- Page 1 CAT6 to HDMI v1.3 Transmitter and Receiver - ID# 15183 Operation Manual...
- Page 2 Introduction This HDMI over CAT5e/6 Transmitter and Receiver Set with IR Source Control can extend HDMI signals over dual CAT5e/6 cabling up to 45m. It has the added benefit of allowing the control of a source device with your existing Remote Control with the included IR Extender and Blaster cables. Features HDMI, HDCP 1.1 and DVI 1.0 compliant •...
- Page 3 Operation Controls and Functions Transmitter Front and Rear Panels IR TRANSMITTER Connect to the supplied IR blaster cable for IR signal transmission. Place the IR blaster in direct line of sight of the equipment to be controlled. HDMI INPUT Connect to an HDMI source such as a DVD or Blu-ray player. POWER 5V Connect the 5 V DC power supply to the unit and plug the adaptor...
- Page 4 VIDEO INPUT Connect the video output of the transmitter to the video input of the receiver using a CAT5e/6 cable. DDC INPUT Connect the DDC output of the transmitter to the DDC input of the receiver using a CAT5e/6 cable. POWER 5V Plug the 5 V DC power supply into the unit and connect the...
- Page 5 RJ-45 Pin Definition VIDEO TMDS2+ TMDS2- TMDS1+ TMDS1- Power 5V TMDS0+ TMDS0- TMDSC+ TMDSC- Specifications Transmitter 1×HDMI, 1×IR Blaster, 1×CAT5e/6 Output Video, 1×CAT5e/6 Output DDC Receiver 1×HDMI, 1×IR Extender, 1×CAT5e/6 Input Video, 1×CAT5e/6 Input DDC HDMI Input Cable 1080p/8-bit (6 m) HDMI Output Cable 1080p/8-bit (10 m) CAT5e/6 Cable...
- Page 6 Connection Diagram...
- Page 7 Input Connection Examples...
- Page 8 Output Connection Examples Compatible Products The models (Daul CAT5e/6) listed below are compatible with each other: #733, #743, #744, #745, #748, #749, #761, #787 #874 and #995,...
