8. Once the file export-pub is created and uploaded to iMM server, in bookmark Energy you
can assign in the counter value line (electricity_VALUE). It must be VALUE in the line.
Connection of energy meter
Energy meter connects by means of a binary output unit. Output from supported energy meter is
distinguished to + a -, that's why polarity has to be maintained by bringing – minus to GND terminal
and + plus to IN terminal. See 3.1.7. for settings.
Creation of counter:
Bookmark
Counters
Bookmark
System
Verze 02‐ 039/2011 Rev.:091013 Stránka 16 z 31
Connection Server Installation Manual
Addition of further
counters
Naming of
counter
