Note: Ports on the switches are allocated using a combination of base switch number and configuration
page. Each Layer 3 Enhanced CCTV Switch has a hardware configuration dial on the base to
allow a unique (in the cascade) identifier to be set. This identifier is used by this configuration
page to configure the base camera number.
AUD 1
AUD 2
AUD 3
AUD 4
ETH-D
ETH-C
ETH-B
ETH-A
SERIAL 1
SERIAL 2
SERIAL 3 PTZ
SERIAL 4 PTZ
KBD
A
HDMI 1
HDMI 2
OUT
OUT
IR
SATA1
SATA2
B
IN
IN
AUX AUD1
AUX AUD2
MON
VID 1
VID 2
USB
ETH-0
ETH-1
Cameras
Example Settings
Scenario 1 - One switch - 16 Analogue cameras attached to NV4 CIP
Switch Hardware Setting
0
Scenario 2 - Two switches - 0 Analogue cameras attached to NV4 CIP
Switch Hardware Setting
0
1
Scenario 3 - Two switches - 8 Analog Cameras (ports 7-16)
Switch Hardware Setting
0
1
Scenario 4 - Three switches - 0 Analogue Cameras
Switch Hardware Setting
0
1
2
Scenario 5 - Four switches - Geographically dispersed IP cameras
Switch Hardware Setting
0
1
2
3
Note: Analogue cameras connected to the rear of the unit will take priority over IP cameras connected
via a Layer 3 Enhanced CCTV Switch. An IP camera connected into a channel that is occupied
by an Analogue camera will be 'bumped' onto the Unallocated Cameras list to allow it to be
assigned to a free channel.
