2.1.5. Bookmark Cameras
Serves for defining IP cameras you want to check by means of Application.
HTTP and RTSP ports are only entered if your IP cameras are configured for access from external
network.
All cameras by Axis manufacturer with V2 and V3 protocol are supported, further we support the below
listed types of cameras:
AirLive-WL2600, AirLive AirCam OD-600HD, AirLive AirCam OD-325HD, Planet ICA-M220, ACTi-
ACM, and the following types by company Vivotek: FD-8134, FD-7132, PZ-7132.
Select any camera name
Verze 02‐ 039/2011 Rev.:091013 Stránka 10 z 31
Connection Server Installation Manual
Camera IP address
User name for access to camera
Access password for camera
HTTP port
RTSP port
Camera type
List of already defined cameras
