7.

Registering the 2-Way Wireless I/O Expander Module

The 2-Way Wireless I/O Expander Module must identify itself to the iConnect 2-Way
Control System as follows:
1. Set the control system to registration mode.
• Go to the main menu and select [9]>[1]>[6] (Programming > Devices >
Zone Expanders)
• Select a 2-Way Wireless I/O Expander Module from the list (1-2) and
press '√ʹ.
2. With the plastic unit cover open send a transmission by pressing and releasing
the tamper switch of the Wireless I/O Expander Module.
The 2-Way Wireless I/O Expander Module will send a transmission to the
control system. If the transmission is successfully received by the control
system it will play a confirmation sound.
3. As soon as 'Save?' appears press '√ʹ.
4. Close the 2-Way Wireless I/O Expander Module front cover and secure the
locking screw.
9
