GeoVision GV-PTZ010D Specifications
10x d1 h.264 ptz
Hide thumbs
Also See for GV-PTZ010D:
- Hardware manual (49 pages) ,
- Quick start manual (13 pages) ,
- User manual (697 pages)
Advertisement
Quick Links
Download this manual
See also:
User Manual
Introduction
The GV‐PTZ010D camera is a ceiling‐mount device that provides panning, tilting and zooming functions. The camera is designed to
monitor a wide area and also to focus on a specific part on the live view when suspicious events occur. There are two models:
Models
Model
Model No.
GV‐PTZ010D‐N
GV‐PTZ010D
GV‐PTZ010D‐P
GV-PTZ010D
•
1/4" CCD image sensor
•
Dual streams from H.264, MJPEG and MPEG4
•
Electronic Day/Night function
•
Up to 30 fps at 704 x 480
•
Up to 25 fps at 704 x 576
•
10x optical zoom lens
•
10x digital zoom
•
Pan and tilt (Pan: ‐175° ~ 175° ; Tilt: ‐45° ~ 90°)
•
Built‐in / external microphone
•
2‐way audio
•
One sensor input and alarm output
•
Micro SD/SDHC Card Slot
•
Input‐triggered Preset points
•
Motion Detection
•
Privacy mask
•
IP address filtering
•
DC 12 V / AC 24 V / PoE
•
Supports iPhone, iPad, Android & 3GPP
•
28 languages on Web interface
* No SD/SDHC card slot & local storage function for Argentina.
Description
NTSC, IPCAM, 10x Optical Zoom, D1, H.264
PAL, IPCAM, 10x Optical Zoom, D1, H.264
- 1 -
January 28, 2013
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for GeoVision GV-PTZ010D
Summary of Contents for GeoVision GV-PTZ010D
- Page 1 • IP address filtering • DC 12 V / AC 24 V / PoE • Supports iPhone, iPad, Android & 3GPP • 28 languages on Web interface * No SD/SDHC card slot & local storage function for Argentina. Introduction The GV‐PTZ010D camera is a ceiling‐mount device that provides panning, tilting and zooming functions. The camera is designed to monitor a wide area and also to focus on a specific part on the live view when suspicious events occur. There are two models: Models Model Model No. Description GV‐PTZ010D‐N NTSC, IPCAM, 10x Optical Zoom, D1, H.264 GV‐PTZ010D GV‐PTZ010D‐P PAL, IPCAM, 10x Optical Zoom, D1, H.264 - 1 - GV-PTZ010D January 28, 2013...
- Page 2 Dimensions - 2 - GV-PTZ010D January 28, 2013...
-
Page 3: Specifications
Environment Temperature ‐10 °C ~ 50 °C / 14 °F ~ 122 °F Humidity 10% to 90% (no condensation) Power Source 12V DC / 24V AC / PoE Max. Power Consumption 12 W With mounting base 168 x 135.2 mm / 6.61 x 5.32 in and cover Dimensions Without mounting 124.55 x 133.3 mm / 4.9 x 5.25 in base and cover Weight 490 g / 1.08 lb Regulatory CE, FCC, C‐Tick, RoHS compliant - 3 - GV-PTZ010D January 28, 2013... - Page 4 GV‐Eye for Android smartphone, tablet, iPhone and iPod Touch Smart Device Access GV‐Eye HD for iPad Live Viewing IE , mobile phone CMS Server support GV‐Control Center, GV‐Center V2, GV‐VSM Note: Specifications are subject to change without notice. Accessories Name Details Weight: 130 g / 0.29 lb GV‐PA191 PoE Adapter Dimensions (H x W x D): 43 x 69 x 40 mm / 1.69 x 2.72 x 1.57 in The GV‐Relay V2 is designed to expand the voltage load of GV IP devices. It provides 4 relay outputs, and each can be set as GV‐Relay V2 normally open (NO) or normally closed (NC) independently as per your requirement. Power adapters are available in 4 regions: U.S.A., Australia, U.K Power Adapter and Europe. - 4 - GV-PTZ010D January 28, 2013...
