Icom IC-A200 Service Manual page 24

[MAIN UNIT]
REF ORDER
NO. NO.
R369 7030003610 S.RES 27K ERJ3GE
R370 7030003440 S.RES 1K ERJ3GE
R371 7030003480 S.RES 2.2K ERJ3GE
R372 7030003580 S.RES 15K ERJ3GE
R373 7030003440 S.RES 1K ERJ3GE
R374 7030003330 S.RES 120 ERJ3GE
R375 7030003420 S.RES 680 ERJ3GE
C1 4030006860 S.CER 0.001 C1608 B
C2 4030006970 S.CER 6P C1608 CH
C3 4030008570 S.CER 0.75P C1608
C4 4030006590 S.CER 8P C1608
C5 4030006860 S.CER 0.001 C1608 B
C6 4030006860 S.CER 0.001 C1608 B
C7 4030006880 S.CER 0.0047 C1608 B
C8 4030006860 S.CER 0.001 C1608 B
C9 4030006860 S.CER 0.001 C1608 B
C10 4030006880 S.CER 0.0047 C1608 B
C11 4030006860 S.CER 0.001 C1608 B
C12 4030008570 S.CER 0.75P C1608
C13 4030006510 S.CER 0.5P C1608
C14 4030006860 S.CER 0.001 C1608 B
C15 4030006860 S.CER 0.001 C1608 B
C16 4030006860 S.CER 0.001 C1608 B
C17 4030006860 S.CER 0.001 C1608 B
C18 4030006860 S.CER 0.001 C1608 B
C19 4030006670 S.CER 27P C1608
C20 4030006880 S.CER 0.0047 C1608 B
C21 4030006880 S.CER 0.0047 C1608 B
C22 4030006550 S.CER 4P C1608
C23 4030006880 S.CER 0.0047 C1608 B
C24 4030006880 S.CER 0.0047 C1608 B
C25 4030006710 S.CER 47P C1608
C27 4030006850 S.CER 470P C1608 B
C28 4030008920 S.CER 0.047 C1608 16V B
C29 4030006860 S.CER 0.001 C1608 B
C30 4030011600 S.CER 0.1 C1608 16V B
C32 4030008920 S.CER 0.047 C1608 16V B
C33 4030006860 S.CER 0.001 C1608 B
C34 4030011600 S.CER 0.1 C1608 16V B
C36 4030008920 S.CER 0.047 C1608 16V B
C37 4030006900 S.CER 0.01 C1608 25V B
C38 4030008920 S.CER 0.047 C1608 16V B
C39 4030011600 S.CER 0.1 C1608 16V B
C41 4030006710 S.CER 47P C1608
C42 4030011600 S.CER 0.1 C1608 16V B
C44 4030011600 S.CER 0.1 C1608 16V B
C47 4030006880 S.CER 0.0047 C1608 B
C49 4550002030 TAN DN 1A 220M
C50 4510003820 ELE 50 ME R22 SWB
C52 4510003790 ELE 16 ME 10 SWB
C53 4510003840 ELE 50 ME 1 SWB
C56 4310000400 MLR 50 F2D 223J
C57 4310000570 MLR 50 F2D 222J
C58 4510003790 ELE 16 ME 10 SWB
C59 4510003800 ELE 25 ME 4R7 SWB
C60 4510003820 ELE 50 ME R22 SWB
C72 4510003810 ELE 50 ME R1 SWB
C73 4510003840 ELE 50 ME 1 SWB
C77 4510005120 ELE 16 ME 47 HC
C81 4510003820 ELE 50 ME R22 SWB
C82 4310000400 MLR 50 F2D 223J
C83 4310000570 MLR 50 F2D 222J
C85 4510003840 ELE 50 ME 1 SWB
C86 4510005040 ELE 25 ME 1000 HC
C87 4510005000 ELE 16 ME 220 HC
C88 4510004320 ELE 25 ME 47 SWB
C89 4510004320 ELE 25 ME 47 SWB
C90 4510008470 ELE 10 ME 1000 CX
C91 4310000480 MLR 50 F2D 104J
C95 4510003790 ELE 16 ME 10 SWB
C97 4510003840 ELE 50 ME 1 SWB
C98 4510003790 ELE 16 ME 10 SWB
C99 4510003830 ELE 50 ME R47 SWB
C101 4510003790 ELE 16 ME 10 SWB
C102 4550000010 TAN DN 1C 4R7M
C103 4510003840 ELE 50 ME 1 SWB
C104 4550000010 TAN DN 1C 4R7M
C106 4510003820 ELE 50 ME R22 SWB
C107 4510003840 ELE 50 ME 1 SWB
C108 4510003800 ELE 25 ME 4R7 SWB
C109 4510005110 ELE 16 ME 33 HC
C111 4510005120 ELE 16 ME 47 HC
C117 4510003800 ELE 25 ME 4R7 SWB
C118 4030006850 S.CER 470P C1608 B
C119 4030006850 S.CER 470P C1608 B
C120 4030006880 S.CER 0.0047 C1608 B
C122 4030006580 S.CER 7P C1608
C123 4030006530 S.CER 2P C1608
C124 4030006580 S.CER 7P C1608
DESCRIPTION
[MAIN UNIT]
REF ORDER
NO. NO.
C125 4030006880 S.CER
C127 4030006880 S.CER
C129 4030006800 S.CER
C135 4030006880 S.CER
C153 4030006710 S.CER
C155 4030006880 S.CER
C156 4030006850 S.CER
C157 4030006660 S.CER
C158 4030006560 S.CER
C159 4030006630 S.CER
C160 4030006880 S.CER
C161 4030006540 S.CER
C162 4030006860 S.CER
C163 4030006540 S.CER
C164 4030008570 S.CER
C166 4030006860 S.CER
C167 4030006860 S.CER
C168 4030006660 S.CER
C169 4030006860 S.CER
C170 4030006860 S.CER
C171 4030006880 S.CER
C172 4030008570 S.CER
C173 4030006540 S.CER
C174 4030006860 S.CER
C175 4030006860 S.CER
C176 4030006610 S.CER
C179 4030006860 S.CER
C180 4030006890 S.CER
C181 4030006860 S.CER
C182 4030008650 S.CER
C183 4510003790 ELE
C185 4510003790 ELE
C187 4510005190 ELE
C189 4510004330 ELE
C190 4510003790 ELE
C193 4510003790 ELE
C194 4510003790 ELE
C205 4610002020 TRI
C218 4510005140 ELE
C222 4510005120 ELE
C223 4510004320 ELE
C224 4510003790 ELE
C230 4510003790 ELE
C231 4510003820 ELE
C234 4310000580 MLR
C235 4310000400 MLR
C236 4310000570 MLR
C237 4510004990 ELE
C238 4510003840 ELE
C240 4510003790 ELE
C241 4550000390 TAN
C243 4510003790 ELE
C244 4510003810 ELE
C246 4510003800 ELE
C247 4510003800 ELE
C249 4510005120 ELE
C250 4510003800 ELE
C251 4310000440 MLR
C253 4020000980 CYR
4040000260 BAR
C254 4510003830 ELE
C255 4510003810 ELE
C272 4510005020 ELE
C273 4310000400 MLR
C274 4510005020 ELE
C275 4510003800 ELE
C276 4310000570 MLR
C277 4310000570 MLR
C278 4510003790 ELE
C280 4510003830 ELE
C291 4510003790 ELE
C292 4510003790 ELE
C293 4510003790 ELE
C300 4550000360 TAN
C301 4510003790 ELE
C302 4510005150 ELE
C308 4510003820 ELE
C309 4510003830 ELE
C313 4510003820 ELE
C314 4510004910 ELE
C315 4510003790 ELE
C317 4010000520 CER
C322 4510005120 ELE
RL1 6330001510 RLY
J1 6510007020 CNR
J2 6510007020 CNR
J3 6510003390 CNR
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
8 - 3
DESCRIPTION
0.0047 C1608 B
0.0047 C1608 B
220P C1608
0.0047 C1608 B
47P C1608
0.0047 C1608 B
470P C1608 B
22P C1608
5P C1608
15P C1608
0.0047 C1608 B
3P C1608
0.001 C1608 B
3P C1608
0.75P C1608
0.001 C1608 B
0.001 C1608 B
22P C1608
0.001 C1608 B
0.001 C1608 B
0.0047 C1608 B
0.75P C1608
3P C1608
0.001 C1608 B
0.001 C1608 B
10P C1608
0.001 C1608 B
0.01 C1608 F
0.001 C1608 B
0.0033 C1608 B
16 ME 10 SWB
16 ME 10 SWB
ECEA1ESS222
35 ME 10 SWB
16 ME 10 SWB
16 ME 10 SWB
16 ME 10 SWB
ECR-HA020D41
25 ME 100 HC
16 ME 47 HC
25 ME 47 SWB
16 ME 10 SWB
16 ME 10 SWB
50 ME R22 SWB
50 F2D 272J
50 F2D 223J
50 F2D 222J
16 ME 100 HC
50 ME 1 SWB
16 ME 10 SWB
DN 1V R22M except [USA] only
16 ME 10 SWB
50 ME R1 SWB
25 ME 4R7 SWB
25 ME 4R7 SWB
16 ME 47 HC
25 ME 4R7 SWB
50 F2D 473J
UP050 B 104K-NA-CZ
UZE 08X 104M
50 ME R47 SWB
50 ME R1 SWB
50 ME R1 SWN
50 F2D 223J
50 ME R1 SWN
25 ME 4R7 SWB
50 F2D 222J
50 F2D 222J
16 ME 10 SWB
50 ME R47 SWB
16 ME 10 SWB
16 ME 10 SWB
16 ME 10 SWB
DN 1V R47M
16 ME 10 SWB
50 ME 10 HC
50 ME R22 SWB
50 ME R47 SWB
50 ME R22 SWB
16 ME 10 SWN
16 ME 10 SWB
DD107-601 B 472K 50V
16 ME 47 HC
TB1-160
TMP-J01X-V6
TMP-J01X-V6
B03B-EH-S
S.=Surface mount
[Others]
[USA]
[USA] only
