Keithley 3700A Series Quick Start Manual
System switch/multimeter
Hide thumbs
Also See for 3700A Series:
- User manual (74 pages) ,
- Reference manual (936 pages) ,
- Firmware release notes (17 pages)
Related Manuals for Keithley 3700A Series
Summary of Contents for Keithley 3700A Series
- Page 1 Series 3700A System Switch/Multimeter Series 3700A System Switch/Multimeter Quick Start Guide Quick Start Guide...
-
Page 2: Safety Precautions
Observe the following safety precautions before using this product and any associated Keithley Instruments products are designed for use with electrical signals that are rated instrumentation. Although some instruments and accessories would normally be used Measurement Category I and Measurement Category II, as described in the with nonhazardous voltages, there are situations where hazardous conditions may be International Electrotechnical Commission (IEC) Standard IEC 60664. - Page 3 Do not connect switching cards directly to unlimited power circuits. They are intended Chassis connections must only be used as shield connections for measuring circuits, to be used with impedance-limited sources. NEVER connect switching cards directly to NOT as safety earth ground connections. AC mains.
- Page 4 (note that selected parts should be purchased only through Keithley Instruments to maintain accuracy and functionality of the product). If you are unsure about the applicability of a replacement component, call a Keithley Instruments office for information.
- Page 5 Introduction to the Series 3700A System Switch/Multimeter The Series 3700A System Switch/Multimeter offers scalable, The Series 3700A instrument documentation includes: instrument-grade switching and multi-channel measurement solutions Quick Start Guide: Shows you how to unpack and set up the that are optimized for automated testing of electronic products and instrument to determine that the instrument is functional.
-
Page 6: Cd-Rom Contents
Runtime Environment ™ The CD-ROMs that are included with your instrument contain: Keithley I/O layer and release notes The Test Script Builder (TSB) Software and Series 3700A TSB Keithley LXI Discovery Utility Add-in, which is a software tool you can use to create, modify,... -
Page 7: Unpack And Inspect The Instrument
Unpack and inspect the instrument 4. Remove the bag that contains the documentation, accessories, To unpack and inspect the instrument: and CD-ROMs. 1. Inspect the box for damage. Series 3700A documentation 2. Open the top of the box. and accessories Packaging insert 3. - Page 8 6. Inspect the instrument for any obvious signs of physical damage. Report any damage to the shipping agent immediately. You have received one of the following Series 3700A System Switch/Multimeters. Model 3706A six-slot system switch with high-performance DMM Model 3706A-NFP six-slot system switch with high-performance DMM, without front-panel display and keypad and Model 3706A-SNFP six-slot system switch without DMM and front-panel display and keypad...
- Page 9 In addition to the Series 3700A System Switch/Multimeter, you should have received: Series 3700A Product Information and Test Script Builder CD-ROMs Power line cord RJ-45 LAN crossover cable Safety Standards Conformance Information Series 3700A Quick Start Guide Refer to the packing list for additional items that might have shipped with your instrument.
-
Page 10: Connect The Instrument
4 counters) service personnel. For a complete list of cards that are available, see www.keithley.com. The Series 3700A instruments support the following cards: Model 3720 Dual 1×30 Multiplexer Card (automatic CJC with 3720-ST accessory) Model 3721 Dual 1×20 Multiplexer Card (automatic CJC with... - Page 11 Equipment needed: NOTE Series 3700A system switch/multimeter For inexperienced users, disconnect DUT and external circuitry Switching card from switching cards. This allows you to exercise safe close/open operations without the dangers associated with live Flat-bladed screwdriver test circuits. WARNING WARNING To prevent electric shock that could result in injury or death, NEVER handle a switching card that has power applied to it.
- Page 12 3. Disconnect the power line cord and any other cables connected to the rear panel. 4. Remove the slot cover plate from the desired slot. Retain the plate and screws for future use. 5. With the top cover of the switching card facing up, align the card edge into the card guide of the slot.
-
Page 13: Install The Instrument
Install the instrument 8. Reconnect the power line cable and any other cables to the rear panel. A Series 3700A instrument can be used on a bench or in a rack. Note that all signal wiring to devices and instruments is done through Please see the instructions that came with your rack-mount kit if you the switch cards. -
Page 14: Turn On The Instrument
Turn on the instrument Operating the instrument on an incorrect line voltage Turn on the instrument by pressing the front-panel POWER switch may cause damage to the instrument, possibly to the on (|) position. voiding the warranty. The Series 3700A instrument must be turned on and allowed to To connect line power: warm up for at least two hours to achieve rated accuracies. -
Page 15: Power-Up Sequence
Three dots All segments of the display light A brief display showing “KEITHLEY Series 3700A” Line frequency detection and other startup checks When initialization is complete, you will see the default display screen, as shown below. - Page 16 Test the instrument These steps confirm basic functionality of your Series 3700A. Please turn instrument power OFF now. For instruments with a front panel (the Models 3706A and 3706A-S), The examples in the Series 3700A User’s Manual are designed to you can view system information to check operation.
-
Page 17: Next Steps
I find the IP address? that came with your instrument. Run the Keithley LXI Discovery Utility, provided on the Refer to the Series 3700A Switching and Control Cards CD-ROM. For information on using this utility, see the Reference Manual “Communication Interfaces”...
