User's Manual
Single Board Computer 3307555
Version 1.0,
Full Size Socket 370 Pentium III / Celeron CPU Card
with 66/100 MHzFSB,
Four DIMM Sockets for up to 1 GB SDRAM,
Flat Panel / CRTSVGA USB 1.0,
and Disk On Chip Interfaces

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 3307555 and is the answer not in the manual?

Questions and answers

Related Manuals for Global American 3307555

Summary of Contents for Global American 3307555

  • Page 1 User’s Manual Single Board Computer 3307555 Version 1.0, Full Size Socket 370 Pentium III / Celeron CPU Card with 66/100 MHzFSB, Four DIMM Sockets for up to 1 GB SDRAM, Flat Panel / CRTSVGA USB 1.0, and Disk On Chip Interfaces...
  • Page 2 Copyrights This manual is copyrighted and all rights are reserved. It does not allow any non authorization in copied, photocopied, translated or reproduced to any electronic or machine readable form in whole or in part without prior written consent from the manufacturer. In general, the manufacturer will not be liable for any direct, indirect, special, incidental or consequential damages arising from the use of inability to use the product or documentation, even if advised of the possibility of such damages.

  • Page 3: Table Of Contents

    Table of Contents How to Use This Manual Chapter 1 Introduction 1.1 Check List ..................1 – 2 1.2 Product Specifications ..............1 – 3 1.3 System Architecture ..............…1 – 6 Chapter 2 Hardware Configuration Setting 2.1 Jumpers ..................2 – 1 2.2 Connectors ...................2 –...

  • Page 4: How To Use This Manual

    5.3 OS diagnostics ................5 – 6 How to Use This Manual The manual describes how to configure your 3307555 system to meet various operating requirements. It is divided into five chapters, with each chapter addressing a basic concept and operation of Single Board Computer.

  • Page 5: Chapter 1 Introduction

    Introduction CHAPTER 1 Introduction The 3307555 all-in-one full-sized single board computer is designed to fit a high performance Celeron based processor and compatible for high-end computer system application with PCI/ISA bus architecture. It is made to meet today’s demanding pace, and keep complete compatibility with hardware and software designed for the IBM PC/AT.

  • Page 6: Check List

    Introduction 1-1 Check List The 3307555 package includes the following basic items accompany with this manual. • One 3307555 single board computer • One Printer port cable kit • One 10-pin cable kit for VGA port • One FDC cable •...

  • Page 7: Product Specifications

    Serial Ports Support two high-speed 16C550 compatible UARTs with 16-byte T/R FIFOs • IR Interface Support one 6-pin header for serial Fast/Standard Infrared wireless communication • Parallel Port Support one parallel port with SPP, Bi-direction, and EPP/ECP mode 3307555 User¶s Manual...
  • Page 8 • CPU Overheat Protection Auto speed down when CPU overheats (OS independent & Driverless) • Power Good On-board power good generator with reset time, 300ms < 500ms • System Monitoring Feature Monitor CPU current temperature. 3307555 User¶s Manual...
  • Page 9 PCB layout : 6 layer Power Requirements : +5V @6A (typ.), +12V @140mA, -12V @30mA Operating Temperature : 0°C ~ 60°C (32°F ~ 140°F) Storage Temperature : -20°C ~ 80°C Relative Humidity : 5% ~ 95%, non-condensing 3307555 User¶s Manual...

  • Page 10: System Architecture

    Introduction 1-3 System Architecture The following illustration of block diagram will show you how 3307555 gives you a highly integrated system solution. The most up-to-date system architecture of 3307555, includes two main VLSI chips , 82443BX Host Bridge and 82371EB PIIX4E, to support...
  • Page 11 In 3307555, it contains Watch-dog Timer (WDT) enabled by jumper setting and triggered by software, and DiskOnChip (DOC) for M-systems Flash disk. Besides, an advanced feature is used on 3307555 to support detection of CPU temperature. The CPU operation will be automatically forced to speed down when overheating happens.
  • Page 12 IDE 2 TEMP. SENSOR CNTL XD Bus ISA Bus BUFFER B UFFER D SD Bus LOGIC ISA Bus PC/104 Bus BIOS DISK-On-Chip Hardware Monitor SUPER I/O KEYBOARD W83977ATF 2UART/LPT/FDD/IR (128 PQFP) MOUSE Figure 1-1 3307555 System Block Diagram 3307555 User¶s Manual...

  • Page 13: Jumpers

    This chapter gives the definitions and shows the positions of jumpers, headers and connectors. All of the configuration jumpers on 3307555 are in the proper The default settings set by factory are marked with a star ( * ). position.
  • Page 14 Watch-Dog Timer Jumper Setting (JP4, JP5, JP6, JP7, JP9) NC : Enabled WDT function Short : Disabled WDT function NC : Allocate I/O port 0533H/0033H for programming of H/W WDT Short : Allocate I/O port 0543H/0343H for programming of H/W WDT 3307555 User¶s Manual...
  • Page 15 CMOS RAM clear option has been enabled in Advanced Chipset Setup before CMOS clearing happens. AT/ATX Power Supply Selection (JP3) 1 – 2 : Select ATX power supply 2 – 3 : Select AT power supply 3307555 User¶s Manual...
  • Page 16 NOTE : This jumper JP1 is only for reference. It will be ignored by BIOS panel setting in Advanced CMOS Setup. Normally, it is not set by factory default. Onboard devices (VGA) enable/disable jumper (JP10) JP10 1 – 2 : Normal operation 2 – 3 : Disable onboard VGA 3307555 User¶s Manual...

  • Page 17: Connectors

    DI M M 2 DIM M3 DIM M4 W83977ATF Socket370 82371EB 82443BX B69000 39 40 < Figure 2-2 3307555 Connector Locations CONNECTOR FUNCTION REMARK System reset External speaker interface Keyboard lock and power indicator IDE active LED interface IDE1 (Primary) interface Floppy connector...
  • Page 18 J4 : IDE1 Active LED Header PIN No. Signal Description +5V (470 ohm pull-up for HDD LED) HDD Active # (LED cathode terminal) J7 : Wake-On-LAN Interface PIN No. Signal Description 5V Stand-by Power LAN Wake-up Activating Signal 3307555 User¶s Manual...
  • Page 19 Auto Form Feed# Data 0 Error# Data 1 Initialization# Data 2 Printer Select IN# Data 3 Ground Data 4 Ground Data 5 Ground Data 6 Ground Data 7 Ground Acknowledge# Ground Busy Ground Paper Empty Ground Printer Select 3307555 User¶s Manual...
  • Page 20 ATX Power On Control Ground J11 : Fast & Standard IrDA Header PIN No. Signal Description VCC (+5V) FIRRX SIRRX Ground IRTX J12 : ATX Power Button Interface PIN No. Signal Description Power Button Control Signal Ground 3307555 User¶s Manual...
  • Page 21 Data Terminal Ready (DTR) Ground (GND) Data Set Ready (DSR) Request to Send (RTS) Clear to Send (CTS) Ring Indicator (RI) J18 : PS/2 Mouse Connector (6-pin Mini-DIN) PIN No. Signal Description Mouse Data Ground Mouse Clock 3307555 User¶s Manual...
  • Page 22 Ground Ground J19 : VGA Connector (2x5 Shrouded Connector) Signal Description Signal Description DDC_CLK GREEN Ground BLUE DDC_DATA VSYNC Ground HSYNC J20 : External PS/2 Mouse Connector PIN No. Signal Description Mouse Clock Mouse Data Ground 2-10 3307555 User¶s Manual...
  • Page 23 IOCHKJ RSTDRV SBHEJ MEM16J LA23 IO16J IRQ9 LA22 IRQ10 LA21 IRQ11 DRQ2 LA20 IRQ12 -12V LA19 IRQ15 0WSJ LA18 IRQ14 +12V LA17 DACK0J B10 IOCRDY MEMRJ DRQ0 SMEWJ MEMWJ DACK5J SMERJ SA19 DRQ5 IOWJ SA18 DACK6J 2-11 3307555 User¶s Manual...
  • Page 24 Name Name Name Name IORJ SA17 SD10 DRQ6 DACK3J SA16 SD11 DACK7J DRQ3 SA15 SD12 DRQ7 DACK1J SA14 SD13 DRQ1 SA13 SD14 MASTERJ REFRSH SA12 SD15 ATCLK SA11 IRQ7 SA10 IRQ6 IRQ5 IRQ4 IRQ3 DACK2J BALE 2-12 3307555 User¶s Manual...

  • Page 25: Chapter 3 System Installation

    3-2 Main Memory This 3307555 provides four 168-pin Dual In-line Memory Modules (DIM M) to support on-board main memory. The maximum memory size for 3.3V EDO DRAM or SDRAM is 1GB. Normally, the DIMM used could be either 3.3V EDO (Extended Data Out) memory with speed less than 70ns or 3.3V SDRAM...

  • Page 26: M-System Flash Disk

    3-3 M-systems Flash Disk 3307555 reserves one 32-pin DIP sockets for installing M-systems Flash disk from 2MB to 144MB. This operation structure is running with pure ISA-bus without PnP (Plug and Play) function. Before installing, make certain that I/O address jumper setting is set on right position to prevent unworkable system due to I/O resource conflict.

  • Page 27: Installing The Single Board Computer

    Step 1 : Check all jumpers setting on proper position Step 2 : Install and configure CPU and memory module on right position Step 3 : Place 3307555 into the dedicated position in your system Step 4 : Attach cables to existing peripheral devices and secure it...
  • Page 28 1024x768 60, 75, 85 1280x1024 3307555 utilizes on-board CHIPS 69000 and optional panel display module to support 16 types of panels. You can select one of sixteen LCD panel type by BIOS panel setting in Advanced CMOS Setup. 3307555 User¶s Manual...

  • Page 29: Driver Support

    System Installation 3-4-3 Driver Support 3307555 provides one CD-Title to support on-board VGA device drivers in various operating systems. This CD-Title only includes one directory \vga69000. Before installing the device driver, please see the reference files in each sub- directory. You can not install driver from CD-Title directly.

  • Page 30: Watch Dog Timer Programming

    WDT output to NMI input by setting JP6 jumper to generate NMI event to support special interrupt service routine. An optional two-port WDT is provided on 3307555. This WDT comes with 8 possible ranges of time intervals from 500 ms to 64 sec., which can be adjusted by setting jumper positions.

  • Page 31: Chapter 4 Bios Setup Information

    CHAPTER 4 BIOS Setup Information 3307555 is equipped with the AMI BIOS stored in Flash ROM. This BIOS has a built-in Setup program that allows users to modify the basic system configuration easily. This type of information is stored in CMOS RAM so that it is retained during power-off periods.

  • Page 32: Main Menu

    BIOS Setup Information 4.2 Main Menu Once you enter 3307555 AMI BIOS CMOS Setup Utility, the Main Menu will appear on the screen. The Main Menu allows you to select from eleven setup functions and two exit choices. Use arrow keys to switch the items and press <Enter>...

  • Page 33: Cmos Setup Reference Table

    DRAM Refresh Rate 15.6 us 15.6 us 31.2 us, 62.4 us, 124.8 us, 249.6 us Memory Hole Disabled Disabled 512KB-640KB, 15MB-16MB 8bit I/O Recovery Time 1 Sysclk 1 Sysclk Disabled, 2, 3, 4, 5, 6, 7, 8 Sysclk 3307555 User¶s Manual...
  • Page 34 25 – 37.5%, 37.5 – 50%, 62.5 – 75% CPU Critical Temperature 75°C/167°C 75°C /167°C Disabled, 45°C/113°F ,50°C/122°F, 55°C/131°F, 60°C/140°F, 65°C/149°F, 70°C/158°F 75°C/167°F Power Button Function On/Off On/Off Suspend Ring Resume From Soft Off Disabled Disabled Enabled 3307555 User¶s Manual...
  • Page 35 PERIPHERAL SETUP DEFAULTS BIOS Setup Items Optimal Default Failsafe Default Other Options OnBoard FDC Auto Auto Enabled, Disabled OnBoard Serial PortA Auto Auto 3F8h/COM1, 2F8h/COM2, 3E8h/COM3, 2E8h/COM4, Disabled OnBoard Serial PortB Auto Auto 3F8h/COM1, 2F8h/COM2, 3E8h/COM3, 2E8h/COM4, Disabled 3307555 User¶s Manual...

  • Page 36: Standard Cmos Setup Menu

    This setup includes all of the advanced features in the system. The detail descriptions are specified as belows. Quick Boot Set “Disabled” for normal booting or select “Enabled” to skip minor BIOS test items to obtain quick boot response. 3307555 User¶s Manual...

  • Page 37: Primary Display

    Setup : This option will force system to check password before running Setup if you have already entered the current user password in “Change User Password”. By that time, the system will be only able to boot but deny accessing Setup. 3307555 User¶s Manual...

  • Page 38: System Bios Cacheable

    4.6 Advanced Chipset Setup Menu This setup is very important to keep system stability. If you are not technical person, do not attempt to change any parameters. The best way is to choose optimal default setting. Configure SDRAM Timing by SPD 3307555 User¶s Manual...

  • Page 39: Dram Integrity Mode

    There are three options Non-ECC, EC-Only (Error Check Only) and ECC Hardware (Error Checking and Correction) in this feature. The DRAM integrity mode will be implemented by the parity algorithm when this option is set to “Non-ECC”. 3307555 User¶s Manual...

  • Page 40: Memory Hole

    Choose the “Enabled” option to help raise the available bandwidth of the PCI bus for acquiring higher PCI bus performance. PIIX4 Delayed Transaction Choose the “Enabled” option to obtain higher PCI bus performance for slower ISA bus application. Spread Spectrum Control This option is for EMI test issue only. 3307555 User¶s Manual 4-10...

  • Page 41: Usb Function

    This APM (Advanced Power Management) determines how much power energy can be saved by setting below items to handle system power resource. The following descriptions will specify the definition of each item in details. Power Management/APM 3307555 User¶s Manual 4-11...

  • Page 42: Video Power Down Mode

    Port”, “Floppy”, “Pri-HDD”, and “Sec-HDD” independently. It is also used to control CPU throttle running function. All of sub-items will be ineffective in selection of disabling “Stand by Time out” or “Suspend Time out” even if it can be choosed by user in BIOS setup menu. 3307555 User¶s Manual 4-12...

  • Page 43: Throttle Slow Clock Ratio

    The overall system performance will be reduced to half. This option is a trad-off of system performance and stability and configurable by user. The default setting is Ignore. You can choose Monitor setting to enable this thermal function. Thermal Slow Clock Ratio 3307555 User¶s Manual 4-13...

  • Page 44: Pci/Plug And Play Setup Menu

    CPU’s when they communicate with own special components. All of options described in this section are important and technical and it is strongly recommended that only experienced users could make any changes to the default settings. Plug and Play Aware O/S 3307555 User¶s Manual 4-14...

  • Page 45: Clear Nvram

    This option will be used to allocate IRQ for PCI VGA card. In general, some of PCI VGA cards need IRQ support. PCI IDE BusMaster Set this option to Enabled to specify that the IDE controller on the PCI local bus has bus mastering capability. 3307555 User¶s Manual 4-15...
  • Page 46 PCI/PnP Setup to remove the IRQ by assigning the option to the ISA/EISA setting. All IRQs used by on-board I/O are configured as PCI/PnP. 3307555 User¶s Manual 4-16...

  • Page 47: Peripheral Setup Menu

    : Auto > user can not control all of LPT port I/O resources Disabled > on-board parallel port function is ineffective and N/A 378h > locate IRQ7 for this default I/O address 3307555 User¶s Manual 4-17...
  • Page 48 Parallel Port Mode is ECP. This option sets the DMA channel used by ECP-capable parallel port. On Board IDE This option specifies the onboard IDE controller channels that will be used. The settings are Disabled, Primary, Secondary, or Both. 3307555 User¶s Manual 4-18...

  • Page 49: Hardware Monitor Setup Menu

    Initializing the DMA controller, performing the keyboard controller BAT test, starting memory refresh, and going to 4GB flat mode. To start memory sizing. Returning to real mode. Executing any OEM patches and setting the stack next. 3307555 User¶s Manual 4-19...
  • Page 50 F0000h shadow RAM. Code Description The NMI is disabled. Next, checking for a soft reset or a power on condition. The BIOS stack has been built. Next, disabling cache memory. Uncompressing the POST code next. 3307555 User¶s Manual 4-20...
  • Page 51 Alternate display memory R/W test passed. To look for the alternate display retrace checking. Video display checking is over. Setting the display mode next. The display mode is set. Displaying the power on message next. Initializing the bus input, IPL, and general devices next, if present. 3307555 User¶s Manual 4-21...
  • Page 52 The memory size was adjusted for relocation and shadowing. Clearing the Hit <DEL> message next. The Hit <DEL> message is cleared. The <WAIT«> message is displayed. Staring the DMA and interrupt controller test next. 3307555 User¶s Manual 4-22...
  • Page 53 Return after setting timer and printer base address. Going to set the RS-232 base address. Returned after setting the RS-232 base address. Performing any required initialization before the Coprocessor test next. Required initialization before the Coprocessor test is over. Initializing the Coprocessor next. 3307555 User¶s Manual 4-23...

  • Page 54: Flash Bios Utility

    BIOS version. Please contact your technical window to get this utility if necessary. NOTE : Remark or delete any installed Memory Management Utility (such as HIMEM.SYS, EMM386.EXE, QEMM.EXE, …, etc.) in the CONFIG.SYS files before running Flash programming utility. 3307555 User¶s Manual 4-24...

  • Page 55: Troubleshooting

    BIOS setting, and OS diagnostics. 5-1 Backplane setup Backplane 3307555 is a full-sized SBC, and therefore is able to run on any PICMG backplane, active or passive. ATX power 3307555 is designed to support ATX powering. Please refer to the following instruction to apply ATX power on your 3307555 and backplane.
  • Page 56 POWER CONNECTOR,20-pin) connector on the backplane. The CN7 is located on the upper-right side of the backplane with white color. Step3: Use a 4-pin power cable to connect the CN4 (ATX P/S CONTROL CONNECTOR,4-pin) connector on the backplane. 3307555 User¶s Manual...
  • Page 57 You can also see a mark with “J10” besides the J10 connector on the SBC. Connect the other end of the 4-pin power cable with this J10 connector on the SBC. Step5: Connect a 2-pin TOGGLE SWITCH with J12 connector on the SBC. 3307555 User¶s Manual...

  • Page 58: Bios Setting

    To make sure that you have a successful first go with your 3307555, it is recommended, when proceeding the boot-up sequence, to hit “DEL” key and enter the BIOS setup menu to tune up a stable BIOS configuration so that you can wake up your system far well.
  • Page 59 Certainly, users fail to detect this device/feature and end up with system failure. Please do check in the BIOS setting that the devices or ports that you need are not disabled. 3307555 User¶s Manual...
  • Page 60 What will be presented here is a brief guide to properly house-in the driver for any Microsoft Windows-95/98/NT device as well as start special function in a specific operating system. For other operating systems, please refer to OS manual/guidebook. Booting 3307555 User¶s Manual...
  • Page 61 By default, any Windows OS starts with 640 x 480 by 16 colors display. Please load in the display driver provided in 3307555 product CDROM to maximize the VGA performance. If you are using a monitor that Windows cannot identify, you will need also to set, in the display setup menu, a system monitor to correctly retrieve display output.
  • Page 62 Network setup within Windows-NT 4.0 is not as easy as that within Windows- 95/98. Special familiarity and care are required to come out with a successful installation. 3307555 User¶s Manual...
  • Page 63 Any advice or comments about our products and service, or anything we can help you with please don’t hesitate to contact with us. We will do our best to support your products, projects and business. Address: Global American, Inc. 17 Hampshire Drive Hudson, NH 03051 Telephone: Toll Free (U.S. Only) 800-833-8999...
