Potterton Envoy Flowsure Installation & Service Instructions Manual

Wall mounted fan powered balanced flue gas condensing combination boiler and storage combination boiler
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Wall Mounted Fan Powered Balanced Flue Gas Condensing
Combination Boiler and Storage Combination Boiler
THE GAS SAFETY (INSTALLATION AND USE) REGULATIONS 1994.
'' In your own interest, and that of safety, it is law that all gas appliances are installed by competent persons,
in accordance with the above regulations. Failure to install appliances correctly could lead to prosecution.''
The polythene bags used for packaging are a potential hazard to babies and young children and
Installation must be in accordance with the Installation & Service Instructions and the rules in force.
LEAVE THESE INSTRUCTIONS WITH THE USER FOR USE ON FUTURE CALLS
For Use With Natural Gas
(G20) Only At 20mbar
For Use in GB & IE
Installation & Service Instructions
Envoy Flowsure & Envoy Flowsure+
MUST BE DISPOSED OF IMMEDIATELY.
Boiler Module - G.C. No. 41 607 89
20 Litre Tank Module - G.C. No. 114 792
50 Litre Tank Module - G.C. No. 114 793
IMPORTANT
PLEASE READ THIS BOOK
BEFORE INSTALLING,
OPERATING OR SERVICING
THIS BOILER.
