Global American 3307810 User Manual

Single board computer 3307810
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
User's Manual
Single Board Computer 3307810
Version 1.1, August 2007

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 3307810 and is the answer not in the manual?

Questions and answers

Related Manuals for Global American 3307810

Summary of Contents for Global American 3307810

  • Page 1 User’s Manual Single Board Computer 3307810 Version 1.1, August 2007...
  • Page 2 Copyrights This manual is copyrighted and all rights are reserved. It does not allow any non authorization in copied, photocopied, translated or reproduced to any electronic or machine readable form in whole or in part without prior written consent from the manufacturer. In general, the manufacturer will not be liable for any direct, indirect, special, incidental or consequential damages arising from the use of inability to use the product or documentation, even if advised of the possibility of such damages.

  • Page 3: Manual Conventions

    Cautionary messages should also be heeded to help reduce the chance of losing data or damaging the 3307810. Cautions are easy to recognize. The word “caution” is written as “CAUTION,” both capitalized and bold and is followed. The italicized text is the cautionary message.
  • Page 4 3307810 CAUTION: This is an example of a caution message. Failure to adhere to cautions messages may result in permanent damage to the 3307810. Please take caution messages seriously. NOTE: These messages inform the reader of essential but non-critical information. These messages should be read carefully as any directions or instructions contained therein can help avoid making mistakes.

  • Page 5: Packing List

    Global American sales representative directly. To contact a Global American sales representative, please send an email to salesinfo@globalamericaninc.com. The items listed below should all be included in the 3307810 package. 1 x 3307810 single board computer 1 x IDE cable...

  • Page 6: Table Of Contents

    1.1.1 3307810 Benefits....................20 1.1.2 3307810 Features .................... 20 1.2 3307810 O ....................21 VERVIEW 1.2.1 3307810 Overview Photo................. 21 1.2.2 3307810 Peripheral Connectors and Jumpers ..........22 1.2.3 Technical Specifications................... 23 DETAILED SPECIFICATIONS ................27 2.1 O ........................ 28 VERVIEW 2.2 D...
  • Page 7 2.9.2 Operating Temperature and Temperature Control........... 48 2.9.3 Power Consumption..................48 2.10 E ....................48 XPANSION PTIONS 2.10.1 Expansion Options Overview................. 48 2.10.2 GLOBAL AMERICAN INC. Expansion PICOe Backplanes......48 2.10.3 GLOBAL AMERICAN INC. Chassis.............. 49 UNPACKING ......................50 3.1 A ..................51 STATIC RECAUTIONS...
  • Page 8 3.3.1 Package Contents..................... 52 3.3.2 Optional Items....................54 CONNECTOR PINOUTS..................56 4.1 P ..............57 ERIPHERAL NTERFACE ONNECTORS 4.1.1 3307810 Layout ....................57 4.1.2 Peripheral Interface Connectors ..............58 4.1.3 External Interface Panel Connectors............... 59 4.2 I ..............60 NTERNAL ERIPHERAL ONNECTORS 4.2.1 +12V ATX Power Supply Connector ...............
  • Page 9 3307810 5.1 A ..................89 STATIC RECAUTIONS 5.2 I ................90 NSTALLATION ONSIDERATIONS 5.2.1 Installation Notices ..................90 5.2.2 Installation Checklist ..................91 5.3 CPU, CPU C DIMM I ..........92 OOLING IT AND NSTALLATION 5.3.1 Socket M CPU Installation ................92 5.3.2 Cooling Kit 2107703 Installation ..............
  • Page 10 3307810 A.3 A ................126 SSEMBLY ANGUAGE AMPLES A.3.1 Enable the DIO Input Function..............126 A.3.2 Enable the DIO Output Function ..............126 WATCHDOG TIMER ..................128 ADDRESS MAPPING..................133 C.1 A ....................... 134 DDRESS C.2 1 MB M ................134...
  • Page 11 Figure 4-15: Parallel Port Connector Location ................77 Figure 4-16: SATA Drive Connector Locations ................79 Figure 4-17: COM1 and COM2 Connector Pinout Locations ...........80 Figure 4-18: USB Connector Pinout Locations .................82 Figure 4-19: 3307810 External Peripheral Interface Connector ..........83 Page xii...
  • Page 12 Figure 5-1: Make sure the CPU socket retention screw is unlocked ........93 Figure 5-2: Lock the CPU Socket Retention Screw..............94 Figure 5-3: GLOBAL AMERICAN INC. 2107703 Cooling Kit .............95 Figure 5-4: Cooling Kit Support Bracket ..................96 Figure 5-5: Connect the cooling fan cable.................96 Figure 5-6: Installing a DIMM .......................97...
  • Page 13 Table 2-2: Supported Processors ....................32 Table 2-3: Supported HDD Specifications..................38 Table 2-4: Power Consumption ....................48 Table 2-5: Compatible GLOBAL AMERICAN INC. PICOe Backplanes........49 Table 2-6: Compatible GLOBAL AMERICAN INC. Chassis ............49 Table 3-1: Package List Contents....................53 Table 3-2: Optional Items ......................54 Table 4-1: Peripheral Interface Connectors ................59...
  • Page 14 Table 5-2: CF Card Setup Jumper Settings................100 Table 5-3: Clear CMOS Jumper Settings ................. 102 Table 5-4: LVDS Voltage Selection Jumper Settings.............. 103 Table 5-5: PCIe Interface Select Jumper Settings ..............104 Table 5-6: GLOBAL AMERICAN INC. Provided Cables ............106 Page xv...

  • Page 15: Bios Menus

    3307810 BIOS Menus Menu 1: Main ..................Error! Bookmark not defined. Menu 2: Advanced ................Error! Bookmark not defined. Menu 3: CPU Configuration..............Error! Bookmark not defined. Menu 4: IDE Configuration..............Error! Bookmark not defined. Menu 5: IDE Master and IDE Slave Configuration......Error! Bookmark not defined.
  • Page 16 3307810 Glossary AC ’97 Audio Codec 97 Hard Disk Drive ACPI Advanced Configuration and Integrated Data Electronics Power Interface Input/Output Advanced Power Management ICH4 I/O Controller Hub 4 ARMD ATAPI Removable Media Device L1 Cache Level 1 Cache ASKIR Shift Keyed Infrared...

  • Page 17: Introduction

    3307810 THIS PAGE IS INTENTIONALLY LEFT BLANK Chapter Introduction Page xix...

  • Page 18: Introduction

    3307810 1.1 Introduction The half-size 3307810 CPU card is a Socket M Intel® Core™2 Duo, Intel® Core™ Duo, Intel® Core™ Solo or Intel® Celeron M (Yohan core) CPU platform. The 3307810 has a maximum front side bus (FSB) frequency of 667MHz and supports 667MHz 2GB dual channel memory modules.

  • Page 19: 3307810 Overview

    3307810 is shown in Figure 1-1. Figure 1-1: 3307810 Overview [Front View] A labeled photo of the peripheral connectors on the back of the 3307810 is shown in Figure 1-1.

  • Page 20: 3307810 Peripheral Connectors And Jumpers

    2 x Serial port connectors (internal COM 1 and COM 2 RS-232) 1 x Parallel port connector 2 x Serial ATA (SATA) drive connectors 2 x USB connectors The 3307810 has the following external peripheral interface connectors on the board rear panel Page 22...

  • Page 21: Technical Specifications

    The 3307810 has the following on-board jumpers: Clear CMOS CF Card setup LVDS voltage selection PCIe interface setup 1.2.3 Technical Specifications 3307810 technical specifications are listed in Table 1-1. See Chapter 2 for details. Specification 3307810 Form Factor Half-size Socket M Intel® Core™2 Duo Socket M Intel®...
  • Page 22 3307810 ® CRT: Integrated in the Intel 945GM to support CRT Display LVDS: Dual channel 18-bit LVDS LCD panel HDTV: Supported by component interface AMI Flash BIOS BIOS Audio 7.1 channel or 5.1 channel audio with an optional AC-KIT Intel® 82573 PCIe GbE chipset Intel®...

  • Page 23: Table 1-1: Technical Specifications

    3307810 Temperature 0ºC – 60ºC (32ºF - 140ºF) Humidity (operating) 5%~95% non-condensing Dimensions (LxW) 185mm x 122mm Weight (GW/NW) 1000g/ 171g Table 1-1: Technical Specifications Page 25...
  • Page 24 3307810 THIS PAGE IS INTENTIONALLY LEFT BLANK Page 26...

  • Page 25: Detailed Specifications

    3307810 Chapter Detailed Specifications Page 27...

  • Page 26: Overview

    3307810 2.1 Overview This chapter describes the specifications and on-board features of the 3307810 in detail. 2.2 Dimensions 2.2.1 Board Dimensions The dimensions of the board are listed below: Length: 185mm Width: 122mm Figure 2-1: 3307810 Dimensions (mm) 2.2.2 External Interface Panel Dimensions...

  • Page 27: Data Flow

    3307810 External peripheral interface connector panel dimensions are shown in Figure 2-2. Figure 2-2: External Interface Panel Dimensions (mm) 2.3 Data Flow Figure 2-3 shows the data flow between the two on-board chipsets and other components installed on the motherboard and described in the following sections of this chapter.

  • Page 28: Figure 2-3: Data Flow Block Diagram

    3307810 Figure 2-3: Data Flow Block Diagram Page 30...

  • Page 29: Compatible Processors

    3307810 2.4 Compatible Processors 2.4.1 Compatible Processor Overview The 3307810 supports the following Socket M processors: Intel® Core™2 Duo Mobile processors Intel® Core™ Duo processors Intel® Core™ Solo processors Intel® Celeron® M processors ® All three of the above processors communicate with the Intel 945GM northbridge chipset through a 667MHz front side bus (FSB).

  • Page 30: Intel ® 945Gm Northbridge Chipset

    3307810 Family CPU Speed Processor # Bus Speed Mfg Tech Stepping Cache Size 2 GHz T7200 667 MHz 65 nm 4 MB 1.83 GHz T5600 667 MHz 65 nm 2 MB 1.66 GHz T5500 667 MHz 65 nm 2 MB Core™...

  • Page 31: Intel ® 945Gm Memory Support

    ® 2.5.2 Intel 945GM Memory Support WARNING: Only DDR2 memory module can be installed on the 3307810. Do not install DDR memory modules. If a DDR memory module is installed on the 3307810, the 3307810 may be irreparably damaged. ®...

  • Page 32: Intel ® 945Gm Pcie X1 Bus: Pcie Gbe Ethernet Controller

    3307810 ® 2.5.3 Intel 945GM PCIe x1 Bus: PCIe GbE Ethernet Controller One lane of the PCIe (PCIe x1) bus on the Intel® 945GM northbridge chipset is interfaced to an external RJ-45 LAN connector (LAN1) through an Intel® PC82573V PCIe GbE controller.

  • Page 33: Intel ® 945Gm Lvds Support

    3307810 integrated 400MHz RAMDAC and hot plug CRT support, supports analog CRT monitors up to QXGA. ® 2.5.4.2 Intel 945GM LVDS Support A 30-pin LVDS crimp connector is interfaced to the Intel® 945GM graphics engine. The Intel® 945GM internal graphics engine supports LVDS displays with the following features:...

  • Page 34: Intel ® Ich7-M Southbridge Chipset

    Integrated SATA host controller with DMA operations interfaced to four SATA connectors on the 3307810 Integrated IDE controller supports Ultra ATA 100/66/33 Supports the four USB 2.0 devices on the 3307810 with four UHCI controllers and one EHCI controller Complies with System Management Bus (SMBus) Specification, Version 2.0 Supports Audio Codec ’97 (AC’97) Revision 2.3...

  • Page 35: Intel ® Ich7-M Ethernet Connection

    3307810 Front left Front right Back left Back right Center Subwoofer ® 2.6.3 Intel ICH7-M Ethernet Connection An integrated PHY on the Intel® ICH7-M southbridge is interfaced to an Intel® EP82562ET 10Mbps or 100Mbps Ethernet controller. The Intel® EP82562ET controller is then connected to the LAN2 RJ-45 connector.

  • Page 36: Intel ® Ich7-M Low Pin Count (Lpc) Interface

    3307810 Ultra ATA/33, with data transfer rates up to 33MB/s Specification Ultra ATA/100 Ultra ATA/66 Ultra ATA/33 IDE devices PIO Mode 0 – 4 0 – 4 0 – 4 PIO Max Transfer Rate 16.6 MB/s 16.6 MB/s 16.6 MB/s...

  • Page 37: Intel ® Ich7-M Pcie X4 Bus

    3307810 Figure 2-7: PCI Golden finger ® 2.6.7 Intel ICH7-M PCIe x4 Bus The Intel® ICH7-M southbridge chipset has four PCIe lanes. The four PCIe lanes are interfaced through a golden finger on the bottom of the CPU card through a compatible half-size backplane to either four PCIe x1 expansion cards or one PCIe x4 expansion card on.

  • Page 38: Intel ® Ich7-M Real Time Clock

    Up to five high-speed, full-speed or low-speed USB devices are supported by the ICH7-M on the 3307810. High-speed USB 2.0, with data transfers of up to 480MB/s, is enabled with the ICH7-M integrated Enhanced Host Controller Interface (EHCI) compliant host controller.

  • Page 39: Lpc Bus Components

    3307810 Figure 2-9: Onboard USB Implementation 2.7 LPC Bus Components 2.7.1 LPC Bus Overview The LPC bus is connected to components listed below: BIOS chipset Super I/O chipset The BIOS chipset and Super I/O chipset are shown in Figure 2-10 below.

  • Page 40: Bios Chipset

    3307810 Figure 2-10: LPC Bus Components 2.7.2 BIOS Chipset The BIOS chipset has a licensed copy of AMI BIOS installed on the chipset. Some of the BIOS features are listed below: AMI Flash BIOS SMIBIOS (DMI) compliant Console redirection function support...

  • Page 41: Super I/O Lpc Interface

    3307810 Fan Speed Controller SmartGuardian Controller Single +5V Power Supply Two 16C550 UARTs for serial port control One IEEE 1284 Parallel Port Floppy Disk Controller Keyboard Controller Watchdog Timer Serial IRQ Support Vbat & Vcch Support Single +5V Power Supply Some of the Super I/O features are described in more detail below: 2.7.3.1 Super I/O LPC Interface...

  • Page 42: Super I/O Fan Speed Controller

    3307810 2.7.3.4 Super I/O Fan Speed Controller The Super I/O fan speed controller enables the system to monitor the speed of the fan. One of the pins on the fan connector is reserved for fan speed detection and interfaced to the fan speed controller on the Super I/O.

  • Page 43: Intel® Pc82573V Pcie Gbe Ethernet Controller

    3307810 2.8.2 Intel® PC82573V PCIe GbE Ethernet Controller 2.8.2.1 Intel® PC82573V Overview The Intel® PC82573V is a PCIe GbE Ethernet controller that interfaces the Intel® 945GM northbridge chipset to the LAN1 RJ-45 connector. The Intel 82573 Gigabit Ethernet ® Controller provides a standard IEEE 802.3 Ethernet interface for 1000BASE-T, 100BASE-TX, and 10BASE-T applications (802.3, 802.3u, and 802.3ab, respectively).

  • Page 44: Intel® Ep82562Et Pcie Gbe Ethernet Controller

    3.3 V device 48-pin Shrink Small Outline Package Platform LAN connect interface support 2.9 Environmental and Power Specifications 2.9.1 System Monitoring Three thermal inputs on the 3307810 Super I/O Enhanced Hardware Monitor monitor the following temperatures: System temperature Power temperature Page 46...
  • Page 45 3307810 CPU temperature Eight voltage inputs on the 3307810 Super I/O Enhanced Hardware Monitor monitor the following voltages: Vcore +2.5V +3.3V +5.0V +12.0V DDR Vtt +1.5V 5VSB The 3307810 Super I/O Enhanced Hardware Monitor also monitors the following voltages internally:...

  • Page 46: Operating Temperature And Temperature Control

    These backplanes and chassis are listed below. 2.10.2 GLOBAL AMERICAN INC. Expansion PICOe Backplanes The backplanes listed in Table 2-5 are compatible with the 3307810 and can be used to develop highly integrated industrial applications. All of the backplanes listed below have...

  • Page 47: Global American Inc. Chassis

    GLOBAL AMERICAN INC. chassis available for 3307810 system development are listed in Table 2-6. For more information about these chassis please consult the GLOBAL AMERICAN INC. catalog or contact your vendor, reseller or the GLOBAL AMERICAN INC. sales team at salesinfo@globalamericaninc.com. Model...

  • Page 48: Unpacking

    3307810 Chapter Unpacking Page 50...

  • Page 49: Anti-Static Precautions

    When the 3307810 is unpacked, please do the following: Follow the anti-static precautions outlined in Section 3.1. Make sure the packing box is facing upwards so the 3307810 does not fall out of the box. Make sure all the components shown in Section 3.3 are present.

  • Page 50: Package Contents

    If some of the components listed in the checklist below are missing, please do not proceed with the installation. Contact the GLOBAL AMERICAN INC. reseller or vendor you purchased the 3307810 from or contact a Global American sales representative directly. To contact a Global American sales representative, please send an email to salesinfo@globalamericaninc.com.

  • Page 51: Table 3-1: Package List Contents

    3307810 Dual RS-232 cable Dual USB cable (w bracket) Mini jumper pack Quick installation guide Utility CD Table 3-1: Package List Contents Page 53...

  • Page 52: Optional Items

    3.3.2 Optional Items NOTE: The items listed in this section are optional items that must be ordered separately. Please contact your 3307810 vendor, distributor or reseller for more information or, contact Global American Inc. directly by sending an email to salesinfo@globalamericaninc.com.
  • Page 53 3307810 THIS PAGE IS INTENTIONALLY LEFT BLANK Page 55...

  • Page 54: Connector Pinouts

    3307810 Chapter Connector Pinouts Page 56...

  • Page 55: Peripheral Interface Connectors

    4.1 Peripheral Interface Connectors Section 4.1.2 shows peripheral interface connector locations. Section 4.1.2 lists all the peripheral interface connectors seen in Section 4.1.2. 4.1.1 3307810 Layout Figure 4-1 shows the on-board peripheral connectors, rear panel peripheral connectors and on-board jumpers.

  • Page 56: Peripheral Interface Connectors

    3307810 Figure 4-2: Connector and Jumper Locations (Solder Side) 4.1.2 Peripheral Interface Connectors Table 4-1 shows a list of the peripheral interface connectors on the 3307810. Detailed descriptions of these connectors can be found below. Connector Type Label +12V ATX power supply connector...

  • Page 57: External Interface Panel Connectors

    8-pin header USB3_4 Table 4-1: Peripheral Interface Connectors 4.1.3 External Interface Panel Connectors Table 4-2 lists the rear panel connectors on the 3307810. Detailed descriptions of these connectors can be found in Section 0 on page 83 Connector Type Label...

  • Page 58: Internal Peripheral Connectors

    Internal peripheral connectors are found on the motherboard and are only accessible when the motherboard is outside of the chassis. This section has complete descriptions of all the internal, peripheral connectors on the 3307810. 4.2.1 +12V ATX Power Supply Connector...

  • Page 59: Audio Connector (9-Pin)

    3307810 PIN NO. DESCRIPTION +12V +12V Table 4-3: +12V ATX Power Connector Pinouts 4.2.2 Audio Connector (9-pin) CN Label: J_AUDIO1 CN Type: 9-pin header CN Location: See Figure 4-4 CN Pinouts: See Table 4-4 An optional module can be connected to the 10-pin audio connector to provide the system with a high quality AC’97 or Azalia compatible codec that provides a complete integrated...

  • Page 60: Backlight Inverter Connector

    5-pin wafer (1x5) CN Location: See Figure 4-5 CN Pinouts: See Table 4-5 The backlight inverter connector provides the backlight on the LCD display connected to the 3307810 with +12V of power. Figure 4-5: Panel Backlight Connector Pinout Locations Page 62...

  • Page 61: Backplane To Mainboard Connector

    3307810 PIN NO. DESCRIPTION BRIGHTNESS GROUND +12V GROUND BACKLIGHT ENABLE Table 4-5: Panel Backlight Connector Pinouts 4.2.4 Backplane to Mainboard Connector CN Label: ATXCTL1 CN Type: 3-pin wafer (1x3) CN Location: See Figure 4-6 CN Pinouts: See Table 4-6 The backplane to mainboard connector closes the circuit between the mainboard and the backplane in which it is installed.

  • Page 62: Compact Flash Socket

    3307810 Figure 4-6: Backplane to Mainboard Connector Location PIN NO. DESCRIPTION PS_ON# 5VSB Table 4-6: Backplane to Mainboard Connector Pinouts 4.2.5 Compact Flash Socket CN Label: CF1 (solder side) CN Type: 50-pin header (2x25) CN Location: See Figure 4-7 CN Pinouts:...

  • Page 63: Figure 4-7: Cf Card Socket Location

    3307810 Figure 4-7: CF Card Socket Location Page 65...

  • Page 64: Table 4-7: Cf Card Socket Pinouts

    3307810 PIN NO. DESCRIPTION PIN NO. DESCRIPTION GROUND VCC-IN CHECK1 DATA 3 DATA 11 DATA 4 DATA 12 DATA 5 DATA 13 DATA 6 DATA 14 DATA 7 DATA 15 HDC_CS0# HDC_CS1 GROUND IOR# IOW# VCC_COM IRQ15 VCC_COM VCC_COM CSEL...

  • Page 65: Digital Input/Output (Dio) Connector

    3307810 4.2.6 Digital Input/Output (DIO) Connector CN Label: DIO1 CN Type: 10-pin header (2x5) CN Location: See Figure 4-8 See Table 4-8 CN Pinouts: The digital input/output connector is managed through a Super I/O chip. The DIO connector pins are user programmable.

  • Page 66: Fan Connector (+12V)

    3307810 PIN NO. DESCRIPTION PIN NO. DESCRIPTION Output 3 Output 2 Output 1 Output 0 Input 3 Input 2 Input 1 Input 0 Table 4-8: DIO Connector Connector Pinouts 4.2.7 Fan Connector (+12V) CN Label: CPU_FAN1 CN Type: 3-pin header...

  • Page 67: Front Panel Connector (8-Pin)

    3307810 Figure 4-9: +12V Fan Connector Location PIN NO. DESCRIPTION Fan Speed Detect +12V Table 4-9: +12V Fan Connector Pinouts 4.2.8 Front Panel Connector (8-pin) CN Label: F_PANEL1 CN Type: 8-pin header (2x8) See Figure 4-10 CN Location: Page 69...

  • Page 68: Figure 4-10: Front Panel Connector Pinout Locations

    3307810 CN Pinouts: See Table 4-10 The front panel connector connects to external switches and indicators to monitor and controls the motherboard. These indicators and switches include: Power button Reset button Power LED HDD LED Figure 4-10: Front Panel Connector Pinout Locations...

  • Page 69: Ide Connector (44-Pin)

    3307810 4.2.9 IDE Connector (44-pin) CN Label: IDE1 CN Type: 44-pin header (2x22) CN Location: See Figure 4-11 See Table 4-11 CN Pinouts: One 44-pin IDE device connector on the 3307810 supports connectivity to two hard disk drives. Page 71...

  • Page 70: Figure 4-11: Ide Device Connector Locations

    3307810 Figure 4-11: IDE Device Connector Locations PIN NO. DESCRIPTION PIN NO. DESCRIPTION RESET# GROUND DATA 7 DATA 8 DATA 6 DATA 9 DATA 5 DATA 10 DATA 4 DATA 11 DATA 3 DATA 12 DATA 2 DATA 13 DATA 1...

  • Page 71: Infrared Interface Connector (5-Pin)

    3307810 HDC CS0# HDC CS1# HDD ACTIVE# GROUND GROUND Table 4-11: IDE Connector Pinouts 4.2.10 Infrared Interface Connector (5-pin) CN Label: 5-pin header (1x5) CN Type: CN Location: See Figure 4-12 CN Pinouts: See Table 4-12 The infrared interface connector supports both Serial Infrared (SIR) and Amplitude Shift Key Infrared (ASKIR) interfaces.

  • Page 72: Keyboard/Mouse Connector

    3307810 PIN NO. DESCRIPTION IR-RX IR-TX Table 4-12: Infrared Connector Pinouts 4.2.11 Keyboard/Mouse Connector CN Label: KB_MS1 CN Type: 6-pin header (1x6) CN Location: See Figure 4-13 CN Pinouts: See Table 4-13 The keyboard and mouse connector can be connected to a standard PS/2 cable or PS/2 Y-cable to add keyboard and mouse functionality to the system.

  • Page 73: Lvds Lcd Connector

    3307810 PIN NO. DESCRIPTION +5V KB DATA MS DATA MS CLK KB DATA KB CLK GROUND Table 4-13: Keyboard/Mouse Connector Pinouts 4.2.12 LVDS LCD Connector CN Label: LVDS1 CN Type: 30-pin crimp (2x10) CN Location: See Figure 4-14 CN Pinouts:...

  • Page 74: Figure 4-14: Lvds Lcd Connector Pinout Locations

    3307810 Figure 4-14: LVDS LCD Connector Pinout Locations PIN NO. DESCRIPTION PIN NO. DESCRIPTION GROUND GROUND LVDSA_Y0+ LVDSA_Y0- LVDSA_Y1+ LVDSA_Y1- LVDSA_Y2+ LVDSA_Y2- LVDSA_CLK+ LVDSA_CLK- GROUND GROUND LVDSB_Y0+ LVDSB_Y0- LVDSB_Y1+ LVDSB_Y1- LVDSB_Y2+ LVDSB_Y2- LVDSB_CLK+ LVDSB_CLK- GROUND GROUND VCC_LVDS VCC_LVDS Page 76...

  • Page 75: Parallel Port Connector

    3307810 VCC_LVDS VCC_LVDS Table 4-14: LVDS LCD Port Connector Pinouts 4.2.13 Parallel Port Connector CN Label: LPT1 26-pin box header CN Type: CN Location: See Figure 4-15 CN Pinouts: See Table 4-15 The 26-pin parallel port connector connects to a parallel port connector interface or some other parallel port device such as a printer.

  • Page 76: Sata Drive Connectors

    3307810 PIN NO. DESCRIPTION PIN NO. DESCRIPTION DATA 7 ACKNOWLEDGE BUSY PAPER EMPTY PRINTER SELECT AUTO FORM FEED # ERROR# INITIALIZE PRINTER SELECT LN# GROUND GROUND GROUND GROUND GROUND GROUND GROUND GROUND Table 4-15: Parallel Port Connector Pinouts 4.2.14 SATA Drive Connectors...

  • Page 77: Figure 4-16: Sata Drive Connector Locations

    3307810 Figure 4-16: SATA Drive Connector Locations PIN NO. DESCRIPTION Table 4-16: SATA Drive Connector Pinouts Page 79...

  • Page 78: Serial Port Connector (Com1 And Com2)

    3307810 4.2.15 Serial Port Connector (COM1 and COM2) CN Label: COM1 and COM2 CN Type: 10-pin header (2x5) CN Location: See Figure 4-17 See Table 4-17 CN Pinouts: The 10-pin serial port connector provides a second RS-232 serial communications channel. The COM 2 serial port connector can be connected to external RS-232 serial port devices.

  • Page 79: Usb Connectors (Internal)

    3307810 PIN NO. DESCRIPTION PIN NO. DESCRIPTION Data Carrier Detect (DCD) Data Set to Ready (DSR) Receive Data (RXD) Request to Send (RTS) Transmit Data (TXD) Clear to Sent (CTS) Data Terminal Ready (DTR) Ring Indicator (RI) Ground (GND) Table 4-17: COM3 and COM4 4.2.16 USB Connectors (Internal)

  • Page 80: Figure 4-18: Usb Connector Pinout Locations

    3307810 Figure 4-18: USB Connector Pinout Locations PIN NO. DESCRIPTION PIN NO. DESCRIPTION DATAN- DATA1M+ DATAN+ DATAM- Table 4-18: USB Port Connector Pinouts Page 82...

  • Page 81: External Peripheral Interface Connector Panel

    3307810 4.3 External Peripheral Interface Connector Panel Figure 4-19 shows the 3307810 rear panel. The 3307810 rear panel consists of two RJ-45 Ethernet connectors, a PS/2 keyboard connector a USB port and a VGA connector. These connectors are accessible when the 3307810 is installed in a chassis.

  • Page 82: Tv Connector

    3307810 Figure 4-20: RJ-45 Ethernet Connector The RJ-45 Ethernet connector has two status LEDs, one green and one yellow. The green LED indicates activity on the port and the yellow LED indicates the port is linked. See Table 4-20. DESCRIPTION...

  • Page 83: Usb Connector

    USB port CN Location: See Figure 4-19 CN Pinouts: See Table 4-22 The 3307810 has a one external USB 2.0 port. The port connects to both USB 2.0 and USB 1.1 devices. PIN NO. DESCRIPTION PIN NO. DESCRIPTION USBV3L 5V USBP4N...

  • Page 84: Figure 4-21: Vga Connector

    3307810 CN Location: See Figure 4-19 CN Pinouts: See Figure 4-21 and Table 4-23 The 3307810 has a single 15-pin female connector for connectivity to standard display devices. Figure 4-21: VGA Connector DESCRIPTION DESCRIPTION GREEN BLUE VCC / NC DDC DAT...
  • Page 85 3307810 THIS PAGE IS INTENTIONALLY LEFT BLANK Page 87...

  • Page 86: Installation

    3307810 Chapter Installation Page 88...

  • Page 87: Anti-Static Precautions

    Electrostatic discharge (ESD) can cause serious damage to electronic components, including the 3307810. Dry climates are especially susceptible to ESD. It is therefore critical that whenever the 3307810, or any other electrical component is handled, the following anti-static precautions are strictly adhered to.

  • Page 88: Installation Considerations

    NOTE: The following installation notices and installation considerations should be read and understood before the 3307810 is installed. All installation notices pertaining to the installation of the 3307810 should be strictly adhered to. Failing to adhere to these precautions may lead to severe damage of the 3307810 and injury to the person installing the motherboard.

  • Page 89: Installation Checklist

    3307810 When working with the 3307810, make sure that it is disconnected from all power supplies and that no electricity is being fed into the system. Before and during the installation of the 3307810 DO NOT: Remove any of the stickers on the PCB board. These stickers are required for warranty validation.

  • Page 90: Cpu, Cpu Cooling Kit And Dimm Installation

    Running a CPU without a cooling kit may also result in injury to the user. The CPU, CPU cooling kit and DIMM are the most critical components of the 3307810. If one of these component is not installed the 3307810 cannot run.

  • Page 91: Figure 5-1: Make Sure The Cpu Socket Retention Screw Is Unlocked

    3307810 WARNING: When handling the CPU, only hold it on the sides. DO NOT touch the pins at the bottom of the CPU. Step 1: Unlock the CPU retention screw. When shipped, the retention screw of the CPU socket should be in the unlocked position. If it is not in the unlocked position, use a screwdriver to unlock the screw.

  • Page 92: Figure 5-2: Lock The Cpu Socket Retention Screw

    3307810 Step 5: Align the CPU pins. Carefully align the CPU pins with the holes in the CPU socket. Step 6: Insert the CPU. Gently insert the CPU into the socket. If the CPU pins are properly aligned, the CPU should slide into the CPU socket smoothly.

  • Page 93: Cooling Kit 2107703 Installation

    3307810 5.3.2 Cooling Kit 2107703 Installation Figure 5-3: GLOBAL AMERICAN INC. 2107703 Cooling Kit An GLOBAL AMERICAN INC. Socket M CPU cooling kit can be purchased separately. The cooling kit comprises a CPU heat sink and a cooling fan. WARNING: Do not wipe off (accidentally or otherwise) the pre-sprayed layer of thermal paste on the bottom of the [Fan model#] heat sink.

  • Page 94: Figure 5-4: Cooling Kit Support Bracket

    3307810 Figure 5-4: Cooling Kit Support Bracket Step 4: Tighten the screws. Use a screwdriver to tighten the four screws. Tighten each nut a few turns at a time and do not over-tighten the screws. Step 5: Connect the fan cable. Connect the cooling kit fan cable to the fan connector on the motherboard.

  • Page 95: Dimm Installation

    5.3.3 DIMM Installation WARNING: Using incorrectly specified DIMM may cause permanently damage the 3307810. Please make sure the purchased DIMM complies with the memory specifications of the 3307810. DIMM specifications compliant with the 3307810 are listed in Chapter 2. To install a DIMM into a DIMM socket, please follow the steps below and refer to Figure 5-6.

  • Page 96: Cf Card Installation

    For the complete specifications of the supported CF cards please refer to Chapter 2. To install the a CF card (Type 1 or Type 2) onto the 3307810, please follow the steps below: Step 1: Locate the CF card socket. Place the 3307810 on an anti-static pad with the solder side facing up.

  • Page 97: Jumper Settings

    Figure 5-8: Jumper Locations plastic clip from a jumper. Before the 3307810 is installed in the system, the jumpers must be set in accordance with the desired configuration. The jumpers on the 3307810 are listed in Table 5-1. Page 99...

  • Page 98: Cf Card Setup

    3307810 Description Label Type CF card setup J_CF1 3-pin header Clear CMOS J_CMOS1 3-pin header LVDS voltage selection J_VLVDS1 3-pin header PCIe interface setup 2-pin header Table 5-1: Jumpers 5.4.1 CF Card Setup Jumper Label: J_CF1 Jumper Type: 3-pin header...

  • Page 99: Clear Cmos Jumper

    Jumper Location: See Figure 5-10 If the 3307810 fails to boot due to improper BIOS settings, the clear CMOS jumper clears the CMOS data and resets the system BIOS information. To do this, use the jumper cap to close pins 2 and 3 for a few seconds then reinstall the jumper clip back to pins 1 and 2.

  • Page 100: Figure 5-10: Clear Cmos Jumper

    3307810 Load Optimal Defaults Load Failsafe Defaults. After having done one of the above, save the changes and exit the CMOS Setup menu. The clear CMOS jumper settings are shown in Table 5-3. AT Power Select Description Short 1 - 2...

  • Page 101: Lvds Voltage Selection

    3307810 5.4.3 LVDS Voltage Selection WARNING: Permanent damage to the screen and 3307810 may occur if the wrong voltage is selected with this jumper. Please refer to the user guide that cam with the monitor to select the correct voltage.

  • Page 102: Pcie Interface Setup

    3307810 Figure 5-11: LVDS Voltage Selection Jumper Pinout Locations 5.4.4 PCIe Interface Setup Jumper Label: Jumper Type: 3-pin header Jumper Settings: See Table 5-5 Jumper Location: See Figure 5-12 The PCIe Interface Select jumper sets the PCIe bus as either PCIe x1 or PCIe x4. The PCIe Interface Select jumper settings are shown in Table 5-5.

  • Page 103: Chassis Installation

    The 3307810 must be installed in a chassis with ventilation holes on the sides allowing airflow to travel through the heat sink surface. In a system with an individual power supply unit, the cooling fan of a power supply can also help generate airflow through the board surface.

  • Page 104: Internal Peripheral Device Connections

    3307810 NOTE: GLOBAL AMERICAN INC. has a wide range of chassis available. Please refer to Chapter 2 in this manual or contact your 3307810 vendor, reseller or a Global American sales representative at salesinfo@globalamericaninc.com or visit the GLOBAL AMERICAN INC. website (http://www.globalamericaninc.com) to find out more about the available chassis.

  • Page 105: Ide Cable Connection

    3307810 5.6.2 IDE Cable Connection The IDE flat cable connects to the 3307810 to one or two IDE devices. To connect an IDE HDD to the 3307810 please follow the instructions below. Step 1: Locate the IDE connector. The location/s of the IDE device connector/s is/are shown in Chapter 3..

  • Page 106: Channel Audio Kit Installation

    Connect the audio kit cable. The audio kit is shipped with a cable that connects the audio kit to the 3307810. Connect the cable to the connector on the back of the audio kit. Make sure the pins are properly aligned (i.e. pin 1 connects to pin Step 2: Locate the audio connector.

  • Page 107: Channel Audio Kit Installation

    Step 4: Mount the audio kit onto the chassis. Once the audio kit is connected to the 3307810, secure the audio kit bracket to the system chassis. Step 5: Connect the audio devices. Connect one speaker to the line-in audio jack, one speaker to the line-out audio jack and a microphone to the mic-in audio jack.
  • Page 108 Connect the audio kit cable. The audio kit is shipped with a cable that connects the audio kit to the 3307810. Connect the cable to the connector on the back of the audio kit. Make sure the pins are properly aligned (i.e. pin 1 connects to pin Step 2: Locate the audio connector.

  • Page 109: Keyboard/Mouse Y-Cable Connector

    The 3307810 is shipped with a keyboard/mouse Y-cable connector. The keyboard/mouse Y-cable connector connects to a keyboard/mouse connector on the 3307810 and branches into two cables that are each connected to a PS/2 connector, one for a mouse and one for a keyboard.

  • Page 110: Parallel Port Cable Without Bracket

    3307810 Figure 5-16: Keyboard/mouse Y-cable Connection Step 4: Attach PS/2 connectors to the chassis. The keyboard/mouse Y-cable connector is connected to two PS/2 connectors. To secure the PS/2 connectors to the chassis please refer to the installation instructions that came with the chassis.

  • Page 111: Figure 5-17: Lpt Cable Connection

    Step 3: Insert the cable connectors. Once the cable connector is properly aligned with the 26-pin box-header connector on the 3307810, connect the cable connector to the onboard connector. See Figure 5-17. Figure 5-17: LPT Cable Connection Step 4: Attach the LPT connector to the chassis. To secure the LPT interface connector to the chassis please refer to the installation instructions that came with the chassis.

  • Page 112: Dual Rs-232 Cable With Slot Bracket

    3307810 Figure 5-18: Connect the LPT Device 5.6.7 Dual RS-232 Cable with Slot Bracket The dual RS-232 cable slot connector consists of two connectors attached to two independent cables. Each cable is then attached to a D-sub 9 male connector that is mounted onto a slot.

  • Page 113: Sata Drive Connection

    0: 5.6.8 SATA Drive Connection The 3307810 is shipped with two SATA drive cables and one SATA drive power cable. To connect the SATA drives to the connectors, please follow the steps below. Step 1: Locate the connectors.

  • Page 114: Figure 5-20: Sata Drive Cable Connection

    3307810 SATA cable and insert the cable connector into the onboard SATA drive connector. See Figure 5-20. Figure 5-20: SATA Drive Cable Connection Step 3: Connect the cable to the SATA disk. Connect the connector on the other end of the cable to the connector at the back of the SATA drive.

  • Page 115: Usb Cable (Dual Port) With Slot Bracket

    3307810 Figure 5-21: SATA Power Drive Connection 5.6.9 USB Cable (Dual Port) with Slot Bracket The 3307810 is shipped with a dual port USB 2.0 cable. To connect the USB cable connector, please follow the steps below. Step 1: Locate the connectors. The locations of the USB connectors are shown in Chapter 3.

  • Page 116: Figure 5-22: Dual Usb Cable Connection

    Step 3: Insert the cable connectors. Once the cable connectors are properly aligned with the USB connectors on the 3307810, connect the cable connectors to the onboard connectors. See Figure 5-22. Figure 5-22: Dual USB Cable Connection Step 4: Attach the bracket to the chassis. The USB 2.0 connectors are attached to a bracket.

  • Page 117: External Peripheral Interface Connection

    USB device VGA monitor To install these devices, connect the corresponding cable connector from the actual device to the corresponding 3307810 external peripheral interface connector making sure the pins are properly aligned. 5.7.1 LAN Connection (Single Connector) There are two external RJ-45 LAN connectors. The RJ-45 connectors enable connection to an external network.

  • Page 118: S-Video Cable Connection

    3307810 Figure 5-23: LAN Connection Step 3: Insert the LAN cable RJ-45 connector. Once aligned, gently insert the LAN cable RJ-45 connector into the onboard RJ-45 connector. Step 0: 5.7.2 S-video Cable Connection There is a single mini DIN TV out connector mounted on the CPU card as an external connector.

  • Page 119: Usb Device Connection (Single Connector)

    5.7.3 USB Device Connection (Single Connector) There are two external USB 2.0 connectors. Both connectors are perpendicular to the 3307810. To connect a USB 2.0 or USB 1.1 device, please follow the instructions below. Step 1: Located the USB connectors. The locations of the USB connectors are shown in Chapter 4.

  • Page 120: Vga Monitor Connection

    Step 0: 5.7.4 VGA Monitor Connection The 3307810 has a single female DB-15 connector on the external peripheral interface panel. The DB-15 connector is connected to a CRT or VGA monitor. To connect a monitor to the 3307810, please follow the instructions below.

  • Page 121: Figure 5-26: Vga Connector

    3307810 3307810. See Figure 5-26. Figure 5-26: VGA Connector Step 4: Secure the connector. Secure the DB-15 VGA connector from the VGA monitor to the external interface by tightening the two retention screws on either side of the connector. Step 0:...

  • Page 122: Adio Interface

    3307810 Appendix DIO Interface Page 124...

  • Page 123: Dio Interface Introduction

    3307810 A.1 DIO Interface Introduction The DIO connector on the 3307810 is interfaced to GIO ports on the iTE Super I/O chipset. The DIO has both 4-bit digital inputs and 4-bit digital outputs. The digital inputs and digital outputs are generally control signals that control the on/off circuit of external devices or TTL devices.

  • Page 124: Assembly Language Samples

    3307810 A.3 Assembly Language Samples A.3.1 Enable the DIO Input Function The BIOS interrupt call INT 15H controls the digital I/O. An assembly program to enable digital I/O input functions is listed below. AX, 6F08H Sets the digital port as input Initiates the INT 15H BIOS call A.3.2 Enable the DIO Output Function...
  • Page 125 3307810 THIS PAGE IS INTENTIONALLY LEFT BLANK Page 127...

  • Page 126: Bwatchdog Timer

    3307810 Appendix Watchdog Timer Page 128...
  • Page 127 NOTE: The following discussion applies to DOS environment. GLOBAL AMERICAN INC. support is contacted or the GLOBAL AMERICAN INC. website visited for specific drivers for more sophisticated operating systems, e.g., Windows and Linux. The Watchdog Timer is provided to ensure that standalone systems can always recover from catastrophic conditions that cause the CPU to crash.
  • Page 128 3307810 Page 130...

  • Page 129: Example Program

    3307810 NOTE: When exiting a program it is necessary to disable the Watchdog Timer, otherwise the system resets. Example program: ; INITIAL TIMER PERIOD COUNTER W_LOOP: AX, 6F02H ;setting the time-out value BL, 30 ;time-out value is 48 seconds ; ADD THE APPLICATION PROGRAM HERE EXIT_AP, 1 ;is the application over?
  • Page 130 3307810 THIS PAGE IS INTENTIONALLY LEFT BLANK Page 132...

  • Page 131: Caddress Mapping

    3307810 Appendix Address Mapping Page 133...

  • Page 132: Address Map

    3307810 C.1 Address Map I/O address Range Description 000-01F DMA Controller 020-021 Interrupt Controller 040-043 System time 060-06F Keyboard Controller 070-07F System CMOS/Real time Clock 080-09F DMA Controller 0A0-0A1 Interrupt Controller 0C0-0DF DMA Controller 0F0-0FF Numeric data processor 1F0-1F7 Primary IDE Channel...

  • Page 133: Irq Mapping Table

    3307810 C.3 IRQ Mapping Table IRQ0 System Timer IRQ8 RTC clock IRQ1 Keyboard IRQ9 ACPI IRQ2 Available IRQ10 IRQ3 COM2 IRQ11 LAN/USB2.0/SATA IRQ4 COM1 IRQ12 PS/2 mouse IRQ5 SMBus Controller IRQ13 IRQ6 IRQ14 Primary IDE IRQ7 Available IRQ15 Secondary IDE Table C-3: IRQ Mapping Table C.4 DMA Channel Assignments...
  • Page 134 3307810 THIS PAGE IS INTENTIONALLY LEFT BLANK Page 136...

  • Page 135: Dhazardous Materials Disclosure

    3307810 Appendix Hazardous Materials Disclosure Page 137...

  • Page 136: Hazardous Material Disclosure Table For Ipb Products Certified As Rohs Compliant Under 2002/95/Ec Without Mercury

    3307810 D.1 Hazardous Material Disclosure Table for IPB Products Certified as RoHS Compliant Under 2002/95/EC Without Mercury The details provided in this appendix are to ensure that the product is compliant with the Peoples Republic of China (China) RoHS standards. The table below acknowledges the presences of small quantities of certain materials in the product, and is applicable to China RoHS only.
  • Page 137 3307810 Part Name Toxic or Hazardous Substances and Elements Lead Mercury Cadmium Hexavalent Polybrominated Polybrominated (Pb) (Hg) (Cd) Chromium Biphenyls Diphenyl Ethers (CR(VI)) (PBB) (PBDE) Housing Display Printed Circuit Board Metal Fasteners Cable Assembly Fan Assembly Power Supply Assemblies Battery...
  • Page 138 3307810 RoHS RoHS ” ” ” ” (Pb) (Hg) (Cd) (CR(VI)) (PBB) (PBDE) SJ/T11363-2006 SJ/T11363-2006 Page 140...

  • Page 139: Eintel Matrix Storage Manager

    3307810 Appendix ® Intel Matrix Storage Manager Page 141...

  • Page 140: Introduction

    3307810 E.1 Introduction ® The Intel ICH7-M chipset can provide data protection for serial ATA (SATA) disks via the ® Intel Matrix Storage Manager using one of three fault-tolerant RAID levels: RAID 1, 5 or 10. When using two hard drives, matrix RAID allows RAID 0 and RAID 1 functions to be combined, where critical files can be stored on RAID 1, and RAID 0 can be used for non-critical items such as software.

  • Page 141: Features And Benefits

    3307810 CAUTION! Do not accidentally disconnect the SATA drive cables. Carefully route the cables within the chassis to avoid system down time. E.2 Features and Benefits Supports RAID levels 0, 1, 5 and 10 Supports connectivity to two or more disk drives...

  • Page 142: Raid Configuration

    3307810 Step 3: Save and Exit BIOS. After the SATA support option is enabled, save and exit the BIOS. Step 4: Reboot the system. Reboot the system after saving and exiting the BIOS. Step 5: Press Ctrl+I. During the system boot process, press Ctrl+I when prompted to enter the RAID configuration software.
  • Page 143 3307810 Step 1: Select “Create RAID Volume.” Use the arrow keys to highlight Create RAID Volume and press E . See Figure E-1. NTER Figure E-1: Matrix Storage Manager Main Menu Step 2: Name the RAID volume. Enter a name for the RAID volume, or press E NTER accept the default volume name.
  • Page 144 3307810 Step 3: Choose the RAID level. Select a RAID level from the list. RAID levels include RAID 0, 1, 5 and 10. See Figure E-3. NOTE: RAID 0 and RAID1 levels require a minimum of two hard drives. RAID 10 level requires a minimum of four hard drives.
  • Page 145 3307810 Step 4: Select the Stripe Size. Select a stripe size from the list. See Figure E-4. Figure E-4: Select the Stripe Size Step 5: Enter the Volume Capacity. Enter the volume capacity, or press E NTER accept the default capacity. See Figure E-5.
  • Page 146 3307810 Step 6: Create the RAID Volume. Press E to create the RAID volume as specified. NTER See Figure E-6. Figure E-6: Create the RAID Volume Step 7: Create RAID Volume Verification. After reading the warning, press Y to create the RAID volume as specified, or N to return to the Create RAID Volume menu.

  • Page 147: Deleting A Raid Volume

    3307810 E.4.2 Deleting a RAID Volume WARNING! All data stored on the member drives of a RAID volume are destroyed during the RAID deletion process. Make sure any data to be saved has been moved or backed up before deleting a RAID volume.
  • Page 148 3307810 Step 2: Select RAID Volume to be Deleted. Use the arrow keys to highlight the RAID volume to be deleted and press E . See Figure E-9. NTER Figure E-9: Select RAID Volume to be Deleted Step 3: Delete Volume Verification. After reading the warning, press Y to delete the specified RAID volume, or N to return to the Delete Volume menu.

  • Page 149: Resetting A Disk To Non-Raid

    3307810 Step 4: Non-RAID Disks. After deleting the RAID volume, the disks belonging to the volume will be shown as non-RAID disks. See Figure E-11. Step 0: Figure E-11: Non-RAID Disks E.4.3 Resetting a Disk to Non-RAID WARNING! All data stored on the disk drive of a RAID volume is destroyed when resetting it to non-RAID.
  • Page 150 3307810 Step 1: Select “Reset Disk to Non-RAID.” Use the arrow keys to highlight Reset Disk to Non-RAID and press E . See Figure E-12. NTER Figure E-12: Reset Disk to Non-RAID Menu Step 2: Select Disks to Reset. Use the arrow keys to scroll through the disk drives and press S to select which drives are to be reset as non-RAID.
  • Page 151 3307810 Step 3: Reset Disk Verification. After reading the warning, press Y to reset the selected disks as non-RAID, or N to return to the Reset RAID Data menu. See Figure E-14. Figure E-14: Reset Disk Verification Step 4: Disk Drive and RAID Volume Status. After the disk drives have been reset, the Matrix Storage Manager Main menu is shown indicating the status of the RAID volumes and disk drives.

  • Page 152: Exiting The Matrix Storage Manager

    3307810 E.4.4 Exiting the Matrix Storage Manager Step 1: Select “Exit.” Use the arrow keys to highlight Exit and press E NTER See Figure E-16. Figure E-16: Exit Menu Step 2: Exit Verification. Press Y to exit the Matrix Storage Manager, or N to return to the Main menu.
  • Page 153 Any advice or comments about our products and service, or anything we can help you with please don’t hesitate to contact with us. We will do our best to support your products, projects and business. Address: Global American, Inc. 17 Hampshire Drive Hudson, NH 03051 Telephone: Toll Free (U.S. Only) 800-833-8999...
