Step 10 - Connecting Power

I R
M S
A R
A L
The NV4 has an internal power supply unit. Connect the mains lead to the unit and then to the wall
P
E X
socket, or to a fused spur connection. To be compliant with wiring regulations in some countries, an Alarm/
D
K B
Security device should be connected to a fused spur and not a wall outlet socket (check local regulations
before installation).
