Potterton Eurocondense Plus Installation Manual

Condensing sectional boiler
Hide thumbs
Table of Contents

Advertisement

Quick Links

INSTALLATION MANUAL
General Safety Precautions
Installation of System:
Electrical installation
Gas connection:
Important notes:
Important: The boiler must be commissioned following completion of
installation. Operation of an uncommissioned appliance may cause injury
to personnel and damage to the boiler/burner unit and could invalidate the
manufactures warranties.
Commissioning must only be carried out by personnel approved and
competent to do so. This facility is available from Potterton Commercial
Service Offices.
Important: The boiler/burner unit is supplied in accordance with Potterton
commercial quality assurance plan registered to meet the requirements of
BSN ISO 9002. A condition of the supply of the appliance for compliance
with this is the return of the appliance commisioning report.
The work must be carried out by a qualified Electrician.
Gas connection as well as commissioning, servicing and
maintenance must be carried out by an approved Gas Installer
(Corgi Registered). For use with natural Gas (G20) only Gas
supply pressure 20 mbar (LPG options available).
Important notes for installation, operation, adjustment and
service are indicated by this symbol.
EUROCONDENSE
(with BMU 64... > SW 2.08)
Plus
