- Page 1 HDMI Video Receiver over Cat5 Cable - 50m # 539 Operation Manual...
- Page 2 Introduction HDMI Video Receiver over Cat5 Cable - 50m is the receiver (Rx) unit of HDMI Video HDMI over CAT5 Tx/Rx solution, works with ID #542: Transmitter over Cat5 Cable - 50m to 250m (the transmitter), can extend HDMI signal through CAT-5 cables for a distance up to 50 meters. The...
- Page 3 1. DDC INPUT: Connect the DDC input to the DDC output of the transmitter unit using CAT-5/CAT-5E/CAT-6 cable. Note: For advanced user only, if it's known that the DDC or HDCP data are not required for the source and the display, you can use a single CAT-5 cable for the VIDEO connection only.
- Page 4 Connection and Installation ID #542 ID # 539...
