User's Manual
Version 1.0
13.3" x 4.8" (338mm x 122mm) Full-Size, Socket 370 Pentium III /
Celeron PC-133 CPU Card with High Drive ISA, CRT SVGA, LCD
Controller (Optional), Single or Dual (Optional) 10/100 Ethernet,
and Audio
3307389

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 3307389 and is the answer not in the manual?

Questions and answers

Related Manuals for Global American 3307389

Summary of Contents for Global American 3307389

  • Page 1 User's Manual Version 1.0 13.3” x 4.8” (338mm x 122mm) Full-Size, Socket 370 Pentium III / Celeron PC-133 CPU Card with High Drive ISA, CRT SVGA, LCD Controller (Optional), Single or Dual (Optional) 10/100 Ethernet, and Audio 3307389...
  • Page 2 Copyright © 2002, 2003, 2004 All Rights Reserved. Manual edition 2 .1, April 2004 The information in this document is subject to change without prior notice in order to improve the reliability, design and function. It does not represent a commitment on the part of the manufacturer.

  • Page 3: Table Of Contents

    Table of Contents Introduction ................... 1 Specifications ................2 General Specifications ..................2 High Speed Multi I/O ..................……..2 High Drive ISA64 Bus (CTI Ready) ............….... 2 Display Controller ...................….... 3 Network Interface Controller ..............….... 3 Audio Interface ..................…..... 3 PC/104-Plus Interface ................……..
  • Page 4 Serial Port Selection (RS232C/422/485) ........16 RS-232C Standard and POS Modes ..............16 RS-422/485 Mode on COM2 ................17 Power Connectors ............... 18 Power Connectors .............……......18 CPU Fan Connector ............…...…......19 Chassis Auxiliary Fan Connector ........…......19 Switches and Indicators ............. 20 Interface Connectors HDD, FDD ..........

  • Page 5: Specifications

    • Type: 16-bit GPIO, 8 independent GPI and 8 independent GPO programmable by software. High Speed Multi I/O • Chipset: included in VT82C686B “Super” Southbridge • Serial Ports: 3 high speed RS-232C ports (COM1,3,4) and one high speed RS-232/422/485 port (COM2) 3307389 User's Manual...

  • Page 6: Flash Disk Diskonchip®2000

    System Monitoring and Alarm: CPU and System temperature, system voltage and cooling fan RPM. • Board Dimensions: 203 mm x 146 mm (5.75" x 8.0") • Board Weight: 0.30 Kg. • Operating Temperature: 0 to 60°C (32 to 140°F) 3307389 User's Manual...

  • Page 7: Ordering Codes

    4. Place the board on a grounded antistatic pad or on the bag that Ordering Codes 3307389: 5.25" Socket 370 Pentium III / Celeron Littleboard Computer with AGP CRT SVGA, Fast Ethernet, AC97 Audio, 16-bit Digital I/O, 4 Serial Ports and DiskOnChip socket 3307389 User's Manual...
  • Page 8 Product Image 3307389 User's Manual...
  • Page 9 58.6 30.0 43.0 20.0 10.0 17.0 24.6 18.0 5.2 6 .0 56.4 38.0 85.7 16.3 11.0 27.0 30.4 18.4 18.0 21.0 15.0 6 .0 32.4 15.2 11.3 6 .3 31.2 49.4 85.0 5.0 5 .0 69.9 54.4 3307389 User's Manual...
  • Page 10 JCOM SONY JRS1 JKB&MS JCOMSEL JDIO JVGA JIR1 LPT1 USB2 LPT2 USB1 JAUDIO LAN-CON LAN-LED IDE1 FAN1 JRTC1 JWDT1 JFRNT JDOC1 SWDT1 DiskOnChip2000...

  • Page 11: Jumper/Connector Quick Reference

    JVGA CRT SVGA 6-pin Power Connector JVOLT1 /LCD voltage JVOLT1 Voltage ATX Power Control JFRNT Signals, RESET, LEDs 3.3 V Riser card cable Connector (For PCI riser JVOLT2 /LCD voltage delay card) JVOLT1 mode immediate delayed 3307389 User's Manual...

  • Page 12: Cmos Operation

    CMOS Jumper Settings CMOS Operation (JRTC1) If the 3307389 refuses to boot due to inappropriate CMOS settings here is how to proceed to clear (reset) the CMOS to its default values Connector:JRTC1 Type: onboard 3-pin header JRTC1 Di sk O n Ch i p 20 00...

  • Page 13: Watchdog Timer

    S W D T1 Di sk O n Ch i p 20 00 1 2 3 4 Time-out Setting (SWDT1) Watch dog Time-o ut Period 1 sec 2 sec 10 sec 20 sec 110 sec 220 sec default setting 3307389 User's Manual...

  • Page 14: Programming Example

    The following program is an examples of how to enable, disable and refresh the Watchdog timer: WDT_EN_RF 444H WDT_DIS 044H WT_Enable PUSH ;save PUSH DX,WDT_EN_RF ;enable watchdog AL,DX ;reco WT_Rresh PUSH ;save PUSH DX,WDT_ET_RF ;refresh watchdog AL,DX ;reco WT_DISABLE PUSH PUSH DX,WDT_DIS; disable watchdog AL,DX ;reco 3307389 User's Manual...

  • Page 15: Diskonchip 2000 Flash Disk

    ® DiskOnChip 2000 Flash Disk Installation Instructions 1. Make sure the 3307389 is powered OFF. 2. Plug the DOC (DiskOn- JDO C1 Chip 2000) device into its socket. Verify the direction is correct (pin 1 of the DiskOnChip 2000 is aligned with pin...

  • Page 16: Single Chip Fast Ethernet Controller

    LAN-LED 10/ S A DiskOnChip2000 100 P C LAN LED Indicator (LED) Connector: LED block Type: 3 LED LE D Description (10)or100 / (light off) green 10MB/100MB Mode SPD / green Speed ACT / yellow Active Transfer 3307389 User's Manual...
  • Page 17 7 -8 9- 10 11 - 12 R S-232C RS- 485 RS-422 TX/RX always enable RX enable by RTS, TX always enable off TX enable by RTS, RX always enable o n TX/RX enable by RTS default setting 3307389 User's Manual...

  • Page 18: Power Connectors

    Type : 4-pin onboard AT Connector Description wire color +12V yellow black black + 5V Di sk O n Ch i p 20 00 ATX power control (JP2) Connector : JP2 Type : 3-pin onboard Wafer connector Description 5V SB(Standby) PS-ON 3307389 User's Manual...

  • Page 19: Cpu Fan Connector

    Type : 3-pin onboard header box Description +12V FAN_CTL FAN1 Di sk O n Ch i p 20 00 FAN3 1 2 3 CPU Fan Connector (FAN3) Connector : CHASFAN Type : 3-pin onboard header box Description +12V FAN_CTL 3307389 User's Manual...

  • Page 20: Switches And Indicators

    P o we r P W R B T S p e a ke r Sw itch G N D N CS S MIS w G N D P K IN itch S M I Note : (+) means LED anode 3307389 User's Manual...

  • Page 21: Interface Connectors Hdd, Fdd

    DRIVE DENSITY SELECT 1 IN D EX- MOTOR EN ABLE A- 33 34 DRIVER SELECT B- DRIVER SELECT A- MOTOR ENABLE B- DIRECTION- STEP- WRITE DATA- WRITE GATE- TRACK 0- WRITE PROTECT- READ DATA- HEAD SELECT- DISK CHANGE- 3307389 User's Manual...

  • Page 22: Enhanced Ide Connector

    Type : onboard 40-pin box headers, primary Description Description RESET D1 0 D1 1 D 12 D 13 D 14 D 15 RE Q IOW-/STOP IOR-/HDMARDY IORDY/DDMARDY IDESE L DACK- CBLID CS0(MASTER CS) CS1(SLAVE CS) LED ACT- 3307389 User's Manual...
  • Page 23 Type : onboard 44-pin box header, secondary Description Description RESET D1 0 D1 1 D 12 D 13 D 14 D 15 RE Q IOW-/STOP IOR-/HDMARDY IORDY/DDMARDY IDESE L DACK- CBLID CS0(MASTER CS) CS1(SLAVE CS) LED ACT- 3307389 User's Manual...

  • Page 24: Peripheral Ports

    Type: onboard 10-pin header for two USB ports Description Description 1 3 5 7 9 DATA0- DATA1- DATA0 + DATA1+ IrDA (JIR1) 1 2 3 4 5 Connector : JIR1 Type : onboard 5-pin header Description Description IRRX IRTX 3307389 User's Manual...
  • Page 25 Description Description D TR RT S COM2 R XD COM3 R XD COM4 R XD RS-422/485 Serial Ports (JRS1) Connector : JRS1 Type : onboard 4-pin header (COM2) COM2 Description Description TX- / 485- TX+ / 485+ 3307389 User's Manual...

  • Page 26: Crt Svga

    E N A VE E SHFCLK EN ABK L CRT SVGA (JVGA) Connector : JVGA Type : onboard 16-pin header Description Description GR E E N BLUE GR OUND GROUND GR OUND GROUND GROUND VDD AT HSYNC VSYNC VDCCLK 3307389 User's Manual...
  • Page 27 1 3 5 7 9 Type : onboard 10-pin header Description Description LINE RIGHT LI NE LEFT SPEAKER LEFT SPEAKER RIGHT CDROM audio interface (SONY) Connector : SONY Type : onboard 4-pin box header Description Description CD Left CD Right 3307389 User's Manual...
  • Page 28 16-bit General Purpose I/O (JDIO) Connector : JDIO Type : Onboard 20-pin header Description Description D O0 D O1 D O2 D O3 D O4 D O5 D O6 D O7 + 5V +12V 3307389 User's Manual...
  • Page 29 Reserved for VGA BIOS 000C 4000h-000C 7FF F h Reserved for VGA BIOS 00 0C 80 00h -0 00C BFFF h Reserved for ROM device 000CC000h -000CFFFFh Reserved for ROM device 000D 0000h-000DF FFF h Reserved for ROM device 3307389 User's Manual...
  • Page 30 DMA controller 2 registers 01 02 h VGA setup register. 03B4h,03B5h,03BAh 03D4h,03D5h,03DAh VGA registers. 03 C0 h- 03 CF h 0CF8h PCI configuration Address register. 0CFCh-0CFFh PCI configuration Data register. 46 E 8 h VGA add-in mode enable register. 3307389 User's Manual...
  • Page 31 This page intentionally left blank 3307389 User's Manual...
  • Page 32 Supported Display Modes : Reso lution Colors Refresh Rate 1280x 1024 8b pp 60 Hz 1024x 768 16 bp p 60,75,85 Hz 800x 600 24b p p 60,75,85 Hz 640x 480 24b p p 60,75,85 Hz 3307389 User's Manual...
  • Page 33 Flat Panel Connector Power Setting +12 V +12 V GNDV The 3307389 's Vcc is ENA V configurable as either +3.3 or +5.0 Volt by jumper setting (JVOLT1) A second jumper (JVOLT2) delays applying power to the LCD's backlight when booting your system. Enabling this delay only initializes the backlight after the LCD itself is initialized.
  • Page 34 PLANAR EL640.480-AA1 Display type : 640 x 480 EL Mono EL 640.480-AA1/ 34-pin 3307389 / 50-pin 2.54 pitch / housing 2.0 pitch / housing Description Description PD 12 PD 13 PD 14 PD 15 R eserved R eserved R eserved...
  • Page 35 KYOCERA KCB104VG2BA-A01 Display type : 640 x 480 16-bit Color STN KCB104VG2BA-A01 3307389 / 50-pin Molex 53261-1510 2.0 pitch / housing Description Description F L M F L M DISP EN ABK L LOAD SHFCLK HD 0 HD 1 HD 2...
  • Page 36 SHARP LQ12S41 Display type : 800 x 600 18-bit Color TFT LQ12S41 3307389 / 50-pin DF9X-41S-1V/Hirose 2.0 pitch / housing Description Description SHFCLK Hsync Vsync +3.3V +3.3V 3307389 User's Manual...
  • Page 37 HITACHI LMG9211XUCC Display type : 640 x 480 16-bit Color STN LMG9211XUCC 3307389 / 50-pin Molex 53261-1510 2.0 pitch / housing Description Description F L M F L M DISP·OFF ENAB KL LOAD SHFCLK UD 0 UD 1 UD 2...
  • Page 38 NAN YA LTBSHT024GC Display type: 640 x 480 8-bit Mono STN LTBSHT024GC 3307389 / 50-pin Molex 53261-1590 2.0 pitch / housing Description Description F L M F L M LOAD SHFCLK D.OFF ENAB KL -17V DU 0 DU 1 DU 2...
  • Page 39 TORISAN MXS121022010 Display type : 800 x 600 18-bit Color TFT MXS121022010 3307389 / 50-pin DF9X-41S-1V/Hirose 2.0 pitch / housing Description Description DCLK SHFCLK Hsync Vsync TEST +3.3V +3.3V MO DE 3307389 User's Manual...
  • Page 40 NEC NL8060AC26-04 Display type : 800 x 600 18-bit Color TFT NL8060AC26-04 3307389 / 50-pin DF9X-41S-1V/Hirose 2.0 pitch / housing Description Description SHFCLK Hsync Vsync +3.3V/+5V +3.3V/+5V +3.3V/+5V MO DE 3307389 User's Manual...
  • Page 41 This page intentionally left blank 3307389 User's Manual...

  • Page 42: Award Bios Setup

    AWARD BIOS Setup The 3307389 uses the Award PCI/ISA BIOS version 6.0 for the system configuration. The Award BIOS setup program is designed to provide the maximum flexibility in configuring the system by offering various options which could be selected for end-user requirements. This chapter is written to assist you in the proper usage of these features.

  • Page 43: Setup Items

    Supervisor / User Password Use this menu to set User and Supervisor Passwords. Save & Exit Setup Save CMOS value changes to CMOS and exit setup. Exit Without Saving Abandon all CMOS value changes and exit setup. 3307389 User's Manual...

  • Page 44: Standard Cmos Setup

    360K : 5.25 in5-1/4 inch PC-type standard drive 1.2M : 5.25 in5-1/4 inch AT-type high-density drive 720K : 3.5 in3-1/2 inch double-sided drive 1.44M : 3.5 in3-1/2 inch double-sided drive 2.88M : 3.5 in3-1/2 inch double-sided drive 3307389 User's Manual...
  • Page 45 All, But Diskette POST does not stop for diskette drive errors, but stops for all other errors. All, But Disk/Key POST does not stop for a keyboard or disk error, but stops for all other errors. 3307389 User's Manual...

  • Page 46: Ide Harddisk Setup (Submenu)

    Access Mode Normal, LBA, Large or Auto Choose the access mode for this hard disk The following options are selectable only if the 'IDE Primary Master' item is set to 'Manual' 3307389 User's Manual...
  • Page 47 We recommend that you select Type "AUTO" for all drives. The BIOS will auto-detect the hard disk drive and CD-ROM drive at the POST stage. If your hard disk drive is a SCSI device, please select "None" for your hard drive setting. 3307389 User's Manual...

  • Page 48: Bios Features Setup

    Enabled Activates automatically when the system boots up causing a warning message to appear when anything attempts to access the boot sector or hard disk partition table. Disabled No warning message will appear when anything attempts to access the boot sector or hard disk partition table. 3307389 User's Manual...
  • Page 49 The choice: 6, 8, 10, 12, 15, 20, 24, 30. Typematic Delay (Msec) Sets the delay time after the key is held down before it begins to repeat the keystroke. The choice: 250, 500, 750, 1000. 3307389 User's Manual...
  • Page 50 'Memory'. This will tell you what segments (if any) are being shadowed For DOS you can use MSD.EXE to see what segments are claimed. CC000-CFFFF - D0000-D3FFF - D4000-D7FFF - D8000-DBFFF and DC000-DFFFF - Same as above. 3307389 User's Manual...

  • Page 51: Chipset Features Setup

    (DRAM Clock, SDRAM Cycle Length and Bank Interleave) DRAM Clock This item allows you to set the DRAM Clock. Options are Host CLK, HCLK+33M or HCLK-33M. Please set the item according to the Host (CPU) Clock and DRAM Clock. 3307389 User's Manual...
  • Page 52 This BIOS option reduces the delay that occurs when the CPU first reads from the RAM and then writes to it. There is normally an extra delay associated with this switch from reading to writing. If you enable this option, 3307389 User's Manual...
  • Page 53 The physical memory is allocated and released as needed only when Direct3D makes a "create non-local surface" call. AGP-4X Mode Set to Enabled if your AGP card supports the 4X mode, which transfers video data at 1066MB/s. 3307389 User's Manual...
  • Page 54 The delay will generally improve the overclockability of the PCI bus. PCI Delay Transaction The chipset has an embedded 32-bit posted write buffer to support delay transactions cycles. Select Enabled to support compliance with PCI specifica- tion version 2.1. 3307389 User's Manual...
  • Page 55 1 wait state or clock cycle. For better AGP read performance, enable this option but disable it if you experience weird graphical anomalies like wire frame effects and pixel artifacts after enabling this option. 3307389 User's Manual...

  • Page 56: Integrated Peripherals

    SB DMA Select [ DMA 1] MPU-4 01 [ Dis able d] MPU-401 I/O Address [330-333 H] GAME Port (200-207H) [ Enabled] ↑ ↓ → ← :Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help F5:Previous Values F6:Fail-SAfe Defaults F7:Optimized Defaults 3307389 User's Manual...
  • Page 57 Select an operating mode for the parallel port. Mode options are Normal, EPP, ECP, ECP/EPP. ECP Mode Use DMA Select a DMA channel if parallel Mode is set as ECP, ECP/EPP. Parallel Port EPP Type Select a EPP Type if parallel Port is set as EPP, ECP/EPP. 3307389 User's Manual...

  • Page 58: Power Management Setup

    SL CPU's.. Doze Mode = 1 min., Standby Mode = 1 min., Suspend Mode = 1 min. User Defined Allows you to set each mode individually. When not disabled, each of the ranges are from 1 min. to 1 hr. HDD Power Down is always set independently 3307389 User's Manual...
  • Page 59 The default is 'Instant-Off'. 3307389 User's Manual...
  • Page 60 Setting an event on each device listed to awaken the system from a soft off state. LPT & COM HDD & FDD PCI Master Power On by PCI Card Wake Up on LAN/Ring RTC Alarm Resume Date (of Month) Resume Time (hh:mm:ss) Primary INTR IRQs Activity Monitoring 3307389 User's Manual...

  • Page 61: Pnp/Pci Configuration

    Resource Controlled By The Award Play and Play BIOS can automatically configure all the boot and Plug-and-Play compatible devices. If you select Auto, all the interrupt request (IRQ) and DMA assignment fields disappear, as the BIOS automatically assigns them. 3307389 User's Manual...
  • Page 62 IRQ. Assign IRQ For USB Windows 95 will automatically give an IRQ to the USB port even if there is no USB peripheral connected. Disabling this will free the IRQ. 3307389 User's Manual...

  • Page 63: Post Codes

    Blank video Keyboard controller initialization Initialize keyboard Reserved Test CMOS Verifies CMOS is working correctly, Interface and detects bad battery. Battery Status Chipset Default Program chipset registers with power Initialization on BIOS defaults. 3307389 User's Manual...
  • Page 64 Setup shadow RAM - Enable shadow according to Setup. Test DMA BIOS checksum test. Controller 0 Keyboard detect and initialization Test DMA Controller 1 Test DMA Page Test DMA Page Registers. Registers 12-13 Reserved 3307389 User's Manual...
  • Page 65 1MB. Test Base and Test base memory from 256K to 640K Extended Memory and extended memory above 1MB using various patterns. NOTE: This test is skipped in EISA mode and can be skipped with ESC key 3307389 User's Manual...
  • Page 66 Initialize math coprocessor. Math Coprocessor Reserved Reserved 48-4D Reserved Manufacturing Reboot if Manufacturing POST Loop pin POST Loop or is set. Otherwise display any Display Messages messages (i.e., any non-fatal errors that were detected during POST) and enter Setup. 3307389 User's Manual...
  • Page 67 Set low stack Boot via INT 19h. Spurious If interrupt occurs in protected mode. Unclaimed NMI If unmasked NMI occurs, display: Press F1 to disable NMI, F2 reboot. E1-EF Setup Pages E1- Page 1, E2 - Page 2, etc. Boot 3307389 User's Manual...

  • Page 68: Howto : Flash The Bios

    1. In CMOS Chipset Features Setup, Disable Video Bios Cacheable. 2. Hit Esc, F10, Save and exit. 3. Flash the BIOS and reboot 4. Enter CMOS Chipset Features Setup,and Enable Video Bios Cacheable, hit Esc, F10, Save and reboot. 3307389 User's Manual...
  • Page 69 The boot-block BIOS will execute an AUTOEXEC.BAT file on a bootable diskette. Copy an Award flasher & the correct BIOS *.bin file on the floppy and execute it automatically by putting awdflash *.bin in the AUTOEXEC.BAT file. 3307389 User's Manual...
  • Page 70 Thank you for purchasing from Global American Inc. We will stand by our slogan, “Integration with Integrity”, that’s the Global way! Questions or comments? Please contact us: Mailing Address Global American, Inc 17 Hampshire Drive Hudson, NH 03051 Phone (603) 886-3900...
