Page 1 Distributed by: www.Jameco.com 1-800-831-4242 The content and copyrights of the attached material are the property of its owner. Jameco Part Number 2079939 Users Manual...
Page 2 PB -300 / 360 Instruction Manual...
Page 3 PB-300,360 Instruction Manual ON/OFF 230/115VAC SWITCH SWITCH INLET 3 POLE IEC320 C14 Battery Connection SVR1 CN5 Vadj DC (+) DC (-) Warning Please make sure the polarity of the battery is Battery connected correctly! Assembly Procedure 1.Make sure the charger is shut off and choosing suitable wires to connect the charger and batteries based on the rating of charging current.
Page 4 Charging Current And Ambient Temperature 1.The charging current of PB-300 will reduce when the ambient temperature goes up. Please refer to the derating curve shown as below: 20 25 EXTERNAL CASE TEMPERATURE ( )
Page 5 (green light) stage after Choose connecting wires The gauge of output wire is not long period with suitable gauge large enough of charging operation If you still cannot eliminate the failure situation, please consult MEAN WELL or any of our distributors...
Page 6 WARNING : Explosive gases. prevent flames and sparks, Provide adequate ventilation during charging. Disconnect the supply before making or breaking the connections to the battery. Against recharging non-rechargeable batteries. Caution : (1)Temperature of the case will be high during the charging operation. (2)If the AC input terminal does not connect to F.G.
