- Page 1 HDMI v1.3 to CAT6 Transmitter Receiver ID #748 & ID#749 & Operation Manual...
- Page 2 Introduction The HDMI 1.3 transmitter and receiver over CAT6 is an extension tool for your long distance HDMI display needs. Instead of using expensive HDMI cables, your existing CAT6 cables/sockets can replace HDMI cables while performing the same functions like transfer Deep Color (12 bits/color) video and new lossless compressed (Dolby TrueHD, Dolby Digital Plus and DTS-HD Master Audio) Digital audio, at a bandwidth of up to 225MHz.
- Page 3 Operating Functions and Controls Front Panel 1. IR Transmitter: This slot is where you connect the IR blaster cable and place the IR eye in front of the source equipment(s) for sending the IR signal to the source equipment(s), The IR blaster accepts the frequency range from 20KHz to 60KHz.
- Page 4 Figures provided in this manual are reference figures only, actual figures may depend on source and display use with cable specification. Connectors Pin Definition IR IN Pin Definition Assignment Power 5V IR Signal IR OUT Pin Definition Assignment Power 5V Power 5V IR Blaster Signal RJ-45 Pin Definition...
- Page 5 Installation Input Connection Specifications Transmitter 1 x HDMI 1 x IR Blaster 1 x CAT-6 Input Video 1 x CAT-6 Input DDC Receiver 1 x HDMI 1 x Receiver 1 x CAT-6 output for Video, 1 x CAT-6 output for DDC HDMI Input Cable 1080p 8-bit (15M), 12-bit (15M) HDMI Output Cable...
