Front Unit; Pa Unit; Dial Unit - Icom IC-A200 Service Manual

[DIAL UNIT]

REF ORDER
NO. NO.
S3001 2260001620 SW SW-133 (RK09720HM)

[FRONT UNIT]

REF ORDER
NO. NO.
R4003 7310000650 TRI RH0621CN3J0SA
DS4001 5030000731 LCD FSD-10394AAH-1
DS4002 5080000260 LMP HRS-7152A=L21
DS4003 5080000260 LMP HRS-7152A=L21
DS4004 5080000260 LMP HRS-7152A=L21
DS4005 5080000260 LMP HRS-7152A=L21
DS4006 5080000260 LMP HRS-7152A=L21
DS4007 5080000260 LMP HRS-7152A=L21
EP4002 8930023170 LCT SRCN-867W

[PA UNIT]

REF ORDER
NO. NO.
Q5002 1540000650 TR 2SD1858TV2 R
Q5003 1530000791 TR 2SC1971-01
Q5004 1540000650 TR 2SD1858TV2 R
Q5005 1530002950 TR 2SC1946A
D5001 1790000720 DIO MA29W-B
D5002 1790000720 DIO MA29W-B
D5003 1790001780 DIO MA700
D5004 1790001780 DIO MA700
D5005 1790001780 DIO MA700
D5006 1790001780 DIO MA700
D5007 1710001081 DIO L308CCB
D5008 1710001081 DIO L308CCB
D5009 1710001081 DIO L308CCB
L5001 2040000490 COL EXC-ELDR25C
L5002 2040000490 COL EXC-ELDR25C
L5003 6180000730 COL LAL 03NA R47M
L5004 6180000810 COL LAL 03NA 2R2M
L5005 6110001990 COL LA-223
L5006 6140002450 COL LR-283
L5008 6180000810 COL LAL 03NA 2R2M
L5009 6910000670 COL BL01RN1A1D2B (BL01RN1-A62)
L5010 6110002620 COL LA-458
L5011 6180000840 COL LAL 03NA 3R9K
L5013 6110001680 COL LA-254
L5014 6110001740 COL LA-263
L5015 6110001740 COL LA-263
L5016 6110001670 COL LA-253
L5017 6110001550 COL LA-235
L5018 6110001550 COL LA-235
L5019 6140002220 COL LR-270 (TR6X3X2 3A9)
L5020 2040000490 COL EXC-ELDR25C
L5021 6110001540 COL LA-234
L5022 6110001550 COL LA-235
L5023 6110001550 COL LA-235
R5001 7010004190 RES R20J 1 k
R5002 7010004250 RES R20J 3.3 k
R5003 7010004110 RES R20J 220
R5004 7010003990 RES R20J 22
R5005 7310000640 TRI RH0621CJ3J1GA
R5006 7010004030 RES R20J 47
R5007 7310000640 TRI RH0621CJ3J1GA
R5008 7010001030 RES R25XJ 100
R5010 7010004270 RES R20J 4.7 k
R5011 7010004270 RES R20J 4.7 k
R5012 7010004270 RES R20J 4.7 k
R5013 7010004270 RES R20J 4.7 k
R5014 7010004270 RES R20J 4.7 k
R5015 7010004270 RES R20J 4.7 k
R5018 7010004130 RES R20J 330
R5019 7010004130 RES R20J 330
DESCRIPTION
DESCRIPTION
DESCRIPTION
[PA UNIT]
REF ORDER
NO. NO.
R5021 7010004070 RES
R5022 7010004110 RES
R5023 7010004070 RES
R5024 7070000210 RES
C5001 4010006280 CER
C5002 4010006060 CER
C5004 4010006880 CER
C5008 4010006330 CER
C5009 4010006900 CER
C5010 4010006210 CER
C5011 4010006230 CER
C5012 4010006170 CER
C5015 4010006290 CER
C5016 4010000410 CER
C5018 4010006880 CER
C5021 4010006900 CER
C5022 4010006290 CER
C5023 4010006230 CER
C5024 4010006280 CER
C5025 4010006250 CER
C5026 4010006130 CER
C5027 4010006290 CER
C5028 4010006230 CER
C5030 4010006880 CER
C5032 4010006290 CER
C5033 4010006900 CER
C5034 4010006290 CER
C5035 4010006290 CER
C5036 4010006330 CER
C5037 4010006900 CER
C5038 4510005500 ELE
C5039 4010006880 CER
C5040 4010006330 CER
C5041 4010006110 CER
C5042 4010006880 CER
C5043 4010006880 CER
C5044 4010006330 CER
C5045 4010006180 CER
C5046 4010006080 CER
C5047 4010006070 CER
C5048 4010006130 CER
C5049 4010006880 CER
C5053 4010006880 CER
C5054 4010006100 CER
C5055 4010006190 CER
C5056 4010006170 CER
C5057 4010006100 CER
C5058 4010006100 CER
C5059 4610001580 TRI
C5060 4010006290 CER
C5061 4010006290 CER
C5062 4010006900 CER
C5063 4010006330 CER
C5064 4010006900 CER
C5065 4010006330 CER
C5066 4010006060 CER
C5067 4010006290 CER
C5068 4510004600 ELE
C5070 4510005090 ELE
C5071 4010006130 CER
C5072 4010006240 CER
C5073 4010006130 CER
C5074 4010006290 CER
C5075 4010006210 CER
C5076 4010006880 CER
W5010 7120000490 JMP
EP5002 9036505001 TUB
EP5003 9036505001 TUB
EP5004 6910000600 BEA
EP5005 6910000600 BEA
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
8 -5
DESCRIPTION
R20J 100
R20J 220
R20J 100
CRH100X R-02J 47
HE50SJ SL 101J 50V
HE40SJ SL 100D 50V
HE50SJ YB 102K 50V
HE70SJ SL 221J 50V
HE80SJ YB 472K 50V
HE40SJ SL 470J 50V
HE40SJ SL 560J 50V
HE40SJ SL 330J 50V
HE50SJ SL 121J 50V
DD107 SL 331J 50V
HE50SJ YB 102K 50V
HE80SJ YB 472K 50V
HE50SJ SL 121J 50V
HE40SJ SL 560J 50V
HE50SJ SL 101J 50V
HE40SJ SL 680J 50V
HE40SJ SL 220J 50V
HE50SJ SL 121J 50V
HE40SJ SL 560J 50V
HE50SJ YB 102K 50V
HE50SJ SL 121J 50V
HE80SJ YB 472K 50V
HE50SJ SL 121J 50V
HE50SJ SL 121J 50V
HE70SJ SL 221J 50V
HE80SJ YB 472K 50V
16 ME 10 HC
HE50SJ YB 102K 50V
HE70SJ SL 221J 50V
HE40SJ SL 180J 50V
HE50SJ YB 102K 50V
HE50SJ YB 102K 50V
HE70SJ SL 221J 50V
HE40SJ SL 360J 50V
HE40SJ SL 120J 50V
HE40SJ SL 110J 50V
HE40SJ SL 220J 50V
HE50SJ YB 102K 50V
HE50SJ YB 102K 50V
HE40SJ SL 150J 50V
HE40SJ SL 390J 50V
HE40SJ SL 330J 50V
HE40SJ SL 150J 50V
HE40SJ SL 150J 50V
CVD30-41 30P
HE50SJ SL 121J 50V
HE50SJ SL 121J 50V
HE80SJ YB 472K 50V
HE70SJ SL 221J 50V
HE80SJ YB 472K 50V
HE70SJ SL 221J 50V
HE40SJ SL 100D 50V
HE50SJ SL 121J 50V
16 MV 1000 HC
6.3 ME 470 HC
HE40SJ SL 220J 50V
HE40SJ SL 620J 50V
HE40SJ SL 220J 50V
HE50SJ SL 121J 50V
HE40SJ SL 470J 50V
HE50SJ YB 102K 50V
ERD25T0
IRRAX 0.7 (d) L=15 mm
IRRAX 0.7 (d) L=15 mm
FSRH050050RN000B (FSOH050RN)
FSRH050050RN000B (FSOH050RN)
S.=Surface mount
