Pro-Form PFEL94910.0 User Manual page 10

8. Attach the Console Cover (32) to the back of
the Console (4) with two M4 x 48mm Screws
(89).
9. Apply some of the included grease to the axle
on the right side of the Upright (2).
Identify the Right Upper Body Arm (9), which is
marked with a "Right" sticker, and orient it as
shown.
Slide the Right Upper Body Arm (9) onto the
right side of the Upright (2).
Attach the Right Upper Body Arm (9) with an
M8 x 20mm Patch Screw (80) and an M8
Washer (33).
Repeat this step to attach the Left Upper
Body Arm (8).
8
4
9
8
10
32
89
9
Grease
2
33 80
