1.

Introduction

Electronics Line's 2-Way Wireless I/O Expander Module (EL-4770) is an extension
module enabling wired devices to be connected to the iConnect 2-Way Control System
(SW versions 305 and above).
The iConnect 2-Way Control System supports up-to two 2-Way Wireless I/O Expander
Modules. Each 2-Way Wireless I/O Module supports 8 hardwired zone inputs, 2
auxiliary outputs and has the capability to control up to 2 PGM devices.
Each output or PGM device can be operated in a response to a wide variety of system
events. For detailed information regarding the programming options of the Wireless I/O
Expander Module refer to the iConnect 2-Way Control System Full Installation Manual.
The 2- Way Wireless I/O Expander Module is installed outside the Control System in its
own dedicated plastic unit equipped with case open and wall removal tamper
protection. The Wireless I/O Module is also provided with its own power supply and
backup battery.
2.

Main Features

• Bi-directional wireless communication
• 2 auxiliary parallel outputs
• 8 zone inputs (NO, NC, EOL, DEOL)
• Fully supervised
• Dual tamper protection (Box & Wall)
• PGM connection for up to 2 PGM devices
