3. User Interface

3.1 Front Panel

A
AC output outlet: For application demands of different geographic areas all over
Receptacle
types
Type-A
Area USA
B
LED Indicating Panel: Shows inverter operating status.
C
Function Setting: Output voltage and frequency can be set through this button.
Ventilation holes: Please make sure there is good ventilation and the lifespan
D
of the inverter can be preserved.

3.2 LED indicator on front panel

Status LED: Represents TS-200/400 current operating status
LED color
Status
*Note: Refer to section 5.2 for explanation of abnormal status

3.3 Rear panel

A
Battery input (+),(-)
B Ventilation opening
C
Power ON/OFF switch
D
Remote control connector (JST B-XH)
E
Frame ground (FG)
the world, there are many different kinds of optional AC outlets
to choose from.
Type-B Type-C
Europe Australia
D A
AC OUTPUT
Figure 3.1: Front Panel
Green Orange (flashing)
Normal Remote control OFF
3
Type-D Type-E
U.K. Japan
B
Status
Setting
C
Red
Abnormal
Type-F
GFCI
