Digital Projection
M-Vision Cine 3D series
Menu Sub Menus and Controls

SYSTEM

Language
Menu Position
Blank Screen
Auto Power Off
Auto Power On
Rear Projection
Ceiling Mode
Lamp Power

CONTROL

1 Key
all available inputs
2 Key
all available inputs
3 Key
all available inputs
4 Key
all available inputs
5 Key
all available inputs
Trigger 1
Trigger 2
Auto Source

SERVICE

Information
H⁄V Refresh Rate, Lamp Hours
Factory Reset
Blue Only
Test Patterns
Altitude
Auto, High
Rev A August 2011
English only
Top Left, Top Right, Bottom Left, Bottom Right, Centre
Logo, Black, Blue, White
On, Off
On, Off
Off, On
Off, On
Standard, Economy
Screen, 1:9, Theaterscope, :, : Narrow, RS22
Screen, 1:9, Theaterscope, :, : Narrow, RS22
On, Off
Model Name, Serial Number, Software Version, Active Source, Signal Format, Pixel Clock,
Projector will ask for confirmation before restoring all settings to factory defaults
Off, On
Off, White, Black, Red, Green, Blue, Cyan, Magenta, Yellow, Chequer Grid
3. MENU MAP Operating Guide
Notes
Some of the information in this menu
map is summarised. See the actual
menu on the projector for full detail.
Some menu options and controls
may not be available due to settings
in other menus. These will be
shaded green on the actual menu.
Where it would be helpful, some
menu options are described in more
detail earlier in this operating guide.
Page 1
