Pin outs

• VGA
STANDARD VGA
1- Red 6- Red Return
2- Green 7- Green Return
3- Blue 8- Blue Return
4- ID Bit 2 9- No Pin
5- Test (Gnd) 10- Sync Return
• DIGITAL VISUAL INTERFACE DVI
Pin
1- TMDS Data 2-
2- TMDS Data 2+
3- TMDS Data 2 Shield 9- TMDS Data 1-
4- Not used 10- TMDS Data 1+
5- Not used 11- TMDS Data 1 Shield
6- DDC Clock 12- Not used
C1- Analog Red Video (or Cr/Pr or C)
C2- Analog Green Video (or Y or Composite Video)
C3- Analog Blue Video (or Cb/Pb)
C4- Analog Horizontal Sync (or Composite Sync)
C5- Analog Common Ground Return
DDC = Display Data Channel
TMDS = Transition Minimized differential signal
• RS-232 CONNECTOR
Pin
1- NC
2- Transmit data to PC (Tx1)
3- Transmit data from PC (Rx1)
4- Receive data from display unit (Rx2)
5- Ground
• S-VIDEO (Y/C) CONNECTOR - 4-pin Mini Din
Pin
1- Y Ground
2- C Ground
3- Y Signal
4- C Signal
• VESA DDC
Pin
1- Red 7- Green Return
2- Green 8- Blue Return
3- Blue 9- DDC+5 Volt supply
4- ID Bit 2 0 10- Sync Return
5- Test 11- ID Bit
6- Red Return 12- Bi-directional data (SDA)
7- DDC Data
8- Analog Vertical Sync
6- NC
7- NC
8- NC (or +12V. dc)
9- Transmit data to display unit (Tx2)
11- ID Bit 0
12- ID Bit 1
13- H Sync
14- V Sync
15- ID Bit 3
13- Not used
14- +5V (Power)
15- Ground for (+5V)
16- Hot Plug Detect.
17- TMDS Data 0-
18- TMDS Data 0+
13- H Sync
14- V Sync
15- Data Clock (SCL)
19- TMDS Data 0 Shield
20- Not used
21- Not used
22- TMDS Clock Shield
23- TMDS Clock +
24- TMDS Clock-
