Series 3700A Switch and Control Cards
Reference Manual
3700AS-909-01 Rev. B / December 2011
A
G
R
E
A
T
E
R
M
E
A
S
U
R
E
O
F
C
O
N
F
I
D
E
N
C
E

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 3720 and is the answer not in the manual?

Questions and answers

Related Manuals for Keithley 3720

Summary of Contents for Keithley 3720

  • Page 1 Series 3700A Switch and Control Cards Reference Manual 3700AS-909-01 Rev. B / December 2011...
  • Page 2 (http://www.lua.org/license.html). Keithley's standard terms and conditions of sale in effect at the time of acceptance of buyer's order by Keithley shall apply to all purchase of goods and performance of services from Keithley, to the exclusion of any additional...
  • Page 3 Keithley Instruments products are designed for use with electrical signals that are rated Measurement Category I and Measurement Category II, as described in the International Electrotechnical Commission (IEC) Standard IEC 60664. Most measurement, control, and data I/O signals are Measurement Category I and must not be directly connected to mains voltage or to voltage sources with high transient over-voltages.
  • Page 4 (note that selected parts should be purchased only through Keithley Instruments to maintain accuracy and functionality of the product). If you are unsure about the applicability of a replacement component, call a Keithley Instruments office for information.

  • Page 5: Table Of Contents

    Interlock status .......................... 3-8 Interlock pin numbers ........................ 3-9 Model 3720 multiplexer card..................4-1 Introduction to the Model 3720 dual 1x30 multiplexer card ............4-1 Available accessories: Model 3720 ................... 4-2 Connection information: Model 3720..................4-2 Schematics: Model 3720 ......................4-3 Model 3721 multiplexer card..................
  • Page 6 Table of Contents Series 3700A Switch and Control Cards Reference Manual Model 3723 high-speed reed relay multiplexer card..........7-1 Introduction to the Model 3723 card ..................7-1 Available accessories: Model 3723..................7-2 Connection information: Model 3723 ................... 7-3 Schematics: Model 3723...................... 7-4 Model 3724 FET multiplexer card ................
  • Page 7 Using match counts....................... 13-18 Latching values ........................13-19 Power consumption implications ................... 13-19 Series 3700 cards connection logs ................A-1 Model 3720 connection log ....................A-2 Model 3721 connection log ....................A-4 Model 3722 connection log ....................A-6 Model 3723 connection logs ....................A-9 Model 3723 connection log (60-channel) ..................A-9 Model 3723 connection log (120-channel) ................A-11...
  • Page 8 Table of Contents Series 3700A Switch and Control Cards Reference Manual Single 4x56 2-pole configuration connection logs ..............A-27 Dual 4x56 configuration connection logs.................A-31 Single 4x112 configuration connection logs ................A-35 Single 8x28 2-pole configuration connection logs ..............A-39 Dual 8x28 configuration connection logs.................A-41 Single 16x28 configuration connection logs ................A-44 Model 3740 connection log ....................A-46 Model 3750 connection log ....................A-48...

  • Page 9: Introduction

    Series 3700A documentation ........... 1-2 Contact information If you have any questions after reviewing this information, please contact your local Keithley Instruments representative or call Keithley Instruments corporate headquarters (toll-free inside the U.S. and Canada only) at 1-888-KEITHLEY (1-888-534-8453), or from outside the U.S. at +1-440-248-0400.

  • Page 10: Series 3700A Documentation

    Model Guide and a brief description of front-panel and 3706A instrument remote interface operation Product Information CD-ROM http://www.keithley.com 3700AS-900-01 Series 3700A System Information about scanning, reading, Product Information CD-ROM Switch/Multimeter User's Manual writing, and controlling channels http://www.keithley.com...

  • Page 11: Series 3700A Cards General Operation

    Pseudocards ................2-4 Available cards The next table shows a list of available cards for the Series 3700A System Switch/Multimeter: Name Description Model 3720 dual 1x30 multiplexer card (see "Model 3720 Offers two independent banks of 1x30 two-pole multiplexers; multiplexer card"...

  • Page 12: Card Installation

    Section 2: Series 3700A cards general operation Series 3700A Switch and Control Cards Reference Manual Card installation WARNING Slot covers must be installed on unused slots to prevent personal contact with high voltage circuits. Perform the following steps to install a switching card into the instrument mainframe: 1.

  • Page 13: Verifying Card Installation

    Series 3700A Switch and Control Cards Reference Manual Section 2: Series 3700A cards general operation Item Description Card guide (part of Series 3700A) Card Card edge (part of card) Mounting screw (part of card) Verifying card installation To verify that the card was properly installed: 1.

  • Page 14: Pseudocards

    Section 2: Series 3700A cards general operation Series 3700A Switch and Control Cards Reference Manual Pseudocards You can perform open, close, and scan operations and configure your system without having an actual switching card installed in your instrument. Using the remote interface, you can assign a pseudocard to an empty switching card slot, allowing the instrument to operate as if a switching card were installed.

  • Page 15: Installed Pseudocards

    A pseudocard can be "installed" in any empty slot. With the 3720 pseudocard "installed," the instrument operates as if a Model 3720 Thermocouple MUX card is installed in the slot. This allows you to configure a scan and exercise its operation before the switching module is installed in the Series 3700A.

  • Page 16: Series 3700A Cards Power Usage

    Section 3 Series 3700A cards power usage In this section: Maximum power usage with Series 3700A cards..... 3-1 Hardware interlocks ..............3-7 Maximum power usage with Series 3700A cards The Series 3700A series offers a growing family of high-density and general-purpose plug-in cards that accommodates a broad range of signals at very competitive pricing.

  • Page 17: Power Budgeting And Calculation

    3700A plug-in cards. The quiescent power is also shown. For latching-type relays NA is used. Model Quiescent power (milliwatts) Channel relay power Backplane relay power consumption (milliwatts) each consumption (milliwatts) each 3720 3721 1350 3722 3723 100 (2-Pole) 50 (1-Pole) 3724...

  • Page 18: Power Budgeting Examples

    Series 3700A Switch and Control Cards Reference Manual Section 3: Series 3700A cards power usage To determine if a given quantity of relay operations can be performed, the previous table must be used to calculate the total power required by applying the example equations: To check power consumption, each slot power must be computed.
  • Page 19 Section 3: Series 3700A cards power usage Series 3700A Switch and Control Cards Reference Manual Totals for each bank are calculated: Slot 1 Slot 2 Slot 3 Total Bank #1 power consumed = 4100 4100 + 4100 12300 Slot 4 Slot 5 Slot 6 Total...
  • Page 20 Series 3700A Switch and Control Cards Reference Manual Section 3: Series 3700A cards power usage Example 3 This example is for a fully loaded Model 3706A-S with Model 3723 cards (all 2-pole mode). Slot # Card Channel relays closed Backplane relays closed Slot 1 3723 Slot 2...
  • Page 21 Series 3700A Switch and Control Cards Reference Manual Example 4 This example is for a fully loaded Model 3706A-S with a mix of cards. Slot # Card Channel relays closed Backplane relays closed Slot 1 3720 Slot 2 3721 Slot 3 3722 15 (2-pole) Slot 4 3723...

  • Page 22: Hardware Interlocks

    Series 3700A Switch and Control Cards Reference Manual Section 3: Series 3700A cards power usage Example 6 This example demonstrates how to calculate the card power of the 3750 when used only as digital outputs. Setup Power Notes CH 1 through 5 set as 3300 Static power required of card under default OUTPUT...

  • Page 23: Engaging Hardware Interlocks

    Section 3: Series 3700A cards power usage Series 3700A Switch and Control Cards Reference Manual Figure 2: Simplified interlock circuit Engaging hardware interlocks To engage the hardware interlocks, you must provide a low-resistance path between the two applicable interlock pins as shown in the diagram. This path routes a 5 V power source to an onboard interlock relay which in turn enables power to the backplane relays.

  • Page 24: Interlock Pin Numbers

    The following table shows the interlock pin numbers for all applicable switching cards. Model Interlock circuit Interlock pins Backplane relays Other relays affected affected 3720 Multiplexer #1 76, 78 n911 through n916 Multiplexer #2 76, 78 n921 through n926 3721...

  • Page 25: Model 3720 Multiplexer Card

    Schematics: Model 3720 ............4-3 Introduction to the Model 3720 dual 1x30 multiplexer card The Model 3720 offers two independent banks of 1×30 two-pole multiplexers (see next figure). It is ideal for general-purpose switching, including temperature measurements. The two banks can automatically be connected to the Series 3700A mainframe backplane and optional DMM through the analog backplane connection relays.

  • Page 26: Available Accessories: Model 3720

    7401 Type K thermocouple wire kit Connection information: Model 3720 Refer to the following figure for the Model 3720 D-sub connection information. Figure : Model 3720 pin connections Figure 4: D-sub connection information for the Model 3720 3700AS-909-01 Rev. B / December 2011...

  • Page 27: Schematics: Model 3720

    Series 3700A Switch and Control Cards Reference Manual Section 4: Model 3720 multiplexer card Schematics: Model 3720 The following figure provides a switching schematic for the Model 3720. Figure : Model 3720 schematic Figure 5: Model 3720 schematic 3700AS-909-01 Rev. A / Preliminary...
  • Page 28 Series 3700A Switch and Control Cards Reference Manual The next figure is a diagram of the screw terminal assembly: Figure: Model 3720 screw terminal assembly circuit board Figure 6: Model 3720 screw terminal assembly circuit board 3700AS-909-01 Rev. B / December 2011...

  • Page 29: Model 3721 Multiplexer Card

    Section 5 Model 3721 multiplexer card In this section: Introduction to the Model 3721 dual 1x20 multiplexer card ..5-1 Available accessories: Model 3721 .......... 5-2 Model 3721-ST accessory board channel list......5-2 Connection information: Model 3721........5-3 Schematics: Model 3721 ............5-4 Amps channel fuse replacement procedure ......

  • Page 30: Available Accessories: Model 3721

    Section 5: Model 3721 multiplexer card Series 3700A Switch and Control Cards Reference Manual Available accessories: Model 3721 Accessory model number Description Model 3721-MTC-1.5 50-pin female-to-male D-sub cable assembly, 1.5 m (4.9 ft) Model 3721-MTC-3 50-pin female-to-male D-sub cable assembly, 3 m (9.8 ft) Model 3721-ST Screw terminal panel with CJC sensor Model 3790-KIT50-R...

  • Page 31: Connection Information: Model 3721

    Series 3700A Switch and Control Cards Reference Manual Section 5: Model 3721 multiplexer card Connection information: Model 3721 Refer to the following figure for the Model 3721 D-sub connection information. Figure : Model 3721 pin connections Figure 8: D-sub connection information for the Model 3721 3700AS-909-01 Rev.

  • Page 32: Schematics: Model 3721

    Section 5: Model 3721 multiplexer card Series 3700A Switch and Control Cards Reference Manual Schematics: Model 3721 The following figure provides a switching schematic for the Model 3721 in two-pole mode. Figure : Model 3721 schematic Figure 9: Schematic of the Model 3721 in two-pole mode 3700AS-909-01 Rev.
  • Page 33 Series 3700A Switch and Control Cards Reference Manual Section 5: Model 3721 multiplexer card The following figure provides a switching schematic for the Model 3721 in 4-wire commonside ohms mode. Figure: Model 3721 wiring diagram Figure 10: Schematic of the Model 3721 in four-wire common side ohm mode 3700AS-909-01 Rev.
  • Page 34 Section 5: Model 3721 multiplexer card Series 3700A Switch and Control Cards Reference Manual Programming Note The 3721 card has three additional backplane relays for commonside ohms functionality. Using 'slotX' or 'allslots' to query settings on this card returns information for channels 1 to 40, 911 to 916, 921 to 926 then 917, 927, and 928 in the response message.

  • Page 35: Amps Channel Fuse Replacement Procedure

    Series 3700A Switch and Control Cards Reference Manual Section 5: Model 3721 multiplexer card Amps channel fuse replacement procedure WARNING Disconnect all external power from the equipment and the line cord before performing any maintenance on the Series 3700A. Make sure that the Model 3721 card is removed from the system before replacing the amps fuse (see next figures).

  • Page 36: Model 3721: Amps Channels Fuse Replacement

    Series 3700A Switch and Control Cards Reference Manual Figure: Model 3721 fuse location on circuit board Figure 13: Fuse location Rating Type Size Keithley Instruments part number 250 V, 3A Fast blow 5 x 20 mm FU-99-1 Model 3721: AMPS channels fuse replacement Channels 41 and 42 are protected by series fuses.

  • Page 37: Model 3722 High-Density Multiplexer Card

    Section 6 Model 3722 high-density multiplexer card In this section: Model 3722 dual 1x48 high-density multiplexer card ....6-1 Available accessories: Model 3722 .......... 6-2 Connection information: Model 3722........6-2 Schematics: Model 3722 ............6-3 Introduction to the Model 3722 card The Model 3722 has two independent banks of 1x48 two-pole multiplexers, which is ideal for applications that require a high channel count.

  • Page 38: Available Accessories: Model 3722

    Section 6: Model 3722 high-density multiplexer card Series 3700A Switch and Control Cards Reference Manual Available accessories: Model 3722 Accessory model number Description Model 3722-MTC-1.5 104-pin, male-to-female D-sub cable assembly, 1.5 m (4.9 ft) Model 3722-MTC-3 104-pin, male-to-female D-sub cable assembly, 3 m (9.8 ft) Model 3792-KIT104-R 104-pin, male, D-sub connector kit (solder-cup contacts) Connection information: Model 3722...

  • Page 39: Schematics: Model 3722

    Series 3700A Switch and Control Cards Reference Manual Section 6: Model 3722 high-density multiplexer card Schematics: Model 3722 The following figure provides a switching schematic for the Model 3722. Figure: Model 3722 schematic Figure 16: Schematic for the Model 3722 3700AS-909-01 Rev.

  • Page 40: Model 3723 High-Speed Reed Relay Multiplexer Card

    Section 7 Model 3723 high-speed reed relay multiplexer card In this section: Model 3723 dual 1x30 high-speed multiplexer card ....7-1 Introduction to the Model 3723 card......... 7-1 Available accessories: Model 3723 .......... 7-2 Connection information: Model 3723........7-3 Schematics: Model 3723 ............7-4 Introduction to the Model 3723 card The Model 3723 has two independent banks of high-speed 1×30 two-pole multiplexers that are ideal for high-speed scanning applications (see next figure).

  • Page 41: Available Accessories: Model 3723

    Section 7: Model 3723 high-speed reed relay multiplexer card Series 3700A Switch and Control Cards Reference Manual Available accessories: Model 3723 Accessory model number Description Model 3720-MTC-1.5 78-pin, female-to-male, D-sub cable assembly, 1.5 m (4.9 ft) Model 3720-MTC-3 78-pin, female-to-male, D-sub cable assembly, 3 m (9.8 ft)

  • Page 42: Connection Information: Model 3723

    Series 3700A Switch and Control Cards Reference Manual Section 7: Model 3723 high-speed reed relay multiplexer card Connection information: Model 3723 Refer to the following figures for the Model 3723 D-sub connection information. Figure: Model 3723 pin connections Figure 18: D-sub connection information for the Model 3723 (two-pole mode) Figure 19: D-sub connection information for the Model 3723 (one-pole mode) 3700AS-909-01 Rev.

  • Page 43: Schematics: Model 3723

    Section 7: Model 3723 high-speed reed relay multiplexer card Series 3700A Switch and Control Cards Reference Manual Schematics: Model 3723 The following figure provides a switching schematic for the Model 3723 in two-pole mode. Figure: Model 3723 schematic Figure 20: Schematic for the Model 3723 in two-pole mode 3700AS-909-01 Rev.
  • Page 44 Series 3700A Switch and Control Cards Reference Manual Section 7: Model 3723 high-speed reed relay multiplexer card The following figure provides a switching schematic for the Model 3723 in single-pole mode. Figure: Model 3723 wiring diagram Figure 21: Schematic: Model 3723 in one-pole mode 3700AS-909-01 Rev.
  • Page 45 Section 7: Model 3723 high-speed reed relay multiplexer card Series 3700A Switch and Control Cards Reference Manual The next figure is a diagram of the screw terminal assembly: Figure: Model 3723 screw terminal assembly circuit board Figure 22: Model 3723 screw terminal assembly circuit board 3700AS-909-01 Rev.
  • Page 46 Series 3700A Switch and Control Cards Reference Manual Section 7: Model 3723 high-speed reed relay multiplexer card NOTE The Model 3723-ST-1 screw terminal assembly has a chassis ground connection for connecting a cable shield (see next figure). Figure: Model 3723-ST-1 screw terminal assembly Figure 23: Model 3723-ST-1 screw terminal assembly 3700AS-909-01 Rev.

  • Page 47: Model 3724 Fet Multiplexer Card

    Section 8 Model 3724 FET multiplexer card In this section: Model 3724 dual 1x30 FET multiplexer card ......8-1 Introduction to the Model 3724 card......... 8-1 Available accessories: Model 3724 .......... 8-2 Connection information: Model 3724........8-2 Schematics: Model 3724 ............8-3 Introduction to the Model 3724 card The Model 3724 has two independent banks of 1×30 2-pole multiplexers.

  • Page 48: Available Accessories: Model 3724

    Section 8: Model 3724 FET multiplexer card Series 3700A Switch and Control Cards Reference Manual Available accessories: Model 3724 Accessory model number Description Model 3720-MTC-1.5 78-pin D-sub female-to-male cable, 1.5 m (4.9 ft) Model 3720-MTC-3 78-pin D-sub female-to-male cable, 3 m (9.8 ft) Model 3724-ST...

  • Page 49: Schematics: Model 3724

    Series 3700A Switch and Control Cards Reference Manual Section 8: Model 3724 FET multiplexer card Schematics: Model 3724 The following figure provides a switching schematic for the Model 3724. Figure: Model 3724 schematic Figure 26: Model 3724 schematic 3700AS-909-01 Rev. A / Preliminary...
  • Page 50 Section 8: Model 3724 FET multiplexer card Series 3700A Switch and Control Cards Reference Manual The next Figure is a diagram of the screw terminal assembly: Figure: Model 3724 screw terminal assembly circuit board Figure 27: Model 3724 screw terminal assembly circuit board 3700AS-909-01 Rev.

  • Page 51: Model 3730 High-Density Matrix Card

    Section 9 Model 3730 high-density matrix card In this section: Model 3730 6x16 high-density matrix card....... 9-1 Introduction to the Model 3730 card......... 9-1 Available accessories: Model 3730 .......... 9-2 Connection information: Model 3730........9-2 Schematics: Model 3730 ............9-3 Introduction to the Model 3730 card The Model 3730 is a two-pole, 6x16 column matrix card.

  • Page 52: Available Accessories: Model 3730

    Section 9: Model 3730 high-density matrix card Series 3700A Switch and Control Cards Reference Manual Available accessories: Model 3730 Accessory model number Description Model 3721-MTC-1.5 50-pin, female-to-male, D-sub cable assembly, 1.5 m (4.9 ft Model 3721-MTC-3 50-pin, female-to-male, D-sub cable assembly, 3 m (9.8 ft) Model 3730-ST Screw terminal panel Model 3790-KIT50-R...

  • Page 53: Schematics: Model 3730

    Series 3700A Switch and Control Cards Reference Manual Section 9: Model 3730 high-density matrix card Schematics: Model 3730 The following figure provides a relay schematic for the Model 3730. Figure: Model 3730 simplified crosspoint relay schmatic Figure 30: Schematic of the Model 3730 3700AS-909-01 Rev.
  • Page 54 Section 9: Model 3730 high-density matrix card Series 3700A Switch and Control Cards Reference Manual The channels on the Model 3730 are matrix channels. Unlike multiplexer (MUX) channels, matrix channels do not have a DMM configuration associated with them. Therefore, specifying a matrix channel in the channel list parameter to the dmm.setconfig() function generates an error.

  • Page 55: Model 3731 High-Speed Reed Relay Matrix Card

    Section 10 Model 3731 high-speed reed relay matrix card In this section: Model 3731 6x16 high-speed reed matrix card ...... 10-1 Introduction to the Model 3731 card........10-1 Available accessories: Model 3731 ........10-2 Connection information: Model 3731........10-2 Schematics: Model 3731 ............10-3 Introduction to the Model 3731 card The Model 3731 is a two-pole, six-row by 16-column reed relay matrix card.

  • Page 56: Available Accessories: Model 3731

    Section 10: Model 3731 high-speed reed relay matrix card Series 3700A Switch and Control Cards Reference Manual Available accessories: Model 3731 Accessory model number Description Model 3721-MTC-1.5 50-pin, female-to-male, D-sub cable assembly, 1.5 m (4.9 ft Model 3721-MTC-3 50-pin, female-to-male, D-sub cable assembly, 3 m (9.8 ft) Model 3731-ST Screw terminal panel Model 3731-KIT50-R...

  • Page 57: Schematics: Model 3731

    Series 3700A Switch and Control Cards Reference Manual Section 10: Model 3731 high-speed reed relay matrix card Schematics: Model 3731 The following figure provides a relay schematic for the Model 3731. Figure: Model 3731 simplified crosspoint relay schematic Figure 34: Model 3731 simplified crosspoint relay schematic 3700AS-909-01 Rev.
  • Page 58 Section 10: Model 3731 high-speed reed relay matrix card Series 3700A Switch and Control Cards Reference Manual The next figure is a diagram of the screw terminal assembly: NOTE The Model 3731-ST screw terminal assembly has a chassis ground connection for connecting a cable shield.

  • Page 59: Model 3732 Quad 4X28 Reed Relay Matrix Card

    Section 11 Model 3732 quad 4x28 reed relay matrix card In this section: Introduction ................11-1 Accessories for Model 3732 ........... 11-2 Maximum power usage with Model 3732 cards ..... 11-2 Measurement considerations ..........11-3 Card configurations .............. 11-14 Model 3732 2-pole operation..........11-35 Cross-card expansion ............

  • Page 60: Additional Features

    The Model 3732 card has two 78-pin D-sub connectors, and two optional screw terminal assemblies are available (Models 3732-ST-C and 3732-ST-R). Accessories for Model 3732 Available accessories for the Keithley Instruments Model 3732 4x28 Ultra-High Density Reed Relay Matrix Card are listed in the table below. Model 3732 available accessories...

  • Page 61: Measurement Considerations

    Series 3700A Switch and Control Cards Reference Manual Section 11: Model 3732 quad 4x28 reed relay matrix card Measurement considerations The Model 3732 uses two 78-pin male D-sub connectors for signal connections. The detachable Models 3732-ST-R and 3732-ST-C screw terminal assemblies can be used for row and column expansion (the Model 3732-ST-C can also be used for direct connections).
  • Page 62 Section 11: Model 3732 quad 4x28 reed relay matrix card Series 3700A Switch and Control Cards Reference Manual Multiplexer examples References Slot Channel 1004 1020 2100 3003 Figure: Multiplexer card display Figure 37: Model 3732 multiplexer card display 11-4 3700AS-909-01 Rev. B / December 2011...
  • Page 63 Series 3700A Switch and Control Cards Reference Manual Section 11: Model 3732 quad 4x28 reed relay matrix card Channel specifiers The channels on the matrix cards are referred to by their slot, bank, row, and column numbers: • Slot number: The number of the slot in which the card is installed. •...

  • Page 64: Configuration And Connection Choices Overview

    Section 11: Model 3732 quad 4x28 reed relay matrix card Series 3700A Switch and Control Cards Reference Manual Backplane relay notation To control analog backplane relays for slots with analog backplane relay channels, use S9BX where: S = Slot number 9 = Backplane notation designation (always 9 when referencing a backplane relay) B = Bank number X = Analog backplane relay number...

  • Page 65: Screw Terminal Assemblies

    NOTE Additional information about screw terminal assemblies is available in the Series 3700A Screw Terminal Assemblies Installation Instructions (part number PA-955), which can be downloaded from the Keithley Instruments website at http://www.keithley.com. 3700AS-909-01 Rev. A / Preliminary 11-7...
  • Page 66 Section 11: Model 3732 quad 4x28 reed relay matrix card Series 3700A Switch and Control Cards Reference Manual Model 3732-ST-C screw terminal assembly The next figure is a diagram of the Model 3732-ST-C screw terminal assembly. NOTE The Model 3732-ST-C screw terminal assembly is labeled to show the correct connections for the default quad 4x28 configuration.
  • Page 67 Series 3700A Switch and Control Cards Reference Manual Section 11: Model 3732 quad 4x28 reed relay matrix card Model 3732-ST-C jumper settings The next table shows the jumper settings for the configurations available using the Model 3732-ST-C screw terminal assembly with your Model 3732 card. Model 3732-ST-C jumper settings Configuration Quad 4x28...
  • Page 68 Section 11: Model 3732 quad 4x28 reed relay matrix card Series 3700A Switch and Control Cards Reference Manual Model 3732-ST-R screw terminal assembly The next figure is a diagram of the Model 3732-ST-R screw terminal assembly. NOTE The Model 3732-ST-R screw terminal assembly is labeled to show the correct connections for the dual 8x28 configuration.

  • Page 69: Direct Wiring

    The next table shows modified jumper settings for direct wiring using the Model 3791-KIT78-R D-sub connector kit, Model 3720-MTC-3 cables, or Model 3720-MTC-1.5 cables to create different configurations. Modified jumper settings and connections for direct wiring:...

  • Page 70: Channel Specifiers

    Section 11: Model 3732 quad 4x28 reed relay matrix card Series 3700A Switch and Control Cards Reference Manual Model 3732 interlock pin numbers The next table shows the Model 3732 interlock pin numbers. Model 3732 interlock pin numbers Interlock circuit Interlock pins Backplane relays affected Other relays affected...
  • Page 71 Series 3700A Switch and Control Cards Reference Manual Section 11: Model 3732 quad 4x28 reed relay matrix card Matrix card notation To specify channels using matrix card notation, use SBRCC, where: Slot number Bank Row number* Some cards use a range of 1 to 4 or 1 to 8; other cards use a range of A to P (refer to the card's documentation) Column number (always use 2 digits) For columns greater than 99, use A0 for column 100, A1 for column 101, A2 for column 102, and so on, through A9 for column 109.

  • Page 72: Single-Pole Configurations

    Section 11: Model 3732 quad 4x28 reed relay matrix card Series 3700A Switch and Control Cards Reference Manual Backplane relay notation To control analog backplane relays for slots with analog backplane relay channels, use S091X, where: Slot number Always zero for Model 3732 backplane relays Always 9 for Model 3732 backplane relays Always 1 for Model 3732 backplane relays Analog backplane relay number...
  • Page 73 Series 3700A Switch and Control Cards Reference Manual Section 11: Model 3732 quad 4x28 reed relay matrix card Quad 4x28 configuration The quad 4x28 configuration, which is the default configuration for the Model 3732 card, allows you to connect four separate banks of 28 crosspoints using jumpers, relays, or the Model 3732-ST-C screw terminal assembly.
  • Page 74 Section 11: Model 3732 quad 4x28 reed relay matrix card Series 3700A Switch and Control Cards Reference Manual Pin assignments and signal naming: Quad 4x28 configuration The Model 3732 is set to the quad 4x28 configuration by default. The next tables show the pin signal name for each pin on each of the D-sub connectors, and list the location of the connection in the switch matrix.
  • Page 75 Series 3700A Switch and Control Cards Reference Manual Section 11: Model 3732 quad 4x28 reed relay matrix card J4 D-sub connector pin assignments for the quad 4x28 configuration: Table 2: Model 3732 J4 D-sub connector pin assignments quad 4x28 3700AS-909-01 Rev. A / Preliminary 11-17...
  • Page 76 Section 11: Model 3732 quad 4x28 reed relay matrix card Series 3700A Switch and Control Cards Reference Manual Matrix crosspoint schematic: Quad 4x28 configuration The next figure is a simplified crosspoint schematic of the quad 4x28 matrix configuration. Figure: Model 3732 simplified crosspoint schematic Figure 44: 3732 4x28 crosspoint Crosspoints 105 Model 3732 in Slot 1 for this configuration...
  • Page 77 Series 3700A Switch and Control Cards Reference Manual Section 11: Model 3732 quad 4x28 reed relay matrix card Dual 4x56 configuration The dual 4x56 configuration allows you to create two banks of 224 crosspoints using bank configuration relays mounted on the Model 3732 card. The columns of these two banks can then be connected using jumpers, relays, or the Model 3732 -ST-C screw terminal assembly.
  • Page 78 Section 11: Model 3732 quad 4x28 reed relay matrix card Series 3700A Switch and Control Cards Reference Manual Pin assignments and signal naming: Dual 4x56 configuration The next tables show the pin signal name for each pin on each of the D-sub connectors, and list the location of the connection in the switch matrix.
  • Page 79 Series 3700A Switch and Control Cards Reference Manual Section 11: Model 3732 quad 4x28 reed relay matrix card J4 D-sub connector pin assignments for the dual 4x56 configuration: Table 4: Model 3732 J4 D-sub connector pin assignments dual 4x56 3700AS-909-01 Rev. A / Preliminary 11-21...
  • Page 80 Section 11: Model 3732 quad 4x28 reed relay matrix card Series 3700A Switch and Control Cards Reference Manual Schematic: Dual 4x56 configuration The next figure is a simplified crosspoint schematic of the dual 4x56 matrix configuration. Figure: Dual 4x56 simplified crosspoint schematic Figure 46: Dual 4x56 simplified crosspoint schematic Crosspoints 105 Bank 1...
  • Page 81 Series 3700A Switch and Control Cards Reference Manual Section 11: Model 3732 quad 4x28 reed relay matrix card Single 4x112 configuration The single 4x112 configuration allows you to connect four banks of 112 crosspoints into a single matrix of 448 crosspoints using bank configuration relays mounted on the Model 3732 card. The columns of these four banks can then be connected using jumpers, relays, or the Model 3732-ST-C screw terminal assembly.
  • Page 82 Section 11: Model 3732 quad 4x28 reed relay matrix card Series 3700A Switch and Control Cards Reference Manual Pin assignments and signal naming: Single 4x112 configuration The next tables show the pin signal name for each pin on each of the D-sub connectors, and list the location of the connection in the switch matrix.
  • Page 83 Series 3700A Switch and Control Cards Reference Manual Section 11: Model 3732 quad 4x28 reed relay matrix card J4 D-sub connector pin assignments for the single 4x112 configuration: Table 6: Model 3732 J4 D-sub connector pin assignments quad 4x112 3700AS-909-01 Rev. A / Preliminary 11-25...
  • Page 84 Section 11: Model 3732 quad 4x28 reed relay matrix card Series 3700A Switch and Control Cards Reference Manual Schematic: Single 4x112 configuration The next figure is a simplified crosspoint schematic of the single 4x112 matrix configuration. Figure: Single 4x112 simplified crosspoint schematic Figure 48: Single 4x112 simplified crosspoint schematic Crosspoints 103 Crosspoints 117...
  • Page 85 Series 3700A Switch and Control Cards Reference Manual Section 11: Model 3732 quad 4x28 reed relay matrix card Dual 8x28 configuration The dual 8x28 configuration allows you to use row expansion to create two banks of 224 crosspoints (each bank consisting of 8 rows and 28 columns) using jumpers, relays, or the Model 3732-ST-R screw terminal assembly.
  • Page 86 Section 11: Model 3732 quad 4x28 reed relay matrix card Series 3700A Switch and Control Cards Reference Manual Pin assignments and signal naming: Dual 8x28 configuration The next tables show the pin signal name for each pin on each of the D-sub connectors, and list the location of the connection in the switch matrix.
  • Page 87 Series 3700A Switch and Control Cards Reference Manual Section 11: Model 3732 quad 4x28 reed relay matrix card J4 D-sub connector pin assignments for the dual 8x28 configuration: Table 8: Model 3732 J4 D-sub connector pin assignments quad 8x28 3700AS-909-01 Rev. A / Preliminary 11-29...
  • Page 88 Section 11: Model 3732 quad 4x28 reed relay matrix card Series 3700A Switch and Control Cards Reference Manual Schematic: Dual 8x28 configuration The next figure is a simplified crosspoint schematic of the dual 8x28 matrix configuration. Figure:Dual 8x28 simplified crosspoint schematic Figure 50: Dual 8x28 simplified crosspoint schematic Model 3732 in Slot 1 for this configuration Crosspoints 105...
  • Page 89 Series 3700A Switch and Control Cards Reference Manual Section 11: Model 3732 quad 4x28 reed relay matrix card Single 16x28 configuration The single 16x28 configuration allows you to use row expansion to create a single bank consisting of 16 rows and 28 columns using jumpers, relays, or the Model 3732-ST-R screw terminal assembly. NOTE Refer to the Screw terminal assemblies...
  • Page 90 Section 11: Model 3732 quad 4x28 reed relay matrix card Series 3700A Switch and Control Cards Reference Manual Pin assignments and signal naming: Single 16x28 configuration The next tables show the pin signal name for each pin on each of the D-sub connectors, and list the location of the connection in the switch matrix.
  • Page 91 Series 3700A Switch and Control Cards Reference Manual Section 11: Model 3732 quad 4x28 reed relay matrix card J4 D-sub connector pin assignments for the single 16x28 configuration: Table 10: Model 3732 J4 D-sub connector pin assignments single 16x28 3700AS-909-01 Rev. A / Preliminary 11-33...
  • Page 92 Section 11: Model 3732 quad 4x28 reed relay matrix card Series 3700A Switch and Control Cards Reference Manual Schematic: Single 16x28 configuration The next figure is a simplified crosspoint schematic of the single 16x28 matrix configuration. Figure: Single 16x28 simplified crosspoint schematic Figure 52: Single 16x28 simplified crosspoint schematic Model 3732 in Slot 1 for this configuration Crosspoints 105...

  • Page 93: Model 3732 2-Pole Operation

    Series 3700A Switch and Control Cards Reference Manual Section 11: Model 3732 quad 4x28 reed relay matrix card Model 3732 2-pole operation There are three additional Model 3732 2-pole configurations available using Model 3706A software with the Model 3732 card: •...
  • Page 94 Section 11: Model 3732 quad 4x28 reed relay matrix card Series 3700A Switch and Control Cards Reference Manual Dual 4x28 2-pole configuration The dual 4x28 2-pole configuration allows you to automatically link four contact sets to act as two pairs. Using the internal relays, you can create a matrix consisting of two banks of paired crosspoints, each with four rows and up to 28 columns.
  • Page 95 Series 3700A Switch and Control Cards Reference Manual Section 11: Model 3732 quad 4x28 reed relay matrix card Pin assignments and signal naming: Dual 4x28 2-pole configuration The next tables show the pin signal name for each pin on each of the D-sub connectors, and list the location of the connection in the switch matrix.
  • Page 96 Section 11: Model 3732 quad 4x28 reed relay matrix card Series 3700A Switch and Control Cards Reference Manual J4 D-sub connector pin assignments for the dual 4x28 2-pole configuration: Table 12: Model 3732 J4 D-sub connector pin assignments dual 4x28 11-38 3700AS-909-01 Rev.
  • Page 97 Series 3700A Switch and Control Cards Reference Manual Section 11: Model 3732 quad 4x28 reed relay matrix card Schematic: Dual 4x28 2-pole configuration The next table is a simplified crosspoint schematic of the dual 4x28 2-pole matrix configuration. NOTE When viewing the crosspoint matrix for your 2-pole configuration in the Series 3700A web interface on your computer, the low crosspoint in a channel pair will appear unavailable (gray).
  • Page 98 Section 11: Model 3732 quad 4x28 reed relay matrix card Series 3700A Switch and Control Cards Reference Manual Single 4x56 2-pole configuration The single 4x56 2-pole configuration allows you to automatically link two contact sets to act as one pair. Using either direct cabling or the Model 3732-ST-C screw terminal assembly, you can create a matrix consisting of one bank of paired crosspoints with four rows and up to 56 columns.
  • Page 99 Series 3700A Switch and Control Cards Reference Manual Section 11: Model 3732 quad 4x28 reed relay matrix card Pin assignments and signal naming: Single 4x56 2-pole configuration The next tables show the pin signal name for each pin on each of the D-sub connectors, and list the location of the connection in the switch matrix.
  • Page 100 Section 11: Model 3732 quad 4x28 reed relay matrix card Series 3700A Switch and Control Cards Reference Manual J4 D-sub connector pin assignments for the single 4x56 2-pole configuration: Table 14: Model 3732 J4 D-sub connector pin assignments single 4x56 11-42 3700AS-909-01 Rev.
  • Page 101 Series 3700A Switch and Control Cards Reference Manual Section 11: Model 3732 quad 4x28 reed relay matrix card Schematic: Single 4x56 2-pole configuration The next figure is a simplified crosspoint schematic of the single 4x56 2-pole matrix configuration. NOTE When viewing the crosspoint matrix for your 2-pole configuration in the Series 3700A web interface on your computer, the low crosspoint in a channel pair will appear unavailable (gray).
  • Page 102 Section 11: Model 3732 quad 4x28 reed relay matrix card Series 3700A Switch and Control Cards Reference Manual Single 8x28 2-pole configuration The single 8x28 2-pole configuration allows you to automatically link two contact sets to act as one pair. Using the Model 3732-ST-R screw terminal assembly, you can create a matrix consisting of one bank of paired crosspoints with eight rows and up to 28 columns.
  • Page 103 Series 3700A Switch and Control Cards Reference Manual Section 11: Model 3732 quad 4x28 reed relay matrix card Pin assignments and signal naming: Single 8x28 2-pole configuration The next tables show the pin signal name for each pin on each of the D-sub connectors, and list the location of the connection in the switch matrix.
  • Page 104 Section 11: Model 3732 quad 4x28 reed relay matrix card Series 3700A Switch and Control Cards Reference Manual J4 D-sub connector pin assignments for the single 8x28 2-pole configuration: Table 16: Model 3732 J4 D-sub connector pin assignments single 8x28 11-46 3700AS-909-01 Rev.
  • Page 105 Series 3700A Switch and Control Cards Reference Manual Section 11: Model 3732 quad 4x28 reed relay matrix card Schematic: Single 8x28 2-pole configuration The next figure is a simplified crosspoint schematic of the single 8x28 2-pole matrix configuration. NOTE When viewing the crosspoint matrix for your 2-pole configuration in the Series 3700A web interface on your computer, the low crosspoint in a channel pair will appear unavailable (gray).

  • Page 106: Cross-Card Expansion

    Section 11: Model 3732 quad 4x28 reed relay matrix card Series 3700A Switch and Control Cards Reference Manual Cross-card expansion You can use the Model 3706A analog backplane to expand the number of columns in a system beyond the capacity of a single Model 3732 card. The signal paths on the backplane can be used to interconnect the rows on up to six Model 3732 cards by closing the appropriate backplane relays on all of the cards.

  • Page 107: Cross-Card Expansion Examples

    Series 3700A Switch and Control Cards Reference Manual Section 11: Model 3732 quad 4x28 reed relay matrix card Cross-card expansion examples The following examples describe cross-card expansion using the Model 3706A with two Model 3732 cards installed in slots 1 and 2. Example 1: Configure an expanded 4x224 1-pole matrix 1.

  • Page 108: Programmatic Connection Method

    Section 11: Model 3732 quad 4x28 reed relay matrix card Series 3700A Switch and Control Cards Reference Manual Programmatic connection method DMM connections can also be made using the backplane relays on the Model 3732 card. This method eliminates the requirement to make external connections to the analog backplane connector. Note that there are two disadvantages to this connection method: 1.

  • Page 109: Using The Series 3700A Front Panel With The Model 3732 Card

    Series 3700A Switch and Control Cards Reference Manual Section 11: Model 3732 quad 4x28 reed relay matrix card Using the Series 3700A front panel with the Model 3732 card Because of the change in channel specifiers for the Model 3732 card, the front panel now displays an extra digit (see next figure).

  • Page 110: Pseudocard Support For The Model 3732

    Section 11: Model 3732 quad 4x28 reed relay matrix card Series 3700A Switch and Control Cards Reference Manual Pseudocard support for the Model 3732 Traditionally, pseudocard numbers have been the same as the desired card model number. Because of the different Model 3732 configurations, a digit has been added to the model number to specify the desired configuration.

  • Page 111: Model 3740 General Purpose Card

    Section 12 Model 3740 general purpose card In this section: Model 3740 32-channel isolated switch card......12-1 Introduction to the Model 3740 card........12-1 Available accessories: Model 3740 ........12-2 Connection information: Model 3740........12-2 Schematics: Model 3740 ............12-3 Introduction to the Model 3740 card The Model 3740 offers 28 general-purpose form C channels that are ideal for routing power or other control devices (see next figure).

  • Page 112: Available Accessories: Model 3740

    Section 12: Model 3740 general purpose card Series 3700A Switch and Control Cards Reference Manual Available accessories: Model 3740 Accessory model number Description Model 3721-MTC-1.5 50-pin, female-to-male, D-sub cable assembly, 1.5 m (4.9 ft Model 3721-MTC-3 50-pin, female-to-male, D-sub cable assembly, 3 m (9.8 ft) Model 3740-ST Screw terminal panel Model 3790-KIT50-R...

  • Page 113: Schematics: Model 3740

    Series 3700A Switch and Control Cards Reference Manual Section 12: Model 3740 general purpose card Schematics: Model 3740 The following figure provides a switching schematic for the Model 3740. Figure: Model 3740 schematic Figure 62: Schematic for the Model 3740 3700AS-909-01 Rev.
  • Page 114 Section 12: Model 3740 general purpose card Series 3700A Switch and Control Cards Reference Manual The next figure is a diagram of the screw terminal assembly: NOTE The Model 3740-ST screw terminal assembly has a chassis ground connection for connecting a cable shield.

  • Page 115: Model 3750 Multifunction Control Card

    Section 13 Model 3750 multifunction control card In this section: Model 3750 multifunction I/O card.......... 13-1 Available accessories: Model 3750 ........13-2 Connection information: Model 3750........13-2 Schematics: Model 3750 ............13-3 Model 3750 additional information ......... 13-4 Digital I/O ................13-4 Counter/totalizer..............

  • Page 116: Available Accessories: Model 3750

    Section 13: Model 3750 multifunction control card Series 3700A Switch and Control Cards Reference Manual Available accessories: Model 3750 Accessory model number Description Model 3721-MTC-1.5 50-pin, female-to-male, D-sub cable assembly, 1.5 m (4.9 ft Model 3721-MTC-3 50-pin, female-to-male, D-sub cable assembly, 3 m (9.8 ft) Model 3750-ST Screw terminal panel Model 3790-KIT50-R...

  • Page 117: Schematics: Model 3750

    Series 3700A Switch and Control Cards Reference Manual Section 13: Model 3750 multifunction control card Schematics: Model 3750 The next figure is a diagram of the screw terminal assembly: NOTE The Model 3750-ST screw terminal assembly has a chassis ground connection for connecting a cable shield.

  • Page 118: Model 3750 Additional Information

    Section 13: Model 3750 multifunction control card Series 3700A Switch and Control Cards Reference Manual Model 3750 additional information Digital I/O CAUTION Do not exceed the maximum rated voltages and currents for the digital I/O banks. Do not apply negative voltages to any of the inputs. Unused inputs should not be left floating, but should be tied to either a ground or a positive DC voltage.
  • Page 119 Series 3700A Switch and Control Cards Reference Manual Section 13: Model 3750 multifunction control card The factory default jumpers are set as follows: • Connects the digital lines on each bank to the internal pull-up resistors. • Connects those pull-up resistors to the internal +5 V. •...
  • Page 120 Section 13: Model 3750 multifunction control card Series 3700A Switch and Control Cards Reference Manual Sourcing current to an external load When outputs are set to logic high, they are capable of sourcing up to 10 mA of current and maintaining a logic high state on the output.
  • Page 121 Series 3700A Switch and Control Cards Reference Manual Section 13: Model 3750 multifunction control card To write to the banks Because the default state of a digital I/O bank is configured as an input, the mode needs to be changed so that it is ready to accept write commands by using the channel.setmode() command: channel.setmode("1005", channel.MODE_OUTPUT) To write a single bank of 8 bits associated with channel 5, send the channel.write() command: channel.write("1005", 9)

  • Page 122: Counter/Totalizer

    Section 13: Model 3750 multifunction control card Series 3700A Switch and Control Cards Reference Manual Counter/totalizer CAUTION Do not exceed the maximum voltage and currents as listed on the Model 3750 specifications. Unused inputs should not be left floating but should be tied to ground or an appropriate DC voltage. There are four separate totalizer channels, numbered 6 through 9, on a Model 3750 card.
  • Page 123 Series 3700A Switch and Control Cards Reference Manual Section 13: Model 3750 multifunction control card • To read the current total closure counts: channel.setmode("1009", channel.MODE_RISING_TTL_EDGE) count = channel.read("1009") • To reset the counter to zero using an explicit command: channel.write("1009", 0) •...

  • Page 124: Analog Output

    Section 13: Model 3750 multifunction control card Series 3700A Switch and Control Cards Reference Manual Analog output There are two channels of isolated analog outputs on the Model 3750 card. Each channel can be configured for either voltage output or current output. Voltage output provides for +/- 12 V and is capable of providing up to 20 mA of current.
  • Page 125 Series 3700A Switch and Control Cards Reference Manual Section 13: Model 3750 multifunction control card Using the card when configured as voltage outputs To set the analog voltage output level to -3.5 volts: channel.setmode('1010', channel.MODE_VOLTAGE_1) channel.setoutputenable('1010', channel.ON) channel.write('1010', -3.5) Once the output voltage is set and the output is enabled, the output attempts to drive the external circuitry to the value specified.

  • Page 126: Hardware Configuration

    Section 13: Model 3750 multifunction control card Series 3700A Switch and Control Cards Reference Manual Output loading precautions In addition to the maximum specified loads for the output voltage and current, note several other precautions: • Excessive amounts of capacitance present on the voltage output nodes can affect their normal behavior.
  • Page 127 Series 3700A Switch and Control Cards Reference Manual Section 13: Model 3750 multifunction control card Figure 71: Removing the top shield Figure: Location of P3 and J5 jumpers Figure 72: Location of P3 and J5 jumpers 3700AS-909-01 Rev. A / Preliminary 13-13...
  • Page 128 Section 13: Model 3750 multifunction control card Series 3700A Switch and Control Cards Reference Manual The connector labeled P3 contains all of the jumpers needed to configure digital I/O and VEXT1, VEXT2. The connector labeled J5 contains a single jumper option that configures the backplane relays.
  • Page 129 Series 3700A Switch and Control Cards Reference Manual Section 13: Model 3750 multifunction control card Calibration steps for analog output channels For DAC channels, a calibration sequence includes these steps: 1. Set voltage, –12 V to +12 V range, generate negative point 1. 2.
  • Page 130 Section 13: Model 3750 multifunction control card Series 3700A Switch and Control Cards Reference Manual Calibration example script The following script creates two functions. You can use "cal_dac" and "cal_tot" to calibrate the analog outputs channels and counter channels respectively. loadscript cal -- Create a function called cal_dac that takes slot number -- and channel number as parameters.
  • Page 131 Series 3700A Switch and Control Cards Reference Manual Section 13: Model 3750 multifunction control card print(rdg) channel.calibration.step("" .. channel_num,10,rdg) dmm.range=.1 channel.calibration.step("" .. channel_num,11) delay(6) rdg=dmm.measure() print(rdg) channel.calibration.step("" .. channel_num,12,rdg) dmm.range=.01 channel.calibration.step("" .. channel_num,13) delay(6) rdg=dmm.measure() print(rdg) channel.calibration.step("" .. channel_num,14,rdg) dmm.range=.1 channel.calibration.step(""...

  • Page 132: Using Match Counts

    Section 13: Model 3750 multifunction control card Series 3700A Switch and Control Cards Reference Manual Power consumption information You can power off each analog channel if it is not being used to reduce the power required of the card with channel.setpowerstate(). The card has a default static power draw of 3300 mW, which includes powering the totalizer channels and both analog output channels.

  • Page 133: Latching Values

    Series 3700A Switch and Control Cards Reference Manual Section 13: Model 3750 multifunction control card Latching values Channels support a status/state concept. The status of a channel indicates what conditions are present on that channel at that point in time. Examples of channel status are: •...
  • Page 134 Section 13: Model 3750 multifunction control card Series 3700A Switch and Control Cards Reference Manual Options for working with power consumption limitations If the system is experiencing power limitations, there are two ways to possibly improve the power capability of the system. •...

  • Page 135: Series 3700 Cards Connection Logs

    Appendix A Series 3700 cards connection logs In this appendix: Model 3720 connection log............A-2 Model 3721 connection log............A-4 Model 3722 connection log............A-6 Model 3723 connection logs.............A-9 Model 3724 connection log.............A-14 Model 3730 connection log.............A-18 Model 3732 connection logs...........A-18 Model 3740 connection log.............A-46...

  • Page 136: Model 3720 Connection Log

    Model 3720 connection log The following figures provide a sample of a connection log that can be used to record the wiring scheme for this module. Figure 73: Sample Model 3720 connection log (1 of 2) 3700AS-909-01 Rev. B / December 2011...
  • Page 137 Series 3700A Switch and Control Cards Reference Manual Appendix A: Series 3700 cards connection logs Figure 74: Sample Model 3720 connection log (2 of 2) 3700AS-909-01 Rev. A / Preliminary...

  • Page 138: Model 3721 Connection Log

    Appendix A: Series 3700 cards connection logs Series 3700A Switch and Control Cards Reference Manual Model 3721 connection log The following figures provide a sample of a connection log that can be used to record the wiring scheme for this module. Figure 75: Sample Model 3721 connection log (1 of 2) 3700AS-909-01 Rev.
  • Page 139 Series 3700A Switch and Control Cards Reference Manual Appendix A: Series 3700 cards connection logs Figure 76: Sample Model 3721 connection log (2 of 2) 3700AS-909-01 Rev. A / Preliminary...

  • Page 140: Model 3722 Connection Log

    Appendix A: Series 3700 cards connection logs Series 3700A Switch and Control Cards Reference Manual Model 3722 connection log The following figures provide a sample of a connection log that can be used to record the wiring scheme for this module. Figure 77: Sample Model 3722 connection log (1 of 3) 3700AS-909-01 Rev.
  • Page 141 Series 3700A Switch and Control Cards Reference Manual Appendix A: Series 3700 cards connection logs Figure 78: Sample Model 3722 connection log (2 of 3) 3700AS-909-01 Rev. A / Preliminary...
  • Page 142 Appendix A: Series 3700 cards connection logs Series 3700A Switch and Control Cards Reference Manual Figure 79: Sample Model 3722 connection log (3 of 3) 3700AS-909-01 Rev. B / December 2011...

  • Page 143: Model 3723 Connection Logs

    Series 3700A Switch and Control Cards Reference Manual Appendix A: Series 3700 cards connection logs Model 3723 connection logs Model 3723 connection log (60-channel) The following figures provide a sample of a connection log that can be used to record the wiring scheme for this module.
  • Page 144 Appendix A: Series 3700 cards connection logs Series 3700A Switch and Control Cards Reference Manual Figure 81: Sample Model 3723 connection log (60-channel) (2 of 2) A-10 3700AS-909-01 Rev. B / December 2011...

  • Page 145: Model 3723 Connection Log (120-Channel

    Series 3700A Switch and Control Cards Reference Manual Appendix A: Series 3700 cards connection logs Model 3723 connection log (120-channel) The following figures provide a sample of a connection log that can be used to record the wiring scheme for this module. Figure 82: Sample Model 3723 connection log (120-channel) (1 of 4) 3700AS-909-01 Rev.
  • Page 146 Appendix A: Series 3700 cards connection logs Series 3700A Switch and Control Cards Reference Manual Figure 83: Sample Model 3723 connection log (120-channel) (2 of 4) A-12 3700AS-909-01 Rev. B / December 2011...
  • Page 147 Series 3700A Switch and Control Cards Reference Manual Appendix A: Series 3700 cards connection logs Figure 84: Sample Model 3723 connection log (120-channel) (3 of 4) 3700AS-909-01 Rev. A / Preliminary A-13...
  • Page 148 Appendix A: Series 3700 cards connection logs Series 3700A Switch and Control Cards Reference Manual Figure 85: Sample Model 3723 connection log (120-channel) (4 of 4) A-14 3700AS-909-01 Rev. B / December 2011...

  • Page 149: Model 3724 Connection Log

    Series 3700A Switch and Control Cards Reference Manual Appendix A: Series 3700 cards connection logs Model 3724 connection log The following table provides a sample of a connection log that can be used to record the wiring scheme for this module. LChannel Color Pin Number...
  • Page 150 Appendix A: Series 3700 cards connection logs Series 3700A Switch and Control Cards Reference Manual LChannel Color Pin Number CH20 CH21 CH22 CH23 CH24 CH25 CH26 CH27 CH28 CH29 CH30 OUTPUT 2 CH31 CH32 CH33 CH34 CH35 CH36 CH37 CH38 CH39 CH40 CH41...
  • Page 151 Series 3700A Switch and Control Cards Reference Manual Appendix A: Series 3700 cards connection logs LChannel Color Pin Number CH43 CH44 CH45 CH46 CH47 CH48 CH49 CH50 CH51 CH52 CH53 CH54 CH55 CH56 CH57 CH58 CH59 CH60 3700AS-909-01 Rev. A / Preliminary A-17...

  • Page 152: Model 3730 Connection Log

    Appendix A: Series 3700 cards connection logs Series 3700A Switch and Control Cards Reference Manual Model 3730 connection log The following figures provide a sample of a connection log that can be used to record the wiring scheme for this module. Figure 86: Sample Model 3730 connection log Model 3732 connection logs Dual 4x28 2-pole configuration connection logs...
  • Page 153 Series 3700A Switch and Control Cards Reference Manual Appendix A: Series 3700 cards connection logs The next tables are examples of connection logs you can use to record the wiring scheme for the Model 3732 in the dual 4x28 2-pole configuration. Model 3732 connection log for the dual 4x28 2-pole configuration (1 of 4): signal Bank...
  • Page 154 Appendix A: Series 3700 cards connection logs Series 3700A Switch and Control Cards Reference Manual Model 3732 connection log for the dual 4x28 2-pole configuration (2 of 4): signal Bank Connection name Color Description Row 1 Low R11L Row 2 Low R12L Row 3 Low R13L...
  • Page 155 Series 3700A Switch and Control Cards Reference Manual Appendix A: Series 3700 cards connection logs Model 3732 connection log for the dual 4x28 2-pole configuration (3 of 4): signal Bank Connection name Color Description Row 1 High R21H Row 2 High R22H Row 3 High R23H...
  • Page 156 Appendix A: Series 3700 cards connection logs Series 3700A Switch and Control Cards Reference Manual Model 3732 connection log for the dual 4x28 2-pole configuration (4 of 4): signal Bank Connection name Color Description Row 1 Low R21L Row 2 Low R22L Row 3 Low R23L...

  • Page 157: Quad 4X28 Configuration Connection Logs

    Series 3700A Switch and Control Cards Reference Manual Appendix A: Series 3700 cards connection logs Quad 4x28 configuration connection logs The next tables are examples of connection logs that you can use to record the wiring scheme for the Model 3732 in the quad 4x28 configuration. Model 3732 connection log for the quad 4x28 configuration (1 of 4): Pin signal Bank...
  • Page 158 Appendix A: Series 3700 cards connection logs Series 3700A Switch and Control Cards Reference Manual Model 3732 connection log for the quad 4x28 configuration (2 of 4): Pin signal name Bank Connection Color Description Row 1 Row 2 Row 3 Row 4 Column 1 C201...
  • Page 159 Series 3700A Switch and Control Cards Reference Manual Appendix A: Series 3700 cards connection logs Model 3732 connection log for the quad 4x28 configuration (3 of 4): Pin signal name Bank Connection Color Description Row 1 Row 2 Row 3 Row 4 Column 1 C301...
  • Page 160 Appendix A: Series 3700 cards connection logs Series 3700A Switch and Control Cards Reference Manual Model 3732 connection log for the quad 4x28 configuration (4 of 4): Pin signal name Bank Connection Color Description Row 1 Row 2 Row 3 Row 4 Column 1 C401...

  • Page 161: Single 4X56 2-Pole Configuration Connection Logs

    Series 3700A Switch and Control Cards Reference Manual Appendix A: Series 3700 cards connection logs Single 4x56 2-pole configuration connection logs The next tables are examples of connection logs that you can use to record the wiring scheme for the Model 3732 in the single 4x56 2-pole configuration.
  • Page 162 Appendix A: Series 3700 cards connection logs Series 3700A Switch and Control Cards Reference Manual Model 3732 connection log for the single 4x56 2-pole configuration (2 of 4) signal Bank Connection name Color Description Column 29 High C129H Column 30 High C130H Column 31 High C131H...
  • Page 163 Series 3700A Switch and Control Cards Reference Manual Appendix A: Series 3700 cards connection logs Model 3732 connection log for the single 4x56 2-pole configuration (3 of 4) signal Bank Connection name Color Description Row 1 Low R11L Row 2 Low R12L Row 3 Low R13L...
  • Page 164 Appendix A: Series 3700 cards connection logs Series 3700A Switch and Control Cards Reference Manual Model 3732 connection log for the single 4x56 2-pole configuration (4 of 4) signal Bank Connection name Color Description Column 29 Low C129L Column 30 Low C130L Column 31 Low C131L...

  • Page 165: Dual 4X56 Configuration Connection Logs

    Series 3700A Switch and Control Cards Reference Manual Appendix A: Series 3700 cards connection logs Dual 4x56 configuration connection logs The next tables are examples of connection logs that you can use to record the wiring scheme for the Model 3732 in the dual 4x56 configuration. Model 3732 connection log for the dual 4x56 configuration (1 of 4): Pin signal Bank...
  • Page 166 Appendix A: Series 3700 cards connection logs Series 3700A Switch and Control Cards Reference Manual Model 3732 connection log for the dual 4x56 configuration (2 of 4): Pin signal name Bank Connection Color Description Column 29 C129 Column 30 C130 Column 31 C131 Column 32...
  • Page 167 Series 3700A Switch and Control Cards Reference Manual Appendix A: Series 3700 cards connection logs Model 3732 connection log for the dual 4x56 configuration (3 of 4): Pin signal name Bank Connection Color Description Row 1 Row 2 Row 3 Row 4 Column 1 C201...
  • Page 168 Appendix A: Series 3700 cards connection logs Series 3700A Switch and Control Cards Reference Manual Model 3732 connection log for the dual 4x56 configuration (4 of 4): Pin signal name Bank Connection Color Description Column 29 C229 Column 30 C230 Column 31 C231 Column 32...

  • Page 169: Single 4X112 Configuration Connection Logs

    Series 3700A Switch and Control Cards Reference Manual Appendix A: Series 3700 cards connection logs Single 4x112 configuration connection logs The next tables are examples of connection logs that you can use to record the wiring scheme for the Model 3732 in the single 4x112 configuration. Model 3732 connection log for the single 4x112 configuration (1 of 4): Pin signal Bank...
  • Page 170 Appendix A: Series 3700 cards connection logs Series 3700A Switch and Control Cards Reference Manual Model 3732 connection log for the single 4x112 configuration (2 of 4): Pin signal name Bank Connection Color Description Column 29 C129 Column 30 C130 Column 31 C131 Column 32...
  • Page 171 Series 3700A Switch and Control Cards Reference Manual Appendix A: Series 3700 cards connection logs Model 3732 connection log for the single 4x112 configuration (3 of 4): Pin signal name Bank Connection Color Description Column 61 C161 Column 62 C162 Column 63 C163 Column 64...
  • Page 172 Appendix A: Series 3700 cards connection logs Series 3700A Switch and Control Cards Reference Manual Model 3732 connection log for the single 4x112 configuration (4 of 4): Pin signal name Bank Connection Color Description Column 93 C193 Column 94 C194 Column 95 C195 Column 96...

  • Page 173: Single 8X28 2-Pole Configuration Connection Logs

    Series 3700A Switch and Control Cards Reference Manual Appendix A: Series 3700 cards connection logs Single 8x28 2-pole configuration connection logs The next tables are examples of connection logs you can use to record the wiring scheme for the Model 3732 in the single 8x28 2-pole configuration. Model 3732 connection log for the single 8x28 2-pole configuration (1 of 2): Bank Connection...
  • Page 174 Appendix A: Series 3700 cards connection logs Series 3700A Switch and Control Cards Reference Manual Model 3732 connection log for the single 8x28 2-pole configuration (2 of 2): Bank Connection Pin signal name Color Description Column 27 High C127H Column 28 High C128H Row 1 Low R11L...

  • Page 175: Dual 8X28 Configuration Connection Logs

    Series 3700A Switch and Control Cards Reference Manual Appendix A: Series 3700 cards connection logs Dual 8x28 configuration connection logs The next tables are examples of connection logs that you can use to record the wiring scheme for the Model 3732 in the dual 8x28 configuration. Model 3732 connection log for the dual 8x28 configuration (1 of 3): Pin signal Bank...
  • Page 176 Appendix A: Series 3700 cards connection logs Series 3700A Switch and Control Cards Reference Manual Model 3732 connection log for the dual 8x28 configuration (2 of 3): Pin signal name Bank Connection Color Description Column 25 C125 Column 26 C126 Column 27 C127 Column 28...
  • Page 177 Series 3700A Switch and Control Cards Reference Manual Appendix A: Series 3700 cards connection logs Model 3732 connection log for the dual 8x28 configuration (3 of 3): Pin signal name Bank Connection Color Description Column 21 C221 Column 22 C222 Column 23 C223 Column 24...

  • Page 178: Single 16X28 Configuration Connection Logs

    Appendix A: Series 3700 cards connection logs Series 3700A Switch and Control Cards Reference Manual Single 16x28 configuration connection logs The next tables are examples of connection logs you can use to record the wiring scheme for the Model 3732 in the single 16x28 configuration. Model 3732 connection log for the single 16x28 configuration (1 of 2): Pin signal Bank...
  • Page 179 Series 3700A Switch and Control Cards Reference Manual Appendix A: Series 3700 cards connection logs Model 3732 connection log for the single 16x28 configuration (2 of 2): Pin signal name Bank Connection Color Description Column 17 C117 Column 18 C118 Column 19 C119 Column 20...

  • Page 180: Model 3740 Connection Log

    Appendix A: Series 3700 cards connection logs Series 3700A Switch and Control Cards Reference Manual Model 3740 connection log The next table is an examples of a connection log you can use to record the wiring scheme for the Model 3740 card configuration. Figure 87: Sample Model 3740 connection log (1 of 2) A-46 3700AS-909-01 Rev.
  • Page 181 Series 3700A Switch and Control Cards Reference Manual Appendix A: Series 3700 cards connection logs Figure 88: Sample Model 3740 connection log (2 of 2) 3700AS-909-01 Rev. A / Preliminary A-47...

  • Page 182: Model 3750 Connection Log

    Appendix A: Series 3700 cards connection logs Series 3700A Switch and Control Cards Reference Manual Model 3750 connection log The next table is an examples of a connection log you can use to record the wiring scheme for the Model 3750 card configuration. Channel Color Pin Number...
  • Page 183 Series 3700A Switch and Control Cards Reference Manual Appendix A: Series 3700 cards connection logs Channel Color Pin Number CH6 - Input+ CH6 - Input- CH7 - Gate+ CH7 - Gate- CH7 - Input+ CH7 - Input- CH8 - Gate+ CH8 - Gate- CH8 - Input+ CH8 - Input-...

  • Page 184: Index

    • 13-11 example script • 13-13 preparing for • 13-11 match counts • 13-15 sequence • 13-12 Model 3720 • 4-1 channel fuse replacement • 5-7 Model 3721 • 5-1 circuits • See logic circuits Model 3722 • 6-1 logic, circuit •...
  • Page 185 Index Series 3700A Switch and Control Cards Reference Manual requirements power • 13-16 scan channels • 13-4 schematics • 4-3, 5-4, 6-3, 7-4, 8-3, 9-3, 12-3, 13-3 threshold voltage • 13-5 totalizer power consumption information • 13-4 VCOM • 13-7 voltage outputs •...
  • Page 186 M E A S U R E C O N F I D E N C E Keithley Instruments, Inc. Corporate Headquarters • 28775 Aurora Road • Cleveland, Ohio 44139 • 440-248-0400 • Fax: 440-248-6168 • 1-888-KEITHLEY • www.keithley.com 12/06...

This manual is also suitable for:

372137223723372437303740 ... Show all

Table of Contents
