1.Safety Guidelines (Please read through this manual before assembling TS-
200/400)
Risk of electrical shock and energy hazard. All failures should be examined by a
qualified technician. Please do not remove the case of the inverter by yourself!
Please do not install the inverter in places with high moisture or near water.
Please do not install the inverter in places with high ambient temperature, under
direct sunlight or near flame source.
Please only connect batteries with the same brand and model number in one battery
bank. Using batteries from different manufacturers or different capacity is strictly
prohibited!
Never allow a spark or flame in the vicinity of the batteries because it may generate
explosive gases during operation.
Make sure the air flow from the fan of TS-400 is not obstructed at both sides (front
and back) of the inverter. Please allow at least 15cm of space.
Please do not stack any object on the inverter because it may impede heat dissipation.
WARNING:
Don't
disassemble

2.Introduction

TS-200/400 is a DC/AC True Sine Wave Inverter using the latest high frequency
High performance inverter designed for use with battery bank drawing power from
the battery and converting it into AC voltage.
TS-200/400 can continuously provide 200W/400W of pure sine wave output with
THD < 3% to various types of loads (e.g. inductive & capacitive). It can also provide
short term power of 230W/460W for 3 minutes and 300W/600W for 10 seconds.
It can withstand surge requirement of 400W/800W for 30 AC cycles.
Reduction in product size and high efficiency of 88.5% were achieved through the
use of high frequency switching technology.
General applications include PC, ITE, vehicles, yachts, home appliances, motors,
power .
TS-200 does not have built-in fan and can be cooled with free air convection.

2.1 Features

True sine wave output (THD < 3.0%)
Rated power 200W (TS-200) / 400W (TS-400)
High efficiency up to 88.5%
Batteries will have aging problem after years of operation.
It is suggested to execute regular battery maintenance
(e.g. every year). Once aged, the batteries should be changed
by professional technician, or the failed batteries may cause
fire or other hazards.
Inverter
Inverter
Keep away from Keep away from
moisture fire or high
temperature
1
Inverter
Inverter
Don't stack on Keep good
the inverter ventilation
