- Page 1 IrDA-9000 UHF 2-Way Synchronizing True Diversity Wireless Microphone System Operation manual ISO 9001 R EG ISTER ED IS O 140 01 ISO 14001 R EG ISTER ED O H S A S 180 01 OHSAS 18001 GREEN PRODUCT...
- Page 2 For more details, please take a few moments to go through this operating manual to have a thorough understanding of the functions and operation of both transmitter and receiver. Parts and functions of IrDA-9000 receiver Front panel 1. Power switch 2.
- Page 3 ISO 9001｜ISO 14001｜OHSAS 18001 Changing CHANNEL / FREQUENCY First, press "SET" till the display shows Then press UP or DOWN to select a new channel. As the channel changes, the frequency changes accordingly, too. After the setting is made, the data will be automatically saved. CHANNEL scanning For an interference- free operation, a cleaner channel might be necessary if the current one receives too much interference.
- Page 4 2. A lower Squelch level means that the audio path will be opened at a weaker RF signal. It is equivalent to increasing the sensitivity of the receiver, thus longer receiving distance. When no interference noise is detected, just adjust the Squelch to the minimum. Receiver installation For best operation, the receiver should be at least 1m above the ground and 1m away from a wall or metal surface to...
- Page 5 ISO 9001｜ISO 14001｜OHSAS 18001 UHF handheld transmitters（SQ-9000 IrDA(R)｜SQ-9000 IrDA｜SQ-8000 IrDA） →SQ-9000 IrDA(R)｜SQ-9000 IrDA 9 10 8 →SQ-8000 IrDA Parts and functions SQ-9000 IrDA(R) SQ-9000 IrDA SQ-8000 IrDA Cartridge Battery power LED Power switch Menu button Setting button IrDA synchronizing button Battery compartment Color cap IrDA sensor area...
- Page 6 4. To change the transmitter’s channel, please press the synchronizing button of the receiver. The receiver will transmit synchronizing signal to the transmitter and change its channel. Other settings 1. Channel setting Use MENU button to go to the CHANNEL page Pressing SET button will increase the channel number.
- Page 7 ISO 9001｜ISO 14001｜OHSAS 18001 UHF belt-pack transmitter（SM-9000 IrDA） Parts and functions 1. Antenna 2. LCD 3. Cover release button 4. Power switch 5. IrDA synchronizing button 6. Menu button 7. Setting button 8. High-impedance gain control (GT) 9. Low-impedance gain control (MT) 10.
- Page 8 AKLN (alkaline) when transmitter is intended for charging as alkaline battery isn’t rechargeable. Wrong battery selection will result in battery sensing electronics to display wrong and misleading status information. CHIAYO ELECTRONICS CO.,LTD. Http://www.chiayo.com.tw｜Email: sales@chiayo.com.tw Office: 30, Lane 27, Section 4, Jen-Ai Road, Taipei 10685, Taiwan｜Tel: 886-2-27415741｜Fax: 886-2-27525242...
