- Page 1 Wireless Multi-Format input Transmitter to HDMI Receiver Box ID # 718 Operation Manual...
-
Page 2: System Requirements
Introduction The wireless HDMI transmitter and receiver boxes use baseband technology with Wireless High Definition Interface (WHDI) to deliver uncompressed HD audio and video. It can transmit within a distance of 20 meters while maintaining superb, wired equivalent quality and reliability with little to no lag. - Page 3 Operating Controls Transmitter Front Panel The following sections describe the hardware components of the unit with installation guide and setting methods. ① IR sensor ② 480i → 480p / 576i → 576p LED indicator and INPUT -I P/5SEC button: Press this button to select the input source from COMP1 to PC or press for 5 seconds to switch between interlace and progressive format, yellow LED light will turn...
- Page 4 • Broadcast mode is not HDCP compliant. • Only supports single transmitter link with multiple receivers. ⑥ Power: The LED will illuminate when power is on. Rear Panel ① Component inputs: These slots are for connecting the component and R/L output ports of your source equipments such as DVD player or set-top-box with component video and R/L cables.
- Page 5 Receiver Front Panel ① Link LED: When the system is in search mode the LED will flash repeatedly and when the system is in signal linking mode it will slowly flash. When the LED is on and no longer flashing it means a connection has been established and audio/ video can then be sent.
- Page 6 Rear Panel ① HDMI output: This slot is to connect the HDMI cable to the HDMI input of your display. ② Power: Plug in the 5V DC power supply included in the package and connect the adaptor to an AC outlet.
-
Page 7: Connection And Installation
IR Cable Pin Definitions Note: The frequency on both IR Receiver & Blaster can support 36~387KHz with NEC code. Remote Control ① PC: Press this button to select PC input. ② Format selection: Press this button to switch between Interlace and Progressive format. ③... - Page 8 Broadcast Mode Remote Control distance...
- Page 9 Input Signal Specifications PC Resolution Vert Rate 640x480 60/72Hz SVGA 800x600 56/60/72Hz 1024x768 60/70Hz HDTV Resolutions Vert Rate 480p 720x480 60Hz 480i 720x480 60Hz 576p 720x576 50Hz 576i 720x576 50Hz 720p 1280x720 50, 60Hz 1080i 1920x1080 50, 60Hz 1080p 1920x1080 24, 30fps Output Signal Specifications...
- Page 10 Specifications Radio Power Transmit power is configurable up to 63mW (+18dBm) Video Resolutions 480i/p, 576i/p, 720p, 1080i, VGA@60/72Hz, SVGA@56/60/72Hz, XGA@60/70Hz and 1080p@24/30fps Frequencies Supported 4.9 ~ 5.9GHz Modulation MIMO OFDM with WHDI video-modem technology Bandwidth 18MHz Wireless Range 20 meters open field Antenna Transmitter: 4 transmit antennas and 2 receive antenna...
