Parts List; Main Unit - Icom IC-A200 Service Manual

SECTION 8

[MAIN UNIT]

REF ORDER
NO. NO.
IC5 1110002550 IC TA7252AP
IC6 1120002900 S.IC M5223AFP
IC7 1140009120 S.IC µPD750004GB-F10-3BS-MTX
IC8 1130012670 S.IC BR93L46F
IC9 1110005711 S.IC S-80842CLUA-B63 G
IC10 1130011190 S.IC BU4011BF
IC11 1110002030 IC TA7808S
IC12 1110002020 IC TA7805S
IC13 1110002440 IC µPC1313HA
IC14 1790000050 IC ND487C1-3R
IC15 1790000050 IC ND487C1-3R
IC16 1110002440 IC µPC1313HA
Q4 1560000620 FET 2SK937
1560000630 FET 2SK1747
Q5 1560000620 FET 2SK937
Q6 1560000431 S.FET 2SK302 GR F
Q7 1560000271 S.FET 2SK302 Y F
Q8 1560000431 S.FET 2SK302 GR F
Q9 1560000431 S.FET 2SK302 GR F
Q10 1530002691 S.TR 2SC4116 GR F
Q11 1530002691 S.TR 2SC4116 GR F
Q13 1530002691 S.TR 2SC4116 GR F
Q14 1530002551 S.TR 2SC3326 B F
Q17 1510000501 S.TR 2SA1162 GR F
Q20 1530002601 S.TR 2SC4215 O F
Q24 1530002691 S.TR 2SC4116 GR F
Q25 1510000501 S.TR 2SA1162 GR F
Q29 1530000811 TR 2SC2053-101
Q33 1540000150 TR 2SD1225M R
Q35 1540000150 TR 2SD1225M R
Q36 1540000150 TR 2SD1225M R
Q44 1530000811 TR 2SC2053-101
D6 1710001081 DIO L308CCB
D7 1710001081 DIO L308CCB
D8 1790000690 S.DIO HSM88ASR
D11 1160000050 S.DIO DAP202U
D19 1790001280 S.DIO MA111
D20 1790001780 DIO MA700
D21 1790001780 DIO MA700
D33 1710001081 DIO L308CCB
D34 1710001081 DIO L308CCB
D35 1730000521 ZEN RD20E-AZ B2
FI1 2010001380 FIL 32M20B (FL-167)
FI2 2020000690 CER CFW455D
2020001070 CER CFWLA455KDFA-B0
FI3 2040000480 FIL TU08M
FI4 2040000480 FIL TU08M
FI5 2040000480 FIL TU08M
FI6 2040000480 FIL TU08M
FI7 2040000480 FIL TU08M
X1 6050007970 XTL CR-390 (32.00000 MHz)
6050007971 XTL CR-390A (32.0000 MHz)
X2 6050003110 XTL RF-4A3 FAC NKD (4.194304M)
L1 6150003820 COL LS-440
L2 6150003820 COL LS-440
L3 6150003820 COL LS-440
L4 6180000900 COL LAL 03NA 101K
L5 6150003820 COL LS-440
L6 6140001200 COL LR-145
L7 6180000830 COL LAL 03NA 3R3K
L8 6150004270 COL LS-483A (C-14924)
L9 6180001510 COL LAL 02NA 101K
L10 6150000991 COL LS-424
L11 6140002060 COL LR-225 (RIB3X6.5X3 3A6)
L12 6140002060 COL LR-225 (RIB3X6.5X3 3A6)
L13 6180001510 COL LAL 02NA 101K
L14 6150005370 COL LS-238A
L15 6150005370 COL LS-238A
L16 6150005370 COL LS-238A
L19 2040000490 COL EXC-ELDR25C
L20 6170000140 COL LW-15
L26 6150003340 COL LS-366
L27 6150003340 COL LS-366
L28 6180000900 COL LAL 03NA 101K
L29 6180001510 COL LAL 02NA 101K

PARTS LIST

DESCRIPTION
except [USA]
[USA]
[USA]
except [USA]
[USA]
except [USA]
[MAIN UNIT]
REF ORDER
NO. NO.
L40 6140001200 COL
L41 6110002000 COL
L42 6110001670 COL
L43 6140002060 COL
L44 6140002060 COL
L45 6150003820 COL
L46 6150003820 COL
L47 6150003820 COL
L48 6150003820 COL
L52 6180000880 COL
L53 6180000880 COL
L57 2040000490 COL
L58 2040000490 COL
L59 2040000490 COL
L60 2040000490 COL
L61 2040000490 COL
L62 2040000490 COL
L63 2040000490 COL
L65 2040000490 COL
L66 6170000150 COL
L67 6170000150 COL
R1 7030003680 S.RES
R2 7030003680 S.RES
R3 7030003560 S.RES
R4 7030003320 S.RES
R5 7030003280 S.RES
R6 7030003280 S.RES
R7 7030003320 S.RES
R8 7030003320 S.RES
R9 7030003680 S.RES
R10 7030003680 S.RES
R11 7030003560 S.RES
R12 7030003400 S.RES
R13 7030003400 S.RES
R14 7030003490 S.RES
R16 7030003560 S.RES
R17 7030003440 S.RES
R18 7030003320 S.RES
R19 7030003520 S.RES
R20 7030003320 S.RES
R21 7030003270 S.RES
R22 7030003340 S.RES
R23 7030003340 S.RES
R24 7030003560 S.RES
R25 7030003440 S.RES
R27 7030003320 S.RES
R29 7030003460 S.RES
R30 7030003440 S.RES
R32 7030003320 S.RES
R33 7510000330 TMR
R35 7310000750 TRI
R37 7030003320 S.RES
R38 7030003680 S.RES
R39 7030003320 S.RES
R40 7030003660 S.RES
R41 7030003680 S.RES
R42 7030003430 S.RES
R43 7030003620 S.RES
R45 7030003440 S.RES
R50 7030003460 S.RES
R51 7030003500 S.RES
R52 7030003320 S.RES
R53 7030003320 S.RES
R60 7030003560 S.RES
R61 7030003320 S.RES
R62 7030003440 S.RES
R63 7030003580 S.RES
R64 7030003600 S.RES
R65 7030003600 S.RES
R66 7030003770 S.RES
R67 7310001680 TRI
R73 7310001910 TRI
R83 7310000750 TRI
R89 7210002160 VAR
R90 7030003560 S.RES
R91 7030003460 S.RES
R100 7030003440 S.RES
R101 7030003680 S.RES
R102 7030000370 S.RES
R103 7030003640 S.RES
R105 7030003570 S.RES
R106 7030003520 S.RES
R107 7030003520 S.RES
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
8 - 1
DESCRIPTION
LR-145
LA-226
LA-253
LR-225 (RIB3X6.5X3 3A6)
LR-225 (RIB3X6.5X3 3A6)
LS-440
LS-440
LS-440
LS-440
LAL 03NA 100K
LAL 03NA 100K
EXC-ELDR25C
EXC-ELDR25C
EXC-ELDR25C
EXC-ELDR25C
EXC-ELDR25C
EXC-ELDR25C
EXC-ELDR25C
EXC-ELDR25C
LW-16
LW-16
100K ERJ3GE
100K ERJ3GE
10K ERJ3GE
100 ERJ3GE
47 ERJ3GE
47 ERJ3GE
100 ERJ3GE
100 ERJ3GE
100K ERJ3GE
100K ERJ3GE
10K ERJ3GE
470 ERJ3GE
470 ERJ3GE
2.7K ERJ3GE
10K ERJ3GE
1K ERJ3GE
100 ERJ3GE
4.7K ERJ3GE
100 ERJ3GE
39 ERJ3GE
150 ERJ3GE
150 ERJ3GE
10K ERJ3GE
1K ERJ3GE
100 ERJ3GE
1.5K ERJ3GE
1K ERJ3GE
100 ERJ3GE
ERT-D2ZIL 154S
RH0651C14J2WA (103)
100 ERJ3GE
100K ERJ3GE
100 ERJ3GE
68K ERJ3GE
100K ERJ3GE
820 ERJ3GE
33K ERJ3GE
1K ERJ3GE
1.5K ERJ3GE
3.3K ERJ3GE
100 ERJ3GE
100 ERJ3GE
10K ERJ3GE
100 ERJ3GE
1K ERJ3GE
15K ERJ3GE
22K ERJ3GE
22K ERJ3GE
560K ERJ3GE
RH0621CJ5J2FA
RH0621CJ4J52A
RH0651C14J2WA (103)
RV-270 (RK0971116) 10KB
10K ERJ3GE
1.5K ERJ3GE
1K ERJ3GE
100K ERJ3GE
820 MCR10
47K ERJ3GE
12K ERJ3GE
4.7K ERJ3GE
4.7K ERJ3GE
S.=Surface mount
