Pro-Form 595 User Manual

Performance treadmill
Hide thumbs Also See for 595:

Advertisement

Table of Contents

Model No. PCTL58570
Serial No.
Serial Number Decal
QUESTIONS?
As a manufacturer, we are com-
mitted to providing complete
customer satisfaction. If you
have questions, or if there are
missing or damaged parts, we
will guarantee you complete
satisfaction through direct assis-
tance from our factory.
TO AVOID UNNECESSARY DE-
LAYS, PLEASE CALL DIRECT TO
OUR TOLL-FREE CUSTOMER
HOT LINE. The trained techni-
cians on our Customer Hot Line
will provide immediate assis-
tance, free of charge to you.
CUSTOMER HOT LINE:
1-888-936-4266
Mon.–Thu., 6:00 a.m.–6:30 p.m.,
Fri., 6:00 a.m.–6:00 p.m. ET
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manual
for future reference.
USER'S MANUAL
®

Advertisement

Table of Contents
loading

Related Manuals for Pro-Form 595

Summary of Contents for Pro-Form 595

  • Page 1 ® Model No. PCTL58570 Serial No. Serial Number Decal QUESTIONS? As a manufacturer, we are com- mitted to providing complete customer satisfaction. If you have questions, or if there are missing or damaged parts, we will guarantee you complete satisfaction through direct assis- tance from our factory.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS IMPORTANT PRECAUTIONS ..............2 BEFORE YOU BEGIN .
  • Page 3 15. The treadmill is capable of high speeds. You must be able to safely lift 45 pounds (20 Adjust the speed in small increments to avoid kg) in order to raise, lower, or move the tread- sudden jumps in speed. mill.

  • Page 4: Before You Begin

    BEFORE YOU BEGIN Thank you for selecting the innovative PROFORM ® (excluding holidays). To help us assist you, please 595 treadmill. The PROFORM ® 595 treadmill blends note the product model number and serial number be- advanced technology with innovative design to let you fore calling.

  • Page 5: Assembly

    ASSEMBLY Assembly requires two people. Set the treadmill in a cleared area and remove the packing materials. Do not dispose of the packing materials until assembly is completed. Assembly requires the included allen wrench , and your own adjustable wrench , and phillips screwdriver 1.
  • Page 6 5. Align the hole in the lower end of the right Handrail Arm (10) with the hole in the frame tab as shown. Attach the Handrail Arm with a Handrail Bolt (7) and a Handrail Nut (8). Repeat this step on the left side. Frame Tab 6.

  • Page 7: Operation And Adjustment

    OPERATION AND ADJUSTMENT THE PERFORMANT LUBE WALKING BELT electric shock. This product is equipped with a cord having an equipment-grounding conductor and a Your treadmill features a walking belt coated with grounding plug. Plug the power cord into a surge PERFORMANT LUBE , a high-performance lubricant.
  • Page 8 DIAGRAM OF THE CONSOLE Monitor Displays LED Track Speed Control Incline Control Clip Pulse Sensor CAUTION: Before operating the console, read the following precautions. • Do not stand on the walking belt when turning • The settings marked above the speed control on the power.
  • Page 9 Follow your progress with the LED track and the To reset the displays, four displays. press the ON/RESET button. The displays will The LED Track— darken for a moment The LED track and then light. represents a dis- tance of 1/4 mile. Measure your pulse, if desired.

  • Page 10: How To Fold And Move The Treadmill

    HOW TO FOLD AND MOVE THE TREADMILL HOW TO FOLD THE TREADMILL FOR STORAGE Before folding the treadmill, adjust the incline to the lowest position. If the incline is not at the lowest position, the treadmill will be permanently damaged. Next, unplug the power cord. Caution: You must be able to safely lift 45 pounds (20 kg) in order to raise, lower, or move the treadmill.
  • Page 11 HOW TO LOWER THE TREADMILL FOR USE 1. Hold the upper end of the treadmill with your right hand as shown. Using your left thumb, slide open the storage latch and hold it open. Pivot the treadmill until the frame is past the storage latch.

  • Page 12: Maintenance And Trouble-Shooting

    MAINTENANCE AND TROUBLE-SHOOTING Most treadmill problems can be solved by following the steps below. Find the symptom that applies, and follow the steps listed. If further assistance is needed, please call our Customer Service Department toll- free at 1-888-936-4266, Monday through Thursday, 6 a.m. until 6:30 p.m., Friday, 6 a.m. until 6 p.m., Eastern Time (excluding holidays).
  • Page 13 PROBLEM: The walking belt is off-center or slips when walked on SOLUTION: a. If the walking belt has shifted to the left, first re- move the key and UNPLUG THE POWER CORD. Using the allen wrench, turn the left rear roller adjust- ment bolt clockwise, and the right bolt counterclock- wise, 1/4 of a turn each.

  • Page 14: Conditioning Guidelines

    CONDITIONING GUIDELINES adjust the speed and incline of the treadmill until your WARNING: heart rate is near one of the lower two numbers in your Before beginning training zone. It may also be helpful to set the speed this or any exercise program, consult your control on the console to FAT BURN to help you main- physician.
  • Page 15 SUGGESTED STRETCHES The correct form for several basic stretches is shown at the right. Move slowly as you stretch—never bounce. 1. Toe Touch Stretch Stand with your knees bent slightly and slowly bend forward from your hips. Allow your back and shoulders to relax as you reach down toward your toes as far as possible.

  • Page 16: Part List

    PART LIST—Model No. PCTL58570 R0698A To identify the parts listed below, refer to the EXPLODED DRAWING attached in the center of this manual. No. Qty. Description No. Qty. Description Frame Rear Pad Rear Isolator Rear Endcap Rear Platform Screw Warning Decal Screw Rear Roller Adj.
  • Page 17 No. Qty. Description No. Qty. Description Front Hood Bracket 8” White Wire, Pigtail 106* Motor/Pulley/ Flywheel/Fan 8” Blue Wire, Pigtail Motor Locknut 6” Blue Wire, 2 F/M Incline Stop Bracket 6” Blue Wire, 2 F/ 1M Hood Screw User’s Manual Upright Plug 4”...

  • Page 18: Customer Record

    CUSTOMER RECORD Model No.: Serial No.: Retailer Name: Purchase Date: Retailer Address:...

  • Page 19: Ordering Replacement Parts

    Thursday 6 a.m. until 6:30 p.m., Friday, 6 a.m. until 6 p.m., Eastern Time (excluding holidays). When ordering parts, please be prepared to give the following information: • The MODEL NUMBER OF THE PRODUCT (PCTL58570). • The NAME OF THE PRODUCT (PROFORM ® 595 treadmill).

  • Page 20: Limited Warranty

    LIMITED WARRANTY ICON OF/DU CANADA INC., (ICON), warrants this product to be free from defects in workmanship and material, under normal use and service conditions, for a period of ninety (90) days from the date of purchase. This warranty extends only to the original purchaser. ICON's obligation under this warranty is limited to replacing or repairing, at ICON's option, the product at one of its authorized service centers.
