- Page 1 HDBaseT HDMI over CAT cable Receiver Scaler with LAN/RS-232/IR/Bidirectional PoE - ID# 15225 Operation Manual...
- Page 2 Introduction The HDBaseT HDMI over CAT cable Receiver Scaler with LAN/RS- 232/IR/Bidirectional PoE is an HDBaseT™ Receiver Scaler designed to scale the incoming video signal first, before outputting to its HDMI port. There is an Optical port providing additional audio extraction feature. Besides video and audio from the Transmitter, it also takes in 2-way IR, RS- 232 and bidirectional LAN serving, over a single run of CAT5e/6/7 cable at a distance up to 100 meters.
- Page 3 Operation Controls and Functions Front Panel SERVICE: Reserved for manufacturer use only. IR RECEIVER WINDOW: Receives only the IR signal from the supplied remote control OPTICAL OUT: Connect to an amplifier or active speakers with an optical cable. HDMI OUT: Connect to an HDMI TV/Monitor MENU: Press this button to enter the On-Screen Display (OSD)
-
Page 4: Power Led
Back Panel POWER LED: This LED will illuminate when the device is connected to an active power supply. DC 24V: Connect the 24V DC power supply to the unit and plug the adaptor into an AC outlet. Only one unit requires powering if both the Transmitter and Receiver are both PoE compatible. -
Page 5: Auto Adjust
Remote Control INPUT: Press this button to toggle between the CV or PC input. 2. EXIT: Press this button to exit the menu or the current selection in the on-screen menu. 3. MENU: Press this button to enter into the OSD menu. - Page 6 RS-232 Protocols DEFINITION DEFINITION ← → Baud Rate: 9600bps Data Bit: 8 bits Parity: None Flow Control: None Stop Bit: 1 RS-232 & Telnet Commands Command Description S OUTPUT 0~25 0=Native 12=1600×1200 1=640×480 13=1920×1080 2=800×600 16=1920×1200 3=1024×768 17=480p 5=1360×768 18=720p@60 6=1280×720 19=1080p@60 7=1280×800...
- Page 7 S CONTRAST 0~60 Sets the numerical value for the CONTRAST setting (0~60) R CONTRAST Reports the numerical value for the CONTRAST setting (0~60) S BRIGHTNESS 0~60 Sets the numerical value for the BRIGHTNESS setting (0~60) R BRIGHTNESS Reports the numerical value for the BRIGHTNESS setting (0~60) S HUE 0~60 Sets the numerical value for the HUE setting...
- Page 8 3. Resolutions 1~16 are RGB encoded and 17~25 are YUV encoded Digital audio supports LPCM 2CH only, please ensure the source input audio is set to send LPCM 2CH audio in order to avoid unwanted audio noise. OSD Menu Layer Layer Layer Display...
- Page 9 Under1 Under 2 Mode Info Info Colour R Offset G Offset B Offset Contrast 0~60 Brightness 0~60 0~600~60 Saturation 0~60 Sharpness 0~60 Middle High Audio Volume 0~100 Delay 40ms 110ms 150ms Sound Mute Setup Factory Reset Key Lock Information Input Output...
- Page 10 Revision Note: Items in Bold are the default settings Input Resolutions Support Input Resolution HDMI 480i/576i √ 480p/576p √ 720p@50/60 Hz √ 1080i@50/60 Hz √ 1080p@50/60 Hz √ VGA@60/72/75 Hz √ SVGA@56/60/72/75 Hz √ XGA@60/70/75 Hz √ SXGA@60/75 Hz √ UXGA@60 Hz √...
- Page 11 Specifications Ethernet Speed 100 Mbps Input Video Bandwidth 300MHz / 10.2Gbps Output Video Bandwidth 165MHz / 1.65Gbps Input Ports 1×CAT5e/6/7, 1×IR Extender Output Ports 1×HDMI, 1×IR Blaster, 1×Optical, 1×RS-232, 1×LAN CAT5e/6/7 Output Cable Up to 100 Meters Distance HDMI Resolutions Support HD: Up to 1080p@60 Hz PC: Up to WUXGA (RB) Audio Sampling Rate...
- Page 12 Connection Diagram...
