- Page 1 HDBaseT Dual HDMI Output over Single CAT5e/6/7 Receiver - ID# 15317 Operation Manual...
- Page 2 Introduction The HDMI over CAT5e/6/7 Receiver is designed to receive an HDBaseT™ signal from a compatible transmitter or matrix unit. It features full 5Play™ convergence allowing the transmission of video, Audio, Control (IR/RS-232), Power over Ethernet (PoE) and LAN serving over a single CAT5e/6/7 cable up to 100m.This unit features a simultaneous dual HDMI output allowing the...
- Page 3 Operation Controls and Functions Front Panel 1. HDMI OUT 1/2: Connect each of the HDMI outputs to an HDMI display for simultaneous HDMI distribution, or cascade the output to another transmitter to extend the operating distance. The unit will read the EDID settings of the display device connected to HDMI OUT 1.
- Page 4 Back Panel 1. POWER LED: This LED will illuminate when the device is connected to a power supply. 2. DC 24V: Connect the 24V DC power supply to the receiver and plug the adaptor into an AC outlet. This unit can also supply power to a compatible transmitter unit Note: The power supply is not required when using Power over Ethernet (PoE) from a compatible transmitter.
- Page 5 IR Pin Assignment RS-232 Cable Pin Definitions DEFINITION TxD/RxD RxD/TxD...
- Page 6 Connection Diagram...
- Page 7 Specifications Video Bandwidth 340Mbps/10.2Gbps Input Ports 1×CAT5e/6/7, 1×LAN, 1×IR Extender, 1×USB Mini-B (Service only) Output Ports 2×HDMI, 1×IR Blaster, 1×RS-232 CAT5e/6/7 Cable Distances Up to 100 meters HDMI Cable Distances Up to 10 meters@1080p/8-bit or 12-bit HDMI Resolutions Up to 4K2K (3840×2160@30Hz/4096×2160@24Hz) IR Frequency 30~50kHz...
