  • Page 1 www.proform.com Model No. PFEL99012.0 Serial No. USER’’S MANUAL Write the serial number in the space above for reference. Serial Number Decal ACTIVATE YOUR WARRANTY To register your product and activate your warranty today, go to www.proformservice.com/ registration. CUSTOMER CARE For service at any time, go to www.proformservice.com.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS WARNING DECAL PLACEMENT ............. . . 2 IMPORTANT PRECAUTIONS .

  • Page 3: Important Precautions

    IMPORTANT PRECAUTIONS WARNING: To reduce the risk of burns, fire, electric shock, or injury to persons, read all important precautions and instructions in this manual and all warnings on your elliptical before using your elliptical. ICON assumes no responsibility for personal injury or property damage sus- tained by or through the use of this product.
  • Page 4 STANDARD SERVICE PLANS...

  • Page 5: Before You Begin

    Thank you for selecting the revolutionary PROFORM ® manual. To help us assist you, note the product model 940 CE elliptical. The 940 CE elliptical provides an number and serial number before contacting us. The impressive selection of features designed to make your model number and the location of the serial number workouts at home more effective and enjoyable.

  • Page 6: Part Identification Chart

    PART IDENTIFICATION CHART Use the drawings below to identify the small parts needed for assembly. The number in parentheses below each drawing is the key number of the part, from the PART LIST near the end of this manual. The number following the key number is the quantity needed for assembly.

  • Page 7: Assembly

    ASSEMBLY •• To hire an authorized service technician to •• In addition to the included tool(s), assembly assemble this product, call 1-800-445-2480. requires the following tool(s): one Phillips screwdriver •• Assembly requires two persons. one adjustable wrench •• Place all parts in a cleared area and remove the packing materials.
  • Page 8 3. With the help of another person, place two pack- ing inserts from the packing material under the Frame (1) so that the Frame is lifted off the floor. Have another person hold the elliptical to prevent it from moving from side to side until this step is completed.
  • Page 9 5. Apply a generous amount of the included grease to the Pivot Axle (33) and to two 5/8" Wave Washers (102). Tip: Avoid pinching or damaging the Upper Wire Harness (97). Insert the Pivot Axle (33) through the Upright (6). Then, slide a 5/8" Wave Grease Washer (102) onto each end of the Pivot Axle.
  • Page 10 7. Identify the Right Link Arm (10). Apply a small amount of grease to the axles on the Right Link Arm and to two 5/8" Wave Washers (102). Then, slide a Pivot Spacer (71) and a Wave Washer onto each axle. At the same time, slide the Right Link Arm (10) into the right Upper Body Arm (12) and into the Right Pedal Arm (8).
  • Page 11 9. Identify the Right Handlebar (31) and orient it as shown. Attach the Right Handlebar to the right Upper Body Arm (12) with two 5/16" x 1 1/2" Bolts (73) and two 5/16" Locknuts (106). Make sure that the Locknuts are in the hexagonal holes.

  • Page 12: How To Use The Elliptical

    HOW TO USE THE ELLIPTICAL HOW TO PLUG IN THE POWER CORD A temporary adapter may 2-pole Receptacle This product must be grounded. If it should malfunc- be used to tion or break down, grounding provides a path of least connect the Adapter resistance for electric current to reduce the risk of...
  • Page 13 HOW TO MOVE THE ELLIPTICAL HOW TO EXERCISE ON THE ELLIPTICAL Due to the size and weight of the elliptical, moving To mount the elliptical, hold the handlebars and step it requires two persons. Stand in front of the elliptical, onto the pedal that is in the lowest position.
  • Page 14 CONSOLE DIAGRAM FEATURES OF THE CONSOLE The console also offers sixteen intensity control workouts. Each intensity control workout automatically The advanced console offers an array of features changes the resistance of the pedals and prompts designed to make your workouts more effective and you to increase or decrease your pedaling pace as it enjoyable.
  • Page 15 HOW TO USE THE MANUAL MODE 4. Follow your progress with the display. 1. Press any button on the console or begin The far left section of pedaling to turn on the console. the display——This section of the display will show When you turn on the console, the display will your pedaling pace (in light.
  • Page 16 5. Measure your heart rate if desired. 6. Turn on the fan if desired. If there are sheets The fan has high and low speed settings. Press of plastic on the the Fan button repeatedly to select a fan speed or Contacts metal contacts to turn off the fan.
  • Page 17 HOW TO USE A TARGET TONING WORKOUT As you exercise, the console will display a variety of exercise instructions. For example, the console 1. Press any button on the console or begin may instruct you to pedal backwards or to use only pedaling to turn on the console.
  • Page 18 If the resistance level or the ramp incline level for the workout is completed, the display will continue the current segment is too high or too low, you to show exercise feedback; however, the display can manually override the setting by pressing the will not show the elapsed time until you select the Resistance or the Ramp buttons.
  • Page 19 HOW TO USE AN INTENSITY CONTROL To increase or decrease the overall intensity of WORKOUT the workout, press the + and - buttons next to the matrix. The resistance levels of all remain- 1. Press any button on the console or begin ing segments in the workout will then increase or pedaling to turn on the console.
  • Page 20 HOW TO CREATE A CUSTOM WORKOUT 3. Begin pedaling to start the workout, and program the desired settings. 1. Press any button on the console or begin pedaling to turn on the console. Each custom workout is divided into 40 one-minute segments.
  • Page 21 HOW TO USE A CUSTOM WORKOUT for the current segment. When the words PEDAL FASTER appear in the display, increase your 1. Press any button on the console or begin pace. When the words PEDAL SLOWER appear, pedaling to turn on the console. decrease your pace.

  • Page 22: Maintenance And Troubleshooting

    MAINTENANCE AND TROUBLESHOOTING Inspect and tighten all parts of the elliptical regularly. HOW TO ADJUST THE BELT Replace any worn parts immediately. If the pedals slip while you are pedaling, even while the To clean the elliptical, use a damp cloth and a small resistance is adjusted to the highest setting, the belt amount of mild soap.

  • Page 23: Exercise Guidelines

    EXERCISE GUIDELINES Burning Fat——To burn fat effectively, you must exer- WARNING: cise at a low intensity level for a sustained period of Before beginning this time. During the first few minutes of exercise, your or any exercise program, consult your physi- body uses carbohydrate calories for energy.

  • Page 24: Part List

    PART LIST Model No. PFEL99012.0 R0113A Key No. Qty. Description Key No. Qty. Description Frame Stabilizer Cap Front Stabilizer Leveling Foot Rear Stabilizer Foot Ramp Wheel Right Ramp Cover Left Pivot Cover Upright Right Pivot Cover Left Handlebar Lower Wire Harness Right Pedal Arm Power Cord Left Pedal Arm...
  • Page 25 Key No. Qty. Description Key No. Qty. Description 3/8" x 3/4" Screw M6 Split Washer 3/8" x 2 1/2" Screw Lift Roller Upper Wire Harness –– 10" Ground Wire M8 x 35mm Screw –– 14" White Jumper Wire F/F M8 Locknut ––...

  • Page 26: Exploded Drawing

    EXPLODED DRAWING A Model No. PFEL99012.0 R0113A...
  • Page 27 EXPLODED DRAWING B Model No. PFEL99012.0 R0113A...

  • Page 28: Ordering Replacement Parts

    ORDERING REPLACEMENT PARTS To order replacement parts, see the front cover of this manual. To help us assist you, please be prepared to pro- vide the following information when contacting us: •• the model number and serial number of the product (see the front cover of this manual) ••...
