Summary of Contents for Converters.TV 15493
- Page 1 DMI over CAT Cable Receiver w/ 48V PoH - # 15493 Operation Manual...
- Page 2 Introduction This HDBaseT 2.0 Receiver can receive uncompressed UHD video and audio that has been transmitted over a single Cat.5e/6/7 cable up to 100m. It has the added benefit of extending control and communication signals through the built-in Ethernet, USB, RS-232 and IR ports. Independent external digital and analog audio transmission capability gives users the extra convenience of additional audio connections.
-
Page 3: Audio Out
System Requirements • HDMI input source equipment such as media players, video game consoles, PCs or set-top boxes. • HDMI receiving equipment such as HDTVs, monitors or audio amplifiers. • The use of “Premium High Speed HDMI” cables is highly recommended. •... - Page 4 Side Panels 1. LAN: Connect to an Ethernet supporting device or to your local network as appropriate. The yellow LED will illuminate to indicate a successful LAN connection between the Transmitter and Receiver and will blink to indicate a data transmission. The green LED will illuminate when the connected Ethernet speed is 100Mbit/s.
- Page 5 IR Cable Pin Assignment Specifications Video Bandwidth 340MHz/10.2Gbps Input Ports 1×Cat.5e/6/7, 1×Optical Audio (TOSLINK), 1×IR Extender (3.5mm) Output Ports 1×HDMI, 2×USB 2.0 (Type A), 1×Stereo Audio (Terminal Block), 1×LAN (RJ45), 1×IR Blaster (3.5mm),1×RS-232 (Terminal Block) Supported Resolutions 480i@60Hz - 4K@60Hz (4:2:0, 8-bit) VGA@60Hz - WUXGA@60Hz (RB) HDMI Cable Length 10m (1080p@60Hz, 12-bit)
- Page 6 Connection Diagram...
