Dedicated Micros DV-IP NV4 Installation Manual page 72

Startup Camera
Video Output mode
Video Output mode 2
Note: It will be necessary to reboot the unit to implement any change to the Video Output Mode. The
unit can be rebooted via the Reset (Red) option.
Note: If there is no suitable standard configuration to suit the monitor in use, refer to 'Appendix F
->Monitor Output' for details on enabling more options.
Decoder Mode
Note: For further information regarding Dedicated Micros Pick-a-Point system, please contact
Dedicated Micros customer services in your region.
Mouse Sensitivity
Applet Location
Set Location
72
When accessing the Viewer function, select the camera image which
will initially be displayed. If one of the multi display formats has been
selected via the 'Startup Multi Display' option, the camera channel
selected here will be displayed in first (top left) position. Subsequent
camera channels will be displayed in sequential order.
Select the display output that best suits the primary viewing monitor.
Typically PAL Default is most suited for a CRT monitor, PAL Reduced
for a TFT monitor.
Select from:
Safe Mode:
PAL Default:
PAL Reduced:
HD Default:
HD 4x3:
HDMI Alternate 1: Res:
HDMI Alternate 2: Res:
HDMI Alternate 3: Res:
HDMI Alternate 4: Res:
HDMI Alternate 5: Res:
HDMI Alternate 6: Res:
Select the display output that best suits the secondary viewing monitor,
the options available are the same as shown in 'Video Output mode'
above.
Select from Normal Display or Decoder Mode. Normal Display allows
cameras to be accessed and controlled via the Viewer menu. In
Decoder Mode, connected cameras can be accessed, viewed or
controlled via Dedicated Micros Pick-a-Point system.
The sensitivity settings of the mouse can be adjusted from the least
sensitive (1) to the most sensitive (10). The setting can be adjusted
via the slidebar or a number entered directly into the accompanying
textbox. The default setting is 4.
The location of the unit's Viewer menu applet is displayed. The default
location will always be the applet installed on the unit. If accessing
multiple units via a remote connection, all can be assigned the same
Viewer applet. This will lessen the load time required when accessing
different DVRs/Servers.
For example, if a local unit and a remote DVR are to be accessed, it is
possible to set the Applet location for both DVRs as the local unit.
If viewing the unit remotely, Dedicated Micros provide a remote
applet. This remote applet can be selected via the 'Set Location' option.
The applet is located on the website (www.dedicatedmicros.com/software_
release/index_firmware.php). Due to possible bandwidth restrictions on the
network the DVR is located, using this remote applet may improve data
transfer speeds.
Select the applet location. Choose from 'Default location' i.e. the applet
installed on the unit; or the 'website' option i.e. the
remote applet.
NV4
Res: 640 x 512
Res: 704 x 512
Res: 640 x 512
Res: 1280 x 720
Res: 1280 x 720
1280 x 688
1216 x 688
1192 x 676
1264 x 716
1220 x 690
1216 x 688
