9.

Technical Specification

Frequency:
Power Input:
Current Consumption:
Rechargeable Standby Battery:
Auxiliary Power Outputs:
PGM Relay Output Dry Contact
Rating:
Number of Zones:
Zone Loop Type:
Tamper Protection:
RF immunity:
Operating temperature
Storage temperature
Usage:
Dimensions (Plastic Case):
*EN 50131-3 Grade 2 Class II
868*MHz or 433MHz
AC/DC Adaptor 100-240V,50/60Hz/14.4VDC,1.5A
Typical:40 mA;65mA maximum
12VDC±2VDC up to 7Ah, typical
12VDC@1000mA, maximum (from all AUX
terminals)
Dry contact – 1A@30VDC,0.5A@25VDC
8
N.C. / N.O. / E.O.L.(Programmed at the Control
System)
Front cover and back tamper (N.C.)
According to EN50130-4
-10°C to 40°C (14°F to 104°F)
-20°C to 50°C (-4°F to 122°F)
Indoor
290 x 254 x 97 mm (11.2 x 9.7 x 3.6 inch)
11
