QUICK START
Thank you for choosing
Analog Way
and use your powerful Multi Layer Hi-Res. Mixer Seamless Switcher within minutes. Discover the
capabilities and intuitive interface while configuring your first show, and unleash your creativity for a new experience in
show and event management by
What's in the box
1 x
Eikos
(Ref. EKS500)
1 x Power supply cord
2 x DVI male to HD15 female and DVI-D female breakout cable
1 x HD15 to 5 BNC cable
1 x Ethernet cross cable (for device update)
1 x Set of 11 audio 5 pin screw terminals
1 x Quick Start guide *
1 x User Manual *
1x RCS - Remote Control Software (PC only) *
* Download on our website:
Quick install and setup
Getting started:
You may wish to reset the unit to factory settings to get started.
Go to:
Menu -- > Control -- > Default Values -- >
1.
Select the Output resolution that matches the native
resolution of your display. You will next be prompted to
choose enable follow mode if desired and output rate.
Menu -- > Output -- > Output format -- > 1024x768 -- >
Internal Ref -- > 60
Hz.
2.
 I nputscanbeconfiguredautomaticallyusingtheAuto Set
All function.
Menu -- > Intputs -- > AutoSet All -- >
It will scan each input and detect the sync type that is
plugged in. You can still do an Autoset or manual setup
per input.
The Eikos has 6 (up to 7 in Quadravision Mode) layers
available called:
[BACKGROUND
LIVE], up to 3x
[PIP]
in Quadravision Mode and 2x [LOGO].
Each layer will obscure your view other layers below.
3. To display a source, select the
layer (it will begin to blink) then, select a source (it will
also blink). Press
[TAKE]
preview to program output.
There will always be a layer selected (blinking) and a source
selected (blinking) to the selected layer (blinking). To view on
preview or change the contents of a different layer, simply
select it. Only 1 layer can be seen on the preview at a time.
and the Eikos. By following these simple steps, you should be able to setup
Analog
Way.
www.analogway.com
Yes.
Yes.
FRAME],
[BACKGROUND
[BACKGROUND LIVE]
to transition your source from
WARNING !
If required, front handles of the device can be dismantled,
but with caution.
The original screws removed must not be reintroduced to
their location without handles in place.
Substantial damages can occur, including risk of elec-
tric shock from the mains voltage.
Only M4x12mm screws can be used.
(They are supplied with the unit)
4. To display a PIP, select the PIP layer (it will begin to blink)
then select your source (it will also blink). Press
display the PIP on program output.
To see the layer beneath, you will need to clear or move the
layers that are on top.
5. To clear the PIP or any other layer, select the layer (it will
blink) then, select [BLACK]. Press
layer from the program output.
*TIP*
If you would like the Program and Preview to toggle/
flipflop during each Take, enable this feature by going to
Menu -- > Control -- > Preset
Once enabled, everything on the Program output will become
the Preview during each Take.
6. To display a logo or frame (framestore) follow the steps
on page 4.
See the next page which describes the button lighting color
code and other front panel features.
Eikos can be used to display (in Mixer Mode):
- sources seamlessly switched in the Background Live layer.
- 2 PIPs and 2 Logos over the Background Live layer.
- 3 PIPs and 2 Logos over a Background Frame by resizing the
Background Live
layer.
IMPORTANT:
Simply selecting a menu item will not set it to
that value. Be sure to press the ENTER button when para-
metering the menu items.
Eikos - EKS500
Eikos
extensive
[TAKE]
[TAKE]
to remove the
Toggle.
to
