8 SPECIFICATIONS
The following specifications are divided into sections corresponding to the carious
functional blacks within the receiver.
Receiver Interface Specification
8.1
Status LEDs
Monitor and Control Interface
Web Interface
Mechanical/Electrical Specification
8.2
Dimensions
Mounting
Weight
Input Voltage
Power Consumption
Environmental Specifications
8.3
The power supply will be a 65W universal input switching power supply that is UL
safety rated. We expect the system to operate without a need for a fan in air conditioned
locations. The fan will be electronically controlled via temperature sensor. This will
allow the unit to operate under less than optimal conditions.
8.4 M&C Interface Connector
The Monitor and Control (M&C) port allows basic configuration of the XDS receiver via
an asynchronous RS232C electrical interface. It uses the following protocol settings:
115.2K baud, 8 data bits, No Parity, 1 stop bits, and no hardware flow control. In addition
to the asynchronous interface, the M&C connector provides a status relay output and four
optical inputs. The four optical inputs are activated grounding the input signal. The
following table provides the pin-out for the M&C port.
PIN
1
power, signal, update, and fault indications
RS-232C compatible, DB-9 female
automatically broadcast via LAN
Table 5. Interface Specifications
3.5" x 18" x 12"
19", 2RU
8 lbs
90 – 240 VAC (50/60 Hz)
65 W maximum
Table 6. Mechanical and Electrical Specifications
FUNCTION
ALARM -
