A250/B001

SERVICE MANUAL

000846MIU
RICOH GROUP COMPANIES

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the A250 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Ricoh A250

Summary of Contents for Ricoh A250

  • Page 1: Service Manual

    A250/B001 SERVICE MANUAL 000846MIU RICOH GROUP COMPANIES...
  • Page 2 2.3.3 AUTO POWER CONTROL (APC) ..........2-35 2.3.4 LD SAFETY SWITCH ..............2-36 2.4 ALL-IN-ONE CARTRIDGE (AIO CARTRIDGE) ........2-37 2.4.1 OVERVIEW..................2-37 2.4.2 DRIVE .................... 2-38 2.4.3 DRUM CHARGE ................2-39 2.4.4 DEVELOPMENT................2-40 2.4.5 DRUM CLEANING ................. 2-43 A250...
  • Page 3 3.6.1 ACCESSORY CHECK ..............3-23 3.6.2 1-BIN SORTER INSTALLATION PROCEDURE......3-24 3.7 PLATEN COVER INSTALLATION............3-29 3.7.1 ACCESSORY CHECK ..............3-29 3.7.2 PLATEN COVER INSTALLATION PROCEDURE ......3-29 3.8 EXTENDED MEMORY BOARD INSTALLATION ........3-30 3.8.1 ACCESSORY CHECK ..............3-30 A250...
  • Page 4 4.1.1 HOW TO ENTER AND EXIT USER TOOLS........4-58 4.1.2 USER TOOLS TABLE..............4-58 4.4 LEDS ...................... 4-60 4.5 SPECIAL TOOLS AND LUBRICANTS ........... 4-60 4.5.1 SPECIAL TOOLS................4-60 4.5.2 LUBRICANTS ................4-60 PREVENTIVE MAINTENANCE 5. PREVENTIVE MAINTENANCE SCHEDULE....... 5-1 A250...
  • Page 5 4.1.1 HOW TO ENTER AND EXIT USER TOOLS........4-58 4.1.2 USER TOOLS TABLE..............4-58 4.4 LEDS ...................... 4-60 4.5 SPECIAL TOOLS AND LUBRICANTS ........... 4-60 4.5.1 SPECIAL TOOLS................4-60 4.5.2 LUBRICANTS ................4-60 4.6 ROM HISTORY..................4-61 PREVENTIVE MAINTENANCE 5. PREVENTIVE MAINTENANCE SCHEDULE ....... 5-1 A250...
  • Page 6 6.6.3 STANDARD TRAY PAPER FEED CLUTCH REPLACEMENT..6-25 6.6.4 VERTICAL TRANSPORT ROLLER/SENSOR/ CLUTCH REPLACEMENT............. 6-26 6.6.5 BY-PASS FEED ROLLER REPLACEMENT........6-27 6.6.6 BY-PASS FEED FRICTION PAD REPLACEMENT ....... 6-28 6.6.7 BY-PASS FEED SENSOR REPLACEMENT ......... 6-29 6.6.8 BY-PASS TRAY REMOVAL ............6-30 A250...
  • Page 7 7.3.2 SENSORS ..................7-11 7.4 COPY QUALITY ..................7-12 7.4.1 LOW IMAGE DENSITY..............7-12 7.5 FIRMWARE HISTORY ................7-14 7.5.1 A250 FIRMWARE MODIFICATION HISTORY ......7-14 DOCUMENT FEEDER A859 1. OVERALL INFORMATION............8-1 1.1 SPECIFICATIONS ..................8-1 1.2 MECHANICAL COMPONENT LAYOUT........... 8-2 1.3 ELECTRICAL COMPONENT LAYOUT ............
  • Page 8 3.1 FEED ROLLER REPLACEMENT ............9-14 3.2 TRAY MAIN BOARD REPLACEMENT........... 9-15 3.3 TRAY MOTOR REPLACEMENT ............9-15 3.4 RELAY CLUTCH REPLACEMENT............9-16 3.5 UPPER PAPER FEED CLUTCH REPLACEMENT......... 9-17 3.6 LOWER PAPER FEED CLUTCH REPLACEMENT........ 9-18 3.7 LIFT MOTOR REPLACEMENT .............. 9-19 A250...
  • Page 9 1.4 ELECTRICAL COMPONENT DESCRIPTION ........11-4 2. DETAILED SECTION DESCRIPTIONS........11-5 2.1 BASIC OPERATION ................11-5 3. REPLACEMENT AND ADJUSTMENT........11-6 3.1.1 TOP COVER REMOVAL ............... 11-6 3.1.2 TRAY OPEN SWITCH REPLACEMENT ........11-6 3.1.3 PAPER SENSOR AND EXIT SENSOR REPLACEMENT ..... 11-6 A250...
  • Page 10 2.1.2 PROGRAMMING A CARD WITH THE SOURCE ......13-2 2.2 DOWNLOADING TO A MACHINE............13-4 2.3 SAVING DATA TO A FILE............... 13-4 3. FUNCTIONS ................13-5 3.1 FILE MENU....................13-5 3.1.1 FILE – OPEN .................. 13-5 3.1.2 FILE – CLOSE ................13-5 A250 viii...
  • Page 11 3.2.2 VIEW – STATUS BAR ..............13-6 3.3 IMAGE MENU..................13-7 3.3.1 IMAGE – ERASE ................13-7 3.3.2 IMAGE – READ ................13-8 3.3.3 IMAGE – WRITE................13-9 3.3.4 IMAGE – VERIFICATION ............. 13-10 3.4 HELP MUNU..................13-11 3.4.1 HELP – ABOUT SWAPUTI ............13-11 A250...
  • Page 12 A250...

  • Page 13: Overall Machine Information

    2.5 LINE TYPE CHANGE ................2-20 2.6 PCBS ...................... 2-21 2.6.1 FCU....................2-21 2.6.2 NCU (US)..................2-23 2.6.3 NCU (EUROPE/ASIA)..............2-24 2.6.4 EXFUNC BOARD ................2-25 3. INSTALLATION................3-1 3.1 FAX UNIT ....................3-1 3.2 EXFUNC BOARD (FAX FUNCTION UPGRADE) ........3-10 A250...

  • Page 14: Precautions

    4.4.1 PROGRAMMING PROCEDURE ........... 4-63 4.4.2 PARAMETERS ................4-64 4.5 SERVICE RAM ADDRESSES ..............4-68 5. PREVENTIVE MAINTENANCE ........... 5-1 5.1 SPECIAL TOOLS AND LUBRICANTS ............. 5-1 5.2 PM TABLE ....................5-1 6. REMOVAL AND REPLACEMENT ..........6-1 6.1 PRECAUTION ..................6-1 A250...

  • Page 15: Troubleshooting

    7.1 ERROR CODES ..................7-1 7.2 FAX SC CODES ..................7-10 7.2.1 OVERVIEW..................7-10 7.2.2 SC1201 ..................7-10 7.2.3 SC1207 ..................7-10 7.2.4 FAX SC CODE TABLE ..............7-11 7.3 ROM HISTORY..................7-12 7.3.1 ROM HISTORY – A891 ..............7-12 A250...
  • Page 16 A250...
  • Page 17 3.2.3 NETWORK LAYER (LAYER 3)............3-8 3.2.4 TRANSPORT LAYER (LAYER 4) ............ 3-8 3.2.5 SESSION LAYER, SESSION CONTROL LAYER (LAYER 5)..................3-8 3.2.6 SESSION LAYER, DOCUMENT CONTROL LAYER (LAYER 5)..................3-8 3.3 LEDS ......................3-9 3.4 BACK-TO-BACK TEST................3-10 A250...
  • Page 18 A250...

  • Page 19: Overall Machine Information

    2.2.7 HHH (OPTIONAL)................2-7 3. INSTALLATION PROCEDURES..........3-1 3.1 PRECAUTIONS ..................3-1 3.2 PRINTER CONTROLLER................. 3-1 3.3 HARD DISK (HDD) ................... 3-4 3.4 NETWORK INTERFACE BOARD (NIB) ........... 3-5 3.5 POSTSCRIPT DIMM ................3-7 3.6 MEMORY (SDRAM DIMM) ............... 3-9 A250...

  • Page 20: Overview

    5.2 CONTROLLER ..................5-1 5.3 NIB......................5-3 6. TROUBLESHOOTING..............6-1 6.1 SC CODES ....................6-1 6.2 ERROR CODES ..................6-1 6.3 LED DISPLAY................... 6-2 6.3.1 LOCATION..................6-2 6.3.2 FATAL ERROR................6-3 6.4 ROM HISTORY..................6-5 6.4.1 ROM HISTORY – B305 ..............6-5 A250...

  • Page 21: Overall Information

    2.3.4 APPLETALK (ETHERTALK) NETWORKS ........2-5 3. SERVICE TABLES AND PROCEDURES........3-1 3.1 PRINTING REPORTS ................3-1 3.1.1 NIB STATUS SHEET................3-1 3.1.2 NIB LOG LIST ..................3-1 3.2 NVRAM RESET..................3-1 4. TROUBLESHOOTING ..............4-1 4.1 LED INDICATIONS ...................4-1 4.2 FIRMWARE HISTORY ................4-2 A250...

  • Page 23: Machine Configuration

    3.1 SERVICE PROGRAM MODE TABLES ............ 3-1 3.2 MISFEED DETECTION ................3-1 3.3 OUTPUT CHECK TABLE ................. 3-2 3.4 USER TOOLS................... 3-2 TROUBLESHOOTING 4. TROUBLESHOOTING..............4.1 4.1 SC CODE DESCRIPTION ................. 4-1 ROM HISTORY 5. ROM HISTORY................5.1 5.1 ROM HISTORY ..................5-1 A250/B001...

  • Page 24: Detailed Descriptions

    Rev. 1/00 OVERALL INFORMATION PAPER TRAY UNIT A860 SwapFTL Binary Utility DETAILED DESCRIPTIONS PAPER TRAY UNIT A861 B001 SERVICE MANUAL INSTALLATION 1-BIN SORTER A869 SERVICE TABLES FAX UNIT A891 PREVENTIVE MAINTENANCE ISDN UNIT A890 REPLACEMENT AND ADJUSTMENT PRINTER CONTROLLER B305 TROUBLESHOOTING NETWORK INTERFACE BOARD B307 DOCUMENT FEEDER A859...

  • Page 25: Copy Process

    50% to 200% in 1% steps Power Source: 120 V, 60 Hz: More than 10 A (for North America) 220 ~ 240 V, 50/60 Hz More than 6 A (for Europe/Asia) 110 V, 50/60 Hz More than 11 A (for Taiwan) A250...
  • Page 26 Dimensions (W x D x H): 550 x 575 x 460 mm (21.7" x 22.7" x 18.2") NOTE: Measurement Conditions 1) With by-pass feed table closed 2) Without the ADF Weight: Less than 35 kg (78 lb) Not including ADF, Platen Cover, and AIO A250...

  • Page 27: A4 Sideways

    10 sheets (A3, B4, 11" x 17", 8 " x 13") 1 sheets (non-standard sizes) NOTE: Copy weight: 80g/m (20 lb). Toner Replenishment: All-in-one toner cassette cartridge (750 g/cartridge) Toner Yield: 12 k copies (A4 sideways, 6% full black, 1 to 1 copying, ADS mode) A250...

  • Page 28: Copy Tray

    A3, 11" x 17" A4 6% 80 sheets 99 sheets Number of pages A4 ITU-T#4 12% 35 sheets 99 sheets : Available NOTE: The paper sizes that can be used with Rotate Sort are A4/8 " x 11" and B5 only. A250...

  • Page 29: Parts Catalog

    A250/B001 PARTS CATALOG 000845MIU...

  • Page 30: Paper Feed

    LOCATION OF UNIT............2 LOCATION OF UNIT ............2 1. EXTERIOR (A250) ............6 1. EXTERIOR (B001)............6 2. PLATEN COVER (OPTION A250) ......... 8 2. PLATEN COVER (OPTION B001) ......... 8 3. OPERATION PANEL (A250).......... 10 3. OPERATION PANEL (B001) .......... 10 4.

  • Page 31: Functions

    DOCUMENT FEEDER A859 PARTS LOCATION AND LIST 1-BIN SORTER A869 PARTS LOCATION AND LIST 1. EXTERIOR (A859) ............. 2 1. PT180 (A869)..............2 2. ORIGINAL FEED 1 (A859) ..........4 1-BIN SORTER A869 PARTS INDEX 3. ORIGINAL FEED 2 (A859) ..........6 4.

  • Page 32: Scanner

    LOCATION OF UNIT 1. EXTERIOR (A250) 2. PLATEN COVER (OPTION A250) 3. OPERATION PANEL (A250) See Page 7 See Page 9 See Page 11 4. SCANNER SECTION 1 (A250) 5. SCANNER SECTION 2 (A250) 6. SCANNER SECTION 3 (A250) See Page 13...
  • Page 33 Ricoh Aficio 180, Aficio 150 service manual Ricoh Aficio 180, Aficio 150 service manual Ricoh Aficio 180, Aficio 150 service manual Ricoh Aficio 180, Aficio 150 service manual Ricoh Aficio 180, Aficio 150 service manual Ricoh Aficio 180, Aficio 150 service manual...

This manual is also suitable for:

B001
