Quick Start Guide

GV-PTZ010D / GV-PT110D Camera
Thank you for purchasing GV-PTZ010D / GV-PT110D Camera. This guide is designed to
assist the new user in getting immediate results from the GV-PTZ010D / GV-PT110D
Camera. For advanced information on how to use the GV-PTZ010D / GV-PT110D Camera,
please refer to GV-IPCam H.264 User's Manual on Software DVD.
© 2010 GeoVision Inc. All rights reserved.
1
Introduction
Welcome to the GV-PTZ010D / GV-PT110D Camera Quick Start Guide. In
the following sections, you will learn about the basic installations and
configurations of the GV-PTZ010D and GV-PT110D. For a detailed user's
manual, see GV-IPCam H.264 User's Manual on the software CD.

Packing List

• GV-PTZ010D / GV-PT110D camera
GV-PTZ010D
• Mounting cover
• Mounting base
• Wall mount bracket
• Short screws
• Washers
2010/10
English
ICH264V106-PTZ-QG-A
or
GV-PT110D
• Round screws
• Screw anchors
• Long screws
• DC 12V power adaptor
• GV-PTZ010D / GV-PT110D
software CD

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GV-PTZ010D and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for GeoVision GV-PTZ010D

Summary of Contents for GeoVision GV-PTZ010D

  • Page 1: Packing List

    • DC 12V power adaptor • Short screws Thank you for purchasing GV-PTZ010D / GV-PT110D Camera. This guide is designed to assist the new user in getting immediate results from the GV-PTZ010D / GV-PT110D Camera. For advanced information on how to use the GV-PTZ010D / GV-PT110D Camera, •...

  • Page 2: Hardware Installation

    Hardware Installation The GV-PTZ010D / GV-PT110D camera is designed for indoor usage. 5. Put on the mounting cover. To fit the installation environment, you can cut the parts indicated by arrows to make an opening for wires and Please make sure that the installing location is shielded from rain and cables.

  • Page 3: Wall Mount

    Wall Mount You may mount GV-PTZ010D / GV-PT110D camera on the wall, with or 5. Without Mounting Cover without the mounting cover. • Attach the wall mount bracket with the PTZ / PT camera using 3 washers and 3 round screws.
  • Page 4 Power LED Turns green when the power is on and turns off when the power is off. GV-PTZ010D GV-PT110D Focus Ring Manually rotates this ring left or right to adjust focus. Turns on to illuminate a surveillance area by infrared light to produce clearer images during the night.
  • Page 5 3. In the left menu, select Network and then LAN to configure the System Requirement network settings. To access GV-PTZ010D / GV-PT110D camera through the Web browser, ensure your PC connects to the network properly and meets the system requirement below: •...

  • Page 6: The Web Interface

    The Web Interface Name Function Play Plays live video. Stop Stops playing video. Microphone Talks to the surveillance area from the local computer. Speaker Listens to the audio around the camera. Snapshot Takes a snapshot of live video. File Save Records live video to the local computer.
  • Page 7 User’s Manual on the software CD. Note : The functions related to focus, zoom and image quality on the control panel are only available in GV-PTZ010D. For details on the functions supported on the GV-PT110D, see 6.8 PT Control in the...
  • Page 8 Configuring a Preset Point You can configure the GV-PTZ010D / GV-PT110D camera to automatically To start a Preset movement, click the Option button on the control panel, move toward a point in live view. You can save up to 256 Preset points.
  • Page 9 Configuring a Sequence You can also configure the GV-PTZ010D / GV-PT110D camera to perform a 4. Use the Index drop-down list to select a Sequence number. Sequence, which links up more than two Preset points to form a series of 5.

  • Page 10: Upgrading System Firmware

    Upgrading System Firmware GeoVision will periodically release updated firmware on the web site. To load 1. In the Live View window, click the Show System Menu button, select the new firmware into the GV-PTZ010D / GV-PT110D camera, read the Remote Config, and click the Firmware Upgrade tab. This dialog box important note and then follow the instruction below.

  • Page 11: Restoring To Default Settings

    Restoring to Default Settings You can restore the system default settings of the GV-PTZ010D / Using the Web Interface: GV-PT110D directly on the camera or through the Web interface. 1. On the left menu of Web interface, select Management and select Tools.
  • Page 12 9F, No. 246, Sec. 1, Neihu Rd., Neihu District, Taipei, Taiwan Tel: +886-2-8797-8376 Fax: +886-2-8797-8335 support@geovision.com.tw http://www.geovision.com.tw...
