Space requirements

1.6 Space requirements
To ensure that machine operation, consumables replenishing, part replacement, and regular maintenance
can easily be performed, adhere to the recommended space requirements detailed below.

d-Color MF452 plus/MF552 plus

34-11/16 (881)
d-Color MF552 plus+PC-210+FS-535+SD-512+ZU-606+PI-505+LU-204
25-7/8 (658)
d-Color MF452 plus/MF552 plus+PC-210+FS-534+SD-511+LU-301
6-11/16
(170)
d-Color MF222 plus/MF282 plus/MF362 plus/MF452 plus/MF552 plus
100-3/8 (2548)
7-5/16
49 (1244)
(185)
80-3/8 (2041)
15-13/16
38-11/16 (982)
(401)
52-7/16 (1332)
11-5/8
34-1/8 (867)
(295)
d-Color MF452 plus/MF552 plus+PC-210+FS-533+MK-730
9-3/8 16-7/8
(238) (428)
49-1/16 (1246)
16-7/8
(428)
49-1/16 (1246)
16-7/8
(428)
49-1/16 (1246)
32-3/16 (818)
Unit: inch (mm)
32-3/16 (818)
Unit: inch (mm)
32-3/16 (818)
Unit: inch (mm)
