Analog way smx200 Quick Start Manual

QUICK START GUIDE
Thank you for choosing Analog Way
and use your powerful 12x2 Scaled Matrix with Native Hi-Res. within minutes. Discover the
capabilities and intuitive interface while configuring your first show, and unleash your creativity for a new experience in
show and event management by
What's in the box
1 x Smart MatriX (SMX200)
1 x Power supply cord
2 x DVI male to HD15 female and DVI-D female breakout cable
1 x HD15 to 5 BNC cable
1 x Ethernet cross cable (for device update)
1 x Set of 11 audio 5 pin screw terminals
4 x Screws (M4x12mm)
1 x RCS - Remote Control Software CD-ROM (PC only) *
1 x Quick Start Guide (PDF version) *
1 x User Manual (PDF version) *
* Download on our website:
Quick install and setup
Key points:
DSK function uses a layer
Frame and Logo are unscaled sources
One logo available in Native Matrix Mode per output
BLACK button allows to remove Layer (Clear function)
(use an external Analog Way Controller).
SMX200 can be used to display:
- Sources seamlessly switched in the Background Live
layer
- 1 PIP on Background Live + 1 Logo / per output
- 2 PIPs on Background Frame + 1 Logo / per output
- No preview
Getting Started:
You may wish to reset the unit to factory settings to get
started. Go to Menu - > Control - > Default Values - > Yes.
1. Select the Output #1 and #2 resolution that matches
the native resolution of your display. You will next be
prompted to choose enable follow mode if desired and
the output rate.
2.  I nputs can be configured automatically using the
AutoSet All function.
Menu - > Inputs - > AutoSet
and the Smart MatriX. By following these simple steps, you will be able to setup
Analog Way.
www.analogway.com
All.
Smart MatriX - SMX200
WARNING !
If required, front handles of the device can be dismantled,
but with caution.
The original screws removed must not be reintroduced to
their location without handles in place.
Substantial damages can occur, including risk of elec-
tric shock from the mains voltage.
Only M4x12mm screws can be used.
(They are supplied with the unit)
It will scan each input and detect the sync type that is
plugged in. You can still do an Autoset or Manual setup
per input.
The advanced Features of SMX200 are available by the
external remote control as:
- Orchestra – Ref. ORC50
- Axion2 – Ref. ARC200
- Remote Control Software – Ref. RCS (supplied)
- Triple Remote Control Keypad – Ref. TRK-800
- Remote Control Keypad – Ref. RK-300.
The Smart Matrix has 4 layers available called:
[BACKGROUND FRAME],
[PIP2] and [LOGO1].
Each output can display the following Layers Hierarchy.
Logo1
Live PIP 2
Live Background/PIP 1
Background Frame
IMPORTANT: simply selecting a menu item will not
set it to that value. Be sure to press the ENTER
button when parametering the menu items.
Smart MatriX extensive
[BACKGROUND LIVE/PIP1],
