CÓPIA NÃO CONTROLADA EXIT GUIDE PLATE MOTOR 1.7 EXIT GUIDE PLATE MOTOR 1. Tray 1 back fence (! 1.6) 2. Exit guide plate motor [A] ( x2,  x1) Disengage the shaft of the exit guide plate motor from the ring. B352R111.WMF 1.8 LIFT MOTORS 1.
  • Page 614 CÓPIA NÃO CONTROLADA LIFT MOTORS 4. Motor bracket [C] ( x3,  x 2) B352R204.WMF 5. Tray 1 lift motor [D] ( x2, drive belt) 6. Tray 2 lift motor [E] ( x2, drive belt) B352R205.WMF B545 CÓPIA NÃO CONTROLADA...

  • Page 615: Lower Exit Sensor

    CÓPIA NÃO CONTROLADA LOWER EXIT SENSOR 1.9 LOWER EXIT SENSOR 1. Front door, external and internal covers. (! 1.1) 2. Exit guide plate motor (! 1.7) 3. Guide plate [A] ( x1) Pull the shaft toward you through the round hole. B352R112.WMF 4.

  • Page 616: Lower Stack Height Sensors

    CÓPIA NÃO CONTROLADA LOWER STACK HEIGHT SENSORS 1.10 LOWER STACK HEIGHT SENSORS 1. Stapler tray (! 1.5) 2. Sensor bracket [A] ( x1,  x2) 3. Bracket [B] ( x1) 4. Feeler [C] 5. Lower stack height sensors [D] B352R116.WMF 1.11 TRAY 2 SHUNT POSITION SENSOR 1.

  • Page 617: Stapler Unit

    CÓPIA NÃO CONTROLADA STAPLER UNIT 1.12 STAPLER UNIT 1. Open the front door 2. Stapler unit [A] ( x1,  x2) Hold the stapler holder [B] with one hand as you remove the stapler. Do not twist or rotate the stapler bracket as you remove it.

  • Page 618: Tray 1 Interior

    CÓPIA NÃO CONTROLADA TRAY 1 INTERIOR 1.14 TRAY 1 INTERIOR 1.14.1 TRAY 1 COVERS 1. Tray 1 [A] ( x1) 2. Rear tray cover [B] ( x1) 3. Front tray cover [C] ( x1) 4. Bottom tray cover [D] ( x2) 5.

  • Page 619: Tray Shift Sensors And Tray Release Sensor

    CÓPIA NÃO CONTROLADA TRAY 1 INTERIOR 1.14.2 TRAY SHIFT SENSORS AND TRAY RELEASE SENSOR 1. Tray 1 covers (! 1.14.1) 2. Gear disk [A] ( x1) 3. Tray shift sensors [B] ( x1 each). 4. Tray release sensor [C] ( x1) B352R210.WMF 1.14.3 TRAY 1 SHIFT MOTOR 1.

  • Page 620: Finisher Main Board

    CÓPIA NÃO CONTROLADA FINISHER MAIN BOARD 1.15 FINISHER MAIN BOARD 1. Rear cover (! 1.1.1) 2. Main PCB [A] ( x 6, All ) B352R206.WMF 1.16 PUNCH HOLE POSITION ADJUSTMENT To adjust the position of the punch holes in the paper feed direction, use the appropriate SP mode.

  • Page 621: Troubleshooting

    CÓPIA NÃO CONTROLADA TIMING CHARTS 2. TROUBLESHOOTING 2.1 TIMING CHARTS 2.1.1 A4(S)/LT(S) SHIFT MODE WITH PUNCH – TRAY 1 B352D501.WMF B545 CÓPIA NÃO CONTROLADA...

  • Page 622: A4(S)/Lt(S) Shift Mode With Punch - Tray 2

    CÓPIA NÃO CONTROLADA TIMING CHARTS 2.1.2 A4(S)/LT(S) SHIFT MODE WITH PUNCH – TRAY 2 B352D502.WMF B545 CÓPIA NÃO CONTROLADA...

  • Page 623: A4(S)/Lt(S) Staple Mode With Punch

    CÓPIA NÃO CONTROLADA TIMING CHARTS 2.1.3 A4(S)/LT(S) STAPLE MODE WITH PUNCH B352D503.WMF B545 CÓPIA NÃO CONTROLADA...

  • Page 624: Jam Detection

    CÓPIA NÃO CONTROLADA JAM DETECTION 2.2 JAM DETECTION Mode Content Shift Staple Entrance sensor: The entrance sensor does not turn on within On check 399 pulse after the main machine exit sensor turns off. Entrance sensor: The entrance sensor does not turn off within Off check 34 pulse after it turns on.

  • Page 625: Service Tables

    CÓPIA NÃO CONTROLADA DIP SWITCH SETTINGS 3. SERVICE TABLES 3.1 DIP SWITCH SETTINGS The DIP switches should not be set to any combination other than those described in the table below. DPS101 Mode Description Default. Free run. No paper. Factory shipping. See the note below.

  • Page 626: Detailed Descriptions

    CÓPIA NÃO CONTROLADA GENERAL LAYOUT 4. DETAILED DESCRIPTIONS 4.1 GENERAL LAYOUT B352D118.WMF 1 Upper junction gate 5 Stapler 2 Punch unit (option) 6 Stapler tray 3 Stapler junction gate 7 Tray 2 4 Pre-stack tray 8 Tray 1 Tray junction gate: Directs paper either to the upper or lower exit. In staple mode, the stack always goes out to the lower exit.

  • Page 627: Drive Layout

    CÓPIA NÃO CONTROLADA DRIVE LAYOUT DRIVE LAYOUT B352D104.WMF B352D103.WMF 1. Tray 1 lift motor 10. Lower transport motor 2. Entrance roller 11. Pre-stack motor 3. Tray 2 lift motor 12. Upper transport motor 4. Upper exit roller 13. Punch motor 5.

  • Page 628: Junction Gates

    CÓPIA NÃO CONTROLADA JUNCTION GATES 4.3 JUNCTION GATES The two junction gates can direct paper to three destinations. In sort/stack mode for tray 1, the tray junction solenoid [A] is on, and the copies go to the upper exit (tray 1 is at the upper exit for sort/stack mode). B302D506.WMF In sort/stack mode for tray 2, both the tray junction gate solenoid [A] and stapler junction gate solenoid...

  • Page 629: Tray Shifting

    CÓPIA NÃO CONTROLADA TRAY SHIFTING 4.4 TRAY SHIFTING 4.4.1 TRAY SHIFT MECHANISMS B352D106.WMF Tray 1 (Upper Tray) In sort/stack mode, tray 1 [A] moves from side to side to separate the printed sets. The tray 1 shift motor [B], inside the shift tray, controls the horizontal position of tray 1 through the timing belt [C] and gear disk [D].

  • Page 630: Tray 2 (Lower Tray)

    CÓPIA NÃO CONTROLADA TRAY SHIFTING Tray 2 (Lower Tray) B352D105.WMF In sort/stack mode, tray 2 [A] moves from side to side to separate the sets of prints. The shift mechanism for tray 2 is similar to that used for tray 1. However, when the tray 2 shift motor [B] turns on, the arm [D] moves the entire end fence [C] from side to side (not just the tray).

  • Page 631: Introduction

    CÓPIA NÃO CONTROLADA TRAY UP/DOWN MECHANISMS 4.5 TRAY UP/DOWN MECHANISMS 4.5.1 TRAY 1 B352D204.WMF Introduction The tray 1 lift motor [A] controls the vertical position of tray 1 [B] through gears and timing belts [C]. Normal and sort/stack modes When the main switch is turned on, the tray is initialized at the upper position. To do this, the tray is moved up until upper stack height sensor 1 [D] is de-actuated.

  • Page 632: Staple Mode

    CÓPIA NÃO CONTROLADA TRAY UP/DOWN MECHANISMS Staple mode B352D204.WMF In staple mode, stapled stacks can be delivered to either tray, but they can only go to the lower exit. So, if tray 1 is selected, tray 1 [A] moves down to the lower paper exit.

  • Page 633: Tray 1 Release Mechanism

    CÓPIA NÃO CONTROLADA TRAY UP/DOWN MECHANISMS Tray 1 release mechanism When tray 1 is selected for staple mode, tray 1 must be moved down to the lower paper exit. However, to move past the sensors at the lower exit, the tray must be moved away from the finisher.
  • Page 634 CÓPIA NÃO CONTROLADA TRAY UP/DOWN MECHANISMS When tray 1 is at the lower exit, the tray lock solenoid [F] is on, and the lever [G] locks the tray. This prevents the user from moving the tray out of position (the first tray has some play when it is at the lower position).

  • Page 635: Tray 2

    CÓPIA NÃO CONTROLADA TRAY UP/DOWN MECHANISMS 4.5.2 TRAY 2 Overflow condition Multi Tray Staple Mode Normal Mode B352D500.WMF B352D109.WMF The tray 2 lift motor [A] controls the vertical position of tray 2 [B] through gears and timing belts [C]. The paper height detection is the same as for tray 1. When the tray lowers during printing, the tray is judged to be overflowing when the tray 2 overflow sensor 1 [D] is off and the tray 2 overflow sensor-2 [F] is on (see ‘Normal Mode’...

  • Page 636: Pre-Stack Mechanism

    CÓPIA NÃO CONTROLADA TRAY UP/DOWN MECHANISMS 4.5.3 PRE-STACK MECHANISM 00MTY.WMF This feature is available only when using A4 L, LT L, and B5 L. During stapling, the main machine must wait. This mechanism reduces the wait by holding the first two sheets of a job while the previous job is still being stapled. It only works during the second and subsequent sets of a multi-set print job.

  • Page 637: Jogger Unit Paper Positioning Mechanism

    CÓPIA NÃO CONTROLADA JOGGER UNIT PAPER POSITIONING MECHANISM 4.6 JOGGER UNIT PAPER POSITIONING MECHANISM B352D110.WMF In staple mode, each sheet of copy paper is vertically and horizontally aligned when it arrives in the stapler tray. Vertical Paper Alignment After the trailing edge of the paper passes the stapler tray entrance sensor [A], the positioning roller solenoid [B] is energized for a specified time to push the positioning roller [C] into contact with the paper.

  • Page 638: Stapler Mechanism

    CÓPIA NÃO CONTROLADA STAPLER MECHANISM 4.7 STAPLER MECHANISM 4.7.1 STAPLER MOVEMENT B352D112.WMF B352D113.WMF The stapler can be moved from side to side or rotated according to the requirements of the selected stapling mode. Stapler Rotation After the start key is pressed, the stapler rotation motor [A] rotates the staple unit [B] until the stapler rotation HP sensor [C] is activated.

  • Page 639: Stapler

    CÓPIA NÃO CONTROLADA STAPLER MECHANISM 4.7.2 STAPLER B352D208.WMF The staple hammer is driven by the stapler hammer motor [A] inside the stapler. As soon as the paper stack is aligned, the staple hammer motor starts. When stapling is finished, the staple hammer HP sensor [B] is turned on, and the staple hammer motor then stops.

  • Page 640: Feed Out And Transport

    CÓPIA NÃO CONTROLADA STAPLER MECHANISM 4.7.3 FEED OUT AND TRANSPORT B352D115.WMF B352D114.WMF When stapling starts, the exit guide plate motor [A] switches on and opens the exit guide plate [B], so that the stapled stack can exit to the tray. The exit guide plate sensor [C] detects when to switch off the exit guide plate motor.

  • Page 641: Punch Unit (Optional)

    CÓPIA NÃO CONTROLADA PUNCH UNIT (OPTIONAL) 4.8 PUNCH UNIT (OPTIONAL) The punch unit punches holes in printed sheets, one by one. The punch unit is provided with a new punch mechanism to improve the accuracy of punching. B352D116.WMF B377D101.WMF 4.8.1 PUNCH DRIVE MECHANISM The punch drive mechanism is driven by the punch motor [A].

  • Page 642: Punch Waste Collection

    CÓPIA NÃO CONTROLADA PUNCH UNIT (OPTIONAL) 4.8.2 PUNCH WASTE COLLECTION B352D117.WMF Waste punchouts are collected in the punch waste hopper [A] below the punch unit inside the finisher. When the top of the punchout waste in the hopper reaches and actuates the hopper sensor [B], a message will be displayed on the operation panel after the current job is completed.

  • Page 643: Bridge Unit

    CÓPIA NÃO CONTROLADA BRIDGE UNIT B538 CÓPIA NÃO CONTROLADA...
  • Page 644 CÓPIA NÃO CONTROLADA CÓPIA NÃO CONTROLADA...
  • Page 645 CÓPIA NÃO CONTROLADA BRIDGE UNIT B538 TABLE OF CONTENTS 1 OVERALL INFORMATION .............. 1 1.1 MECHANICAL COMPONENT LAYOUT............1 1.2 ELECTRICAL COMPONENT LAYOUT ............2 1.3 DRIVE LAYOUT ................... 3 2 DETAILED SECTION DESCRIPTIONS ........... 4 2.1 ORIGINAL SIZE DETECTION..............4 2.2 PICK-UP AND SEPARATION ..............
  • Page 646 CÓPIA NÃO CONTROLADA CÓPIA NÃO CONTROLADA...

  • Page 647: Overall Information

    CÓPIA NÃO CONTROLADA MECHANICAL COMPONENT LAYOUT 1. OVERALL INFORMATION 1.1 MECHANICAL COMPONENT LAYOUT B387V103.WMF 1. Separation roller 6. Original exit roller 2. Original feed belt 7. 2nd transport roller 3. Pick-up roller 8. Original exposure guide 4. Original entrance guide 9.

  • Page 648: Electrical Component Layout

    CÓPIA NÃO CONTROLADA ELECTRICAL COMPONENT LAYOUT 1.2 ELECTRICAL COMPONENT LAYOUT B387V101.WMF 1. DF feed clutch 8. Original length sensor 1 2. Feed cover open sensor 9. Original trailing edge sensor 3. DF pick-up solenoid 10. Original width sensor 1 4. DF transport motor 11.

  • Page 649: Drive Layout

    CÓPIA NÃO CONTROLADA DRIVE LAYOUT 1.3 DRIVE LAYOUT B387V102.WMF 1. DF feed clutch 5. Separation roller 2. DF transport motor 6. 1st transport roller 3. 2nd transport roller 7. Original feed belt 4. Exit roller 8. Pick-up roller B538 CÓPIA NÃO CONTROLADA...

  • Page 650: Detailed Section Descriptions

    CÓPIA NÃO CONTROLADA ORIGINAL SIZE DETECTION 2. DETAILED SECTION DESCRIPTIONS 2.1 ORIGINAL SIZE DETECTION B387V101.WMF The DF uses two width sensors (width sensor 1 [A] and width sensor 2 [B]) to detect the original width, and two length sensors (length sensor 1 [C] and length sensor 2 [D]) to detect the original length.
  • Page 651 CÓPIA NÃO CONTROLADA ORIGINAL SIZE DETECTION Original Original Length 1 Length 2 A3 (297 x 420) B4 (257 x 364) A4 SEF (210 x 297) A4 LEF (297 x 210) B5 SEF (182 x 257) B5 LEF (257 x 182) A5 SEF (148 x 210) A5 LEF (210 x 148) 11"...

  • Page 652: Pick-Up And Separation

    CÓPIA NÃO CONTROLADA PICK-UP AND SEPARATION 2.2 PICK-UP AND SEPARATION B387D102.WMF B387D106.WMF An FRR (feed and reverse roller) system is used. Setting original(s) onto the feed table lifts the original set sensor feeler [A], causing the original set sensor [B] to issue a signal informing the main CPU that the DF is ready to start feeding.

  • Page 653: Original Transport And Exit Mechanism

    CÓPIA NÃO CONTROLADA ORIGINAL TRANSPORT AND EXIT MECHANISM 2.3 ORIGINAL TRANSPORT AND EXIT MECHANISM B387V104.WMF When the leading edge of the original reaches the registration sensor at [A], the DF transport motor turns off. After a short time the DF transport motor turns on again. The original is fed past the DF exposure glass [B], where it is scanned.

  • Page 654: Stamp

    CÓPIA NÃO CONTROLADA STAMP 2.4 STAMP B387D103.WMF This function is only for fax mode. The fax unit includes the stamp. The stamp solenoid [A] is located between the 2nd transport roller [B] and the exit roller [C]. The copier controls this solenoid directly. When the original reaches the stamp position, the DF transport motor stops.

  • Page 655: Timing Charts

    CÓPIA NÃO CONTROLADA TIMING CHARTS 2.5 TIMING CHARTS 2.5.1 A3 B387D001.WMF B538 CÓPIA NÃO CONTROLADA...

  • Page 656: A3, Stamp Mode

    CÓPIA NÃO CONTROLADA TIMING CHARTS 2.5.2 A3, STAMP MODE B387D002.WMF B538 CÓPIA NÃO CONTROLADA...

  • Page 657: Jam Detection

    CÓPIA NÃO CONTROLADA JAM DETECTION 2.6 JAM DETECTION JAM 1: If the registration sensor fails to turn on within x ms after the DF transport motor comes on to feed the original from the original tray. = (114 x 1.1)/original speed + 2,000 ms JAM 2: If the registration sensor fails to turn off within x ms after the DF transport motor comes on to feed the original from the original tray.

  • Page 658: Overall Electrical Circuit

    CÓPIA NÃO CONTROLADA OVERALL ELECTRICAL CIRCUIT 2.7 OVERALL ELECTRICAL CIRCUIT The DF CPU controls the DF feed motor, DF feed clutch, DF pick-up solenoid, and stamp solenoid. The DF CPU also monitors all sensors and provides updated status when prompted at regular intervals by the mainframe, which may then take action based on this information.

  • Page 659: Free Run

    CÓPIA NÃO CONTROLADA FREE RUN 2.8 FREE RUN You can use DIP switch 100 (on the DF control board) to carry out a one-sided free run. Bits Mode Normal FR: Free run Procedure 1. Set bit 1 and/or bit 2 on SW100 (on the DF control board) to ON. 2.

  • Page 660: Replacement And Adjustment

    CÓPIA NÃO CONTROLADA EXTERIOR COVERS 3. REPLACEMENT AND ADJUSTMENT 3.1 EXTERIOR COVERS 3.1.1 REAR COVER 1. Lift the DF. 2. Unhook the three latches [A] in the order marked on the DF body. 3. Close the DF. 4. Open the DF feed cover [B]. 5.

  • Page 661: Df Feed Cover

    CÓPIA NÃO CONTROLADA FEED UNIT 3.1.5 DF FEED COVER 1. Rear cover (% 3.1.1) 2. Original table (% 1.1.2) 3. Front cover (% 1.1.3) 4. Clip [A] 5. Strap [B] ( x 1) 6. DF feed cover [C] ( x 2) B387R110.WMF 3.2 FEED UNIT 1.

  • Page 662: Pick-Up Roller

    CÓPIA NÃO CONTROLADA PICK-UP ROLLER 3.4 PICK-UP ROLLER B387R102.WMF 1. Feed unit (% 1.2) 2. Remove 2 clip rings and 1 bushing [A] 3. Pull the shaft [B] part way out at the gear end, so that the pick-up roller [C] can be taken off.

  • Page 663: Original Sensors (Width, Length, Trailing Edge)

    CÓPIA NÃO CONTROLADA ORIGINAL SENSORS (WIDTH, LENGTH, TRAILING EDGE) 3.6 ORIGINAL SENSORS (WIDTH, LENGTH, TRAILING EDGE) B387R107.WMF B387R108.WMF 1. Original table (% 1.1.2) 2. Sensor platform [A] ( x 3). 3. Length sensors [B], [C] ( x 1 on each sensor) NOTE: Replace both sensors at the same time, together with the wiring and connectors.

  • Page 664: Original Set Sensor

    CÓPIA NÃO CONTROLADA ORIGINAL SET SENSOR 3.7 ORIGINAL SET SENSOR B387R109.WMF 1. Original entrance guide (% 1.1.4) 2. Sensor bracket [A] ( x 1) 3. Original set sensor [B] ( x 1) 3.8 TRANSPORT MOTOR B387R111.WMF 1. Rear cover (% 3.1.1) 2.

  • Page 665: Df Cover Open Sensor/Feed Clutch/Rom/Df Drive Board

    CÓPIA NÃO CONTROLADA DF COVER OPEN SENSOR/FEED CLUTCH/ROM/DF DRIVE BOARD 3.9 DF COVER OPEN SENSOR/FEED CLUTCH/ROM/DF DRIVE BOARD B387R199.WMF Exterior 1. Rear cover (% 3.1.1) Feed Cover Open Sensor 2. Sensor bracket [A] ( x 1) 3. Feed cover open sensor [B] ( x 1) Feed Clutch 2.

  • Page 666: Registration Sensor

    CÓPIA NÃO CONTROLADA REGISTRATION SENSOR 3.10 REGISTRATION SENSOR B387R113.WMF 1. DF feed cover (% 1.1.5) 2. Original entrance guide (% 1.1.4) 3. Outer turn guide [A] ( x 2) 4. Pop out the inner turn guide [B], and remove the registration sensor [C] ( x 3.11 PICK-UP SOLENOID B387R112.WMF 1.

  • Page 667: Stamp Solenoid

    CÓPIA NÃO CONTROLADA STAMP SOLENOID 3.12 STAMP SOLENOID B387R114.WMF 1. Rear cover (% 3.1.1) 2. Disconnect the stamp solenoid connector. NOTE: Pull out the small connector piece from the large connector. (The large connector itself cannot fit through the hole in the frame.) 3.
  • Page 668 CÓPIA NÃO CONTROLADA CÓPIA NÃO CONTROLADA...
  • Page 669 CÓPIA NÃO CONTROLADA PRINTER OPTION B548 CÓPIA NÃO CONTROLADA...
  • Page 670 CÓPIA NÃO CONTROLADA CÓPIA NÃO CONTROLADA...
  • Page 671 CÓPIA NÃO CONTROLADA PRINTER OPTION B548 TABLE OF CONTENTS 1. INSTALLATION................1 1.1 ACCESSORY CHECK ................. 1 1.2 PRINTER INSTALLATION PROCEDURE............ 2 1.2.1 CONTROLLER BOARD AND HDD REMOVAL........2 1.2.2 PRINTER CONTROLLER INSTALLATION ......... 3 Paper Limit Sensor Installation ..............4 Paper Sensor Installation.................
  • Page 672 CÓPIA NÃO CONTROLADA Infrastructure Mode................38 4.4.3 SECURITY FEATURES ..............39 Using the SSID in Ad hoc mode ............39 4.4.4 WIRELESS LAN TROUBLESHOOTING NOTES ......40 Communication Status................40 Channel Settings ................... 40 Troubleshooting Procedure..............41 4.5 BLUETOOTH....................42 4.5.1 SPECIFICATIONS................

  • Page 673: Installation

    CÓPIA NÃO CONTROLADA ACCESSORY CHECK 1. INSTALLATION 1.1 ACCESSORY CHECK Check the accessories in the box against the following list: Description Q’ty Note Paper Sensor Key Tops - Printer English (1 set), Universal (1 set) Key Tops - Scanner English (1 set), Universal (1 set) Paper Limit Sensor Unit Tapping Screw - M3x8 To secure the paper limit sensor unit...

  • Page 674: Printer Installation Procedure

    CÓPIA NÃO CONTROLADA PRINTER INSTALLATION PROCEDURE 1.2 PRINTER INSTALLATION PROCEDURE All procedures require removal of the controller board from the machine. Some procedures also require removal of the controller board.  CAUTION Switch the main machine off and unplug the main machine power cord before starting any procedure described in these instructions.

  • Page 675: Printer Controller Installation

    CÓPIA NÃO CONTROLADA PRINTER INSTALLATION PROCEDURE 1.2.2 PRINTER CONTROLLER INSTALLATION  CAUTION Unplug the main machine power cord before starting the following procedure. B548I110.WMF 1. Remove the controller board. (!1.2.1) 2. Install the printer ROM DIMM [A] in the inside slot of the controller board. 3.

  • Page 676: Paper Limit Sensor Installation

    CÓPIA NÃO CONTROLADA PRINTER INSTALLATION PROCEDURE Paper Limit Sensor Installation B548I901.WMF B548I902.WMF NOTE: If the optional bridge unit is installed, you cannot install the paper limit sensor. Go to the next section. 1. Peel off the black tape [A] from the anti-static brush [B], then pull out the cable [C].

  • Page 677: Paper Sensor Installation

    CÓPIA NÃO CONTROLADA PRINTER INSTALLATION PROCEDURE Paper Sensor Installation B548I903.WMF B548I904.WMF NOTE: Install the paper sensor only if the optional Bridge Unit has been installed. If the bridge unit is not installed, go to the next section. 1. Remove the connector cover [A] and bridge unit [B] ( x 2,  x 2). 2.

  • Page 678: Operation Panel Keytops

    CÓPIA NÃO CONTROLADA PRINTER INSTALLATION PROCEDURE Operation Panel Keytops Copy Printer Scanner B548I905.WMF 1. Remove the bottom cap [A]. 2. Install the “Printer” and “Scanner” keys in the 4th and 5th slots. NOTE: Correct order, reading from top to bottom: •...

  • Page 679: Postscript 3 (G354-17)

    CÓPIA NÃO CONTROLADA POSTSCRIPT 3 (G354-17) 1.3 POSTSCRIPT 3 (G354-17)  CAUTION Unplug the main machine power cord before starting the following procedure. B548I102.WMF NOTE: To install the Postscript 3 option, the Printer Option must be installed first. (!1.2.2) 1. Remove the controller board. (!1.2.1) 2.

  • Page 680: Mb Memory (G331)

    CÓPIA NÃO CONTROLADA 128 MB MEMORY (G331) 1.4 128 MB MEMORY (G331) B548I107.WMF  CAUTION Unplug the main machine power cord before starting the following procedure. NOTE: Only one optional memory DIMMs are available: 128 MB (G331). It can be installed in the one available slot (only one can be installed).

  • Page 681: Nib (B525)

    CÓPIA NÃO CONTROLADA NIB (B525) 1.5 NIB (B525) B548I106.WMF  CAUTION Unplug the main machine power cord before starting the following procedure. NOTE: To install the NIB option, the Printer Option must be installed first. 1. Remove the controller board and HDD unit (! 1.2.1). 2.

  • Page 682: Ieee 1394 Firewire (G336)

    CÓPIA NÃO CONTROLADA IEEE 1394 FIREWIRE (G336) 1.6 IEEE 1394 FIREWIRE (G336) B548I105.WMF  CAUTION Unplug the main machine power cord before starting the following procedure. NOTE: To install the IEEE1394 option, the Printer Option must be installed first. (!1.2.2) Only one slot is available for the interface option. You can install only one printer interface option at a time: IEEE 1394, USB 2.0, IEEE 802.11b, or Bluetooth.
  • Page 683 CÓPIA NÃO CONTROLADA IEEE 1394 FIREWIRE (G336) UP Mode Settings for IEEE 1394 Enter the UP mode and follow the procedure below to perform the initial interface settings for IEEE 1394. These settings take effect every time the machine is powered on.

  • Page 684: Usb 2.0 (B525)

    CÓPIA NÃO CONTROLADA USB 2.0 (B525) 1.7 USB 2.0 (B525) B548I104.WMF  CAUTION Unplug the main machine power cord before starting the following procedure. NOTE: To install the USB 2.0 option, the Printer Option must be installed first. (!1.2.2) Only one slot is available for the interface option. You can install only one printer interface option at a time: IEEE 1394, USB 2.0, IEEE 802.11b, or Bluetooth.
  • Page 685 CÓPIA NÃO CONTROLADA USB 2.0 (B525) USB SP Settings The following SP commands are available. However, only one setting may require adjustment and this setting should be performed only if the customer is experiencing USB data transmission errors. NOTE: Do not change the settings marked “DFU”. These settings are for design and factory use only.

  • Page 686: Ieee 802.11B B515 (Wireless Lan)

    CÓPIA NÃO CONTROLADA IEEE 802.11B B515 (WIRELESS LAN) 1.8 IEEE 802.11B B515 (WIRELESS LAN) B548I108.WMF  CAUTION Unplug the main machine power cord before starting the following procedure. NOTE: To install the IEEE 801.11b option, the Printer Option B548 must be installed first.
  • Page 687 CÓPIA NÃO CONTROLADA IEEE 802.11B B515 (WIRELESS LAN) B548I109.WMF 6. Pull off the edge connector protector [A] off the card and discard it. 7. With the card label facing left, insert the card [B] into the PCI slot. 8. Use the Velcro pads to install the antennas [C] on the left rear corner of the machine.
  • Page 688 CÓPIA NÃO CONTROLADA IEEE 802.11B B515 (WIRELESS LAN) UP Mode Settings for Wireless LAN Enter the UP mode and follow the procedure below to perform the initial interface settings for IEEE 802.11b. These settings take effect every time the machine is powered on.
  • Page 689 CÓPIA NÃO CONTROLADA IEEE 802.11B B515 (WIRELESS LAN) 11. Transmission Speed. Press the Next button to display more settings, then select the transmission speed for the mode: Auto, 11 Mbps, 5.5 Mbps, 2 Mbps, 1 Mbps (default: Auto). This setting should match the distance between the closest machine or access point, depending on which mode is selected.

  • Page 690: Bluetooth (G354-04)

    CÓPIA NÃO CONTROLADA BLUETOOTH (G354-04) 1.9 BLUETOOTH (G354-04) B548I108.WMF  CAUTION Unplug the main machine power cord before starting the following procedure. NOTE: To install the Bluetooth option, the Printer Option B548 must be installed first. (!1.2.2) Only one slot is available for the interface option. You can install only one printer interface option at a time: IEEE 1394, USB 2.0, or IEEE 802.11b, or Bluetooth.
  • Page 691 CÓPIA NÃO CONTROLADA BLUETOOTH (G354-04) B548I111.WMF 6. Insert the Bluetooth card [A] into the slot. 7. Press the antenna [B] to extend it. 8. Attach the antenna cap [C]. B548 CÓPIA NÃO CONTROLADA...

  • Page 692: Check All Connections

    CÓPIA NÃO CONTROLADA CHECK ALL CONNECTIONS 1.10 CHECK ALL CONNECTIONS 1. Plug in the power cord and turn on the main switch. 2. Enter the printer user mode and print the configuration page. User Tools> Printer Settings> List Test Print> Config. Page NOTE: The same data can also be printed by executing SP1-004 –...

  • Page 693: Troubleshooting

    CÓPIA NÃO CONTROLADA CONTROLLER ERRORS 2. TROUBLESHOOTING 2.1 CONTROLLER ERRORS Refer to section 4.1 of the main unit service manual for descriptions on SC code information because the GW architecture includes controller SC codes in the main unit SC code table. B548 CÓPIA NÃO CONTROLADA...

  • Page 694: Service Tables

    CÓPIA NÃO CONTROLADA SCANNER SERVICE MODE 3. SERVICE TABLES 3.1 SCANNER SERVICE MODE 3.1.1 SCANNER PROGRAM MODE TABLE Service Table Key Notation: What it means [range / default / step]: Example: [-9 ~ +9 / +3.0 / 0.1 mm step]. The setting can be adjusted in the range ±9, value reset to +3.0 after an NVRAM reset, and the value can be changed in 0.1 mm steps with each key press.
  • Page 695 CÓPIA NÃO CONTROLADA SCANNER SERVICE MODE Mode Number Function and [Setting] 2002 [Text (Print) Mode Settings] MTF Filter Coefficient Selects the MTF filter coefficient in the main (Main scan) scan direction for Text mode. Select a higher number for a stronger filter. If this is “0”, the MTF filter is not applied.
  • Page 696 CÓPIA NÃO CONTROLADA SCANNER SERVICE MODE Mode Number Function and [Setting] 2002 Independent Dot Erase Selects the independent dot erase level. With a larger SP setting, more dots are detected as independent dots and erased. If this is “0”, independent dot erase is disabled. [0-7 / 0 / 1 step] Unevenness correction Selects whether the unevenness correction is...
  • Page 697 CÓPIA NÃO CONTROLADA SCANNER SERVICE MODE Mode Number Function and [Setting] [0-255 / 128 / 1 step] 2003 Brightness – Notch 3 Contrast – Notch 3 Adjusts the image density for each image density level for Text (OCR) mode when using binary picture processing mode.
  • Page 698 CÓPIA NÃO CONTROLADA SCANNER SERVICE MODE Mode Number Function and [Setting] 2004 Contrast – Notch 7 [0-255 / 128 / 1 step] Threshold Level – Notch 7 [0-255 / 128 / 1 step] Brightness – Notch 6 [0-255 / 128 / 1 step] Contrast –...
  • Page 699 CÓPIA NÃO CONTROLADA SCANNER SERVICE MODE Mode Number Function and [Setting] 2005 Contrast – Notch 7 [0-255 / 128 / 1 step] Threshold Level – Notch 7 [0-255 / 128 / 1 step] Brightness – Notch 6 [0-255 / 128 / 1 step] Contrast –...
  • Page 700 CÓPIA NÃO CONTROLADA SCANNER SERVICE MODE Mode Number Function and [Setting] 2006 Brightness – Notch 7 Adjusts the image density for each image density level when using the grayscale processing mode. [0-255 / 98 / 1 step] Contrast – Notch 7 [0-255 / 98 / 1 step] Threshold Level –...
  • Page 701 CÓPIA NÃO CONTROLADA SCANNER SERVICE MODE Mode Number Function and [Setting] 9001 Sysop Bit switches for debugging. DFU Dapp Rapp Hpim B548 CÓPIA NÃO CONTROLADA...

  • Page 702: Details

    CÓPIA NÃO CONTROLADA ETHERNET BOARD 4. DETAILS 4.1 ETHERNET BOARD 4.1.1 ETHERNET BOARD LAYOUT EEPROM PHY DP83843 25 MHz Filter Module Connector LAN I/F B548D002.WMF The Ethernet board is provided as a standard feature of this machine. Function Blocks Description PHY (Physical Layer Device) Completely standardized physical layer device for the functions of each device in the network.

  • Page 703: Ethernet Board Operation

    CÓPIA NÃO CONTROLADA ETHERNET BOARD 4.1.2 ETHERNET BOARD OPERATION The NIB is a standard IEEE802.3u type which implements 10/100Mbps auto negotiation. System initialization sets the network for 10Mbps/100Mbps. LED 2 LED 1 B548D003.WMF LED 1 (Green) Indicates the link status: Link Safe Link Fail LED 2 (Orange)

  • Page 704: Ieee1394 Board (Firewire)

    CÓPIA NÃO CONTROLADA IEEE1394 BOARD (FIREWIRE) 4.2 IEEE1394 BOARD (FIREWIRE) 4.2.1 OVERVIEW An IEEE1394 interface board is available as an option for this machine to provide high speed connectivity through what is commonly called Firewire or i.LINK (Sony). Some important advantages of Firewire are: •...
  • Page 705 CÓPIA NÃO CONTROLADA IEEE1394 BOARD (FIREWIRE) When the host computer powers up, it queries all the devices connected to the bus and assigns each one an address, a process called enumeration. Here are some general features of Firewire: • Firewire is Plug-and-Play. •...

  • Page 706: Usb

    CÓPIA NÃO CONTROLADA 4.3 USB 4.3.1 SPECIFICATIONS USB connectivity is provided as an option for this machine. Interface: USB 1.1, USB 2.0 Data rates: 480 Mbps (high speed), 12 Mbps (full speed), 1.5 Mbps (low speed) High speed mode is only supported by USB 2.0. 4.3.2 USB 1.1/2.0 USB (Universal Serial Bus) offers simple connectivity for computers, printers, keyboards, and other peripherals.

  • Page 707: Usb Connectors

    CÓPIA NÃO CONTROLADA 4.3.3 USB CONNECTORS USB is a serial protocol and a physical link, which transmits all data on a single pair of wires. Another pair provides power to downstream peripherals. The USB standard specifies two types of connectors, type “A” connectors for upstream connection to the host system, and type “B”...

  • Page 708: Remarks About Usb

    CÓPIA NÃO CONTROLADA 4.3.5 REMARKS ABOUT USB • The machine does not print reports specifically for USB. • Only one host computer is allowed for the USB connection. • After starting a job using USB, do not switch the printer off until the job has been completed.

  • Page 709: Ieee 802.11B (Wireless Lan)

    CÓPIA NÃO CONTROLADA IEEE 802.11B (WIRELESS LAN) 4.4 IEEE 802.11B (WIRELESS LAN) 4.4.1 SPECIFICATIONS The IEEE 802.11b wireless LAN interface card is available as an option for this machine. A wireless LAN is a flexible data communication system used to extend or replace a wired LAN.

  • Page 710: Transmission Modes

    CÓPIA NÃO CONTROLADA IEEE 802.11B (WIRELESS LAN) 4.4.2 TRANSMISSION MODES Wireless communication has two modes: 1) ad hoc mode, and 2) infrastructure mode. Ad Hoc Mode The ad hoc mode allows communication between each device (station) in a simple peer-to-peer network.

  • Page 711: Security Features

    CÓPIA NÃO CONTROLADA IEEE 802.11B (WIRELESS LAN) 4.4.3 SECURITY FEATURES SSID (Service Set ID) The SSID is used by the access point to recognize the client and allow access to the network. Only clients that share the same SSID with the access point can access the network.

  • Page 712: Wireless Lan Troubleshooting Notes

    CÓPIA NÃO CONTROLADA IEEE 802.11B (WIRELESS LAN) 4.4.4 WIRELESS LAN TROUBLESHOOTING NOTES Communication Status Wireless LAN communication status can be checked with the UP mode “W.LAN Signal” in the Maintenance menu. This can also be checked using the Web Status Monitor or Telnet.

  • Page 713: Troubleshooting Procedure

    CÓPIA NÃO CONTROLADA IEEE 802.11B (WIRELESS LAN) Troubleshooting Procedure If there are problems using the wireless LAN, check the following. 1) Check the LED indicator on the wireless LAN card. 2) Check if “IEEE802.11b” is selected in the following user tool: Host Interface menu - Network Setup - LAN Type.

  • Page 714: Bluetooth

    CÓPIA NÃO CONTROLADA BLUETOOTH 4.5 BLUETOOTH 4.5.1 SPECIFICATIONS Bluetooth wireless provides radio links between mobile computers, mobile phones and other portable handheld devices. Bluetooth contains the following features. • Cheaper compared to the IEEE802.11b wireless LAN. • Many protocols for infrared transmission (IrDA) can be used with Bluetooth. •...

  • Page 715: Bluetooth Profiles

    CÓPIA NÃO CONTROLADA BLUETOOTH 4.5.2 BLUETOOTH PROFILES A Bluetooth device will not operate if it is located to close another Bluetooth device. However, the Bluetooth device should support the protocols to communicate with each other. There are many types of Bluetooth and service protocols. These are listed below.

  • Page 716: Specifications

    CÓPIA NÃO CONTROLADA SPECIFICATIONS SPECIFICATIONS 1. SYSTEM COMPONENTS Memory DIMM Controller Board IEEE 1394 MARIMBA IEEE 802.11b CN517 USB 2.0 CN508 (SLOT1) CN509 (SLOT2) Bluetooth Printer/ PS3 DIMM Scanner DIMM B548V501.WMF Machine Item Remarks Code Memory 128 MB G331 IEEE 1394 G336 Used in common with Model-MT IEEE 802.11b Wireless LAN...

  • Page 717: Printer Specifications

    CÓPIA NÃO CONTROLADA SPECIFICATIONS 3. PRINTER SPECIFICATIONS Printing Speed: Maximum 35 ppm (A4/LT LEF): B079 model Maximum 45 ppm (A4/LT LEF): B082 model Printer Languages: PCL6/PCL5e PostScript 3 (option) RPCS (Refined Printing Command Stream) - an original Ricoh PDL) Resolution:...

  • Page 718: Ieee 802.11B Specifications

    CÓPIA NÃO CONTROLADA SPECIFICATIONS 5. IEEE 802.11B SPECIFICATIONS Standard applied IEEE802.11b Data transmission rates Speed Distance 11 Mbps 140 m (153 yd.) 5.5 Mbps 200 m (219 yd.) 2 Mbps 270 m (295 yd.) 1 Mbps 400 m (437 yd.) Network protocols TCP/IP, Apple Talk, NetBEUI, IPX/SPX Bandwidth...

  • Page 719: Software Accessories

    CÓPIA NÃO CONTROLADA SPECIFICATIONS 7. SOFTWARE ACCESSORIES 7.1 PRINTER The printer drivers and utility software are provided on one CD-ROM. An auto-run installer allows you to select which components to install. PRINTER DRIVERS Printer Windows Windows Windows Windows Macintosh Language 95/98/ME NT4.0 2000...

  • Page 720: Scanner

    CÓPIA NÃO CONTROLADA SPECIFICATIONS 7.2 SCANNER The scanner driver and utility software are provided on one CD-ROM. SCANNER DRIVER • Network Twain Driver for Win95/98/ME/NT3.51/NT4.0/2000/XP SCANNER UTILITIES • Scan Router V2 Lite for Win95/98/ME/NT4.0/2000/XP • Desk Top Binder V2 Lite for Win95/98/ME/NT4.0/2000/XP B548 CÓPIA NÃO CONTROLADA...
  • Page 721 CÓPIA NÃO CONTROLADA FAX OPTION B547 CÓPIA NÃO CONTROLADA...
  • Page 722 CÓPIA NÃO CONTROLADA CÓPIA NÃO CONTROLADA...
  • Page 723 CÓPIA NÃO CONTROLADA FAX OPTION B547 TABLE OF CONTENTS 1. INSTALLATION................1 1.1 CAUTIONS AND WARNINGS..............1 1.2 PROCEDURE FLOWCHART ............... 2 1.3 FAX OPTION TYPE 2045................3 1.4 G3 INTERFACE UNIT TYPE 2045 ............... 9 1.4.1 JBIG A892 ..................14 2.
  • Page 724 CÓPIA NÃO CONTROLADA CAUTIONS AND WARNINGS 3.2.5 G3-1 SWITCHES................70 3.2.6 G3-2 SWITCHES................78 3.2.7 G3-3 SWITCHES................83 3.2.8 G4 INTERNAL SWITCHES ............... 84 G4 to G3 Fallback .................. 90 3.2.9 G4 PARAMETER SWITCHES............91 3.3 NCU PARAMETERS .................. 94 3.4 DEDICATED TRANSMISSION PARAMETERS ........
  • Page 725 CÓPIA NÃO CONTROLADA Conventions in this Manual This manual uses several symbols. Symbol What it means Refer to section number  See Core Tech Manual for details  Screw  Connector  E-ring  Clip ring Short Edge Feed (SEF) Long Edge Feed (LEF) CÓPIA NÃO CONTROLADA...
  • Page 726 CÓPIA NÃO CONTROLADA CÓPIA NÃO CONTROLADA...

  • Page 727: Installation

    CÓPIA NÃO CONTROLADA CAUTIONS AND WARNINGS 1. INSTALLATION 1.1 CAUTIONS AND WARNINGS  WARNING 1. Never install telephone writing during a lightning storm. 2. Never install telephone jacks in wet locations unless the jack is specifically designed for wet locations. 3.

  • Page 728: Procedure Flowchart

    CÓPIA NÃO CONTROLADA PROCEDURE FLOWCHART 1.2 PROCEDURE FLOWCHART Before installing the fax unit and/or fax options, refer to the following flow chart. START Install the Fax Function Upgrade Will you be installing the Fax Unit and/or Expansion Memory Function Upgrade Unit and/or to the FCU board.

  • Page 729: Fax Option Type

    CÓPIA NÃO CONTROLADA FAX OPTION TYPE 2045 1.3 FAX OPTION TYPE 2045 B547I903.WMF B547I926.WMF  CAUTION Before installing this option, do the following: 1. If there is a printer option in the machine, print out all data in the printer buffer.
  • Page 730 CÓPIA NÃO CONTROLADA FAX OPTION TYPE 2045 B547I902.WMF B547I925.WMF 4. Attach the NCU unit [A] ( x 2). NOTE: If a G3 Interface Unit type 2045 has to been installed, attach the additional NCU boards to the NCU unit before attaching the NCU unit to the machine.

  • Page 731: Fax Option Type 2045

    CÓPIA NÃO CONTROLADA FAX OPTION TYPE 2045 B547I904.WMF 6. Remove the controller unit [A] ( x 2) 7. Remove the FCU cover [B] ( x 2) B547 CÓPIA NÃO CONTROLADA...
  • Page 732 CÓPIA NÃO CONTROLADA FAX OPTION TYPE 2045 B547I105.WMF 8. Tune on the battery switch (SW1) [A] On the MBU board. 9. Connect harness [B] to the FCU board ( x 2). 10. Slide the FCU board [C] into the right slot of the expansion box. If any following options are to be installed at the same time, connect the option board to the FCU board before sliding the FCU board into the expansion box.
  • Page 733 CÓPIA NÃO CONTROLADA FAX OPTION TYPE 2045 B547I905.WMF B547I906.WMF 12. Attach the harness clamps [A] and connect the FCU harness [B] to the NCU board. Then clamp the harness as shown. 13. Reattach the FCU cover and the controller unit. 14.
  • Page 734 CÓPIA NÃO CONTROLADA FAX OPTION TYPE 2045 B547I927.WMF B547I924.WMF 15. Cut away the telephone connector cover [A]. 16. Attach the FCC decal and the serial number decal [B] to the rear cover as shown. 17. Reattach the covers. 18. If the ARDF is installed, raise the ARDF and insert the stamp cartridge [C]. 19.
  • Page 735 CÓPIA NÃO CONTROLADA G3 INTERFACE UNIT TYPE 2045 1.4 G3 INTERFACE UNIT TYPE 2045 B547I911.WMF B547I909.WMF B547I912.WMF 1. Remove the covers. (!1.3) 2. Remove the controller unit [A] ( x 2). 3. Remove the FCU cover [B] ( x 2). 4.

  • Page 736: G3 Interface Unit Type 2045

    CÓPIA NÃO CONTROLADA G3 INTERFACE UNIT TYPE 2045 B547I913.WMF B547I914.WMF 9. Remove the NCU unit [A] ( x 2). 10. Attach the Option NCU unit [B] to the lower of the reverse side of the NCU unit ( x 2) as shown. B547 CÓPIA NÃO CONTROLADA...
  • Page 737 CÓPIA NÃO CONTROLADA G3 INTERFACE UNIT TYPE 2045 B547I914.WMF B547I925.WMF 11. Set up the jumper switches [A and B] on the NCU. NOTE: European/Asian models only (non-U.S. version: B591-27) Region/Country TB1 [A] TB2 [B] Hong Kong Hungary Poland Czech Republic Israel South Africa Regions/countries where...
  • Page 738 CÓPIA NÃO CONTROLADA G3 INTERFACE UNIT TYPE 2045 B547I915.WMF B547I916.WMF 14. Connect harness [A] to the option NCU board 15. Attach the harness clamps [B] (x2) then clamp the harness. 16. Attach the NCU unit [C] to the machine ( x 2), and slide the FCU board into the machine.
  • Page 739 CÓPIA NÃO CONTROLADA G3 INTERFACE UNIT TYPE 2045 B547I919.WMF B547I917.WMF 19. Cut away the small cover [A] for the first option G3 unit. NOTE: If there is another G3 option unit, cut away the upper small cover [B]. 20. Attach the FCC decal [C] to the rear cover. 21.

  • Page 740: Jbig A892

    CÓPIA NÃO CONTROLADA G3 INTERFACE UNIT TYPE 2045 1.4.1 JBIG A892  CAUTION Before installing this option, do the following: 1. Print out all messages stored in the memory, the lists of user- programmed items, and the system parameter list. 2.
  • Page 741 CÓPIA NÃO CONTROLADA G3 INTERFACE UNIT TYPE 2045 B547I201.WMF 1. Attach the FAX function upgrade board [A]. 2. Turn on the battery switch [B]. NOTE: If installing the FAX unit at the same time, be sure to turn on the FCU board battery switch.

  • Page 742: Troubleshooting

    CÓPIA NÃO CONTROLADA 2. TROUBLESHOOTING 2.1 ERROR CODES If an error code occurs, retry the communication. If the same problem occurs, try to fix the problem as suggested below. Note that some error codes appear only in the error code display and on the service report. Code Meaning Suggested Cause/Action...
  • Page 743 CÓPIA NÃO CONTROLADA ERROR CODES Code Meaning Suggested Cause/Action 0-06 The other terminal did not • Check the line connection. reply to DCS • Check the FCU - NCU connectors. • Try adjusting the tx level and/or cable equalizer settings. •...
  • Page 744 CÓPIA NÃO CONTROLADA Code Meaning Suggested Cause/Action 0-15 The other terminal is not The other terminal is not capable of accepting the capable of specific following functions, or the other terminal’s memory functions. is full. • Confidential rx • Transfer function •...
  • Page 745 CÓPIA NÃO CONTROLADA ERROR CODES Code Meaning Suggested Cause/Action 0-23 Too many errors during • Check the line connection. reception • Check the FCU - NCU connectors. • Replace the NCU or FCU. • Defective remote terminal. • Check for line noise or other line problems. •...
  • Page 746 CÓPIA NÃO CONTROLADA Code Meaning Suggested Cause/Action 0-77 The called terminal fell back • The calling terminal could not detect a JM due to to T.30 mode, because it noise, etc. could not detect a CJ in • A network that has narrow bandwidth cannot response to JM pass JM to the other end.
  • Page 747 CÓPIA NÃO CONTROLADA ERROR CODES Code Meaning Suggested Cause/Action 2-12 Modem clock irregularity • Replace the FCU. 2-13 Modem initialization error • Turn off the machine, then turn it back on. • Update the modem ROM. • Replace the FCU. 2-20 Abnormal coding/decoding •...
  • Page 748 CÓPIA NÃO CONTROLADA Code Meaning Suggested Cause/Action 5-00 Data construction not • Replace the FCU. possible 5-01 Data reconstruction not possible 5-10 DCR timer expired 5-20 Storage impossible because • Temporary memory shortage. of a lack of memory • Test the SAF memory. •...
  • Page 749 CÓPIA NÃO CONTROLADA ERROR CODES Code Meaning Suggested Cause/Action 6-10 G3 ECM - error frames still • Check for line noise. received at the other end • Adjust the tx level (use NCU parameter 01 or the after all communication dedicated tx parameter for that address).

  • Page 750: Error Codes For The Isdn Option

    CÓPIA NÃO CONTROLADA 2.2 ERROR CODES FOR THE ISDN OPTION The tables on the following pages show the error codes for the ISDN option. The meaning of the numbers in the Action column is as follows. 1. Check Layer 1 signaling with a protocol analyzer to determine the cause of the problem.

  • Page 751: D-Channel Layer Management

    CÓPIA NÃO CONTROLADA ERROR CODES FOR THE ISDN OPTION 2.2.1 D-CHANNEL LAYER MANAGEMENT Code Probable Cause Action 7-00 Link reset 7-01 Link set-up failed because of time-out. 7-02 Link release failed because of time-out. 7-03 Link set-up parameter error 2.2.2 D-CHANNEL, LAYER 1 Code Probable Cause Action...

  • Page 752: D-Channel Network Layer

    CÓPIA NÃO CONTROLADA 2.2.4 D-CHANNEL NETWORK LAYER Code Probable Cause Action 7-40 Insufficient mandatory information elements 7-41 Abnormal LI for a mandatory information element 7-42 T301 timeout; timeout while waiting for R:CONN 7-43 T303 timeout; timeout while waiting for R: CALL-PROC etc. 7-44 T304 timeout;...

  • Page 753: B-Channel Network Layer

    CÓPIA NÃO CONTROLADA ERROR CODES FOR THE ISDN OPTION 2.2.6 B-CHANNEL NETWORK LAYER Code Probable Cause Action 7-80 A packet having an abnormal GFI was received 7-81 A packet was received that had a logical channel number different from the logical channel being used for the communication 7-82 A packet containing a format error was received 7-83...

  • Page 754: Session Layer

    CÓPIA NÃO CONTROLADA 2.2.8 SESSION LAYER Code Probable Cause Action 8-30 Invalid frame received 8-31 RSSN received 8-32 CSA received 8-34 Calling terminal identification error in CSS 8-35 Date and time error in CSS 8-36 Window size error in CSS 8-37 Service identification error in CSS 8-38...

  • Page 755: Document Layer

    CÓPIA NÃO CONTROLADA ERROR CODES FOR THE ISDN OPTION 2.2.9 DOCUMENT LAYER Code Probable Cause Action 8-60 T.62 coding format error (LI error) 8-61 A mandatory PI was absent, or the LI for a mandatory PI was 0 8-62 Calling/called terminal identification LI was different from that specified by F.184 (LI = 24) 8-63 The LI for session user data exceeded the maximum value (512)

  • Page 756: Fax Sc Codes

    CÓPIA NÃO CONTROLADA 2.3 FAX SC CODES 2.3.1 OVERVIEW When the FCU detects a Fax SC Code condition other than SC1201 and SC1207, it resets itself automatically (default setting). This initializes the FCU without erasing files in the SAF memory or resetting the switches. NOTE: For details on Fax SC Codes 1201 and 1207, refer to the following sections.

  • Page 757: Fax Sc Code Table

    CÓPIA NÃO CONTROLADA FAX SC CODES 2.3.4 FAX SC CODE TABLE Sys Switch Sys Switch Suggested SC Code Description Action 1F bit 7 = 0 1F bit 7 = 1 1102 Handshake error with Initialize the fax Automatic SC Code controller at start-up unit.

  • Page 758: Isdn Test Function

    CÓPIA NÃO CONTROLADA 2.4 ISDN TEST FUNCTION 2.4.1 LEDS There are four LEDs on the G4 board. These LEDs describe the status of the machine. LED 1 LED 2 LED 3 LED 4 Initial Settings O=ON, --=OFF Initial check (if the flash ROM is updated) Handshaking with the FCU ready Standby Mode Ready to communicate...

  • Page 759: Back-To-Back Test

    CÓPIA NÃO CONTROLADA ISDN TEST FUNCTION 2.4.2 BACK-TO-BACK TEST To make a back-to-back test, you need: • Two machines, with different types of CiG4 option boards. NOTE: You cannot make a back-to-back test using two machines with identical type CiGH option boards. The procedure is as follows.

  • Page 760: Service Tables

    CÓPIA NÃO CONTROLADA SERVICE PROGRAM MODE 3. SERVICE TABLES  CAUTION Never turn off the main power switch when the power LED is lit or flashing. To avoid damaging the hard disk or memory, press the operation power switch to switch the power off, wait for the power LED to go off, and then switch the main power switch off.
  • Page 761 CÓPIA NÃO CONTROLADA SERVICE PROGRAM MODE SP1-XXX (Bit Switches) ! Section 3.2 Bit Switches Mode No. Function System Switch 001 – 032 00 – 1F Change the bit switches for system settings for the fax option ! Section 3.2 Bit Switches FAX Switch 001 –...

  • Page 762: Sp2-Xxx (Ram Data)

    CÓPIA NÃO CONTROLADA SERVICE PROGRAM MODE SP2-XXX (RAM Data) Mode No. Function RAM Read/Write Change RAM data for the fax board directly. ! Section 3.5 Service RAM Addresses Memory Dump G3-1 Memory Dump Print out RAM data for the fax board. ! Section 3.5 Service RAM Addresses G3-2 Memory Dump Print out RAM data for the SG3-1 board.

  • Page 763: Sp4-Xxx (Rom Versions)

    CÓPIA NÃO CONTROLADA SERVICE PROGRAM MODE Mode No. Function Memory Lock If the customer does not want to receive Disabled transmissions using Memory Lock on this line, change this SP to on. Transmission If you turn this SP on, the machine will not Disabled send any fax messages on the G3-2 line.

  • Page 764: Sp5-Xxx (Initializing)

    CÓPIA NÃO CONTROLADA SERVICE PROGRAM MODE SP5-XXX (Initializing) Mode No. Function Initialize SRAM Initializes the bit switches and user parameters, user data in the SRAM, files in the SAF memory, and clock. Erase All Files Erases all files stored in the SAF memory. Reset Bit Switches Resets the bit switches and user parameters.
  • Page 765 CÓPIA NÃO CONTROLADA SERVICE PROGRAM MODE Mode No. Function All Files print out Prints out all the user files in the SAF memory, including confidential messages. NOTE: Do not use this function, unless the customer is having trouble printing confidential messages or recovering files stored using the memory lock feature.

  • Page 766: Sp7-Xxx (Test Modes)

    CÓPIA NÃO CONTROLADA SERVICE PROGRAM MODE SP7-XXX (Test Modes) These are the test modes for PTT approval. Function G3-1 Modem Tests G3-1 DTMF Tests Ringer Test G3-1 V34 (S2400baud) G3-1 V34 (S2800baud) G3-1 V34 (S3000baud) G3-1 V34 (S3200baud) G3-1 V34 (S3429baud) Recorded Message Test G3-2 Modem Tests G3-2 DTMF Tests...

  • Page 767: Bit Switches

    CÓPIA NÃO CONTROLADA BIT SWITCHES 3.2 BIT SWITCHES  WARNING Do not adjust a bit switch or use a setting that is described as “Not used”, as this may cause the machine to malfunction or to operate in a manner that is not accepted by local regulations.
  • Page 768 CÓPIA NÃO CONTROLADA BIT SWITCHES System Switch 00 SP No. 1-101-001 FUNCTION COMMENTS Rx level calculation Example: 0000 32 V34 288/264 L 01 00 03 04 The four-digit hexadecimal value (N) after “L” indicates the rx level. The high byte is given first, followed by the low byte. Divide the decimal value of N by - 16 to get the rx level.
  • Page 769 CÓPIA NÃO CONTROLADA BIT SWITCHES Width and A4: A4 (8.3"), no reduction reduction B4: B4 (10.1"), no reduction A3: A3 (11.7"), no reduction I/O rate 0: 0 ms/line 10: 10 ms/line 25: 2.5 ms/line 20: 20 ms/line 5: 5 ms/line 40: 40 ms/line Note: “40”...
  • Page 770 CÓPIA NÃO CONTROLADA BIT SWITCHES System Switch 04 SP No. 1-101-005 FUNCTION COMMENTS Printing dedicated tx 1: Each Quick/Speed dial number on the list is parameters on Quick/Speed printed with the dedicated tx parameters (10 bytes Dial Lists each). 0: Disabled The first 10 bytes of data are the programmed 1: Enabled dedicated tx parameters;...
  • Page 771 CÓPIA NÃO CONTROLADA BIT SWITCHES System Switch 0A SP No. 1-101-011 FUNCTION COMMENTS Not used Do not change the settings. Continuous polling reception This feature allows a series of stations to be polled 0: Disabled 1: Enabled in a continuous cycle. This will continue until the polling reception file is erased.
  • Page 772 CÓPIA NÃO CONTROLADA BIT SWITCHES System Switch 0F SP No. 1-101-016 FUNCTION COMMENTS Country/area code for This country/area code determines the factory functional settings (Hex) settings of bit switches and RAM addresses. However, it has no effect on the NCU parameter 00: France 11: USA settings and communication parameter RAM...
  • Page 773 CÓPIA NÃO CONTROLADA BIT SWITCHES System Switch 12 SP No. 1-101-019 FUNCTION COMMENTS TTI/CIL printing position in the TTI/CIL: 08 to 92 (BCD) mm main scan direction Input even numbers only. This setting determines the print start position for the TTI and CIL from the left edge of the paper. If the TTI is moved too far to the right, it may overwrite the file number which is on the top right of the page.
  • Page 774 CÓPIA NÃO CONTROLADA BIT SWITCHES System Switch 1A SP No. 1-101-026 FUNCTION COMMENTS LS RX memory remaining Sets a value of 4K. refresh value setting If the amount of memory remaining falls below 4K, documents received in memory are printed to create more space in memory.
  • Page 775 CÓPIA NÃO CONTROLADA BIT SWITCHES System Switch 1E SP No. 1-101-031 FUNCTION COMMENTS RTI/CSI display priority This bit determines which identifier, RTI or CSI, is 0: RTI 1: CSI displayed on the LCD while the machine is communicating in G3 non-standard mode. File No.
  • Page 776 CÓPIA NÃO CONTROLADA BIT SWITCHES System Switch 1F SP No. 1-101-032 FUNCTION COMMENTS Not used Do not change the setting. Report printout after an original 0: When an original jams, or the SAF memory overflows during scanning, a report will be printed. jam during SAF storage or if the SAF memory fills up Change this bit to “1”...

  • Page 777: Fax Switches

    CÓPIA NÃO CONTROLADA BIT SWITCHES 3.2.2 FAX SWITCHES FAX Switch 00 - Not used (do not change the settings) FAX Switch 01 SP No. 1-102-002 FUNCTION COMMENTS Scan density step value When scan density is adjusted manually away from (Text mode) the Normal setting, the threshold value for binary picture processing changes for each step from the value specified by Scanner Switch 02, by the...
  • Page 778 CÓPIA NÃO CONTROLADA BIT SWITCHES FAX Switch 05 SP No. 1-102-006 FUNCTION COMMENTS Binary picture processing: This setting determines the threshold value for Threshold for colored binary picture processing in colored background background special original 2 special original 2 mode (when the scan density mode - Normal setting (center setting is at the center).
  • Page 779 CÓPIA NÃO CONTROLADA BIT SWITCHES FAX Switch 09 SP No. 1-102-010 FUNCTION COMMENTS Independent dot erase level The value can be between 0 (Off) and 7. (monotone background special For a higher threshold, input a higher value (larger original 1 mode) dots are erased).
  • Page 780 CÓPIA NÃO CONTROLADA BIT SWITCHES FAX Switch 0C SP No. 1-102-013 FUNCTION COMMENTS Action when an original jam This bit is only effective when parallel memory tx is has occurred while scanning disabled (user parameter 07 - bit 2). the original into memory for If parallel memory tx is enabled, the machine always memory tx erases the scanned pages when an original jam...
  • Page 781 CÓPIA NÃO CONTROLADA BIT SWITCHES FAX Switch 0E SP No. 1-102-015 FUNCTION COMMENTS Wait time for the next page This bit determines how long the machine waits for when scanning a book original the next page when scanning a book original for into memory memory transmission.

  • Page 782: Printer Switches

    CÓPIA NÃO CONTROLADA BIT SWITCHES 3.2.3 PRINTER SWITCHES Printer Switch 00 SP No. 1-103-001 FUNCTION COMMENTS Page separation mark 0: No marks are printed. 0: Disabled 1: If a received page has to be printed out on two 1: Enabled sheets, an asterisk inside square brackets is printed at the bottom right hand corner of the first sheet, and a “2”...
  • Page 783 CÓPIA NÃO CONTROLADA BIT SWITCHES Relationship between available paper sizes and printer width used in the setup protocol Available Paper Size Printer width used in the Protocol (NSF/DIS) A4 or 8.5" x 11" 297 mm width 256 mm width A5 or 8.5" x 5.5" 216 mm width No paper available (Paper end) 216 mm width...
  • Page 784 CÓPIA NÃO CONTROLADA BIT SWITCHES Printer Switch 03 SP No. 1-103-004 FUNCTION COMMENTS Page separation threshold (with reduction disabled with switch 03-0 above) If the incoming page is up to x mm longer than the length of copy paper, the excess portion will not be printed.
  • Page 785 CÓPIA NÃO CONTROLADA BIT SWITCHES Printer Switch 06 SP No. 1-103-007 FUNCTION COMMENTS Printing while a paper cassette is pulled out, when the Just Size Printing feature is Cross reference enabled. Just size printing on/off – User switch 05, bit 5 0: Printing will not start 1: Printing will start if another cassette has a suitable size of...
  • Page 786 CÓPIA NÃO CONTROLADA BIT SWITCHES Printer Switch 0E SP No. 1-103-015 FUNCTION COMMENTS Page separation 1: If all paper sizes in the machine require page 0: Enabled separation to print a received fax message, the 1: Disabled machine does not print the message (Substitute Reception is used).

  • Page 787: Communication Switches

    CÓPIA NÃO CONTROLADA BIT SWITCHES 3.2.4 COMMUNICATION SWITCHES Communication Switch 00 SP No. 1-104-001 FUNCTION COMMENTS Compression modes available These bits determine the compression capabilities in receive mode to be declared in phase B (handshaking) of the T.30 Bit 1 Modes protocol.
  • Page 788 CÓPIA NÃO CONTROLADA BIT SWITCHES Communication Switch 01 SP No. 1-104-002 FUNCTION COMMENTS If this bit is set to 0, ECM is switched off for all 0: Off 1: On communications. In addition, V.8 protocol and JBIG compression are switched off automatically. Not used Do not change the setting.
  • Page 789 CÓPIA NÃO CONTROLADA BIT SWITCHES Communication Switch 02 SP No. 1-104-003 FUNCTION COMMENTS Hang-up decision when a 0: The next page will be sent even if RTN or PIN is negative code (RTN or PIN) is received. received during G3 immediate 1: The machine will send DCN and hang up if it transmission receives RTN or PIN.
  • Page 790 CÓPIA NÃO CONTROLADA BIT SWITCHES Communication Switch 07 SP No. 1-104-008 FUNCTION COMMENTS Fallback from G4 to G3 if the Also see system switch 0A bit 7. other terminal is not a G4 Refer to the ISDN G4 option service manual (G4 terminal Internal Switches 17, 18, 1A, 1B, and 1C) for the 0: Disabled...
  • Page 791 CÓPIA NÃO CONTROLADA BIT SWITCHES Communication Switch 0B SP No. 1-104-012 FUNCTION COMMENTS Use of Economy Transmission These bits determine whether the machine uses the during a Transfer operation to Economy Transmission feature when it is carrying end receivers out a Transfer operation as a Transfer Station. 0: Disabled 1: Enabled Use of Economy Transmission during a Transfer operation to...
  • Page 792 CÓPIA NÃO CONTROLADA BIT SWITCHES Communication Switch 0C SP No. 1-104-013 FUNCTION COMMENTS Number of digits compared to 00 - 1F (0 to 31 digits) find the requester’s fax number After the machine receives a transfer request, the from the programmed machine compares the own telephone number sent Quick/Speed Dials when acting from the Requesting Terminal with all Quick/Speed...
  • Page 793 CÓPIA NÃO CONTROLADA BIT SWITCHES Communication Switch 0F - Not used (do not change the settings.) Communication Switch 10 SP No. 1-104-017 FUNCTION COMMENTS 01 - FE (Hex) times Memory transmission: Maximum number of dialing attempts to the same destination Communication Switch 11 - Not used (do not change the settings.) Communication Switch 12 SP No.
  • Page 794 CÓPIA NÃO CONTROLADA BIT SWITCHES Communication Switch 15 - Not used (do not change the settings) Communication Switch 16 SP No. 1-104-023 FUNCTION COMMENTS Standard G3 unit Set this bit to 0 if the user wants to use only the 0: Disabled ISDN line (option G4 unit), even for G3 1: Enabled...
  • Page 795 CÓPIA NÃO CONTROLADA BIT SWITCHES Communication Switch 18 - Not used (do not change the settings) Communication Switch 19 - Not used (do not change the settings) Communication Switch 1A - Not used (do not change the settings) Communication Switch 1B SP No.

  • Page 796: G3-1 Switches

    CÓPIA NÃO CONTROLADA BIT SWITCHES 3.2.5 G3-1 SWITCHES G3-1 Switch 00 SP No. 1-105-001 FUNCTION COMMENTS Monitor speaker during (0, 0): The monitor speaker is disabled all through communication (tx and rx) the communication. Bit 1 Bit 0 Setting (0, 1): The monitor speaker is on up to phase B in Disabled the T.30 protocol.
  • Page 797 CÓPIA NÃO CONTROLADA BIT SWITCHES G3-1 Switch 03 SP No. 1-105-004 FUNCTION COMMENTS DIS detection number 0: The machine will hang up if it receives the same (Echo countermeasure) DIS frame twice. 0: 1 1: Before sending DCS, the machine will wait for the 1: 2 second DIS which is caused by echo on the line.
  • Page 798 CÓPIA NÃO CONTROLADA BIT SWITCHES G3-1 Switch 04 SP No. 1-105-005 FUNCTION COMMENTS Training error detection 0 - F (Hex); 0 - 15 bits threshold If the number of error bits in the received TCF is below this threshold, the machine informs the sender that training has succeeded.
  • Page 799 CÓPIA NÃO CONTROLADA BIT SWITCHES G3-1 Switch 06 SP No. 1-105-007 FUNCTION COMMENTS Initial Rx modem rate These bits set the initial starting modem rate for Bit 3 2 1 0 Setting (bps) reception. 0 0 0 1 2.4 k 0 0 1 0 4.8 k Use a lower setting if high speeds pose problems 0 0 1 1 7.2 k...
  • Page 800 CÓPIA NÃO CONTROLADA BIT SWITCHES G3-1 Switch 07 SP No. 1-105-008 FUNCTION COMMENTS PSTN cable equalizer Use a higher setting if there is signal loss at higher (rx mode: Internal) frequencies because of the length of wire between Bit 3 Bit 2 Setting the modem and the telephone exchange.
  • Page 801 CÓPIA NÃO CONTROLADA BIT SWITCHES G3-1 Switch 09 SP No. 1-105-010 FUNCTION COMMENTS ISDN cable equalizer Use a higher setting if there is signal loss at higher (rx mode: Internal) frequencies because of the length of wire between Bit 3 Bit 2 Setting the modem and the telephone exchange.
  • Page 802 CÓPIA NÃO CONTROLADA BIT SWITCHES G3-1 Switch 0B SP No. 1-105-012 FUNCTION COMMENTS Protocol requirements: Europe The machine does not automatically reset these bits 0: Disabled 1: Enabled for each country after a country code (System Switch 0F) is programmed. Protocol requirements: Spain Change the required bits manually at installation.
  • Page 803 CÓPIA NÃO CONTROLADA BIT SWITCHES G3-1 Switch 0E - Not used (do not change the settings) G3-1 Switch 0F SP No. 1-105-016 FUNCTION COMMENTS Alarm when an error occurred If the customer wants to hear an alarm after each in Phase C or later error communication, change this bit to “1”.

  • Page 804: G3-2 Switches

    CÓPIA NÃO CONTROLADA BIT SWITCHES 3.2.6 G3-2 SWITCHES These switches require an optional G3 interface unit. G3-2 Switch 00 SP No. 1-106-001 FUNCTION COMMENTS Monitor speaker during (0, 0): The monitor speaker is disabled all through communication (tx and rx) the communication.
  • Page 805 CÓPIA NÃO CONTROLADA BIT SWITCHES G3-2 Switch 03 SP No. 1-106-004 FUNCTION COMMENTS DIS detection number 0: The machine will hang up if it receives the same (Echo countermeasure) DIS frame twice. 0: 1 1: Before sending DCS, the machine will wait for the 1: 2 second DIS which is caused by echo on the line.
  • Page 806 CÓPIA NÃO CONTROLADA BIT SWITCHES G3-2 Switch 05 SP No. 1-106-006 FUNCTION COMMENTS Initial Tx modem rate These bits set the initial starting modem rate for Bit 3 2 1 0 Setting (bps) transmission. 0 0 0 1 2.4 k 0 0 1 0 4.8 k Use the dedicated transmission parameters if you...
  • Page 807 CÓPIA NÃO CONTROLADA BIT SWITCHES G3-2 Switch 06 SP No. 1-106-007 FUNCTION COMMENTS Modem types available for The setting of these bits is used to inform the reception transmitting terminal of the available modem type for Bit 7 6 5 4 Setting the machine in receive mode.
  • Page 808 CÓPIA NÃO CONTROLADA BIT SWITCHES G3-2 Switch 08 - Not used (do not change the settings) G3-2 Switch 09 - Not used (do not change the settings) G3-2 Switch 0A SP No. 1-106-011 FUNCTION COMMENTS Maximum allowable carrier These bits set the acceptable modem carrier drop drop during image data time.

  • Page 809: G3-3 Switches

    CÓPIA NÃO CONTROLADA BIT SWITCHES G3-2 Switch 0C SP No. 1-106-013 FUNCTION COMMENTS Pulse dialing method P = Number of pulses sent out, N = Number dialed. Bit 1 Bit 0 Setting Normal(P=N) Oslo (P=10 - N) Sweden (N+1) Not used Not used Do not change the settings.

  • Page 810: G4 Internal Switches

    CÓPIA NÃO CONTROLADA BIT SWITCHES 3.2.8 G4 INTERNAL SWITCHES NOTE: These G4 internal switches are for the Japanese model only. Do not change these settings. G4 Internal Switch 00 FUNCTION COMMENTS Country code Bit 4 Country Germany (1TR6 mode) Universal (Europe Euro ISDN) Note: In Germany, use the Universal setting for the Euro ISDN lines.
  • Page 811 CÓPIA NÃO CONTROLADA BIT SWITCHES G4 Internal Switch 05 FUNCTION COMMENTS Not used Do not change these settings. Protocol ID check The Protocol ID is in the CR packet. 0: Yes 1: No Not used Do not change these settings. G4 Internal Switch 06 - Not used (do not change these settings) G4 Internal Switch 07 - Not used (do not change these settings) G4 Internal Switch 08 - Not used (do not change these settings)
  • Page 812 CÓPIA NÃO CONTROLADA BIT SWITCHES G4 Internal Switch 13: D channel layer 3 (Attachment IE in S: SETUP) FUNCTION COMMENTS Not used Do not change the setting. Information transfer capability shift 1: The machine changes the ISDN G3 down to retry transmission information transfer capability informed in the [SETUP] signal to “Speech”...
  • Page 813 CÓPIA NÃO CONTROLADA BIT SWITCHES G4 Internal Switch 13: D channel layer 3 (Attachment IE in S: SETUP) FUNCTION COMMENTS Condition for fallback from G4 to 0: Fallback occurs when a CPS code is the same as the CPS code settings specified by G4 internal switches 17, 18, 1A, 1B, and 0: Refer to the CPS code setting 1: Fallback in response to any CPS...
  • Page 814 CÓPIA NÃO CONTROLADA BIT SWITCHES G4 Internal Switch 15: D channel layer 3 (Judgement R: MSG) FUNCTION COMMENTS Action when receiving [SETUP] This bit depends on user requirements. If it is signal containing no called at 1, communication will be halted if the other subaddress terminal has not input the subaddress.
  • Page 815 CÓPIA NÃO CONTROLADA BIT SWITCHES G4 Internal Switch 16: D channel layer 3 (Approval) FUNCTION COMMENTS Transfer capabilities (SI) informed This bit determines whether transfer in 1TR6 ISDN G3 transmission capabilities informed in the Service Indicator for 1TR6 ISDN G3 transmission. This switch is 0: G3 Fax effective in coping with communication 1: Analog...

  • Page 816: G4 To G3 Fallback

    CÓPIA NÃO CONTROLADA BIT SWITCHES G4 to G3 fallback Bit 0 of Communication Switch 07 must be at 0, or fallback from G4 to G3 will be disabled. The CPS codes for which fallback occurs are decided as follows. • G4 bit switch 17, bit 7 - If set to “0”, fallback occurs on receipt of a code from a set that depends on the country code.

  • Page 817: G4 Parameter Switches

    CÓPIA NÃO CONTROLADA BIT SWITCHES 3.2.9 G4 PARAMETER SWITCHES NOTE: These G4 internal switches are for the Japanese model only. Do not change these settings. G4 Parameter Switch 00 FUNCTION COMMENTS Do not change the default setting. Network type Bit 2 Type Circuit switched ISDN...
  • Page 818 CÓPIA NÃO CONTROLADA BIT SWITCHES G4 Parameter Switch 05 FUNCTION COMMENTS Not used Do not change these settings. B-channel T3 timer 1: This switch is useful when used in 0: 30s 1: 57s combination with the Communication Bit SW 07 bit 4. This is to cope with communication problems where G4 communication fails on the ISDN B- channel.
  • Page 819 CÓPIA NÃO CONTROLADA BIT SWITCHES G4 Parameter Switch 09 - Not used (do not change these settings) G4 Parameter Switch 0A - Not used (do not change these settings) G4 Parameter Switch 0B FUNCTION COMMENTS Transport block size This value must match the value set in the Bit 3 Value other terminal.

  • Page 820: Ncu Parameters

    CÓPIA NÃO CONTROLADA NCU PARAMETERS 3.3 NCU PARAMETERS The following tables give the RAM addresses and the parameter calculation units that the machine uses for ringing signal detection and automatic dialing. The factory settings for each country are also given. Most of these must be changed by RAM read/write (SP2-102), but some can be changed using NCU Parameter programming (SP2-103, 104 and 105);...
  • Page 821 CÓPIA NÃO CONTROLADA NCU PARAMETERS Address Function Unit Remarks 680500 Country/Area code for NCU Use the Hex value to program the parameters country/area code directly into this address, or use the decimal value to program it using SP2-103-001 Country/Area Decimal Hex France Germany Italy...
  • Page 822 CÓPIA NÃO CONTROLADA NCU PARAMETERS Address Function Unit Remarks 680508 PSTN dial tone detection time 20 ms If 680508 contains FF(H), the machine pauses for 680509 PSTN dial tone reset time (LOW) the pause time (address 68050A PSTN dial tone reset time (HIGH) 68050D / 68050E).
  • Page 823 CÓPIA NÃO CONTROLADA NCU PARAMETERS Address Function Unit Remarks 680526 PABX busy tone frequency upper Hz (BCD) If both addresses contain limit (high byte) FF(H), tone detection is disabled. 680527 PABX busy tone frequency upper limit (low byte) 680528 Hz (BCD) PABX busy tone frequency lower If both addresses contain limit (high byte)
  • Page 824 CÓPIA NÃO CONTROLADA NCU PARAMETERS Address Function Unit Remarks 68053F Country dial tone upper frequency Hz (BCD) If both addresses contain limit (HIGH) FF(H), tone detection is disabled. 680540 Country dial tone upper frequency limit (LOW) 680541 Country dial tone lower frequency If both addresses contain limit (HIGH) FF(H), tone detection is...
  • Page 825 CÓPIA NÃO CONTROLADA NCU PARAMETERS Address Function Unit Remarks -N x 0.5 –3.5 680554 PSTN: DTMF tone attenuation level Function 06-2 (parameter after dialling 21). See Note 5. 680555 ISDN: DTMF tone attenuation level -dBm x 0.5 See Note 5 after dialling 680556 Not used...
  • Page 826 CÓPIA NÃO CONTROLADA NCU PARAMETERS Address Function Unit Remarks 680576 Number of rings until a call is Function 06-2 (parameter detected 06). The setting must not be zero. 680577 Minimum required length of the first 20 ms See Note 4. ring Function 06-2 (parameter 07).
  • Page 827 CÓPIA NÃO CONTROLADA NCU PARAMETERS Address Function Unit Remarks 6805A8 Acceptable CNG detection frequency BCD (Hz) If both addresses contain lower limit (high byte) FF(H), tone detection is disabled. 6805A9 Acceptable CNG detection frequency lower limit (low byte) 6805AA Not used Do not change the setting.
  • Page 828 CÓPIA NÃO CONTROLADA NCU PARAMETERS Address Function Unit Remarks 6805BE Not used Do not change the settings. 6805C6 6805C7 Bits 0 to 3 – Not used. Bit 4 – V.34 protocol dump 0: Simple, 1: Detailed (default) Bits 5 to 7 – Not used. 6805C8 Not used Do not change the...
  • Page 829 CÓPIA NÃO CONTROLADA NCU PARAMETERS 6. 68054A: Europe - Between Ds opening and Di opening, France - Between Ds closing and Di opening 68054D: Europe - Between Ds closing and Di closing, France - Between Ds opening and Di closing 7.

  • Page 830: Dedicated Transmission Parameters

    CÓPIA NÃO CONTROLADA DEDICATED TRANSMISSION PARAMETERS 3.4 DEDICATED TRANSMISSION PARAMETERS Each Quick Dial Key and Speed Dial Code has eight bytes of programmable parameters allocated to it. If transmissions to a particular machine often experience problems, store that terminal’s fax number as a Quick Dial or Speed Dial, and adjust the parameters allocated to that number.

  • Page 831: Parameters

    CÓPIA NÃO CONTROLADA DEDICATED TRANSMISSION PARAMETERS 3.4.2 PARAMETERS The initial settings of the following parameters are all FF(H) - all the parameters are disabled. Switch 01 FUNCTION AND COMMENTS ITU-T T1 time (for PSTN G3 mode) If the connection time to a particular terminal is longer than the NCU parameter setting, adjust this byte.
  • Page 832 CÓPIA NÃO CONTROLADA DEDICATED TRANSMISSION PARAMETERS Switch 03 FUNCTION COMMENTS Initial Tx modem rate If training with a particular remote terminal always Bit 3 2 1 0 Setting (bps) takes too long, the initial modem rate may be too 0 0 0 0 Not used high.
  • Page 833 CÓPIA NÃO CONTROLADA DEDICATED TRANSMISSION PARAMETERS Switch 04 FUNCTION COMMENTS V.8 protocol If transmissions to a specific destination always end 0: Off at a lower modem rate (14,400 bps or lower), 1: Disabled disable V.8 protocol so as not to use V.34 protocol. 0: V.34 communication will not be possible.
  • Page 834 CÓPIA NÃO CONTROLADA DEDICATED TRANSMISSION PARAMETERS Switch 09 - Optional ISDN G4 kit required FUNCTION COMMENTS Layer 3 protocol If the setting is “Disabled”, the current setting of G4 parameter switch 6 (bit 0) is used. Bits 3 2 1 0 Setting 0 0 0 0 ISO 8208 0 0 0 1 T.70 NULL 1 1 1 1 Disabled...

  • Page 835: Service Ram Addresses

    CÓPIA NÃO CONTROLADA SERVICE RAM ADDRESSES 3.5 SERVICE RAM ADDRESSES  CAUTION Do not change the settings which are marked as “Not used” or “Read only.” 680001 to 680004(H) - ROM version (Read only) 680001(H) - Revision number (BCD) 680002(H) - Year (BCD) 680003(H) - Month (BCD) 680004(H) - Day (BCD) 680006 to 680015(H) - Machine’s serial number (16 digits - ASCII)
  • Page 836 CÓPIA NÃO CONTROLADA SERVICE RAM ADDRESSES 6800D3(H) - User parameter switch 03 (SWUSR_03: Automatic report printout) Bit 0: Transmission result report (memory transmissions) 0: Off, 1: On Bit 1: Not used Bit 2: Memory storage report 0: Off, 1: On Bit 3: Polling reserve report (polling reception) 0: Off, 1: On Bit 4: Polling result report (polling reception) 0: Off, 1: On Bit 5: Transmission result report (immediate transmissions) 0: Off, 1: On...
  • Page 837 CÓPIA NÃO CONTROLADA SERVICE RAM ADDRESSES 6800D8(H) - User parameter switch 08 (SWUSR_08) Bits 0 and 1: Not used. Bit 2: Authorized reception 0: Only faxes from senders whose RTIs/CSIs are specified for this feature are accepted. 1: Only faxes from senders whose RTIs/CSIs are not specified for this feature are accepted.
  • Page 838 CÓPIA NÃO CONTROLADA SERVICE RAM ADDRESSES 6800DE(H) - User parameter switch 14 (SWUSR_0E) Bit 0: Message printout while the machine is in Night Printing mode 0: On, 1: Off Bit 1: Maximum document length detection 0: Double letter, 1: Longer than double-letter (well log) – up to 1,200 mm Bit 2: Batch transmission 0: Off, 1: On Bit 3: Fax mode settings, such as resolution, before a mode key (Copy/Fax/Printer /Scanner) is pressed...
  • Page 839 CÓPIA NÃO CONTROLADA SERVICE RAM ADDRESSES 6800E3(H) - User parameter switch 19 (SWUSR_13) Bit 0: Offset sort function for the fax (only using the shift tray on the 1,000 sheet finisher) 0: Disabled, 1: Enabled Bit 1: Journal format 0: The Journal is separated into transmissions and receptions 1: The Journal is separated into G3-1, G3-2, G3-3 and G4 communications Bit 2: Action when the paper cassette that was selected by the specified cassette selection feature becomes empty.
  • Page 840 CÓPIA NÃO CONTROLADA SERVICE RAM ADDRESSES 6800E8(H) - User parameter switch 24 (SWUSR_18) Bits 0 and 1: File retention time (Cross reference: System switch 02 bit 4) Setting File retention impossible 24 hours File retention impossible 72 hours Bits 2 to 7: Not used 6800E9(H) - User parameter switch 25 (SWUSR_19) Bits 0 to 3: Not used Bit 4: RDS operation...
  • Page 841 CÓPIA NÃO CONTROLADA SERVICE RAM ADDRESSES note. 6802B7 to 6802F6(H) - TTI 3 (Max. 64 characters - ASCII) - See the following 6802F7 to 68030A(H) - PSTN-1 CSI (Max. 20 characters - ASCII) 68030B to 68031E(H) - PSTN-2 CSI (Max.20 characters - ASCII) 68031F to 680332(H) –...
  • Page 842 CÓPIA NÃO CONTROLADA SERVICE RAM ADDRESSES 680362(H) - Confidential ID (low - BCD) 680363(H) - Confidential ID (high - BCD) 680364(H) - Memory Lock ID (low - BCD) 680365(H) - Memory Lock ID (high - BCD) 68036C(H) - Network type used for the service station number 0 1 (H) - PSTN-1 0 2 (H) - PSTN-2 0 3 (H) - PSTN-3...
  • Page 843 CÓPIA NÃO CONTROLADA SERVICE RAM ADDRESSES 6803F9(H) - Month (BCD) 6803FA(H) - Day (BCD) 6803FB to 6803FF(H) – Option G3 board (G3-3) ROM information (Read only) 6803FB(H) - Suffix (BCD) 6803FC(H) - Version (BCD) 6803FD(H) - Year (BCD) 6803FE(H) - Month (BCD) 6803FF(H) - Day (BCD) 680402(H) - Option G3 board (G3-2) modem ROM version (Read only) 680404(H) - Option G3 board (G3-3) modem ROM version (Read only)

  • Page 844: Detailed Section Descriptions

    CÓPIA NÃO CONTROLADA OVERVIEW 4. DETAILED SECTION DESCRIPTIONS 4.1 OVERVIEW Fax Function Upgrade CCUIF Expansion Memory Controller B360V501.WMF The basic fax unit consists of two PCBs: an FCU and an NCU. The FCU controls all the fax communications and fax features, in cooperation with the controller board.

  • Page 845: Boards

    CÓPIA NÃO CONTROLADA BOARDS 4.2 BOARDS 4.2.1 FCU SRAM Flash ROM (512 kB) (3 MB) CPU BUS FACE V.34 MODEM (RU30) DMA BUS Analog Circuit DRAM (8 MB) Monitor Function Speaker DIMM Upgrade Unit (32 MB) (512 kB) B360D510.WMF The FCU (Facsimile Control Unit) controls fax communications, the video interface to the base copier’s engine, and all the fax options.
  • Page 846 CÓPIA NÃO CONTROLADA BOARDS • 3MB flash ROMs for system software storage 2MB (16bit x 1M) + 1MB (16bit x 512K) DRAM • The DRAM is shared as follows. • SAF Standard: 4MB With optional expansion memory: 32MB (4MB + 28MB) •...

  • Page 847: Ncu (Us)

    CÓPIA NÃO CONTROLADA BOARDS 4.2.2 NCU (US) OHDI SW. Surge Protection TRXD Noise Over- Filter Relay RING DC Loop current Transformer Protection Surge Protection Current Sensor OHDISW CMLSW Hook0 Hook1 ExRing Ring Noise Detection Filter Circuit A895D520.WMF Jumpers Item Description These jumpers should be shorted when the machine is connected to a dry line.

  • Page 848: Ncu (Europe/Asia)

    CÓPIA NÃO CONTROLADA BOARDS 4.2.3 NCU (EUROPE/ASIA) Noise SHUNT CML Relay Filter DCLSW Filter (16Hz) DO Sw. RING TRXD Current Sensor Loop OHDI Sw. DOSW OHDISW GS Sw. CMLLSW Hook0 Hook1 SHUNT GSSW Noise Filter Ring CSEL Detection RSEL Circuit ExRing A895D521.WMF Control Signals and Jumpers...

  • Page 849: Sg3 Board

    CÓPIA NÃO CONTROLADA BOARDS 4.2.4 SG3 BOARD Standard DTMF Hybrid IC Receiver Flash ROM MN195003MFL DPRAM DMAC JBIGIF TONE (RU8) (4MB) Modem Modem DATA/ADDRESS BUS Flash ROM DRAM JBIG (4MB) (4MB) M65761 Program SG3-V.34 B360D513.WMF The SG3 board allows up to two simultaneous communications when used in combination with the FCU.

  • Page 850: Sig4 Board

    CÓPIA NÃO CONTROLADA BOARDS 4.2.5 SIG4 BOARD Flash SiG4 DRAM SYSTEM BUS LAPD ISDN Reset ICCP ISDN Circuit Controller Interface Analog I/F CODEC Circuit MODEM H548D500.WMF The SiG4 (Standard ISDN G4) board contains ICCP (ISDN Communication Control Processor), Flash ROM, DRAM, LAPD controller, CODEC, ISDN interface and analog interface.

  • Page 851: Video Data Path

    CÓPIA NÃO CONTROLADA VIDEO DATA PATH 4.3 VIDEO DATA PATH 4.3.1 TRANSMISSION SCANNER BICU FACE Page Memory CODER CODER (Option) Modem Modem SiG4 ISDN G4 ISDN G3 Analog G3 Analog G3 B360D511.WMF B547 CÓPIA NÃO CONTROLADA...

  • Page 852: Immediate Transmission

    CÓPIA NÃO CONTROLADA VIDEO DATA PATH Memory Transmission and Parallel Memory Transmission The base copier's scanner scans the original at the selected resolution in inch format. The BiCU processes the data and transfers it to the FCU. When scanning a fax original, the BiCU uses the MTF, independent dot erase and thresholding parameter settings programmed in the fax unit’s scanner bit switches, not the copier's SP modes.
  • Page 853 CÓPIA NÃO CONTROLADA VIDEO DATA PATH Adjustments • Line used for G3 transmissions (PSTN or ISDN): System switch 0A bit 6 • Line used for G3 transmissions (PSTN 1/PSTN 2): System switch 16 bit 1 • I-G3 modem default: System switch 16 bit 2 and 3 B547 CÓPIA NÃO CONTROLADA...

  • Page 854: Reception

    CÓPIA NÃO CONTROLADA VIDEO DATA PATH 4.3.2 RECEPTION Analog G3 Analog G3 ISDN G3 ISDN G4 SiG4 Modem Modem CODER (DCR) CODER (Option) Page Memory FACE BICU Printer B360D512.WMF B547 CÓPIA NÃO CONTROLADA...
  • Page 855 CÓPIA NÃO CONTROLADA VIDEO DATA PATH First, the FCU stores the incoming data from either an analog line or an ISDN line to the SAF memory. (The data goes to the FACE at the same time, and is checked for error lines/frames.) The FCU then decompresses the data and transfers it to page memory.

  • Page 856: Fax Communication Features

    CÓPIA NÃO CONTROLADA FAX COMMUNICATION FEATURES 4.4 FAX COMMUNICATION FEATURES 4.4.1 PERSONAL/INFORMATION/TRANSFER BOXES When an incoming message has a SUB or SEP code attached, the machine will look for a Personal Box, Transfer Box or Information Box with an identical SUB or SEP code.
  • Page 857 CÓPIA NÃO CONTROLADA FAX COMMUNICATION FEATURES Transfer Box The user can create transfer boxes in the machine’s memory for forwarding incoming fax messages. Each box must have a name and a code. Each box must also have destinations associated with it; any message arriving in this box will automatically be sent on to these destinations.
  • Page 858 CÓPIA NÃO CONTROLADA FAX COMMUNICATION FEATURES Information Box (Polling Tx) The user can set up documents in memory to be picked up by another machine. The user makes an information box for each document. The information box is identified by a code. Anybody who wishes to call the fax machine and receive the document from the information box has to input this code as the SEP code when calling the machine.

  • Page 859: Multi-Port

    CÓPIA NÃO CONTROLADA FAX COMMUNICATION FEATURES 4.4.2 MULTI-PORT When the optional ISDN Unit or optional extra G3 Interface Unit is installed, communication can take place at the same time through the two or three lines at once. Available protocol Option Available Line Type Combinations Standard only...

  • Page 860: Document Server

    CÓPIA NÃO CONTROLADA FAX COMMUNICATION FEATURES 4.4.3 DOCUMENT SERVER Scanner Controller Comoressed Page BICU Memory FACE Modem PSTN DATA/ADDRESS BUS SiG4 To ISDN B360D514.WMF The base copier's scanner scans the original at the selected resolution. The BICU video processes the data and transfers it to the controller board. Then the controller stores the data in the page memory for the copier function, and compresses the data in MMR (by software) to store it in the HDD.

  • Page 861: Lan Fax Driver

    CÓPIA NÃO CONTROLADA FAX COMMUNICATION FEATURES 4.4.4 LAN FAX DRIVER Application Fax Driver Compressed MMR Fax Number Address/Book CONTROLLER BICU PRINTER FACE Modem PSTN DATA/ADDRESS BUS SiG4 To ISDN Page Memory B360D515.WMF B547 CÓPIA NÃO CONTROLADA...
  • Page 862 CÓPIA NÃO CONTROLADA FAX COMMUNICATION FEATURES The fax driver makes print data from an application, then compresses the print data into MMR data. PJL commands are added to the compressed data and the destination telephone number and the line selection are included in the PJL commands.

  • Page 863: Address Book

    CÓPIA NÃO CONTROLADA ADDRESS BOOK 4.5 ADDRESS BOOK The address book (directory) for this machine combines under one user name the fax address and mail address. All the address data is stored on the HDD. Up to a maximum of 2,000 items can be stored for addresses.
  • Page 864 CÓPIA NÃO CONTROLADA ADDRESS BOOK There are three methods you can use to back up address book data: • HDD ←→ IC Card • FCU (MBU) ←→ IC Card • HDD ←→ FCU Each is described below. HDD ←→ IC Card Address data stored on the HDD can be uploaded to an IC card with SP5846 51 (UCS Settings - All Directory Info.

  • Page 865: Sp Modes

    CÓPIA NÃO CONTROLADA ADDRESS BOOK SP Modes 1. SP5846 051 UCS Settings - All Directory Info. Upload This SP mode is used to upload address data to an IC card. The machine automatically detects where the address data is stored. If there is address data on the HDD, the address data from the HDD is uploaded to the IC card.

  • Page 866: Specifications

    CÓPIA NÃO CONTROLADA SPECIFICATIONS SPECIFICATIONS 1. GENERAL SPECIFICATIONS Type: Desktop type transceiver Circuit: PSTN (max. 3ch.) PABX ISDN Connection: Direct couple Original Size: Book (Face down) Maximum Length: 432 mm [17 ins] Maximum Width: 297 mm [11.7 ins] ARDF (Face up) (single sided document) Length: 128 - 1200 mm [5.0 - 47.2 ins] Width: 105 - 297 mm [4.1 - 11.7 inch]...

  • Page 867: Capabilities Of Programmable Items

    CÓPIA NÃO CONTROLADA SPECIFICATIONS Memory Capacity: ECM: 128 KB Standard: 4 MB With optional Expansion Memory: 32 MB (4 MB+ 28 MB) Page Memory Standard: 4 MB (Print: 2 MB + Scanner: 2 MB) With optional Expansion Memory: 12 MB (4 MB + 8 MB) (Print 8 MB + Scanner: 4 MB) 2.

  • Page 868: Machine Configuration

    CÓPIA NÃO CONTROLADA SPECIFICATIONS The following table shows how the capabilities of the document memory will change after the optional Fax Function Upgrade Unit and the Expansion Memory are installed. With the Without the Expansion Expansion Memory Memory Memory Transmission file Maximum number of Without the Fax 1000...
